derailed/k9s

K9s - Kubernetes CLI To Manage Your Clusters In Style!

K9s provides a terminal UI to interact with your Kubernetes clusters. The aim of this project is to make it easier to navigate, observe and manage your applications in the wild. K9s continually watches Kubernetes for changes and offers subsequent commands to interact with your observed resources.

---

Note...

K9s is not pimped out by a big corporation with deep pockets. It is a complex OSS project that demands a lot of my time to maintain and support. K9s will always remain OSS and therefore free! That said, if you feel k9s makes your day to day Kubernetes journey a tad brighter, saves you time and makes you more productive, please consider sponsoring us! Your donations will go a long way in keeping our servers lights on and beers in our fridge!

Thank you!

---

---

Screenshots

1. Pods
2. Logs
3. Deployments

---

Demo Videos/Recordings

• K9s v0.40.0 -Column Blow- Sneak peek
• K9s v0.31.0 Configs+Sneak peek
• K9s v0.30.0 Sneak peek
• Vulnerability Scans
• K9s v0.29.0
• K9s v0.21.3
• K9s v0.19.X
• K9s v0.18.0
• K9s v0.17.0
• K9s Pulses
• K9s v0.15.1
• K9s v0.13.0
• K9s v0.9.0
• K9s v0.7.0 Features
• K9s v0 Demo

---

Documentation

Please refer to our K9s documentation site for installation, usage, customization and tips.

---

Slack Channel

Wanna discuss K9s features with your fellow K9sers or simply show your support for this tool?

• Channel: K9sersSlack
• Invite: K9slackers Invite

---

Installation

K9s is available on Linux, macOS and Windows platforms. Binaries for Linux, Windows and Mac are available as tarballs in the release page.

• Via Homebrew for macOS or Linux

  brew install derailed/k9s/k9s


• Via MacPorts

  sudo port install k9s


• Via snap for Linux

  snap install k9s --devmode


• On Arch Linux

  pacman -S k9s


• On OpenSUSE Linux distribution

  zypper install k9s


• On FreeBSD

  pkg install k9s


• On Ubuntu

  wget https://github.com/derailed/k9s/releases/latest/download/k9s_linux_amd64.deb && sudo apt install ./k9s_linux_amd64.deb && rm k9s_linux_amd64.deb


• On Fedora (42+)

  dnf install k9s


• Via Winget for Windows

  winget install k9s


• Via Scoop for Windows

  scoop install k9s


• Via Chocolatey for Windows

  choco install k9s


• Via a GO install

  # NOTE: The dev version will be in effect!
  go install github.com/derailed/k9s@latest


• Via Webi for Linux and macOS

  curl -sS https://webinstall.dev/k9s | bash


• Via pkgx for Linux and macOS

  pkgx k9s


• Via gah for Linux and macOS

  gah install k9s


• Via Webi for Windows

  curl.exe -A MS https://webinstall.dev/k9s | powershell


• As a Docker Desktop Extension (for the Docker Desktop built in Kubernetes Server)

  docker extension install spurin/k9s-dd-extension:latest


---

Building From Source

K9s is currently using GO v1.23.X or above. In order to build K9s from source you must:

1. Clone the repo

2. Build and run the executable

   make build && ./execs/k9s


---

Running with Docker

Running the official Docker image

You can run k9s as a Docker container by mounting your KUBECONFIG:

docker run --rm -it -v $KUBECONFIG:/root/.kube/config derailed/k9s

For default path it would be:

docker run --rm -it -v ~/.kube/config:/root/.kube/config derailed/k9s

Building your own Docker image

You can build your own Docker image of k9s from the Dockerfile with the following:

docker build -t k9s-docker:v0.0.1 .

You can get the latest stable kubectl version and pass it to the docker build command with the --build-arg option. You can use the --build-arg option to pass any valid kubectl version (like v1.18.0 or v1.19.1).

KUBECTL_VERSION=$(make kubectl-stable-version 2>/dev/null)
docker build --build-arg KUBECTL_VERSION=${KUBECTL_VERSION} -t k9s-docker:0.1 .

Run your container:

docker run --rm -it -v ~/.kube/config:/root/.kube/config k9s-docker:0.1

Building a multi-platform image

The make imgx target builds for linux/amd64 and linux/arm64 via Docker buildx:

make imgx

Cross-architecture builds rely on QEMU emulation. Docker Desktop includes this out of the box. On a plain Docker Engine install, see the buildx multi-platform docs for enabling emulation.

Override the defaults with BUILD_PLATFORMS, IMG_NAME and VERSION:

make imgx BUILD_PLATFORMS=linux/amd64,linux/arm64 IMG_NAME=your-org/k9s VERSION=v0.0.1

---

PreFlight Checks

• K9s uses 256 colors terminal mode. On `Nix system make sure TERM is set accordingly.

  export TERM=xterm-256color


• In order to issue resource edit commands make sure your EDITOR and KUBE_EDITOR env vars are set.

