bpmn-io/bpmn-js-properties-panel

<div class="modeler">
  <div id="canvas"></div>
  <div id="properties"></div>
</div>

import BpmnModeler from 'bpmn-js/lib/Modeler';
import {
  BpmnPropertiesPanelModule,
  BpmnPropertiesProviderModule,
} from 'bpmn-js-properties-panel';

const modeler = new BpmnModeler({
  container: '#canvas',
  propertiesPanel: {
    parent: '#properties'
  },
  additionalModules: [
    BpmnPropertiesPanelModule,
    BpmnPropertiesProviderModule
  ]
});

<link rel="stylesheet" href="https://unpkg.com/@bpmn-io/properties-panel/dist/assets/properties-panel.css">

const propertiesPanel = bpmnJS.get('propertiesPanel');

// detach the panel
propertiesPanel.detach();

// attach it to some other element
propertiesPanel.attachTo('#other-properties');

import BpmnModeler from 'bpmn-js/lib/Modeler';
import {
  BpmnPropertiesPanelModule,
  BpmnPropertiesProviderModule,
  ZeebePropertiesProviderModule // Camunda 8 provider
} from 'bpmn-js-properties-panel';

// Camunda 8 moddle extension
import zeebeModdle from 'zeebe-bpmn-moddle/resources/zeebe';

// Camunda 8 behaviors
import ZeebeBehaviorsModule from 'camunda-bpmn-js-behaviors/lib/camunda-cloud';

const modeler = new BpmnModeler({
  container: '#canvas',
  propertiesPanel: {
    parent: '#properties'
  },
  additionalModules: [
    BpmnPropertiesPanelModule,
    BpmnPropertiesProviderModule,
    ZeebePropertiesProviderModule,
    ZeebeBehaviorsModule
  ],
  moddleExtensions: {
    zeebe: zeebeModdle
  }
});

const propertiesPanel = modeler.get('propertiesPanel');

propertiesPanel.attachTo('#other-properties');

// or attach the panel body and header to different containers
propertiesPanel.attachTo('#properties', '#panel-header');

const propertiesPanel = modeler.get('propertiesPanel');

propertiesPanel.detach();

class ExamplePropertiesProvider {
  constructor(propertiesPanel) {
    propertiesPanel.registerProvider(500, this);
  }

  getGroups(element) {
    return (groups) => {

      // add, modify or remove groups
      // ...

      return groups;
    };
  }
}

ExamplePropertiesProvider.$inject = [ 'propertiesPanel' ];

const propertiesPanel = modeler.get('propertiesPanel');

const entryId = propertiesPanel.getEntryId(element, [
  'extensionElements', 'values', 0, 'inputParameters', 1, 'source'
]);
// 'ServiceTask_1-input-1-source'

npm install

# build the library and run all tests
npm run all

# spin up a single local modeler instance
npm start

# run the full development setup
npm run dev
