AlexeyAB/darknet

Yolo v4, v3 and v2 for Windows and Linux

• Read the FAQ: https://www.ccoderun.ca/programming/darknet_faq/
• Join the Darknet/YOLO Discord: https://discord.gg/zSq8rtW
• Recommended GitHub repo for Darknet/YOLO: https://github.com/hank-ai/darknetcv/
• Hank.ai and Darknet/YOLO: https://hank.ai/darknet-welcomes-hank-ai-as-official-sponsor-and-commercial-entity/

(neural networks for object detection)

• Paper YOLOv7: https://arxiv.org/abs/2207.02696

• source code YOLOv7 - Pytorch (use to reproduce results): https://github.com/WongKinYiu/yolov7

---

• Paper YOLOv4: https://arxiv.org/abs/2004.10934

• source code YOLOv4 - Darknet (use to reproduce results): https://github.com/AlexeyAB/darknet

---

• Paper Scaled-YOLOv4 (CVPR 2021): https://openaccess.thecvf.com/content/CVPR2021/html/Wang_Scaled-YOLOv4_Scaling_Cross_Stage_Partial_Network_CVPR_2021_paper.html

• source code Scaled-YOLOv4 - Pytorch (use to reproduce results): https://github.com/WongKinYiu/ScaledYOLOv4

---

YOLOv7: Trainable bag-of-freebies sets new state-of-the-art for real-time object detectors

• Paper: https://arxiv.org/abs/2207.02696

• source code - Pytorch (use to reproduce results): https://github.com/WongKinYiu/yolov7

YOLOv7 is more accurate and faster than YOLOv5 by 120% FPS, than YOLOX by 180% FPS, than Dual-Swin-T by 1200% FPS, than ConvNext by 550% FPS, than SWIN-L by 500% FPS, than PPYOLOE-X by 150% FPS.

YOLOv7 surpasses all known object detectors in both speed and accuracy in the range from 5 FPS to 160 FPS and has the highest accuracy 56.8% AP among all known real-time object detectors with 30 FPS or higher on GPU V100, batch=1.

• YOLOv7-e6 (55.9% AP, 56 FPS V100 b=1) by +500% FPS faster than SWIN-L C-M-RCNN (53.9% AP, 9.2 FPS A100 b=1)
• YOLOv7-e6 (55.9% AP, 56 FPS V100 b=1) by +550% FPS faster than ConvNeXt-XL C-M-RCNN (55.2% AP, 8.6 FPS A100 b=1)
• YOLOv7-w6 (54.6% AP, 84 FPS V100 b=1) by +120% FPS faster than YOLOv5-X6-r6.1 (55.0% AP, 38 FPS V100 b=1)
• YOLOv7-w6 (54.6% AP, 84 FPS V100 b=1) by +1200% FPS faster than Dual-Swin-T C-M-RCNN (53.6% AP, 6.5 FPS V100 b=1)
• YOLOv7x (52.9% AP, 114 FPS V100 b=1) by +150% FPS faster than PPYOLOE-X (51.9% AP, 45 FPS V100 b=1)
• YOLOv7 (51.2% AP, 161 FPS V100 b=1) by +180% FPS faster than YOLOX-X (51.1% AP, 58 FPS V100 b=1)

---

---

---

More details in articles on medium:

• Scaled_YOLOv4
• YOLOv4

Manual: https://github.com/AlexeyAB/darknet/wiki

Discussion:

• Discord

About Darknet framework: http://pjreddie.com/darknet/

• YOLOv4 model zoo

• Requirements (and how to install dependencies)

• Pre-trained models

• FAQ - frequently asked questions

• Explanations in issues

• Yolo v4 in other frameworks (TensorRT, TensorFlow, PyTorch, OpenVINO, OpenCV-dnn, TVM,...)

• Datasets

• Yolo v4, v3 and v2 for Windows and Linux

  • (neural networks for object detection)
    • GeForce RTX 2080 Ti
      • Youtube video of results
      • How to evaluate AP of YOLOv4 on the MS COCO evaluation server
      • How to evaluate FPS of YOLOv4 on GPU
      • Pre-trained models
    • Requirements for Windows, Linux and macOS
    • Yolo v4 in other frameworks
      • Datasets
    • Improvements in this repository
      • How to use on the command line
        • For using network video-camera mjpeg-stream with any Android smartphone
    • How to compile on Linux/macOS (using CMake)
    • Using also PowerShell
    • How to compile on Linux (using make)
    • How to compile on Windows (using CMake)
    • How to compile on Windows (using vcpkg)
  • How to train with multi-GPU
  • How to train (to detect your custom objects)
    • How to train tiny-yolo (to detect your custom objects)
  • When should I stop training
    • Custom object detection
  • How to improve object detection
  • How to mark bounded boxes of objects and create annotation files
  • How to use Yolo as DLL and SO libraries
  • Citation

AP50:95 - FPS (Tesla V100) Paper: https://arxiv.org/abs/2011.08036

---

AP50:95 / AP50 - FPS (Tesla V100) Paper: https://arxiv.org/abs/2004.10934

tkDNN-TensorRT accelerates YOLOv4 ~2x times for batch=1 and 3x-4x times for batch=4.

• tkDNN: https://github.com/ceccocats/tkDNN
• OpenCV: https://gist.github.com/YashasSamaga/48bdb167303e10f4d07b754888ddbdcf

GeForce RTX 2080 Ti

• Yolo v4 Full comparison: map_fps
• Yolo v4 tiny comparison: tiny_fps
• CSPNet: paper and map_fps comparison: https://github.com/WongKinYiu/CrossStagePartialNetworks
• Yolo v3 on MS COCO: Speed / Accuracy ([email protected]) chart
• Yolo v3 on MS COCO (Yolo v3 vs RetinaNet) - Figure 3: https://arxiv.org/pdf/1804.02767v1.pdf
• Yolo v2 on Pascal VOC 2007: https://hsto.org/files/a24/21e/068/a2421e0689fb43f08584de9d44c2215f.jpg
• Yolo v2 on Pascal VOC 2012 (comp4): https://hsto.org/files/3a6/fdf/b53/3a6fdfb533f34cee9b52bdd9bb0b19d9.jpg

Youtube video of results

Others: https://www.youtube.com/user/pjreddie/videos

How to evaluate AP of YOLOv4 on the MS COCO evaluation server

1. Download and unzip test-dev2017 dataset from MS COCO server: http://images.cocodataset.org/zips/test2017.zip
2. Download list of images for Detection tasks and replace the paths with yours: https://raw.githubusercontent.com/AlexeyAB/darknet/master/scripts/testdev2017.txt
3. Download yolov4.weights file 245 MB: yolov4.weights (Google-drive mirror yolov4.weights )
4. Content of the file cfg/coco.data should be

classes= 80
train  = <replace with your path>/trainvalno5k.txt
valid = <replace with your path>/testdev2017.txt
names = data/coco.names
backup = backup
eval=coco

5. Create /results/ folder near with ./darknet executable file
6. Run validation: ./darknet detector valid cfg/coco.data cfg/yolov4.cfg yolov4.weights
7. Rename the file /results/coco_results.json to detections_test-dev2017_yolov4_results.json and compress it to detections_test-dev2017_yolov4_results.zip
8. Submit file detections_test-dev2017_yolov4_results.zip to the MS COCO evaluation server for the test-dev2019 (bbox)