  # Kubectl edit command will use this env var.
  export KUBE_EDITOR=my_fav_editor


• K9s prefers recent kubernetes versions ie 1.28+

---

K8S Compatibility Matrix

---

The Command Line

# List current version
k9s version

# To get info about K9s runtime (logs, configs, etc..)
k9s info

# List all available CLI options
k9s help

# To run K9s in a given namespace
k9s -n mycoolns

# Start K9s in an existing KubeConfig context
k9s --context coolCtx

# Start K9s in readonly mode - with all cluster modification commands disabled
k9s --readonly

Logs And Debug Logs

Given the nature of the ui k9s does produce logs to a specific location. To view the logs and turn on debug mode, use the following commands:

# Find out where the logs are stored
k9s info

 ____  __.________
|    |/ _/   __   \______
|      < \____    /  ___/
|    |  \   /    /\___ \
|____|__ \ /____//____  >
        \/            \/

Version:           vX.Y.Z
Config:            /Users/fernand/.config/k9s/config.yaml
Logs:              /Users/fernand/.local/state/k9s/k9s.log
Dumps dir:         /Users/fernand/.local/state/k9s/screen-dumps
Benchmarks dir:    /Users/fernand/.local/state/k9s/benchmarks
Skins dir:         /Users/fernand/.local/share/k9s/skins
Contexts dir:      /Users/fernand/.local/share/k9s/clusters
Custom views file: /Users/fernand/.local/share/k9s/views.yaml
Plugins file:      /Users/fernand/.local/share/k9s/plugins.yaml
Hotkeys file:      /Users/fernand/.local/share/k9s/hotkeys.yaml
Alias file:        /Users/fernand/.local/share/k9s/aliases.yaml

View K9s logs

tail -f /Users/fernand/.local/data/k9s/k9s.log

Start K9s in debug mode

k9s -l debug

Customize logs destination

You can override the default log file destination either with the --logFile argument:

k9s --logFile /tmp/k9s.log
less /tmp/k9s.log

Or through the K9S_LOGS_DIR environment variable:

K9S_LOGS_DIR=/var/log k9s
less /var/log/k9s.log

Key Bindings

K9s uses aliases to navigate most K8s resources.

---

K9s Configuration

K9s keeps its configurations as YAML files inside of a k9s directory and the location depends on your operating system. K9s leverages XDG to load its various configurations files. For information on the default locations for your OS please see this link. If you are still confused a quick k9s info will reveal where k9s is loading its configurations from. Alternatively, you can set K9S_CONFIG_DIR to tell K9s the directory location to pull its configurations from.

NOTE: This is still in flux and will change while in pre-release stage!

You can now override the context portForward default address configuration by setting an env variable that can override all clusters portForward local address using K9S_DEFAULT_PF_ADDRESS=a.b.c.d

Clipboard behavior can also be controlled via environment variables:

• K9S_CLIPBOARD=auto|native|osc52 (default auto)

  • auto: try native clipboard utilities first, then fall back to OSC52 when available.
  • native: only use native clipboard utilities (xclip/xsel/wl-clipboard/etc).
  • osc52: force OSC52 clipboard writes.

• K9S_OSC52_MAX=<encoded-bytes> sets the maximum allowed OSC52 payload size before k9s rejects the copy operation. Default is 74994.

  # $XDG_CONFIG_HOME/k9s/config.yaml
  k9s:
    # Enable periodic refresh of resource browser windows. Default false
    liveViewAutoRefresh: false
    # !!New!! v0.50.8...
    # Extends the list of supported GPU vendors. The key is the vendor name, the value must correspond to k8s resource driver designation.
    # Default known GPU vendors:
    # nvidia: nvidia.com/gpu
      # nvidia-shared: nvidia.com/gpu.shared
      # amd: amd.com/gpu
      # intel: gpu.intel.com/i915
    gpuVendors:
      bozo: bozo/gpu  # extends the gpu vendor and add "bozo"
    # The path to screen dump. Default: '%temp_dir%/k9s-screens-%username%' (k9s info)
    screenDumpDir: /tmp/dumps
    # Represents ui poll intervals in seconds. Default 2.0 secs. Minimum value is 2.0 - values below will be capped to the minimum.
    refreshRate: 2
    # Overrides the default k8s api server requests timeout. Defaults 120s
    apiServerTimeout: 15s
    # Number of retries once the connection to the api-server is lost. Default 15.
    maxConnRetry: 5
    # Indicates whether modification commands like delete/kill/edit are disabled. Default is false
    readOnly: false
    # This setting allows users to specify the default view, but it is not set by default.
    defaultView: ""
    # Toggles whether k9s should exit when CTRL-C is pressed. When set to true, you will need to exit k9s via the :quit command. Default is false.
    noExitOnCtrlC: false
    #UI settings
    ui:
      # Enable mouse support. Default false
      enableMouse: false
      # Set to true to hide K9s header. Default false
      headless: false
      # Set to true to hide the K9S logo Default false
      logoless: false
      # Set to true to hide K9s crumbs. Default false
      crumbsless: false
      # Set to true to suppress the K9s splash screen on start. Default false. Note that for larger clusters or higher latency connections, there may be no resources visible initially until local caches have finished populating.
      splashless: false
      # Toggles icons display as not all terminal support these chars. Default: true
      noIcons: false
      # Toggles reactive UI. This option provide for watching on disk artifacts changes and update the UI live Defaults to false.
      reactive: false
      # By default all contexts will use the dracula skin unless explicitly overridden in the context config file.
      skin: dracula # => assumes the file skins/dracula.yaml is present in the  $XDG_DATA_HOME/k9s/skins directory. Can be overridden with K9S_SKIN.
      # Convert dark skins to light, or vice versa, preserving hue. Default: false
      invert: false
      # Allows to set certain views default fullscreen mode. (yaml, helm history, describe, value_extender, details, logs) Default false
      defaultsToFullScreen: false
      # Show full resource GVR (Group/Version/Resource) vs just R. Default: false.
      useFullGVRTitle: false
    # Toggles icons display as not all terminal support these chars.
    noIcons: false
    # Toggles whether k9s should check for the latest revision from the GitHub repository releases. Default is false.
    skipLatestRevCheck: false
    # Logs configuration
    logger:
      # Defines the number of lines to return. Default 100
      tail: 200
      # Defines the total number of log lines to allow in the view. Default 1000
      buffer: 500
      # Represents how far to go back in the log timeline in seconds. Setting to -1 will tail logs. Default is -1.
      sinceSeconds: 300 # => tail the last 5 mins.
      # Toggles log line wrap. Default false
      textWrap: false
      # Autoscroll in logs will be disabled. Default is false.
      disableAutoscroll: false
      # Enable column locking when autoscroll is enabled. Default is false.
      columnLock: false
      # Toggles log line timestamp info. Default false
      showTime: false
      # Sets the internal log channel buffer size. Increase when log lines are dropped under high throughput. Default 50
      logBufferSize: 100
    # Provide shell pod customization when nodeShell feature gate is enabled!
    shellPod:
      # The shell pod image to use.
      image: killerAdmin
      # The namespace to launch to shell pod into.
      namespace: default
      # The resource limit to set on the shell pod.
      limits:
        cpu: 100m
        memory: 100Mi
      # Enable TTY
      tty: true
      hostPathVolume:
      - name: docker-socket
        # Mount the Docker socket into the shell pod
        mountPath: /var/run/docker.sock
        # The path on the host to mount
        hostPath: /var/run/docker.sock
        readOnly: true


