drduh/YubiKey-Guide

This guide demonstrates how to store credentials on a YubiKey. The private keys cannot be copied back out of the device; a separate offline "Certify" key is retained only to replace or renew them.

• Purchase YubiKey
• Prepare environment
• Install software
• Prepare GnuPG
  • Configuration
  • Identity
  • Key
  • Expiration
  • Passphrase
• Create Certify key
• Create Subkeys
• Verify keys
• Backup keys
• Export public key
• Configure YubiKey
  • Change PIN
  • Set attributes
• Transfer Subkeys
  • Signature key
  • Encryption key
  • Authentication key
• Verify transfer
• Finish setup
• Using YubiKey
  • Encryption
  • Signature
  • Configure touch
  • SSH
    • Replace agents
    • Copy public key
    • Import SSH keys
    • SSH agent forwarding
      • Use ssh-agent
      • Use S.gpg-agent.ssh
      • Chained forwarding
  • GitHub
  • GnuPG agent forwarding
    • Legacy distributions
    • Chained GnuPG agent forwarding
  • Using multiple YubiKeys
  • Email
    • Thunderbird
    • Mailvelope
    • Mutt
  • Keyserver
• Updating keys
  • Renew Subkeys
  • Rotate Subkeys
• Reset YubiKey
• Optional hardening
  • Improving entropy
  • Enable KDF
  • Network considerations
• Notes
• Troubleshooting
• Alternative solutions
• Additional resources

Purchase YubiKey

Choose a YubiKey with the OpenPGP application - Security Key and Bio models are not compatible.

Verify YubiKey by visiting yubico.com/genuine. Select Verify Device to begin the process. Touch the YubiKey when prompted and allow the site to see the make and model of the device when prompted. This device attestation may help mitigate supply chain attacks.

Have at least two USB drives or microSD cards for storing encrypted offline backups in different physical locations.

Prepare environment

A dedicated and hardened operating environment should be used to generate materials.

The following is a ranked list of least to most defensible environments to consider:

1. Public, shared or other computer owned by someone else
2. Daily-use personal operating system with unrestricted network access
3. Virtualized system with limited capabilities (using virt-manager, VirtualBox or VMware, for example)
4. Dedicated and hardened Debian or OpenBSD installation
5. Ephemeral Debian Live or Tails booted without primary storage attached
6. Hardened hardware and firmware (e.g., Coreboot, Intel ME removed)
7. Air-gapped system without network capabilities, preferably ARM-based Raspberry Pi or other architecturally diverse equivalent

For most people, booting Debian Live from USB on a personal computer is a practical baseline.

Download the latest Debian Live image and signature files. These commands download the checksum file, its signature, and the current 64-bit XFCE Live ISO:

export imageUrl="https://cdimage.debian.org/debian-cd/current-live/amd64/iso-hybrid/"
curl -sfL -O "$imageUrl/SHA512SUMS" -O "$imageUrl/SHA512SUMS.sign"
curl -sfLO "$imageUrl/$(awk '/xfce\.iso$/ {print $NF}' SHA512SUMS)"

Download the Debian signing public key:

gpg --keyserver hkps://keyring.debian.org \
    --recv DF9B9C49EAA9298432589D76DA87E80D6294BE9B

If the public key cannot be received, use a different keyserver or DNS server:

gpg --keyserver hkps://keyserver.ubuntu.com:443 \
    --recv DF9B9C49EAA9298432589D76DA87E80D6294BE9B

The Debian Live signing public key is also available for import in pubkeys:

gpg --import pubkeys/debian-DA87E80D6294BE9B.asc

Verify the signature:

gpg --verify SHA512SUMS.sign SHA512SUMS

Confirm the fingerprint matches Debian's published fingerprint:

gpg: Good signature from "Debian CD signing key <[email protected]>"

Verify the image hash matches the signed sums file:

grep $(sha512sum debian-live-*-amd64-xfce.iso) SHA512SUMS

See Verifying authenticity of Debian CDs for more information.

Connect a portable storage device and identify the device path - this guide uses /dev/sdc throughout, but this value may differ on your system.

[!WARNING] The following dd commands overwrite every partition and file on the selected device. Check the device path before continuing.