How to evaluate FPS of YOLOv4 on GPU

1. Compile Darknet with GPU=1 CUDNN=1 CUDNN_HALF=1 OPENCV=1 in the Makefile
2. Download yolov4.weights file 245 MB: yolov4.weights (Google-drive mirror yolov4.weights )
3. Get any .avi/.mp4 video file (preferably not more than 1920x1080 to avoid bottlenecks in CPU performance)
4. Run one of two commands and look at the AVG FPS:

• include video_capturing + NMS + drawing_bboxes: ./darknet detector demo cfg/coco.data cfg/yolov4.cfg yolov4.weights test.mp4 -dont_show -ext_output
• exclude video_capturing + NMS + drawing_bboxes: ./darknet detector demo cfg/coco.data cfg/yolov4.cfg yolov4.weights test.mp4 -benchmark

Pre-trained models

There are weights-file for different cfg-files (trained for MS COCO dataset):

FPS on RTX 2070 (R) and Tesla V100 (V):

• yolov4-p6.cfg - 1280x1280 - 72.1% [email protected] (54.0% [email protected]:0.95) - 32(V) FPS - xxx BFlops (xxx FMA) - 487 MB: yolov4-p6.weights

  • pre-trained weights for training: https://github.com/AlexeyAB/darknet/releases/download/darknet_yolo_v4_pre/yolov4-p6.conv.289

• yolov4-p5.cfg - 896x896 - 70.0% [email protected] (51.6% [email protected]:0.95) - 43(V) FPS - xxx BFlops (xxx FMA) - 271 MB: yolov4-p5.weights

  • pre-trained weights for training: https://github.com/AlexeyAB/darknet/releases/download/darknet_yolo_v4_pre/yolov4-p5.conv.232

• yolov4-csp-x-swish.cfg - 640x640 - 69.9% [email protected] (51.5% [email protected]:0.95) - 23(R) FPS / 50(V) FPS - 221 BFlops (110 FMA) - 381 MB: yolov4-csp-x-swish.weights

  • pre-trained weights for training: https://github.com/AlexeyAB/darknet/releases/download/darknet_yolo_v4_pre/yolov4-csp-x-swish.conv.192

• yolov4-csp-swish.cfg - 640x640 - 68.7% [email protected] (50.0% [email protected]:0.95) - 70(V) FPS - 120 (60 FMA) - 202 MB: yolov4-csp-swish.weights

  • pre-trained weights for training: https://github.com/AlexeyAB/darknet/releases/download/darknet_yolo_v4_pre/yolov4-csp-swish.conv.164

• yolov4x-mish.cfg - 640x640 - 68.5% [email protected] (50.1% [email protected]:0.95) - 23(R) FPS / 50(V) FPS - 221 BFlops (110 FMA) - 381 MB: yolov4x-mish.weights

  • pre-trained weights for training: https://github.com/AlexeyAB/darknet/releases/download/darknet_yolo_v4_pre/yolov4x-mish.conv.166

• yolov4-csp.cfg - 202 MB: yolov4-csp.weights paper Scaled Yolo v4

  just change width= and height= parameters in yolov4-csp.cfg file and use the same yolov4-csp.weights file for all cases:

  • width=640 height=640 in cfg: 67.4% [email protected] (48.7% [email protected]:0.95) - 70(V) FPS - 120 (60 FMA) BFlops
  • width=512 height=512 in cfg: 64.8% [email protected] (46.2% [email protected]:0.95) - 93(V) FPS - 77 (39 FMA) BFlops
  • pre-trained weights for training: https://github.com/AlexeyAB/darknet/releases/download/darknet_yolo_v4_pre/yolov4-csp.conv.142

• yolov4.cfg - 245 MB: yolov4.weights (Google-drive mirror yolov4.weights ) paper Yolo v4 just change width= and height= parameters in yolov4.cfg file and use the same yolov4.weights file for all cases:

  • width=608 height=608 in cfg: 65.7% [email protected] (43.5% [email protected]:0.95) - 34(R) FPS / 62(V) FPS - 128.5 BFlops
  • width=512 height=512 in cfg: 64.9% [email protected] (43.0% [email protected]:0.95) - 45(R) FPS / 83(V) FPS - 91.1 BFlops
  • width=416 height=416 in cfg: 62.8% [email protected] (41.2% [email protected]:0.95) - 55(R) FPS / 96(V) FPS - 60.1 BFlops
  • width=320 height=320 in cfg: 60% [email protected] ( 38% [email protected]:0.95) - 63(R) FPS / 123(V) FPS - 35.5 BFlops

• yolov4-tiny.cfg - 40.2% [email protected] - 371(1080Ti) FPS / 330(RTX2070) FPS - 6.9 BFlops - 23.1 MB: yolov4-tiny.weights

• enet-coco.cfg (EfficientNetB0-Yolov3) - 45.5% [email protected] - 55(R) FPS - 3.7 BFlops - 18.3 MB: enetb0-coco_final.weights

• yolov3-openimages.cfg - 247 MB - 18(R) FPS - OpenImages dataset: yolov3-openimages.weights

CLICK ME - Yolo v3 models

• csresnext50-panet-spp-original-optimal.cfg - 65.4% [email protected] (43.2% [email protected]:0.95) - 32(R) FPS - 100.5 BFlops - 217 MB: csresnext50-panet-spp-original-optimal_final.weights

• yolov3-spp.cfg - 60.6% [email protected] - 38(R) FPS - 141.5 BFlops - 240 MB: yolov3-spp.weights

• csresnext50-panet-spp.cfg - 60.0% [email protected] - 44 FPS - 71.3 BFlops - 217 MB: csresnext50-panet-spp_final.weights

• yolov3.cfg - 55.3% [email protected] - 66(R) FPS - 65.9 BFlops - 236 MB: yolov3.weights

• yolov3-tiny.cfg - 33.1% [email protected] - 345(R) FPS - 5.6 BFlops - 33.7 MB: yolov3-tiny.weights

• yolov3-tiny-prn.cfg - 33.1% [email protected] - 370(R) FPS - 3.5 BFlops - 18.8 MB: yolov3-tiny-prn.weights

CLICK ME - Yolo v2 models

• yolov2.cfg (194 MB COCO Yolo v2) - requires 4 GB GPU-RAM: https://pjreddie.com/media/files/yolov2.weights
• yolo-voc.cfg (194 MB VOC Yolo v2) - requires 4 GB GPU-RAM: http://pjreddie.com/media/files/yolo-voc.weights
• yolov2-tiny.cfg (43 MB COCO Yolo v2) - requires 1 GB GPU-RAM: https://pjreddie.com/media/files/yolov2-tiny.weights
• yolov2-tiny-voc.cfg (60 MB VOC Yolo v2) - requires 1 GB GPU-RAM: http://pjreddie.com/media/files/yolov2-tiny-voc.weights
• yolo9000.cfg (186 MB Yolo9000-model) - requires 4 GB GPU-RAM: http://pjreddie.com/media/files/yolo9000.weights