---

Popeye Configuration

K9s has integration with Popeye, which is a Kubernetes cluster sanitizer. Popeye itself uses a configuration called spinach.yml, but when integrating with K9s the cluster-specific file should be name $XDG_CONFIG_HOME/share/k9s/clusters/clusterX/contextY/spinach.yml. This allows you to have a different spinach config per cluster.

---

Node Shell

By enabling the nodeShell feature gate on a given cluster, K9s allows you to shell into your cluster nodes. Once enabled, you will have a new s for shell menu option while in node view. K9s will launch a pod on the selected node using a special k9s_shell pod. Furthermore, you can refine your shell pod by using a custom docker image preloaded with the shell tools you love. By default k9s uses a BusyBox image, but you can configure it as follows:

Alternatively, you can now override the context configuration by setting an env variable that can override all clusters node shell gate using K9S_FEATURE_GATE_NODE_SHELL=true|false

# $XDG_CONFIG_HOME/k9s/config.yaml
k9s:
  # You can also further tune the shell pod specification
  shellPod:
    image: cool_kid_admin:42
    namespace: blee
    limits:
      cpu: 100m
      memory: 100Mi

Then in your cluster configuration file...

# $XDG_DATA_HOME/k9s/clusters/cluster-1/context-1
k9s:
  cluster: cluster-1
  readOnly: false
  namespace:
    active: default
    lockFavorites: false
    favorites:
    - kube-system
    - default
  view:
    active: po
  featureGates:
    nodeShell: true # => Enable this feature gate to make nodeShell available on this cluster
  portForwardAddress: localhost

Customizing the Shell Pod

You can also customize the shell pod by adding a hostPathVolume to your shell pod. This allows you to mount a local directory or file into the shell pod. For example, if you want to mount the Docker socket into the shell pod, you can do so as follows:

k9s:
  shellPod:
    hostPathVolume:
    - name: docker-socket
      # Mount the Docker socket into the shell pod
      mountPath: /var/run/docker.sock
      # The path on the host to mount
      hostPath: /var/run/docker.sock
      readOnly: true

This will mount the Docker socket into the shell pod at /var/run/docker.sock and make it read-only. You can also mount any other directory or file in a similar way.

---

Command Aliases

In K9s, you can define your very own command aliases (shortnames) to access your resources. In your $HOME/.config/k9s define a file called aliases.yaml. A K9s alias defines pairs of alias:gvr. A gvr (Group/Version/Resource) represents a fully qualified Kubernetes resource identifier. Here is an example of an alias file:

#  $XDG_DATA_HOME/k9s/aliases.yaml
aliases:
  pp: v1/pods
  crb: rbac.authorization.k8s.io/v1/clusterrolebindings
  # As of v0.30.0 you can also refer to another command alias...
  fred: pod fred app=blee # => view pods in namespace fred with labels matching app=blee

Using this aliases file, you can now type :pp or :crb or :fred to activate their respective commands.

---

HotKey Support

Entering the command mode and typing a resource name or alias, could be cumbersome for navigating thru often used resources. We're introducing hotkeys that allow users to define their own key combination to activate their favorite resource views.

Additionally, you can define context specific hotkeys by add a context level configuration file in $XDG_DATA_HOME/k9s/clusters/clusterX/contextY/hotkeys.yaml

In order to surface hotkeys globally please follow these steps:

1. Create a file named $XDG_CONFIG_HOME/k9s/hotkeys.yaml

2. Add the following to your hotkeys.yaml. You can use resource name/short name to specify a command ie same as typing it while in command mode.

   #  $XDG_CONFIG_HOME/k9s/hotkeys.yaml
   hotKeys:
     # Hitting Shift-0 navigates to your pod view
     shift-0:
       shortCut:    Shift-0
       description: Viewing pods
       command:     pods
     # Hitting Shift-1 navigates to your deployments
     shift-1:
       shortCut:    Shift-1
       description: View deployments
       command:     dp
     # Hitting Shift-2 navigates to your xray deployments
     shift-2:
       shortCut:    Shift-2
       description: Xray Deployments
       command:     xray deploy
     # Hitting Shift-S view the resources in the namespace of your current selection
     shift-s:
       shortCut:    Shift-S
       override:    true # => will override the default shortcut related action if set to true (default to false)
       description: Namespaced resources
       command:     "$RESOURCE_NAME $NAMESPACE"
       keepHistory: true # whether you can return to the previous view


Not feeling so hot? Your custom hotkeys will be listed in the help view ?. Also your hotkeys file will be automatically reloaded so you can readily use your hotkeys as you define them.