Linux

$ sudo dmesg | tail
usb-storage 3-2:1.0: USB Mass Storage device detected
sd 2:0:0:0: [sdc] Attached SCSI removable disk

Copy the Debian image to the device:

sudo dd if=debian-live-*-amd64-xfce.iso of=/dev/sdc bs=4M status=progress ; sync

OpenBSD

$ dmesg | tail -n2
sd2 at scsibus4 targ 1 lun 0: <TS-RDF5, SD Transcend, TS3A> SCSI4 0/direct removable serial.0000000000000
sd2: 15193MB, 512 bytes/sector, 31116288 sectors

$ doas dd if=debian-live-*-amd64-xfce.iso of=/dev/rsd2c bs=4m
465+1 records in
465+1 records out
1951432704 bytes transferred in 139.125 secs (14026448 bytes/sec)

Power off. Disconnect internal hard drives and all unnecessary devices, such as the wireless card.

Install software

Load the operating system and configure networking. Optional hardening steps related to networking can be found below.

[!TIP] If the screen locks on Debian Live, unlock with user / live

Open a terminal and install the required software.

Debian/Ubuntu

sudo apt update
sudo apt -y upgrade
sudo apt -y install \
  wget gnupg2 gnupg-agent dirmngr \
  cryptsetup scdaemon pcscd \
  yubikey-personalization yubikey-manager

OpenBSD

doas pkg_add gnupg pcsc-tools

macOS

Download and install Homebrew and the following packages:

brew install gnupg yubikey-personalization ykman pinentry-mac wget

Or using MacPorts, install the following packages:

sudo port install gnupg2 yubikey-manager pinentry wget

NixOS

Build the image, then copy it to removable media and boot offline. The booted environment can be air-gapped.

ref=$(git ls-remote https://github.com/drduh/Yubikey-Guide refs/heads/main | awk '{print $1}')
nix build --experimental-features "nix-command flakes" \
  github:drduh/YubiKey-Guide/$ref?dir=nix#nixosConfigurations.yubikeyLive.x86_64-linux.config.system.build.isoImage

If you have this repository checked out:

Recommended, but optional: update nixpkgs and drduh/config:

nix flake update --commit-lock-file

Build the image:

nix build --experimental-features "nix-command flakes" nix#nixosConfigurations.yubikeyLive.x86_64-linux.config.system.build.isoImage

Copy to USB drive:

sudo cp -v result/iso/yubikeyLive.iso /dev/sdc ; sync

Skip steps to create a temporary working directory and a hardened configuration, as they are already part of the image.

Test builds using virtualization tools like QEMU. Keep in mind a virtualized environment does not provide the same amount of security as an ephemeral system (see Prepare environment above).

Here is an example QEMU invocation after placing yubikeyLive in result/iso using the above nix build command, with 4G memory, 2 CPUs and KVM enabled:

qemu-system-x86_64 -enable-kvm -m 4G -smp 2 \
  -drive readonly=on,media=cdrom,format=raw,file=result/iso/yubikeyLive.iso

Arch

sudo pacman -Syu --needed gnupg pcsclite ccid yubikey-personalization

RHEL7

sudo yum install -y gnupg2 pinentry-curses pcsc-lite pcsc-lite-libs gnupg2-smime

Fedora

sudo dnf install --skip-unavailable \
  wget gnupg2 \
  cryptsetup gnupg2-scdaemon pcsc-lite \
  yubikey-personalization-gui yubikey-manager

Prepare GnuPG

Create a temporary directory for GnuPG configuration:

export GNUPGHOME=$(mktemp -d "${TMPDIR:-/tmp}/$(date +%Y.%m.%d)-XXXXXXXX")
printf "\nTemporary directory:\t%s\n\n" "$GNUPGHOME"

[!NOTE] This temporary directory is only cleared on reboot only when /tmp is memory-backed. Verify the environment uses tmpfs, or securely remove the directory after use.

Configuration

Download the recommended GnuPG configuration into the temporary GnuPG directory.

wget https://raw.githubusercontent.com/drduh/YubiKey-Guide/main/config/gpg.conf -P $GNUPGHOME

Review it before use; modern algorithms and privacy-related defaults are selected:

$ grep -v "^#" $GNUPGHOME/gpg.conf
personal-cipher-preferences AES256 AES192 AES
personal-digest-preferences SHA512 SHA384 SHA256
personal-compress-preferences ZLIB BZIP2 ZIP Uncompressed
default-preference-list SHA512 SHA384 SHA256 AES256 AES192 AES ZLIB BZIP2 ZIP Uncompressed
cert-digest-algo SHA512
s2k-digest-algo SHA512
s2k-cipher-algo AES256
charset utf-8
no-comments
no-emit-version
no-greeting
keyid-format 0xlong
list-options show-uid-validity
verify-options show-uid-validity
with-fingerprint
require-cross-certification
require-secmem
no-symkey-cache
armor
use-agent
throw-keyids

[!IMPORTANT] Networking should be disabled for the remainder of the setup.