Put it near compiled: darknet.exe

You can get cfg-files by path: darknet/cfg/

Requirements for Windows, Linux and macOS

• CMake >= 3.18: https://cmake.org/download/
• Powershell (already installed on windows): https://docs.microsoft.com/en-us/powershell/scripting/install/installing-powershell
• CUDA >= 10.2: https://developer.nvidia.com/cuda-toolkit-archive (on Linux do Post-installation Actions)
• OpenCV >= 2.4: use your preferred package manager (brew, apt), build from source using vcpkg or download from OpenCV official site (on Windows set system variable OpenCV_DIR = C:\opencv\build - where are the include and x64 folders image)
• cuDNN >= 8.0.2 https://developer.nvidia.com/rdp/cudnn-archive (on Linux follow steps described here https://docs.nvidia.com/deeplearning/sdk/cudnn-install/index.html#installlinux-tar , on Windows follow steps described here https://docs.nvidia.com/deeplearning/sdk/cudnn-install/index.html#installwindows)
• GPU with CC >= 3.0: https://en.wikipedia.org/wiki/CUDA#GPUs_supported

Yolo v4 in other frameworks

• Pytorch - Scaled-YOLOv4: https://github.com/WongKinYiu/ScaledYOLOv4
• TensorFlow: pip install yolov4 YOLOv4 on TensorFlow 2.0 / TFlite / Android: https://github.com/hunglc007/tensorflow-yolov4-tflite Official TF models: https://github.com/tensorflow/models/tree/master/official/vision/beta/projects/yolo For YOLOv4 - convert yolov4.weights/cfg files to yolov4.pb by using TNTWEN project, and to yolov4.tflite TensorFlow-lite
• OpenCV the fastest implementation of YOLOv4 for CPU (x86/ARM-Android), OpenCV can be compiled with OpenVINO-backend for running on (Myriad X / USB Neural Compute Stick / Arria FPGA), use yolov4.weights/cfg with: C++ example or Python example
• Intel OpenVINO 2021.2: supports YOLOv4 (NPU Myriad X / USB Neural Compute Stick / Arria FPGA): https://devmesh.intel.com/projects/openvino-yolov4-49c756 read this manual (old manual ) (for Scaled-YOLOv4 models use https://github.com/Chen-MingChang/pytorch_YOLO_OpenVINO_demo )
• PyTorch > ONNX:
  • WongKinYiu/PyTorch_YOLOv4
  • maudzung/3D-YOLOv4
  • Tianxiaomo/pytorch-YOLOv4
  • YOLOv5
• ONNX on Jetson for YOLOv4: https://developer.nvidia.com/blog/announcing-onnx-runtime-for-jetson/ and https://github.com/ttanzhiqiang/onnx_tensorrt_project
• nVidia Transfer Learning Toolkit (TLT>=3.0) Training and Detection https://docs.nvidia.com/metropolis/TLT/tlt-user-guide/text/object_detection/yolo_v4.html
• TensorRT+tkDNN: https://github.com/ceccocats/tkDNN#fps-results
• Deepstream 5.0 / TensorRT for YOLOv4 https://github.com/NVIDIA-AI-IOT/yolov4_deepstream or https://github.com/marcoslucianops/DeepStream-Yolo read Yolo is natively supported in DeepStream 4.0 and PDF. Additionally jkjung-avt/tensorrt_demos or wang-xinyu/tensorrtx
• Triton Inference Server / TensorRT https://github.com/isarsoft/yolov4-triton-tensorrt
• DirectML https://github.com/microsoft/DirectML/tree/master/Samples/yolov4
• OpenCL (Intel, AMD, Mali GPUs for macOS & GNU/Linux) https://github.com/sowson/darknet
• HIP for Training and Detection on AMD GPU https://github.com/os-hackathon/darknet
• ROS (Robot Operating System) https://github.com/engcang/ros-yolo-sort
• Xilinx Zynq Ultrascale+ Deep Learning Processor (DPU) ZCU102/ZCU104: https://github.com/Xilinx/Vitis-In-Depth-Tutorial/tree/master/Machine_Learning/Design_Tutorials/07-yolov4-tutorial
• Amazon Neurochip / Amazon EC2 Inf1 instances 1.85 times higher throughput and 37% lower cost per image for TensorFlow based YOLOv4 model, using Keras URL
• TVM - compilation of deep learning models (Keras, MXNet, PyTorch, Tensorflow, CoreML, DarkNet) into minimum deployable modules on diverse hardware backend (CPUs, GPUs, FPGA, and specialized accelerators): https://tvm.ai/about
• Tencent/ncnn: the fastest inference of YOLOv4 on mobile phone CPU: https://github.com/Tencent/ncnn
• OpenDataCam - It detects, tracks and counts moving objects by using YOLOv4: https://github.com/opendatacam/opendatacam#-hardware-pre-requisite
• Netron - Visualizer for neural networks: https://github.com/lutzroeder/netron

Datasets

• MS COCO: use ./scripts/get_coco_dataset.sh to get labeled MS COCO detection dataset
• OpenImages: use python ./scripts/get_openimages_dataset.py for labeling train detection dataset
• Pascal VOC: use python ./scripts/voc_label.py for labeling Train/Test/Val detection datasets
• ILSVRC2012 (ImageNet classification): use ./scripts/get_imagenet_train.sh (also imagenet_label.sh for labeling valid set)
• German/Belgium/Russian/LISA/MASTIF Traffic Sign Datasets for Detection - use this parser: https://github.com/angeligareta/Datasets2Darknet#detection-task
• List of other datasets: https://github.com/AlexeyAB/darknet/tree/master/scripts#datasets

Improvements in this repository

• developed State-of-the-Art object detector YOLOv4
• added State-of-Art models: CSP, PRN, EfficientNet
• added layers: [conv_lstm], [scale_channels] SE/ASFF/BiFPN, [local_avgpool], [sam], [Gaussian_yolo], [reorg3d] (fixed [reorg]), fixed [batchnorm]
• added the ability for training recurrent models (with layers conv-lstm[conv_lstm]/conv-rnn[crnn]) for accurate detection on video
• added data augmentation: [net] mixup=1 cutmix=1 mosaic=1 blur=1. Added activations: SWISH, MISH, NORM_CHAN, NORM_CHAN_SOFTMAX
• added the ability for training with GPU-processing using CPU-RAM to increase the mini_batch_size and increase accuracy (instead of batch-norm sync)
• improved binary neural network performance 2x-4x times for Detection on CPU and GPU if you trained your own weights by using this XNOR-net model (bit-1 inference) : https://github.com/AlexeyAB/darknet/blob/master/cfg/yolov3-tiny_xnor.cfg
• improved neural network performance ~7% by fusing 2 layers into 1: Convolutional + Batch-norm
• improved performance: Detection 2x times, on GPU Volta/Turing (Tesla V100, GeForce RTX, ...) using Tensor Cores if CUDNN_HALF defined in the Makefile or darknet.sln
• improved performance ~1.2x times on FullHD, ~2x times on 4K, for detection on the video (file/stream) using darknet detector demo...
• improved performance 3.5 X times of data augmentation for training (using OpenCV SSE/AVX functions instead of hand-written functions) - removes bottleneck for training on multi-GPU or GPU Volta
• improved performance of detection and training on Intel CPU with AVX (Yolo v3 ~85%)
• optimized memory allocation during network resizing when random=1
• optimized GPU initialization for detection - we use batch=1 initially instead of re-init with batch=1
• added correct calculation of mAP, F1, IoU, Precision-Recall using command darknet detector map...
• added drawing of chart of average-Loss and accuracy-mAP (-map flag) during training
• run ./darknet detector demo ... -json_port 8070 -mjpeg_port 8090 as JSON and MJPEG server to get results online over the network by using your soft or Web-browser
• added calculation of anchors for training
• added example of Detection and Tracking objects: https://github.com/AlexeyAB/darknet/blob/master/src/yolo_console_dll.cpp
• run-time tips and warnings if you use incorrect cfg-file or dataset
• added support for Windows
• many other fixes of code...