You can choose any keyboard shortcuts that make sense to you, provided they are not part of the standard K9s shortcuts list.

Similarly, referencing environment variables in hotkeys is also supported. The available environment variables can refer to the description in the Plugins section.

NOTE: This feature/configuration might change in future releases!

---

Port Forwarding over websockets

K9s follows kubectl feature flag environment variables to enable/disable port-forwarding over websockets. (default enabled in >1.30) To disable Websocket support, set KUBECTL_PORT_FORWARD_WEBSOCKETS=false

---

FastForwards

As of v0.25.0, you can leverage the FastForwards feature to tell K9s how to default port-forwards. In situations where you are dealing with multiple containers or containers exposing multiple ports, it can be cumbersome to specify the desired port-forward from the dialog as in most cases, you already know which container/port tuple you desire. For these use cases, you can now annotate your manifests with the following annotations:

@ k9scli.io/auto-port-forwards activates one or more port-forwards directly bypassing the port-forward dialog all together. @ k9scli.io/port-forwards pre-selects one or more port-forwards when launching the port-forward dialog.

The annotation value takes on the shape container-name::[local-port:]container-port

NOTE: for either cases above you can specify the container port by name or number in your annotation!

Example

# Pod fred
apiVersion: v1
kind: Pod
metadata:
  name: fred
  annotations:
    k9scli.io/auto-port-forwards: zorg::5556        # => will default to container zorg port 5556 and local port 5566. No port-forward dialog will be shown.
    # Or...
    k9scli.io/port-forwards: bozo::9090:p1          # => launches the port-forward dialog selecting default port-forward on container bozo port named p1(8081)
                                                    # mapping to local port 9090.
    ...
spec:
  containers:
  - name: zorg
    ports:
    - name: p1
      containerPort: 5556
    ...
  - name: bozo
    ports:
    - name: p1
      containerPort: 8081
    - name: p2
      containerPort: 5555
    ...

The annotation value must specify a container to forward to as well as a local port and container port. The container port may be specified as either a port number or port name. If the local port is omitted then the local port will default to the container port number. Here are a few examples:

1. bozo::http - creates a pf on container bozo with port name http. If http specifies port number 8080 then the local port will be 8080 as well.
2. bozo::9090:http - creates a pf on container bozo mapping local port 9090->http(8080)
3. bozo::9090:8080 - creates a pf on container bozo mapping local port 9090->8080

---

Custom Views

SneakCast v0.17.0 on The Beach! - Yup! sound is sucking but what a setting!

You can change which columns shows up for a given resource via custom views. To surface this feature, you will need to create a new configuration file, namely $XDG_CONFIG_HOME/k9s/views.yaml. This file leverages GVR (Group/Version/Resource) to configure the associated table view columns. If no GVR is found for a view the default rendering will take over (ie what we have now). Going wide will add all the remaining columns that are available on the given resource after your custom columns. To boot, you can edit your views config file and tune your resources views live!

📢 🎉 As of release v0.40.0 you can specify json parse expressions to further customize your resources rendering.

The new column syntax is as follows:

COLUMN_NAME<:json_parse_expression><|column_attributes>

Where :json_parse_expression represents an expression to pull a specific snippet out of the resource manifest. Similar to kubectl -o custom-columns command. This expression is optional.

IMPORTANT! Columns must be valid YAML strings. Thus if your column definition contains non-alpha chars they must figure with either single/double quotes or escaped via \

NOTE! Be sure to watch k9s logs as any issues with the custom views specification are only surfaced in the logs.

Additionally, you can specify column attributes to further tailor the column rendering. To use this you will need to add a | indicator followed by your rendering bits. You can have one or more of the following attributes:

• T -> time column indicator
• N -> number column indicator
• W -> turns on wide column aka only shows while in wide mode. Defaults to the standard resource definition when present.
• S -> Ensures a column is visible and not wide. Overrides wide std resource definition if present.
• H -> Hides the column
• L -> Left align (default)
• R -> Right align

Here is a sample views configuration that customize a pods and services views.

# $XDG_CONFIG_HOME/k9s/views.yaml
views:
  v1/pods:
    columns:
      - AGE
      - NAMESPACE|WR                                     # => 🌚 Specifies the NAMESPACE column to be right aligned and only visible while in wide mode
      - ZORG:.metadata.labels.fred\.io\.kubernetes\.blee # => 🌚 extract fred.io.kubernetes.blee label into it's own column
      - BLEE:.metadata.annotations.blee|R                # => 🌚 extract annotation blee into it's own column and right align it
      - NAME
      - IP
      - NODE
      - STATUS
      - READY
      - MEM/RL|S                                         # => 🌚 Overrides std resource default wide attribute via `S` for `Show`
      - '%MEM/R|'                                        # => NOTE! column names with non alpha names need to be quoted as columns must be strings!

  v1/pods@fred:                                          # => 🌚 New v0.40.6! Customize columns for a given resource and namespace!
    columns:
      - AGE
      - NAME|WR

  v1/pods@kube*:                                         # => 🌚 New v0.40.6! You can also specify a namespace using a regular expression.
    columns:
      - NAME
      - AGE
      - LABELS

  cool-kid:                                              # => 🌚 New v0.40.8! You can also reference a specific alias and display a custom view for it
    columns:
      - AGE
      - NAMESPACE|WR

  v1/services:
    columns:
      - AGE
      - NAMESPACE
      - NAME
      - TYPE
      - CLUSTER-IP

🩻 NOTE: This is experimental and will most likely change as we iron this out!