Identity

Generate a random attribute for the Identity label:

export IDENTITY="yk.$(LC_ALL=C tr -dc 'a-z0-9' < /dev/urandom | head -c 16)"
printf "\nIdentity:\t\t%s\n\n" "$IDENTITY"

If you intend to use email encryption or Git verification, set the Identity label to a real name or email:

export IDENTITY="YubiKey User <[email protected]>"

[!TIP] Use single quotes to wrap double quote characters ("):

export IDENTITY='My Identity (a.k.a. "YubiKey User") <[email protected]>'

Key

Set the algorithm and key size - RSA 4096 is recommended:

export KEY_TYPE=rsa4096

Expiration

Determine the desired Subkey validity duration. An expiration date means Subkeys must be periodically renewed or replaced. This limits how long a lost or obsolete key remains usable. However, setting an expiry on the Certify key is pointless, because it can be used to extend itself.¹

A two-year expiration for Subkeys is recommended, balancing security and usability. Longer expiration durations reduce maintenance frequency.

When Subkeys expire, they can still be used to decrypt with GnuPG and authenticate with SSH, however they can not be used to encrypt nor sign new messages.

Subkeys are renewed or rotated using the Certify key - see Updating keys.

Set Subkeys to expire on a planned date:

export KEY_EXPIRATION=2028-08-01

The expiration date may also be relative, for example set to two years from today:

export KEY_EXPIRATION=2y

Passphrase

Generate a passphrase for the Certify key, which will be used to manage the identity and Subkeys.

A passphrase consisting only of uppercase letters and numbers is recommended: the limited character set makes handwritten storage easier to write and read.

The following commands will generate and print a strong passphrase²:

export CERTIFY_PASS=$(LC_ALL=C tr -dc "A-Z3-9" < /dev/urandom |
  tr -d "IOUS5" |
  head -c ${PASS_LENGTH:-24} |
  fold -w ${PASS_GROUPSIZE:-4} |
  paste -sd ${PASS_DELIMITER:--} -)
printf "\nCertify passphrase:\t%s\n\n" "$CERTIFY_PASS"

To change the passphrase length, delimiting character or group sizes, export the respective variable(s) prior to running the passphrase generation command, for example:

export PASS_GROUPSIZE=6
export PASS_DELIMITER=+
export PASS_LENGTH=48

Write the passphrase in a secure location - separate from the portable storage device used for key material, or memorize it.

This repository includes a passphrase.html template to help with credential transcription. Save the raw file, open in a browser to render and print.

Mark the corresponding character on sequential rows for each passphrase character. passphrase.txt can also be printed without a browser:

lp -d Printer-Name passphrase.txt

Diceware is another popular method for creating memorable passphrases.

Create Certify key

The primary key to generate is the Certify key, which is used to issue Subkeys for signing (sign commits/messages), encryption (decrypt data), and authentication (SSH login).

The Certify key should be kept offline and only accessed from a dedicated and secure environment to issue or revoke Subkeys.

Do not set an expiration date on the Certify key.

Generate the Certify key:

printf '%s' "$CERTIFY_PASS" |
  gpg --batch --passphrase-fd 0 \
      --quick-generate-key "$IDENTITY" "$KEY_TYPE" cert never

Set and view the Certify key identifier and fingerprint for use later:

export KEY_FP=$(gpg -k --with-colons $IDENTITY | awk -F: '/^fpr:/ { print $10; exit }')
export KEY_ID="${KEY_FP: -16}"
printf "\nKey ID/Fingerprint:\t%s\n%s\n\n" "$KEY_ID" "$KEY_FP"

declare -a additional_uids
additional_uids=("Super Cool YubiKey 2026" "uid 1 <[email protected]>")

for uid in "${additional_uids[@]}" ; do \
  printf '%s' "$CERTIFY_PASS" |
  gpg --batch --passphrase-fd 0 \
      --pinentry-mode loopback --quick-add-uid "$KEY_FP" "$uid"
done

gpg --command-fd 0 --pinentry-mode loopback --edit-key "$KEY_ID" <<EOF
uid *
trust
5
y
save
EOF