And added manual - How to train Yolo v4-v2 (to detect your custom objects)

Also, you might be interested in using a simplified repository where is implemented INT8-quantization (+30% speedup and -1% mAP reduced): https://github.com/AlexeyAB/yolo2_light

How to use on the command line

If you use build.ps1 script or the makefile (Linux only) you will find darknet in the root directory.

If you use the deprecated Visual Studio solutions, you will find darknet in the directory \build\darknet\x64.

If you customize build with CMake GUI, darknet executable will be installed in your preferred folder.

• Yolo v4 COCO - image: ./darknet detector test cfg/coco.data cfg/yolov4.cfg yolov4.weights -thresh 0.25
• Output coordinates of objects: ./darknet detector test cfg/coco.data yolov4.cfg yolov4.weights -ext_output dog.jpg
• Yolo v4 COCO - video: ./darknet detector demo cfg/coco.data cfg/yolov4.cfg yolov4.weights -ext_output test.mp4
• Yolo v4 COCO - WebCam 0: ./darknet detector demo cfg/coco.data cfg/yolov4.cfg yolov4.weights -c 0
• Yolo v4 COCO for net-videocam - Smart WebCam: ./darknet detector demo cfg/coco.data cfg/yolov4.cfg yolov4.weights http://192.168.0.80:8080/video?dummy=param.mjpg
• Yolo v4 - save result videofile res.avi: ./darknet detector demo cfg/coco.data cfg/yolov4.cfg yolov4.weights test.mp4 -out_filename res.avi
• Yolo v3 Tiny COCO - video: ./darknet detector demo cfg/coco.data cfg/yolov3-tiny.cfg yolov3-tiny.weights test.mp4
• JSON and MJPEG server that allows multiple connections from your soft or Web-browser ip-address:8070 and 8090: ./darknet detector demo ./cfg/coco.data ./cfg/yolov3.cfg ./yolov3.weights test50.mp4 -json_port 8070 -mjpeg_port 8090 -ext_output
• Yolo v3 Tiny on GPU #1: ./darknet detector demo cfg/coco.data cfg/yolov3-tiny.cfg yolov3-tiny.weights -i 1 test.mp4
• Alternative method Yolo v3 COCO - image: ./darknet detect cfg/yolov4.cfg yolov4.weights -i 0 -thresh 0.25
• Train on Amazon EC2, to see mAP & Loss-chart using URL like: http://ec2-35-160-228-91.us-west-2.compute.amazonaws.com:8090 in the Chrome/Firefox (Darknet should be compiled with OpenCV): ./darknet detector train cfg/coco.data yolov4.cfg yolov4.conv.137 -dont_show -mjpeg_port 8090 -map
• 186 MB Yolo9000 - image: ./darknet detector test cfg/combine9k.data cfg/yolo9000.cfg yolo9000.weights
• Remember to put data/9k.tree and data/coco9k.map under the same folder of your app if you use the cpp api to build an app
• To process a list of images data/train.txt and save results of detection to result.json file use: ./darknet detector test cfg/coco.data cfg/yolov4.cfg yolov4.weights -ext_output -dont_show -out result.json < data/train.txt
• To process a list of images data/train.txt and save results of detection to result.txt use: ./darknet detector test cfg/coco.data cfg/yolov4.cfg yolov4.weights -dont_show -ext_output < data/train.txt > result.txt
• To process a video and output results to a json file use: darknet.exe detector demo cfg/coco.data cfg/yolov3.cfg yolov3.weights file.mp4 -dont_show -json_file_output results.json
• Pseudo-labelling - to process a list of images data/new_train.txt and save results of detection in Yolo training format for each image as label <image_name>.txt (in this way you can increase the amount of training data) use: ./darknet detector test cfg/coco.data cfg/yolov4.cfg yolov4.weights -thresh 0.25 -dont_show -save_labels < data/new_train.txt
• To calculate anchors: ./darknet detector calc_anchors data/obj.data -num_of_clusters 9 -width 416 -height 416
• To check accuracy mAP@IoU=50: ./darknet detector map data/obj.data yolo-obj.cfg backup\yolo-obj_7000.weights
• To check accuracy mAP@IoU=75: ./darknet detector map data/obj.data yolo-obj.cfg backup\yolo-obj_7000.weights -iou_thresh 0.75

For using network video-camera mjpeg-stream with any Android smartphone

1. Download for Android phone mjpeg-stream soft: IP Webcam / Smart WebCam

   • Smart WebCam - preferably: https://play.google.com/store/apps/details?id=com.acontech.android.SmartWebCam2
   • IP Webcam: https://play.google.com/store/apps/details?id=com.pas.webcam

2. Connect your Android phone to the computer by WiFi (through a WiFi-router) or USB

3. Start Smart WebCam on your phone

4. Replace the address below, shown in the phone application (Smart WebCam) and launch:

• Yolo v4 COCO-model: ./darknet detector demo data/coco.data yolov4.cfg yolov4.weights http://192.168.0.80:8080/video?dummy=param.mjpg -i 0

How to compile on Linux/macOS (using CMake)

The CMakeLists.txt will attempt to find installed optional dependencies like CUDA, cudnn, ZED and build against those. It will also create a shared object library file to use darknet for code development.

To update CMake on Ubuntu, it's better to follow guide here: https://apt.kitware.com/ or https://cmake.org/download/

git clone https://github.com/AlexeyAB/darknet --recurse-submodules
cd darknet
mkdir build_release
cd build_release
cmake ..
cmake --build . --target install --parallel 8

Using also PowerShell

Install: Cmake, CUDA, cuDNN How to install dependencies

Install powershell for your OS (Linux or MacOS) (guide here).

Open PowerShell type these commands

git clone https://github.com/AlexeyAB/darknet --recurse-submodules
cd darknet
./CCM/build.ps1 -UseVCPKG -EnableOPENCV -EnableCUDA -EnableCUDNN

• remove options like -EnableCUDA or -EnableCUDNN if you are not interested into
• remove option -UseVCPKG if you plan to manually provide OpenCV library to darknet or if you do not want to enable OpenCV integration
• add option -EnableOPENCV_CUDA if you want to build OpenCV with CUDA support - very slow to build! (requires -UseVCPKG)

If you open the build.ps1 script at the beginning you will find all available switches.