---

Resource Jumps

K9s allows you to define custom jump shortcuts between Custom Resource Definitions (CRDs) and their related resources. This feature enables you to quickly jump from one CRD to its dependent or associated resources, similar to the built-in "jump to owner" behavior.

By default, K9s provides built-in jumps for standard Kubernetes resources (e.g., Deployment → Pods, Node → Pods). With custom jumps, you can extend this behavior to your own CRDs without modifying k9s source code.

To use this feature, create a configuration file at $XDG_CONFIG_HOME/k9s/jumps.yaml.

Configuration Format

# $XDG_CONFIG_HOME/k9s/jumps.yaml
jumps:
  # Define jump from source GVR to target GVR
  "myoperator.io/v1/patchplans":
    targetGVR: "myoperator.io/v1/patchjobs"
    fieldSelector: "spec.patchPlanRef={{.metadata.name}}"

Configuration Fields

• Source GVR (map key): The Group/Version/Resource of the source CRD in format group/version/resource or version/resource for core resources
• targetGVR: The target resource to jump to
• labelSelector (optional): Kubernetes label selector to filter target resources. Supports Go template syntax
• fieldSelector (optional): Kubernetes field selector to filter target resources. Supports Go template syntax
• targetNamespace (optional): Controls namespace behavior:
  • Empty (default): Use the source resource's namespace (or cluster-scoped if source is cluster-scoped)
  • all: View resources across all namespaces
  • <namespace-name>: Jump to a specific namespace
  • {{.spec.field}}: Use template expression to extract namespace from source resource

Template Syntax

Both labelSelector and fieldSelector support Go template syntax to dynamically reference fields from the selected (source) resource. Any field of the source object can be used on the value side of a selector:

• {{.metadata.name}} - The resource name
• {{.metadata.namespace}} - The resource namespace
• {{.metadata.labels.key}} - A specific label value
• {{.spec.fieldName}} - Any field from the source resource spec
• {{.status.field}} - Any field from the source resource status

Note: The template above only controls the selector value (the right-hand side, computed from the source resource). The selector key is still validated by the Kubernetes API server against the target resource. Label selector keys can be any label, but field selector keys are restricted: for most resources only metadata.name/metadata.namespace are selectable, and for CRDs the target field must be declared in the CRD's spec.versions[].selectableFields. k9s passes the field selector straight to the API server (no local filtering), so referencing a non-selectable field returns field label not supported. See the Kubernetes docs on CRD selectable fields.

Examples

Jump between custom operator resources

jumps:
  "myoperator.io/v1/patchplans":
    targetGVR: "myoperator.io/v1/patchjobs"
    fieldSelector: "spec.patchPlanRef={{.metadata.name}}"

Jump from ArgoCD Application to Deployments

jumps:
  "argoproj.io/v1alpha1/applications":
    targetGVR: "apps/v1/deployments"
    labelSelector: "app.kubernetes.io/instance={{.metadata.name}}"

Jump from Karpenter NodePool to Nodes

jumps:
  "karpenter.sh/v1/nodepools":
    targetGVR: "v1/nodes"
    labelSelector: "karpenter.sh/nodepool={{.metadata.name}}"
    targetNamespace: "all"  # Nodes are cluster-scoped

How It Works

1. When viewing a resource that has a custom jump rule defined

2. Pressing Enter on a selected item will:

   • Apply the template expressions using the selected resource's data
   • Jump to the target resource view with filters applied
   • Automatically apply the label/field selectors to show only related resources
   • Adjust the namespace context as configured

3. If no custom jump is defined, the default behavior applies (describe view or built-in jump)

---

Plugins

K9s allows you to extend your command line and tooling by defining your very own cluster commands via plugins. Minimally we look at $XDG_CONFIG_HOME/k9s/plugins.yaml to locate all available plugins. Additionally, K9s will scan the following directories for additional plugins:

• $XDG_CONFIG_HOME/k9s/plugins
• $XDG_DATA_HOME/k9s/plugins
• $XDG_DATA_DIRS/k9s/plugins

The plugin file content can be either a single plugin snippet, a collections of snippets or a complete plugins definition (see examples below...).

A plugin is defined as follows:

• Shortcut option represents the key combination a user would type to activate the plugin. Valid values are [a-z], Shift-[A-Z], Ctrl-[A-Z].
• Override option make that the default action related to the shortcut will be overridden by the plugin
• Confirm option (when enabled) lets you see the command that is going to be executed and gives you an option to confirm or prevent execution
• Description will be printed next to the shortcut in the k9s menu
• Scopes defines a collection of resources names/short-names for the views associated with the plugin. You can specify all to provide this shortcut for all views.
• Command represents ad-hoc commands the plugin runs upon activation
• Background specifies whether or not the command runs in the background
• Args specifies the various arguments that should apply to the command above
• OverwriteOutput boolean option allows plugin developers to provide custom messages on plugin stdout execution. See example in #2644
• Dangerous boolean option enables disabling the plugin when read-only mode is set. See #2604
• Inputs defines a list of input fields to prompt the user for before executing the plugin (see below)

Plugin Inputs

Plugins can define input fields that prompt users for values before execution. This is useful when you need dynamic values like replica counts, environment variables, or profile selections. A maximum of 5 inputs per plugin is allowed.