Create Subkeys

Generate Signature and Encryption Subkeys:

printf '%s' "$CERTIFY_PASS" |
  gpg --batch --pinentry-mode loopback --passphrase-fd 0 \
      --quick-add-key "$KEY_FP" "$KEY_TYPE" sign "$KEY_EXPIRATION"
printf '%s' "$CERTIFY_PASS" |
  gpg --batch --pinentry-mode loopback --passphrase-fd 0 \
      --quick-add-key "$KEY_FP" "$KEY_TYPE" encrypt "$KEY_EXPIRATION"

Then generate the Authentication Subkey:

[!NOTE] Some systems do not accept RSA for SSH authentication. To use Ed25519 instead, run export KEY_TYPE=ed25519 before generating the Authentication Subkey with the following command.

printf '%s' "$CERTIFY_PASS" |
  gpg --batch --pinentry-mode loopback --passphrase-fd 0 \
      --quick-add-key "$KEY_FP" "$KEY_TYPE" auth "$KEY_EXPIRATION"

Verify keys

List available secret keys:

gpg -K

The output should display [C]ertify, [S]ignature, [E]ncryption and [A]uthentication keys:

sec   rsa4096/0xF0F2CFEB04341FB5 2026-08-01 [C]
      Key fingerprint = 4E2C 1FA3 372C BA96 A06A  C34A F0F2 CFEB 0434 1FB5
uid                   [ultimate] yk.pn8wgfx67khlhext
ssb   rsa4096/0xB3CD10E502E19637 2026-08-01 [S] [expires: 2028-08-01]
ssb   rsa4096/0x30CBE8C4B085B9F7 2026-08-01 [E] [expires: 2028-08-01]
ssb   rsa4096/0xAD9E24E1B8CB9600 2026-08-01 [A] [expires: 2028-08-01]

Backup keys

Export the public key:

gpg --output $GNUPGHOME/public-$KEY_ID-$(date +%F).asc \
    --armor --export $KEY_ID

Export the Certify key:

printf '%s' "$CERTIFY_PASS" |
  gpg --batch --pinentry-mode loopback --passphrase-fd 0 \
      --output $GNUPGHOME/secret-$KEY_ID-Certify.key \
      --armor --export-secret-keys $KEY_ID

Export the Subkeys:

printf '%s' "$CERTIFY_PASS" |
  gpg --batch --pinentry-mode loopback --passphrase-fd 0 \
      --output $GNUPGHOME/secret-$KEY_ID-Subkeys.key \
      --armor --export-secret-subkeys $KEY_ID

[!IMPORTANT] The exported .key files contain private key material. Anyone with access to them and the Certify passphrase has full control of the identity.

Create a backup on encrypted storage to be kept offline in a secure and durable location.

The following process is recommended to be repeated several times on multiple portable storage devices, as they may fail over time. As an additional backup measure, Paperkey can create a physical copy of key materials for improved durability.

[!TIP] ext2 file systems (without encryption) can be mounted on Linux and OpenBSD. Use FAT32 or NTFS file systems for macOS and Windows compatibility instead.

[!WARNING] Confirm the destination (of) before issuing dd commands as they are destructive! This guide uses /dev/sdc - this value may be different on your system.

Linux

Attach a portable storage device and confirm its label - in this example /dev/sdc:

$ sudo dmesg | tail
usb-storage 3-2:1.0: USB Mass Storage device detected
sd 2:0:0:0: [sdc] Attached SCSI removable disk

$ sudo fdisk -l /dev/sdc
Disk /dev/sdc: 14.9 GiB, 15931539456 bytes, 31116288 sectors

Zero the header to prepare for encryption:

sudo dd if=/dev/zero of=/dev/sdc bs=4M count=1

Remove and reconnect the storage device so the operating system reads the cleared partition table before the next command.

Erase and create a new partition table:

sudo fdisk /dev/sdc <<EOF
g
w
EOF

Create a small partition (at least 20 MB, to account for the LUKS header) for storing secret materials:

sudo fdisk /dev/sdc <<EOF
n


+20M
w
EOF

Use LUKS to encrypt the new partition.

Generate another unique Passphrase (different from the Certify key passphrase) to protect the encrypted volume:

export LUKS_PASS=$(LC_ALL=C tr -dc "A-Z3-9" < /dev/urandom |
  tr -d "IOUS5" |
  head -c ${PASS_LENGTH:-24} |
  fold -w ${PASS_GROUPSIZE:-4} |
  paste -sd ${PASS_DELIMITER:--} -)
printf "\nLUKS passphrase:\t%s\n\n" "$LUKS_PASS"

This passphrase unlocks the encrypted backup volume, which contains the Certify key. It is needed to renew, rotate, or recover Subkeys. Write the passphrase down or memorize it.