How to compile on Linux (using make)

Just do make in the darknet directory. (You can try to compile and run it on Google Colab in cloud link (press «Open in Playground» button at the top-left corner) and watch the video link ) Before make, you can set such options in the Makefile: link

• GPU=1 to build with CUDA to accelerate by using GPU (CUDA should be in /usr/local/cuda)
• CUDNN=1 to build with cuDNN v5-v7 to accelerate training by using GPU (cuDNN should be in /usr/local/cudnn)
• CUDNN_HALF=1 to build for Tensor Cores (on Titan V / Tesla V100 / DGX-2 and later) speedup Detection 3x, Training 2x
• OPENCV=1 to build with OpenCV 4.x/3.x/2.4.x - allows to detect on video files and video streams from network cameras or web-cams
• DEBUG=1 to build debug version of Yolo
• OPENMP=1 to build with OpenMP support to accelerate Yolo by using multi-core CPU
• LIBSO=1 to build a library darknet.so and binary runnable file uselib that uses this library. Or you can try to run so LD_LIBRARY_PATH=./:$LD_LIBRARY_PATH ./uselib test.mp4 How to use this SO-library from your own code - you can look at C++ example: https://github.com/AlexeyAB/darknet/blob/master/src/yolo_console_dll.cpp or use in such a way: LD_LIBRARY_PATH=./:$LD_LIBRARY_PATH ./uselib data/coco.names cfg/yolov4.cfg yolov4.weights test.mp4
• ZED_CAMERA=1 to build a library with ZED-3D-camera support (should be ZED SDK installed), then run LD_LIBRARY_PATH=./:$LD_LIBRARY_PATH ./uselib data/coco.names cfg/yolov4.cfg yolov4.weights zed_camera
• You also need to specify for which graphics card the code is generated. This is done by setting ARCH=. If you use a newer version than CUDA 11 you further need to edit line 20 from Makefile and remove -gencode arch=compute_30,code=sm_30 \ as Kepler GPU support was dropped in CUDA 11. You can also drop the general ARCH= and just uncomment ARCH= for your graphics card.

How to compile on Windows (using CMake)

Requires:

• MSVC: https://visualstudio.microsoft.com/thank-you-downloading-visual-studio/?sku=Community
• CMake GUI: Windows win64-x64 Installerhttps://cmake.org/download/
• Download Darknet zip-archive with the latest commit and uncompress it: master.zip

In Windows:

• Start (button) -> All programs -> CMake -> CMake (gui) ->

• look at image In CMake: Enter input path to the darknet Source, and output path to the Binaries -> Configure (button) -> Optional platform for generator: x64 -> Finish -> Generate -> Open Project ->

• in MS Visual Studio: Select: x64 and Release -> Build -> Build solution

• find the executable file darknet.exe in the output path to the binaries you specified

How to compile on Windows (using vcpkg)

This is the recommended approach to build Darknet on Windows.

1. Install Visual Studio 2017 or 2019. In case you need to download it, please go here: Visual Studio Community. Remember to install English language pack, this is mandatory for vcpkg!

2. Install CUDA enabling VS Integration during installation.

3. Open Powershell (Start -> All programs -> Windows Powershell) and type these commands:

Set-ExecutionPolicy unrestricted -Scope CurrentUser -Force
git clone https://github.com/AlexeyAB/darknet --recurse-submodules
cd darknet
.\CCM\build.ps1 -UseVCPKG -EnableOPENCV -EnableCUDA -EnableCUDNN

(add option -EnableOPENCV_CUDA if you want to build OpenCV with CUDA support - very slow to build! - or remove options like -EnableCUDA or -EnableCUDNN if you are not interested in them). If you open the build.ps1 script at the beginning you will find all available switches.

How to train with multi-GPU

1. Train it first on 1 GPU for like 1000 iterations: darknet.exe detector train cfg/coco.data cfg/yolov4.cfg yolov4.conv.137

2. Then stop and by using partially-trained model /backup/yolov4_1000.weights run training with multigpu (up to 4 GPUs): darknet.exe detector train cfg/coco.data cfg/yolov4.cfg /backup/yolov4_1000.weights -gpus 0,1,2,3

If you get a Nan, then for some datasets better to decrease learning rate, for 4 GPUs set learning_rate = 0,00065 (i.e. learning_rate = 0.00261 / GPUs). In this case also increase 4x times burn_in = in your cfg-file. I.e. use burn_in = 4000 instead of 1000.

https://groups.google.com/d/msg/darknet/NbJqonJBTSY/Te5PfIpuCAAJ

How to train (to detect your custom objects)

(to train old Yolo v2 yolov2-voc.cfg, yolov2-tiny-voc.cfg, yolo-voc.cfg, yolo-voc.2.0.cfg, ... click by the link)

Training Yolo v4 (and v3):

0. For training cfg/yolov4-custom.cfg download the pre-trained weights-file (162 MB): yolov4.conv.137 (Google drive mirror yolov4.conv.137 )
1. Create file yolo-obj.cfg with the same content as in yolov4-custom.cfg (or copy yolov4-custom.cfg to yolo-obj.cfg) and:

• change line batch to batch=64
• change line subdivisions to subdivisions=16
• change line max_batches to (classes*2000, but not less than number of training images and not less than 6000), f.e. max_batches=6000 if you train for 3 classes
• change line steps to 80% and 90% of max_batches, f.e. steps=4800,5400
• set network size width=416 height=416 or any value multiple of 32: https://github.com/AlexeyAB/darknet/blob/0039fd26786ab5f71d5af725fc18b3f521e7acfd/cfg/yolov3.cfg#L8-L9
• change line classes=80 to your number of objects in each of 3 [yolo]-layers:
  • https://github.com/AlexeyAB/darknet/blob/0039fd26786ab5f71d5af725fc18b3f521e7acfd/cfg/yolov3.cfg#L610
  • https://github.com/AlexeyAB/darknet/blob/0039fd26786ab5f71d5af725fc18b3f521e7acfd/cfg/yolov3.cfg#L696
  • https://github.com/AlexeyAB/darknet/blob/0039fd26786ab5f71d5af725fc18b3f521e7acfd/cfg/yolov3.cfg#L783
• change [filters=255] to filters=(classes + 5)x3 in the 3 [convolutional] before each [yolo] layer, keep in mind that it only has to be the last [convolutional] before each of the [yolo] layers.
  • https://github.com/AlexeyAB/darknet/blob/0039fd26786ab5f71d5af725fc18b3f521e7acfd/cfg/yolov3.cfg#L603
  • https://github.com/AlexeyAB/darknet/blob/0039fd26786ab5f71d5af725fc18b3f521e7acfd/cfg/yolov3.cfg#L689
  • https://github.com/AlexeyAB/darknet/blob/0039fd26786ab5f71d5af725fc18b3f521e7acfd/cfg/yolov3.cfg#L776
• when using [Gaussian_yolo] layers, change [filters=57] filters=(classes + 9)x3 in the 3 [convolutional] before each [Gaussian_yolo] layer
  • https://github.com/AlexeyAB/darknet/blob/6e5bdf1282ad6b06ed0e962c3f5be67cf63d96dc/cfg/Gaussian_yolov3_BDD.cfg#L604
  • https://github.com/AlexeyAB/darknet/blob/6e5bdf1282ad6b06ed0e962c3f5be67cf63d96dc/cfg/Gaussian_yolov3_BDD.cfg#L696
  • https://github.com/AlexeyAB/darknet/blob/6e5bdf1282ad6b06ed0e962c3f5be67cf63d96dc/cfg/Gaussian_yolov3_BDD.cfg#L789