Each input has the following properties:

• name (required) -- the input identifier used to reference the value in args as $INPUT_<NAME> (uppercase)
• label -- the label shown to the user in the input dialog
• type (required) -- the input type: string, number, bool, or dropdown
• required -- when true, the user must provide a value before the plugin can execute
• default -- a default value pre-filled in the input field (must be a valid option for dropdown, "true"/"false" for bool, or a valid number for number)
• options -- for dropdown type only, defines the list of available choices

Input values are available in plugin args using the format $INPUT_<NAME> where <NAME> is the uppercase version of the input name.

Input Types:

Example:

plugins:
  demo-inputs:
    shortCut: Ctrl-Y
    description: Demo all input types
    scopes:
      - po
    command: bash
    background: false
    args:
      - -c
      - >-
        echo "=== Plugin input demo ===" &&
        echo "" &&
        echo "Pod: $NAME" &&
        echo "Namespace: $NAMESPACE" &&
        echo "Context: $CONTEXT" &&
        echo "" &&
        echo "=== Your inputs ===" &&
        if [ -n "$INPUT_MESSAGE" ]; then echo "Message: $INPUT_MESSAGE (set)"; else echo "Message: (not set)"; fi &&
        if [ -n "$INPUT_COUNT" ]; then echo "Count: $INPUT_COUNT (set)"; else echo "Count: (not set)"; fi &&
        if [ -n "$INPUT_ENABLED" ]; then echo "Enabled: $INPUT_ENABLED (set)"; else echo "Enabled: (not set)"; fi &&
        if [ -n "$INPUT_ENVIRONMENT" ]; then echo "Environment: $INPUT_ENVIRONMENT (set)"; else echo "Environment: (not set)"; fi &&
        echo "" &&
        read -p "Press Enter to return to k9s..."
    inputs:
      - name: message
        label: Enter a message
        type: string
        required: true
        default: hello world
      - name: count
        label: Enter a number
        type: number
        required: true
        default: 3
      - name: enabled
        label: Enable feature
        type: bool
        required: false
        default: true
      - name: environment
        label: Select environment
        type: dropdown
        required: true
        default: staging
        options:
          - development
          - staging
          - production

For a real-world example of plugin inputs, see pvc-resize.yaml which prompts the user for a new PVC size before resizing.

K9s does provide additional environment variables for you to customize your plugins arguments. Currently, the available environment variables are as follows:

• $RESOURCE_GROUP -- the selected resource group
• $RESOURCE_VERSION -- the selected resource api version
• $RESOURCE_NAME -- the selected resource name
• $NAMESPACE -- the selected resource namespace
• $NAME -- the selected resource name
• $CONTAINER -- the current container if applicable
• $FILTER -- the current filter if any
• $KUBECONFIG -- the KubeConfig location.
• $CLUSTER the active cluster name
• $CONTEXT the active context name
• $USER the active user
• $GROUPS the active groups
• $POD while in a container view
• $COL-<RESOURCE_COLUMN_NAME> use a given column name for a viewed resource. Must be prefixed by COL-!

Curly braces can be used to embed an environment variable inside another string, or if the column name contains special characters. (e.g. ${NAME}-example or ${COL-%CPU/L})

Plugin Examples

Define several plugins and host them in a single file. These can leave in the K9s root config so that they are available on any clusters. Additionally, you can define cluster/context specific plugins for your clusters of choice by adding clusterA/contextB/plugins.yaml file.

The following defines a plugin for viewing logs on a selected pod using ctrl-l as shortcut.

# Define several plugins in a single file in the K9s root configuration
# $XDG_DATA_HOME/k9s/plugins.yaml
plugins:
  # Defines a plugin to provide a `ctrl-l` shortcut to tail the logs while in pod view.
  fred:
    shortCut: Ctrl-L
    override: false
    overwriteOutput: false
    confirm: false
    dangerous: false
    description: Pod logs
    scopes:
    - pods
    command: kubectl
    background: false
    args:
    - logs
    - -f
    - $NAME
    - -n
    - $NAMESPACE
    - --context
    - $CONTEXT

Similarly you can define the plugin above in a directory using either a file per plugin or several plugins per files as follow...

The following defines two plugins namely fred and zorg.

# Multiple plugins in a single file...
# Note: as of v0.40.9 you can have ad-hoc plugin dirs
# Loads plugins fred and zorg
# $XDG_DATA_HOME/k9s/plugins/misc-plugins/blee.yaml
fred:
  shortCut: Shift-B
  description: Bozo
  scopes:
  - deploy
  command: bozo

zorg:
  shortCut: Shift-Z
  description: Pod logs
  scopes:
  - svc
  command: zorg

Lastly you can define plugin snippets in their own file. The snippet will be named from the file name. In this case, we define a bozo plugin using a plugin snippet.

# $XDG_DATA_HOME/k9s/plugins/schtuff/bozo.yaml
shortCut: Shift-B
description: Bozo
scopes:
- deploy
command: bozo

NOTE: This is an experimental feature! Options and layout may change in future K9s releases as this feature solidifies.

---

Benchmark Your Applications

K9s integrates Hey from the brilliant and super talented Jaana Dogan. Hey is a CLI tool to benchmark HTTP endpoints similar to AB bench. This preliminary feature currently supports benchmarking port-forwards and services (Read the paint on this is way fresh!).

To setup a port-forward, you will need to navigate to the PodView, select a pod and a container that exposes a given port. Using SHIFT-F a dialog comes up to allow you to specify a local port to forward. Once acknowledged, you can navigate to the PortForward view (alias pf) listing out your active port-forwards. Selecting a port-forward and using CTRL-B will run a benchmark on that HTTP endpoint. To view the results of your benchmark runs, go to the Benchmarks view (alias be). You should now be able to select a benchmark and view the run stats details by pressing <ENTER>. NOTE: Port-forwards only last for the duration of the K9s session and will be terminated upon exit.