Format the partition:

printf '%s' "$LUKS_PASS" | sudo cryptsetup -q luksFormat /dev/sdc1

Mount the partition:

printf '%s' "$LUKS_PASS" | sudo cryptsetup -q luksOpen /dev/sdc1 gnupg-secrets

Create an ext2 filesystem:

sudo mkfs.ext2 /dev/mapper/gnupg-secrets -L gnupg-$(date +%F)

Mount the filesystem and copy the temporary GnuPG working directory with key materials:

sudo mkdir -p /mnt/encrypted-storage
sudo mount /dev/mapper/gnupg-secrets /mnt/encrypted-storage
sudo cp -av $GNUPGHOME /mnt/encrypted-storage/

Unmount and close the encrypted volume:

sudo umount /mnt/encrypted-storage
sudo cryptsetup luksClose gnupg-secrets

Repeat the process for any additional storage devices (at least two are recommended).

OpenBSD

Attach a USB disk and determine its label:

$ dmesg | grep sd.\ at
sd2 at scsibus5 targ 1 lun 0: <TS-RDF5, SD Transcend, TS37> SCSI4 0/direct removable serial.00000000000000000000

Print the existing partitions to make sure it's the right device:

doas disklabel -h sd2

Initialize the disk by creating an a partition with FS type RAID and size of 25 Megabytes:

$ doas fdisk -giy sd2
Writing MBR at offset 0.
Writing GPT.

$ doas disklabel -E sd2
Label editor (enter '?' for help at any prompt)
sd2> a a
offset: [64]
size: [31101776] 25M
FS type: [4.2BSD] RAID
sd2*> w
sd2> q
No label changes

Encrypt with bioctl using a unique Passphrase:

$ doas bioctl -c C -l sd2a softraid0
New passphrase:
Re-type passphrase:
softraid0: CRYPTO volume attached as sd3

Create an i partition on the new crypto volume and the filesystem:

$ doas fdisk -giy sd3
Writing MBR at offset 0.
Writing GPT.

$ doas disklabel -E sd3
Label editor (enter '?' for help at any prompt)
sd3> a i
offset: [64]
size: [16001]
FS type: [4.2BSD]
sd3*> w
sd3> q
No label changes.

$ doas newfs sd3i

Mount the filesystem and copy the temporary directory with the keyring:

doas mkdir -p /mnt/encrypted-storage
doas mount /dev/sd3i /mnt/encrypted-storage
doas cp -av $GNUPGHOME /mnt/encrypted-storage

Unmount and remove the encrypted volume:

doas umount /mnt/encrypted-storage
doas bioctl -d sd3

See OpenBSD FAQ#14 for more information.

Export public key

[!IMPORTANT] The YubiKey holds private keys, but each computer also needs the public key and metadata to identify Subkeys and use them with GnuPG. Without the public key, it will not be possible to use GnuPG to decrypt and sign. However, YubiKey can still be used for SSH authentication.

Connect another portable storage device or create a new partition on the existing one.

Linux

Using the same /dev/sdc device as in the previous step, create a small (at least 20 Mb is recommended) partition for storing materials:

sudo fdisk /dev/sdc <<EOF
n


+20M
w
EOF

Create a filesystem and export the public key:

sudo mkfs.ext2 /dev/sdc2
sudo mkdir -p /mnt/public
sudo mount /dev/sdc2 /mnt/public
gpg --armor --export $KEY_ID | sudo tee /mnt/public/$KEY_ID-$(date +%F).asc
sudo chmod 0444 /mnt/public/*.asc

Unmount and remove the storage device:

sudo umount /mnt/public

OpenBSD

$ doas disklabel -E sd2
Label editor (enter '?' for help at any prompt)
sd2> a b
offset: [32130]
size: [31069710] 25M
FS type: [swap] 4.2BSD
sd2*> w
sd2> q
No label changes.

Create a filesystem and export the public key to it:

doas newfs sd2b
doas mkdir -p /mnt/public
doas mount /dev/sd2b /mnt/public
gpg --armor --export $KEY_ID | doas tee /mnt/public/$KEY_ID-$(date +%F).asc

Unmount and remove the storage device:

doas umount /mnt/public

Configure YubiKey

Connect YubiKey and confirm its status:

gpg --card-status

If the YubiKey is locked, Reset it.