So if classes=1 then should be filters=18. If classes=2 then write filters=21. (Do not write in the cfg-file: filters=(classes + 5)x3)

(Generally filters depends on the classes, coords and number of masks, i.e. filters=(classes + coords + 1)*<number of mask>, where mask is indices of anchors. If mask is absence, then filters=(classes + coords + 1)*num)

So for example, for 2 objects, your file yolo-obj.cfg should differ from yolov4-custom.cfg in such lines in each of 3 [yolo]-layers:

[convolutional]
filters=21

[region]
classes=2

2. Create file obj.names in the directory build\darknet\x64\data\, with objects names - each in new line
3. Create file obj.data in the directory build\darknet\x64\data\, containing (where classes = number of objects):

classes = 2
train  = data/train.txt
valid  = data/test.txt
names = data/obj.names
backup = backup/

4. Put image-files (.jpg) of your objects in the directory build\darknet\x64\data\obj\
5. You should label each object on images from your dataset. Use this visual GUI-software for marking bounded boxes of objects and generating annotation files for Yolo v2 & v3: https://github.com/AlexeyAB/Yolo_mark

It will create .txt-file for each .jpg-image-file - in the same directory and with the same name, but with .txt-extension, and put to file: object number and object coordinates on this image, for each object in new line:

<object-class> <x_center> <y_center> <width> <height>

Where:

• <object-class> - integer object number from 0 to (classes-1)

• <x_center> <y_center> <width> <height> - float values relative to width and height of image, it can be equal from (0.0 to 1.0]

• for example: <x> = <absolute_x> / <image_width> or <height> = <absolute_height> / <image_height>

• attention: <x_center> <y_center> - are center of rectangle (are not top-left corner)

  For example for img1.jpg you will be created img1.txt containing:

  1 0.716797 0.395833 0.216406 0.147222
  0 0.687109 0.379167 0.255469 0.158333
  1 0.420312 0.395833 0.140625 0.166667


6. Create file train.txt in directory build\darknet\x64\data\, with filenames of your images, each filename in new line, with path relative to darknet.exe, for example containing:

data/obj/img1.jpg
data/obj/img2.jpg
data/obj/img3.jpg

7. Download pre-trained weights for the convolutional layers and put to the directory build\darknet\x64

   • for yolov4.cfg, yolov4-custom.cfg (162 MB): yolov4.conv.137 (Google drive mirror yolov4.conv.137 )
   • for yolov4-tiny.cfg, yolov4-tiny-3l.cfg, yolov4-tiny-custom.cfg (19 MB): yolov4-tiny.conv.29
   • for csresnext50-panet-spp.cfg (133 MB): csresnext50-panet-spp.conv.112
   • for yolov3.cfg, yolov3-spp.cfg (154 MB): darknet53.conv.74
   • for yolov3-tiny-prn.cfg , yolov3-tiny.cfg (6 MB): yolov3-tiny.conv.11
   • for enet-coco.cfg (EfficientNetB0-Yolov3) (14 MB): enetb0-coco.conv.132

8. Start training by using the command line: darknet.exe detector train data/obj.data yolo-obj.cfg yolov4.conv.137

   To train on Linux use command: ./darknet detector train data/obj.data yolo-obj.cfg yolov4.conv.137 (just use ./darknet instead of darknet.exe)

   • (file yolo-obj_last.weights will be saved to the build\darknet\x64\backup\ for each 100 iterations)
   • (file yolo-obj_xxxx.weights will be saved to the build\darknet\x64\backup\ for each 1000 iterations)
   • (to disable Loss-Window use darknet.exe detector train data/obj.data yolo-obj.cfg yolov4.conv.137 -dont_show, if you train on computer without monitor like a cloud Amazon EC2)
   • (to see the mAP & Loss-chart during training on remote server without GUI, use command darknet.exe detector train data/obj.data yolo-obj.cfg yolov4.conv.137 -dont_show -mjpeg_port 8090 -map then open URL http://ip-address:8090 in Chrome/Firefox browser)

8.1. For training with mAP (mean average precisions) calculation for each 4 Epochs (set valid=valid.txt or train.txt in obj.data file) and run: darknet.exe detector train data/obj.data yolo-obj.cfg yolov4.conv.137 -map

8.2. One can also set the -mAP_epochs in the training command if less or more frequent mAP calculation is needed. For example in order to calculate mAP for each 2 Epochs run darknet.exe detector train data/obj.data yolo-obj.cfg yolov4.conv.137 -map -mAP_epochs 2

9. After training is complete - get result yolo-obj_final.weights from path build\darknet\x64\backup\

   • After each 100 iterations you can stop and later start training from this point. For example, after 2000 iterations you can stop training, and later just start training using: darknet.exe detector train data/obj.data yolo-obj.cfg backup\yolo-obj_2000.weights

   (in the original repository https://github.com/pjreddie/darknet the weights-file is saved only once every 10 000 iterations if(iterations > 1000))

   • Also you can get result earlier than all 45000 iterations.

Note: If during training you see nan values for avg (loss) field - then training goes wrong, but if nan is in some other lines - then training goes well.

Note: If you changed width= or height= in your cfg-file, then new width and height must be divisible by 32.

Note: After training use such command for detection: darknet.exe detector test data/obj.data yolo-obj.cfg yolo-obj_8000.weights

Note: if error Out of memory occurs then in .cfg-file you should increase subdivisions=16, 32 or 64: link

How to train tiny-yolo (to detect your custom objects)

Do all the same steps as for the full yolo model as described above. With the exception of:

• Download file with the first 29-convolutional layers of yolov4-tiny: https://github.com/AlexeyAB/darknet/releases/download/darknet_yolo_v4_pre/yolov4-tiny.conv.29 (Or get this file from yolov4-tiny.weights file by using command: darknet.exe partial cfg/yolov4-tiny-custom.cfg yolov4-tiny.weights yolov4-tiny.conv.29 29
• Make your custom model yolov4-tiny-obj.cfg based on cfg/yolov4-tiny-custom.cfg instead of yolov4.cfg
• Start training: darknet.exe detector train data/obj.data yolov4-tiny-obj.cfg yolov4-tiny.conv.29

For training Yolo based on other models (DenseNet201-Yolo or ResNet50-Yolo), you can download and get pre-trained weights as showed in this file: https://github.com/AlexeyAB/darknet/blob/master/build/darknet/x64/partial.cmd If you made you custom model that isn't based on other models, then you can train it without pre-trained weights, then will be used random initial weights.