Initially, the benchmarks will run with the following defaults:

• Concurrency Level: 1
• Number of Requests: 200
• HTTP Verb: GET
• Path: /

The PortForward view is backed by a new K9s config file namely: $XDG_DATA_HOME/k9s/clusters/clusterX/contextY/benchmarks.yaml. Each cluster you connect to will have its own bench config file, containing the name of the K8s context for the cluster. Changes to this file should automatically update the PortForward view to indicate how you want to run your benchmarks.

Benchmarks result reports are stored in $XDG_STATE_HOME/k9s/clusters/clusterX/contextY

Here is a sample benchmarks.yaml configuration. Please keep in mind this file will likely change in subsequent releases!

# This file resides in  $XDG_DATA_HOME/k9s/clusters/clusterX/contextY/benchmarks.yaml
benchmarks:
  # Indicates the default concurrency and number of requests setting if a container or service rule does not match.
  defaults:
    # One concurrent connection
    concurrency: 1
    # Number of requests that will be sent to an endpoint
    requests: 500
  containers:
    # Containers section allows you to configure your http container's endpoints and benchmarking settings.
    # NOTE: the container ID syntax uses namespace/pod-name:container-name
    default/nginx:nginx:
      # Benchmark a container named nginx using POST HTTP verb using http://localhost:port/bozo URL and headers.
      concurrency: 1
      requests: 10000
      http:
        path: /bozo
        method: POST
        body:
          {"fred":"blee"}
        header:
          Accept:
            - text/html
          Content-Type:
            - application/json
  services:
    # Similarly you can Benchmark an HTTP service exposed either via NodePort, LoadBalancer types.
    # Service ID is ns/svc-name
    default/nginx:
      # Set the concurrency level
      concurrency: 5
      # Number of requests to be sent
      requests: 500
      http:
        method: GET
        # This setting will depend on whether service is NodePort or LoadBalancer. NodePort may require vendor port tunneling setting.
        # Set this to a node if NodePort or LB if applicable. IP or dns name.
        host: A.B.C.D
        path: /bumblebeetuna
      auth:
        user: jean-baptiste-emmanuel
        password: Zorg!

---

K9s RBAC FU

On RBAC enabled clusters, you would need to give your users/groups capabilities so that they can use K9s to explore their Kubernetes cluster. K9s needs minimally read privileges at both the cluster and namespace level to display resources and metrics.

These rules below are just suggestions. You will need to customize them based on your environment policies. If you need to edit/delete resources extra Fu will be necessary.

NOTE! Cluster/Namespace access may change in the future as K9s evolves. NOTE! We expect K9s to keep running even in atrophied clusters/namespaces. Please file issues if this is not the case!

Cluster RBAC scope

---
# K9s Reader ClusterRole
kind: ClusterRole
apiVersion: rbac.authorization.k8s.io/v1
metadata:
  name: k9s
rules:
  # Grants RO access to cluster resources node and namespace
  - apiGroups: [""]
    resources: ["nodes", "namespaces"]
    verbs: ["get", "list", "watch"]
  # Grants RO access to RBAC resources
  - apiGroups: ["rbac.authorization.k8s.io"]
    resources: ["clusterroles", "roles", "clusterrolebindings", "rolebindings"]
    verbs: ["get", "list", "watch"]
  # Grants RO access to CRD resources
  - apiGroups: ["apiextensions.k8s.io"]
    resources: ["customresourcedefinitions"]
    verbs: ["get", "list", "watch"]
  # Grants RO access to metric server (if present)
  - apiGroups: ["metrics.k8s.io"]
    resources: ["nodes", "pods"]
    verbs: ["get", "list", "watch"]

---
# Sample K9s user ClusterRoleBinding
apiVersion: rbac.authorization.k8s.io/v1
kind: ClusterRoleBinding
metadata:
  name: k9s
subjects:
  - kind: User
    name: fernand
    apiGroup: rbac.authorization.k8s.io
roleRef:
  kind: ClusterRole
  name: k9s
  apiGroup: rbac.authorization.k8s.io

Namespace RBAC scope

If your users are constrained to certain namespaces, K9s will need to following role to enable read access to namespaced resources.

---
# K9s Reader Role (default namespace)
kind: Role
apiVersion: rbac.authorization.k8s.io/v1
metadata:
  name: k9s
  namespace: default
rules:
  # Grants RO access to most namespaced resources
  - apiGroups: ["", "apps", "autoscaling", "batch", "extensions"]
    resources: ["*"]
    verbs: ["get", "list", "watch"]
  # Grants RO access to metric server
  - apiGroups: ["metrics.k8s.io"]
    resources: ["pods", "nodes"]
    verbs:
      - get
      - list
      - watch

---
# Sample K9s user RoleBinding
apiVersion: rbac.authorization.k8s.io/v1
kind: RoleBinding
metadata:
  name: k9s
  namespace: default
subjects:
  - kind: User
    name: fernand
    apiGroup: rbac.authorization.k8s.io
roleRef:
  kind: Role
  name: k9s
  apiGroup: rbac.authorization.k8s.io

---

Skins

Example: Dracula Skin ;)

You can style K9s based on your own sense of look and style. Skins are YAML files, that enable a user to change the K9s presentation layer. See this repo skins directory for examples. You can skin k9s by default by specifying a UI.skin attribute. You can also change K9s skins based on the context you are connecting too. In this case, you can specify a skin field on your cluster config aka skin: dracula (just the name of the skin file without the extension!) and copy this repo skins/dracula.yaml to $XDG_CONFIG_HOME/k9s/skins/ directory. You can also change the skin by setting K9S_SKIN in the environment, e.g. export K9S_SKIN="dracula".