Change PIN

YubiKey's OpenPGP application has its own PINs separate from other modules such as PIV:

The User PIN must be at least 6 characters and the Admin PIN must be at least 8 characters. A maximum of 127 ASCII characters are allowed. See Managing PINs for more information.

YubiKey limits failed PIN attempts, which reduces guessing risk, allowing the User PIN to be short and convenient for regular use.

Generate PIN values - 6 digits for the User and 8 digits for the Admin:

PINS=$(LC_ALL=C tr -dc '0-9' < /dev/urandom | head -c 14)
export ADMIN_PIN=${PINS:0:8}
export USER_PIN=${PINS:8:6}
printf "\nAdmin PIN:\t\t%s\nUser  PIN:\t\t%s\n\n" "$ADMIN_PIN" "$USER_PIN"

Change the Admin PIN:

gpg --command-fd 0 --pinentry-mode loopback --change-pin <<EOF
3
12345678
$ADMIN_PIN
$ADMIN_PIN
q
EOF

Change the User PIN:

gpg --command-fd 0 --pinentry-mode loopback --change-pin <<EOF
1
123456
$USER_PIN
$USER_PIN
q
EOF

Remove and reinsert YubiKey.

[!CAUTION] Three incorrect User PIN entries will cause it to become blocked and must be unblocked with either the Admin PIN or Reset Code. Three incorrect Admin PIN or Reset Code entries will destroy data on YubiKey.

The number of retry attempts can be changed, for example to 5 attempts:

ykman openpgp access set-retries 5 5 5 -f -a $ADMIN_PIN

Set attributes

[!IMPORTANT] OpenPGP card metadata is readable without authentication by anyone with physical access to the YubiKey. This includes the card serial number, key fingerprints, public-key data, and other card attributes. Do not store a name, email address, account name, or other personal identifier in Login data, except for deliberate lost-and-found or asset-management purposes.

Set the card Login attribute. The random label generated by the following command is intentionally non-identifying:

export CARD_ATTR_LOGIN="yk.$(LC_ALL=C tr -dc 'a-z0-9' < /dev/urandom | head -c 16)"
printf "\nLogin attribute:\t%s\n\n" "$CARD_ATTR_LOGIN"

Apply the attribute:

gpg --command-fd 0 --pinentry-mode loopback --edit-card <<EOF
admin
login
$CARD_ATTR_LOGIN
$ADMIN_PIN
quit
EOF

Verify the attribute:

$ gpg --card-status | grep Login
Login data .......: yk-3i568zcrib5f

Smart card attributes can also be set with gpg --edit-card and admin mode. Use help to see available options. The login attribute is required to transfer keys.

Transfer Subkeys

[!NOTE] After transfer, the system no longer holds a usable private copy of the Subkey - it holds only a reference to the YubiKey. A backup is required to provision another YubiKey.

The Certify key passphrase and Admin PIN are required to transfer keys.

Signature key

Transfer the Signature key:

gpg --command-fd 0 --pinentry-mode loopback --edit-key $KEY_FP <<EOF
key 1
keytocard
1
$CERTIFY_PASS
$ADMIN_PIN
save
EOF

Encryption key

Repeat the process for the Encryption key:

gpg --command-fd 0 --pinentry-mode loopback --edit-key $KEY_FP <<EOF
key 2
keytocard
2
$CERTIFY_PASS
$ADMIN_PIN
save
EOF

Authentication key

Repeat the process for the Authentication key:

gpg --command-fd 0 --pinentry-mode loopback --edit-key $KEY_FP <<EOF
key 3
keytocard
3
$CERTIFY_PASS
$ADMIN_PIN
save
EOF

Verify transfer

Verify Subkeys are on YubiKey:

gpg -K

All three Subkeys should appear as ssb> - the > indicates the private key is on the smart card:

sec   rsa4096/0xF0F2CFEB04341FB5 2026-08-01 [C]
      Key fingerprint = 4E2C 1FA3 372C BA96 A06A  C34A F0F2 CFEB 0434 1FB5
uid                   [ultimate] yk.pn8wgfx67khlhext
ssb>  rsa4096/0xB3CD10E502E19637 2026-08-01 [S] [expires: 2028-08-01]
ssb>  rsa4096/0x30CBE8C4B085B9F7 2026-08-01 [E] [expires: 2028-08-01]
ssb>  rsa4096/0xAD9E24E1B8CB9600 2026-08-01 [A] [expires: 2028-08-01]

Finish setup

Confirm the following steps were successfully completed to finish setup:

• Memorized or wrote down the Certify key (identity) passphrase to a secure and durable location
  • echo $CERTIFY_PASS to see it again
  • passphrase.html or passphrase.txt to transcribe it
• Memorized or wrote down passphrase to encrypted volume on portable storage
  • echo $LUKS_PASS to see it again
  • passphrase.html or passphrase.txt to transcribe it
• Saved the Certify key and Subkeys to encrypted portable storage, to be kept offline
  • At least two backups are recommended
  • Backups stored at separate locations
• Exported a copy of the public key where it can be easily accessed later
  • Separate device or non-encrypted partition was used
• Memorized or wrote down the User PIN and Admin PIN, which are unique and changed from default values
  • echo $USER_PIN $ADMIN_PIN to see them again
  • passphrase.html or passphrase.txt to transcribe them
• Moved Encryption, Signature and Authentication Subkeys to YubiKey
  • gpg -K shows ssb> for all 3 Subkeys
• Cleared temporary working directory/environment with reboot or explicit command

Using YubiKey

Create or inspect the local GnuPG keyring. This command lists public keys and initializes ~/.gnupg if needed:

gpg -k

Import the recommended configuration:

cd ~/.gnupg
wget https://raw.githubusercontent.com/drduh/YubiKey-Guide/main/config/gpg.conf

Set the following option. This avoids the problem where GnuPG will repeatedly prompt for the insertion of an already-inserted YubiKey:

touch scdaemon.conf
echo "disable-ccid" >>scdaemon.conf

Install the required packages:

Debian/Ubuntu

sudo apt update
sudo apt install -y gnupg gnupg-agent scdaemon pcscd

Arch

sudo pacman -S --needed gnupg pcsc-tools
sudo systemctl enable --now pcscd.service

macOS

brew install gnupg

Or using MacPorts

sudo port install gnupg2 pcsc-tools

OpenBSD

doas pkg_add gnupg pcsc-tools
doas rcctl enable pcscd
doas reboot

Mount the non-encrypted volume with the public key:

Debian/Ubuntu

sudo mkdir -p /mnt/public
sudo mount /dev/sdc2 /mnt/public

OpenBSD

doas mkdir -p /mnt/public
doas mount /dev/sd3i /mnt/public

Import the public key:

gpg --import /mnt/public/*.asc

Or download the public key from a keyserver:

gpg --recv $KEY_ID

Or with the URL on YubiKey, retrieve the public key:

printf "fetch" | gpg --command-fd 0 --pinentry-mode loopback --card-edit

Determine the key ID:

gpg -k
export KEY_ID=0xF0F2CFEB04341FB5

Assign ultimate trust by typing trust and selecting option 5 then quit:

gpg --command-fd 0 --pinentry-mode loopback --edit-key $KEY_ID <<EOF
trust
5
y
save
EOF

Remove and reinsert YubiKey.

Verify the status with gpg --card-status which will list the available Subkeys:

Reader ...........: Yubico YubiKey FIDO CCID
Application ID ...: D2760001240102010006055532110000
Application type .: OpenPGP
Version ..........: 3.4
Manufacturer .....: Yubico
Serial number ....: 05553211
Name of cardholder: [not set]
Language prefs ...: [not set]
Salutation .......:
URL of public key : [not set]
Login data .......: yk-3i568zcrib5f
Signature PIN ....: not forced
Key attributes ...: rsa4096 rsa4096 rsa4096
Max. PIN lengths .: 127 127 127
PIN retry counter : 3 3 3
Signature counter : 0
KDF setting ......: off
UIF setting ......: Sign=off Decrypt=off Auth=off
Signature key ....: CF5A 305B 808B 7A0F 230D  A064 B3CD 10E5 02E1 9637
      created ....: 2026-08-01 12:00:00
Encryption key....: A5FA A005 5BED 4DC9 889D  38BC 30CB E8C4 B085 B9F7
      created ....: 2026-08-01 12:00:00
Authentication key: 570E 1355 6D01 4C04 8B6D  E2A3 AD9E 24E1 B8CB 9600
      created ....: 2026-08-01 12:00:00
General key info..: sub  rsa4096/0xB3CD10E502E19637 2026-08-01 yk.pn8wgfx67khlhext
sec#  rsa4096/0xF0F2CFEB04341FB5  created: 2026-08-01  expires: never
ssb>  rsa4096/0xB3CD10E502E19637  created: 2026-08-01  expires: 2028-08-01
                                  card-no: 0006 05553211
ssb>  rsa4096/0x30CBE8C4B085B9F7  created: 2026-08-01  expires: 2028-08-01
                                  card-no: 0006 05553211
ssb>  rsa4096/0xAD9E24E1B8CB9600  created: 2026-08-01  expires: 2028-08-01
                                  card-no: 0006 05553211

sec# indicates the corresponding key is not available (the Certify key is offline).