When should I stop training

Usually sufficient 2000 iterations for each class(object), but not less than number of training images and not less than 6000 iterations in total. But for a more precise definition of when you should stop training, use the following manual:

1. During training, you will see varying indicators of error, and you should stop when no longer decreases 0.XXXXXXX avg:

Region Avg IOU: 0.798363, Class: 0.893232, Obj: 0.700808, No Obj: 0.004567, Avg Recall: 1.000000, count: 8 Region Avg IOU: 0.800677, Class: 0.892181, Obj: 0.701590, No Obj: 0.004574, Avg Recall: 1.000000, count: 8

9002: 0.211667, 0.60730 avg, 0.001000 rate, 3.868000 seconds, 576128 images Loaded: 0.000000 seconds

• 9002 - iteration number (number of batch)

• 0.60730 avg - average loss (error) - the lower, the better

  When you see that average loss 0.xxxxxx avg no longer decreases at many iterations then you should stop training. The final average loss can be from 0.05 (for a small model and easy dataset) to 3.0 (for a big model and a difficult dataset).

  Or if you train with flag -map then you will see mAP indicator Last accuracy [email protected] = 18.50% in the console - this indicator is better than Loss, so train while mAP increases.

2. Once training is stopped, you should take some of last .weights-files from darknet\build\darknet\x64\backup and choose the best of them:

For example, you stopped training after 9000 iterations, but the best result can give one of previous weights (7000, 8000, 9000). It can happen due to over-fitting. Over-fitting - is case when you can detect objects on images from training-dataset, but can't detect objects on any others images. You should get weights from Early Stopping Point:

To get weights from Early Stopping Point:

2.1. At first, in your file obj.data you must specify the path to the validation dataset valid = valid.txt (format of valid.txt as in train.txt), and if you haven't validation images, just copy data\train.txt to data\valid.txt.

2.2 If training is stopped after 9000 iterations, to validate some of previous weights use this commands:

(If you use another GitHub repository, then use darknet.exe detector recall... instead of darknet.exe detector map...)

• darknet.exe detector map data/obj.data yolo-obj.cfg backup\yolo-obj_7000.weights
• darknet.exe detector map data/obj.data yolo-obj.cfg backup\yolo-obj_8000.weights
• darknet.exe detector map data/obj.data yolo-obj.cfg backup\yolo-obj_9000.weights

And compare last output lines for each weights (7000, 8000, 9000):

Choose weights-file with the highest mAP (mean average precision) or IoU (intersect over union)

For example, bigger mAP gives weights yolo-obj_8000.weights - then use this weights for detection.

Or just train with -map flag:

darknet.exe detector train data/obj.data yolo-obj.cfg yolov4.conv.137 -map

So you will see mAP-chart (red-line) in the Loss-chart Window. mAP will be calculated for each 4 Epochs using valid=valid.txt file that is specified in obj.data file (1 Epoch = images_in_train_txt / batch iterations)

(to change the max x-axis value - change max_batches= parameter to 2000*classes, f.e. max_batches=6000 for 3 classes)

Example of custom object detection: darknet.exe detector test data/obj.data yolo-obj.cfg yolo-obj_8000.weights

• IoU (intersect over union) - average intersect over union of objects and detections for a certain threshold = 0.24

• mAP (mean average precision) - mean value of average precisions for each class, where average precision is average value of 11 points on PR-curve for each possible threshold (each probability of detection) for the same class (Precision-Recall in terms of PascalVOC, where Precision=TP/(TP+FP) and Recall=TP/(TP+FN) ), page-11: http://homepages.inf.ed.ac.uk/ckiw/postscript/ijcv_voc09.pdf

mAP is default metric of precision in the PascalVOC competition, this is the same as AP50 metric in the MS COCO competition. In terms of Wiki, indicators Precision and Recall have a slightly different meaning than in the PascalVOC competition, but IoU always has the same meaning.

Custom object detection

Example of custom object detection: darknet.exe detector test data/obj.data yolo-obj.cfg yolo-obj_8000.weights

How to improve object detection

1. Before training:

• set flag random=1 in your .cfg-file - it will increase precision by training Yolo for different resolutions: link

• increase network resolution in your .cfg-file (height=608, width=608 or any value multiple of 32) - it will increase precision

• check that each object that you want to detect is mandatory labeled in your dataset - no one object in your data set should not be without label. In the most training issues - there are wrong labels in your dataset (got labels by using some conversion script, marked with a third-party tool, ...). Always check your dataset by using: https://github.com/AlexeyAB/Yolo_mark

• my Loss is very high and mAP is very low, is training wrong? Run training with -show_imgs flag at the end of training command, do you see correct bounded boxes of objects (in windows or in files aug_...jpg)? If no - your training dataset is wrong.

• for each object which you want to detect - there must be at least 1 similar object in the Training dataset with about the same: shape, side of object, relative size, angle of rotation, tilt, illumination. So desirable that your training dataset include images with objects at different: scales, rotations, lightings, from different sides, on different backgrounds - you should preferably have 2000 different images for each class or more, and you should train 2000*classes iterations or more

• desirable that your training dataset include images with non-labeled objects that you do not want to detect - negative samples without bounded box (empty .txt files) - use as many images of negative samples as there are images with objects

• What is the best way to mark objects: label only the visible part of the object, or label the visible and overlapped part of the object, or label a little more than the entire object (with a little gap)? Mark as you like - how would you like it to be detected.

• for training with a large number of objects in each image, add the parameter max=200 or higher value in the last [yolo]-layer or [region]-layer in your cfg-file (the global maximum number of objects that can be detected by YoloV3 is 0,0615234375*(width*height) where are width and height are parameters from [net] section in cfg-file)

• for training for small objects (smaller than 16x16 after the image is resized to 416x416) - set layers = 23 instead of https://github.com/AlexeyAB/darknet/blob/6f718c257815a984253346bba8fb7aa756c55090/cfg/yolov4.cfg#L895

  • set stride=4 instead of https://github.com/AlexeyAB/darknet/blob/6f718c257815a984253346bba8fb7aa756c55090/cfg/yolov4.cfg#L892
  • set stride=4 instead of https://github.com/AlexeyAB/darknet/blob/6f718c257815a984253346bba8fb7aa756c55090/cfg/yolov4.cfg#L989

• for training for both small and large objects use modified models:

  • Full-model: 5 yolo layers: https://raw.githubusercontent.com/AlexeyAB/darknet/master/cfg/yolov3_5l.cfg
  • Tiny-model: 3 yolo layers: https://raw.githubusercontent.com/AlexeyAB/darknet/master/cfg/yolov4-tiny-3l.cfg
  • YOLOv4: 3 yolo layers: https://raw.githubusercontent.com/AlexeyAB/darknet/master/cfg/yolov4-custom.cfg

• If you train the model to distinguish Left and Right objects as separate classes (left/right hand, left/right-turn on road signs, ...) then for disabling flip data augmentation - add flip=0 here: https://github.com/AlexeyAB/darknet/blob/3d2d0a7c98dbc8923d9ff705b81ff4f7940ea6ff/cfg/yolov3.cfg#L17

• General rule - your training dataset should include such a set of relative sizes of objects that you want to detect:

  • train_network_width * train_obj_width / train_image_width ~= detection_network_width * detection_obj_width / detection_image_width
  • train_network_height * train_obj_height / train_image_height ~= detection_network_height * detection_obj_height / detection_image_height

  I.e. for each object from Test dataset there must be at least 1 object in the Training dataset with the same class_id and about the same relative size:

  object width in percent from Training dataset ~= object width in percent from Test dataset

  That is, if only objects that occupied 80-90% of the image were present in the training set, then the trained network will not be able to detect objects that occupy 1-10% of the image.

