allegro/turnilo

Turnilo

[!WARNING] This project is archived and no longer maintained.

Allegro no longer uses Turnilo internally and is stepping back from its development. The repository is now read-only: there will be no further releases, bug fixes, or support, and issues and pull requests are no longer being reviewed or merged.

Thank you to everyone who contributed code, reported issues, shared ideas, and used Turnilo over the years. This project would not have been what it is without you.

Turnilo is a business intelligence, data exploration and visualization web application for Apache Druid. Turnilo is a fork of Pivot which is currently available under commercial licence only. This repository was forked from the stalled repository Swiv with the latest version of Pivot under Apache license.

Motivation

Druid is heavily used as business intelligence platform at Allegro. In order to gain wide adoption of non-technical users, Druid requires simple yet powerful user interface. In Allegro we have decided that we are going to continue Pivot development as an open source software, this is how Turnilo emerged.

Manifesto

• High usability for non-technical users over sophisticated but rarely used features.
• Focus on interactive data exploration over static predefined dashboards.
• Self-describing reports for users without deep domain expertise.
• Outstanding integration with Druid over support for other data sources like SQL databases.
• Focus on data visualizations over Druid cluster or data ingestion management.
• Data cubes configuration as a code over UI editor backed by non-versioned database.
• Stateless over stateful server-side architecture.
• Support for most recent versions of standards compliant browsers.

Features

• Intuitive, drag and drop, gorgeous user interface to visualize Druid datasets.
• Fully dedicated to low latency Druid Timeseries, TopN and GroupBy queries.
• Unified view for historical and real-time data.
• Blazingly fast.

Try it

You can try an online demo with example datasets (Covid-19 and Wikipedia) at https://turnilo.app.

Join us

Feel free to ask on GitHub Discussions or join the chat on Slack.

Pre-requisites

• Node.js - 14.x or 16.x version

:warning: Do not use yarn command for dependency management and project build, use npm instead. With npm builds are reproducible (thanks to package-lock.json) and even faster than with yarn.

Usage

Install Turnilo distribution using npm.

npm install -g turnilo

Start off by running Turnilo with example datasets and open http://localhost:9090/.

turnilo run-examples

Use connect-druid command to connect to the existing Druid broker. Turnilo will automatically introspect your Druid broker and figure out available datasets.

turnilo connect-druid http[s]://druid-broker-hostname[:port]

Documentation

Learn how to configure and customize Turnilo: https://allegro.github.io/turnilo/

Development

Install project dependencies

npm install

Build the project

npm run build

Run project

Run example datasets.

npm run start:examples

Connect to the existing Druid broker.

npm run start -- connect-druid http[s]://druid-broker-hostname[:port]

Connect to the existing Druid broker using your config file.

npm run start -- run-config path/to/config.yml

Run project in developer mode

Every change in frontend code would recompile project and reload page.

Run example datasets.

npm run start:dev:examples

Connect to the existing Druid broker.

npm run start:dev -- connect-druid http[s]://druid-broker-hostname[:port]

Connect to the existing Druid broker using your config file.

npm run start:dev -- run-config path/to/config.yml

Testing

Unit tests

Run all unit tests.

npm run test

Or run tests separately for common, client and server modules.

npm run test:common
npm run test:client
npm run test:server

End to end tests

Run all e2e tests. It will start Turnilo with example datasets in background.

npm run e2e

End to end tests development

Run server

npm start:dev:examples

Run cypress interactive tools for e2e testing

npm run e2e:dev

Debugging

Server module

In WebStorm\IntelliJ open "Run/Debug Configurations", click "Add New Configuration". Next choose "Node.JS", set "JavaScript file" to "./bin/turnilo" and "Application parameters" to "--examples".

You can find more infrmation here

Generating documentation locally

Prerequisites

• Ruby
• Bundler

Go to the docs folder and:

1. Install bundle install or update bundle update dependencies
2. Run bundle exec jekyll serve --livereload
3. Open http://localhost:4000/

License

Turnilo is published under Apache License 2.0.