In the case where your cluster spans several contexts, you can add a skin context configuration to your context configuration. This is a collection of {context_name, skin} tuples (please see example below!)

Colors can be defined by name or using a hex representation. Of recent, we've added a color named default to indicate a transparent background color to preserve your terminal background color settings if so desired.

NOTE: This is very much an experimental feature at this time, more will be added/modified if this feature has legs so thread accordingly! NOTE: Please see K9s Skins for a list of available colors.

To skin a specific context and provided the file in-the-navy.yaml is present in your skins directory.

#  $XDG_DATA_HOME/k9s/clusters/clusterX/contextY/config.yaml
k9s:
  cluster: clusterX
  skin: in-the-navy
  readOnly: false
  namespace:
    active: default
    lockFavorites: false
    favorites:
    - kube-system
    - default
  view:
    active: po
  featureGates:
    nodeShell: false
  portForwardAddress: localhost

You can also specify a default skin for all contexts in the root k9s config file as so:

#  $XDG_CONFIG_HOME/k9s/config.yaml
k9s:
  liveViewAutoRefresh: false
  screenDumpDir: /tmp/dumps
  refreshRate: 2
  maxConnRetry: 5
  readOnly: false
  noExitOnCtrlC: false
  ui:
    enableMouse: false
    headless: false
    logoless: false
    crumbsless: false
    splashless: false
    noIcons: false
    invert: false
    # Toggles reactive UI. This option provide for watching on disk artifacts changes and update the UI live  Defaults to false.
    reactive: false
    # By default all contexts will use the dracula skin unless explicitly overridden in the context config file.
    skin: dracula # => assumes the file skins/dracula.yaml is present in the  $XDG_DATA_HOME/k9s/skins directory
    defaultsToFullScreen: false
  skipLatestRevCheck: false
  disablePodCounting: false
  shellPod:
    image: busybox
    namespace: default
    limits:
      cpu: 100m
      memory: 100Mi
  imageScans:
    enable: false
    exclusions:
      namespaces: []
      labels: {}
  logger:
    tail: 100
    buffer: 5000
    sinceSeconds: -1
    textWrap: false
    disableAutoscroll: false
    columnLock: false
    showTime: false
    logBufferSize: 50
  thresholds:
    cpu:
      critical: 90
      warn: 70
    memory:
      critical: 90
      warn: 70

# $XDG_DATA_HOME/k9s/skins/in-the-navy.yaml
# Skin InTheNavy!
k9s:
  # General K9s styles
  body:
    fgColor: dodgerblue
    bgColor: '#ffffff'
    logoColor: '#0000ff'
  # ClusterInfoView styles.
  info:
    fgColor: lightskyblue
    sectionColor: steelblue
  # Help panel styles
  help:
    fgColor: white
    bgColor: black
    keyColor: cyan
    numKeyColor: blue
    sectionColor: gray
  frame:
    # Borders styles.
    border:
      fgColor: dodgerblue
      focusColor: aliceblue
    # MenuView attributes and styles.
    menu:
      fgColor: darkblue
      # Style of menu text. Supported options are "dim" (default), "normal", and "bold"
      fgStyle: dim
      keyColor: cornflowerblue
      # Used for favorite namespaces
      numKeyColor: cadetblue
    # CrumbView attributes for history navigation.
    crumbs:
      fgColor: white
      bgColor: steelblue
      activeColor: skyblue
    # Resource status and update styles
    status:
      newColor: '#00ff00'
      modifyColor: powderblue
      addColor: lightskyblue
      errorColor: indianred
      highlightcolor: royalblue
      killColor: slategray
      completedColor: gray
    # Border title styles.
    title:
      fgColor: aqua
      bgColor: white
      highlightColor: skyblue
      counterColor: slateblue
      filterColor: slategray
  views:
    # TableView attributes.
    table:
      fgColor: blue
      bgColor: darkblue
      cursorColor: aqua
      # Header row styles.
      header:
        fgColor: white
        bgColor: darkblue
        sorterColor: orange
        selectedSortColumnColor: lightskyblue
    # YAML info styles.
    yaml:
      keyColor: steelblue
      colonColor: blue
      valueColor: royalblue
    # Logs styles.
    logs:
      fgColor: lightskyblue
      bgColor: black
      indicator:
        fgColor: dodgerblue
        bgColor: black
        toggleOnColor: limegreen
        toggleOffColor: gray

---

Contributors

Without the contributions from these fine folks, this project would be a total dud!

---

Known Issues

This is still work in progress! If something is broken or there's a feature that you want, please file an issue and if so inclined submit a PR!

K9s will most likely blow up if...

1. You're running older versions of Kubernetes. K9s works best on later Kubernetes versions.
2. You don't have enough RBAC fu to manage your cluster.

---

ATTA Girls/Boys!

K9s sits on top of many open source projects and libraries. Our sincere appreciations to all the OSS contributors that work nights and weekends to make this project a reality!

---

Meet The Core Team!

If you have chops in GO and K8s and would like to offer your time to help maintain and enhance this project, please reach out to me.

• Fernand Galiana
  • [email protected]
  • @kitesurfer

We always enjoy hearing from folks who benefit from our work!

Contributions Guideline

• File an issue first prior to submitting a PR!
• Ensure all exported items are properly commented
• If applicable, submit a test suite against your PR

---

 © 2026 Imhotep Software LLC. All materials licensed under Apache v2.0