• to speedup training (with decreasing detection accuracy) set param stopbackward=1 for layer-136 in cfg-file

• each: model of object, side, illumination, scale, each 30 grad of the turn and inclination angles - these are different objects from an internal perspective of the neural network. So the more different objects you want to detect, the more complex network model should be used.

• to make the detected bounded boxes more accurate, you can add 3 parameters ignore_thresh = .9 iou_normalizer=0.5 iou_loss=giou to each [yolo] layer and train, it will increase [email protected], but decrease [email protected].

• Only if you are an expert in neural detection networks - recalculate anchors for your dataset for width and height from cfg-file: darknet.exe detector calc_anchors data/obj.data -num_of_clusters 9 -width 416 -height 416 then set the same 9 anchors in each of 3 [yolo]-layers in your cfg-file. But you should change indexes of anchors masks= for each [yolo]-layer, so for YOLOv4 the 1st-[yolo]-layer has anchors smaller than 30x30, 2nd smaller than 60x60, 3rd remaining, and vice versa for YOLOv3. Also you should change the filters=(classes + 5)*<number of mask> before each [yolo]-layer. If many of the calculated anchors do not fit under the appropriate layers - then just try using all the default anchors.

2. After training - for detection:

• Increase network-resolution by set in your .cfg-file (height=608 and width=608) or (height=832 and width=832) or (any value multiple of 32) - this increases the precision and makes it possible to detect small objects: link

• it is not necessary to train the network again, just use .weights-file already trained for 416x416 resolution

• to get even greater accuracy you should train with higher resolution 608x608 or 832x832, note: if error Out of memory occurs then in .cfg-file you should increase subdivisions=16, 32 or 64: link

How to mark bounded boxes of objects and create annotation files

Here you can find repository with GUI-software for marking bounded boxes of objects and generating annotation files for Yolo v2 - v4: https://github.com/AlexeyAB/Yolo_mark

With example of: train.txt, obj.names, obj.data, yolo-obj.cfg, air1-6.txt, bird1-4.txt for 2 classes of objects (air, bird) and train_obj.cmd with example how to train this image-set with Yolo v2 - v4

Different tools for marking objects in images:

1. in C++: https://github.com/AlexeyAB/Yolo_mark
2. in Python: https://github.com/tzutalin/labelImg
3. in Python: https://github.com/Cartucho/OpenLabeling
4. in C++: https://www.ccoderun.ca/darkmark/
5. in JavaScript: https://github.com/opencv/cvat
6. in C++: https://github.com/jveitchmichaelis/deeplabel
7. in C#: https://github.com/BMW-InnovationLab/BMW-Labeltool-Lite
8. DL-Annotator for Windows ($30): url
9. v7labs - the greatest cloud labeling tool ($1.5 per hour): https://www.v7labs.com/

How to use Yolo as DLL and SO libraries

• on Linux
  • using build.sh or
  • build darknet using cmake or
  • set LIBSO=1 in the Makefile and do make
• on Windows
  • using build.ps1 or
  • build darknet using cmake or
  • compile build\darknet\yolo_cpp_dll.sln solution or build\darknet\yolo_cpp_dll_no_gpu.sln solution

There are 2 APIs:

• C API: https://github.com/AlexeyAB/darknet/blob/master/include/darknet.h

  • Python examples using the C API:
    • https://github.com/AlexeyAB/darknet/blob/master/darknet.py
    • https://github.com/AlexeyAB/darknet/blob/master/darknet_video.py

• C++ API: https://github.com/AlexeyAB/darknet/blob/master/include/yolo_v2_class.hpp

  • C++ example that uses C++ API: https://github.com/AlexeyAB/darknet/blob/master/src/yolo_console_dll.cpp

---

1. To compile Yolo as C++ DLL-file yolo_cpp_dll.dll - open the solution build\darknet\yolo_cpp_dll.sln, set x64 and Release, and do the: Build -> Build yolo_cpp_dll

   • You should have installed CUDA 10.2
   • To use cuDNN do: (right click on project) -> properties -> C/C++ -> Preprocessor -> Preprocessor Definitions, and add at the beginning of line: CUDNN;

2. To use Yolo as DLL-file in your C++ console application - open the solution build\darknet\yolo_console_dll.sln, set x64 and Release, and do the: Build -> Build yolo_console_dll

   • you can run your console application from Windows Explorer build\darknet\x64\yolo_console_dll.exe use this command: yolo_console_dll.exe data/coco.names yolov4.cfg yolov4.weights test.mp4

   • after launching your console application and entering the image file name - you will see info for each object: <obj_id> <left_x> <top_y> <width> <height> <probability>

   • to use simple OpenCV-GUI you should uncomment line //#define OPENCV in yolo_console_dll.cpp-file: link

   • you can see source code of simple example for detection on the video file: link

yolo_cpp_dll.dll-API: link

struct bbox_t {
    unsigned int x, y, w, h;    // (x,y) - top-left corner, (w, h) - width & height of bounded box
    float prob;                    // confidence - probability that the object was found correctly
    unsigned int obj_id;        // class of object - from range [0, classes-1]
    unsigned int track_id;        // tracking id for video (0 - untracked, 1 - inf - tracked object)
    unsigned int frames_counter;// counter of frames on which the object was detected
};

class Detector {
public:
        Detector(std::string cfg_filename, std::string weight_filename, int gpu_id = 0);
        ~Detector();

        std::vector<bbox_t> detect(std::string image_filename, float thresh = 0.2, bool use_mean = false);
        std::vector<bbox_t> detect(image_t img, float thresh = 0.2, bool use_mean = false);
        static image_t load_image(std::string image_filename);
        static void free_image(image_t m);

#ifdef OPENCV
        std::vector<bbox_t> detect(cv::Mat mat, float thresh = 0.2, bool use_mean = false);
        std::shared_ptr<image_t> mat_to_image_resize(cv::Mat mat) const;
#endif
};

Citation

@misc{bochkovskiy2020yolov4,
      title={YOLOv4: Optimal Speed and Accuracy of Object Detection},
      author={Alexey Bochkovskiy and Chien-Yao Wang and Hong-Yuan Mark Liao},
      year={2020},
      eprint={2004.10934},
      archivePrefix={arXiv},
      primaryClass={cs.CV}
}

@InProceedings{Wang_2021_CVPR,
    author    = {Wang, Chien-Yao and Bochkovskiy, Alexey and Liao, Hong-Yuan Mark},
    title     = {{Scaled-YOLOv4}: Scaling Cross Stage Partial Network},
    booktitle = {Proceedings of the IEEE/CVF Conference on Computer Vision and Pattern Recognition (CVPR)},
    month     = {June},
    year      = {2021},
    pages     = {13029-13038}
}