YubiKey is now ready for use!

Encryption

Encrypt a message to yourself (useful for storing credentials or protecting backups):

echo -e "\ntest message string" |
  gpg --encrypt --armor \
      --recipient $KEY_ID --output encrypted.txt

Decrypt the message - a prompt for the User PIN will appear:

gpg --decrypt --armor encrypted.txt

To encrypt to multiple recipients/keys, set the preferred key ID last:

echo "test message string" |
  gpg --encrypt --armor \
      --recipient $KEY_ID_2 \
      --recipient $KEY_ID_1 \
      --recipient $KEY_ID_0 \
      --output encrypted.txt

Use a shell function to make encrypting files easier:

secret () {
  output="${1}".$(date +%s).enc
  gpg --encrypt --armor --output ${output} \
    -r $KEY_ID "${1}" && echo "${1} -> ${output}"
}

reveal () {
  output=$(echo "${1}" | rev | cut -c16- | rev)
  gpg --decrypt --output ${output} "${1}" && \
    echo "${1} -> ${output}"
}

Example output:

$ secret document.pdf
document.pdf -> document.pdf.1780000000.enc

$ reveal document.pdf.1780000000.enc
gpg: anonymous recipient; trying secret key 0xF0F2CFEB04341FB5 ...
gpg: okay, we are the anonymous recipient.
gpg: encrypted with RSA key, ID 0x0000000000000000
document.pdf.1780000000.enc -> document.pdf

drduh/Purse is a secrets manager implemented with GnuPG and YubiKey.

Signature

Sign a message:

echo "test message string" | gpg --armor --clearsign > signed.txt

Verify the signature:

gpg --verify signed.txt

The output will be similar to:

gpg: Signature made Sat 01 Aug 2026 12:00:00 PM UTC
gpg:                using RSA key CF5A305B808B7A0F230DA064B3CD10E502E19637
gpg: Good signature from "yk.pn8wgfx67khlhext" [ultimate]
Primary key fingerprint: 4E2C 1FA3 372C BA96 A06A  C34A F0F2 CFEB 0434 1FB5
     Subkey fingerprint: CF5A 305B 808B 7A0F 230D  A064 B3CD 10E5 02E1 9637

Configure touch

By default, cryptographic operations do not require any action from the user after YubiKey is unlocked with the User PIN.

To require a touch for each operation, use YubiKey Manager and the Admin PIN to set key policy.

Encryption:

ykman openpgp keys set-touch dec on

[!NOTE] YubiKey Manager prior to versions 5.1.0 use enc instead of dec for encryption:

ykman openpgp keys set-touch enc on

Even older versions of YubiKey Manager use touch instead of set-touch

Signature:

ykman openpgp keys set-touch sig on

Authentication:

ykman openpgp keys set-touch aut on

To view and adjust policy options:

ykman openpgp keys set-touch --help

Cached or Cached-Fixed may be desirable for YubiKey use with email clients.

YubiKey blinks when waiting for a touch. On Linux, maximbaz/yubikey-touch-detector can also be used for indication.

SSH

Create or import a hardened configuration:

cd ~/.gnupg
wget https://raw.githubusercontent.com/drduh/YubiKey-Guide/main/config/gpg-agent.conf

[!NOTE] cache-ttl options do not apply when using YubiKey as a smart card, because the PIN is cached by the smart card itself. To clear the PIN from cache (equivalent to default-cache-ttl and max-cache-ttl), remove YubiKey, or set forcesig when editing the card to be prompted for the PIN each time.

[!TIP] Set pinentry-program to /usr/bin/pinentry-gnome3 for a GUI-based prompt.

macOS

Install pinentry with brew install pinentry-mac or sudo port install pinentry then edit gpg-agent.conf to set the pinentry-program path to:

• Apple Silicon Macs: /opt/homebrew/bin/pinentry-mac
• Intel Macs: /usr/local/bin/pinentry-mac or /opt/local/bin/pinentry (MacPorts)
• MacGPG Suite: /usr/local/MacGPG2/libexec/pinentry-mac.app/Contents/MacOS/pinentry-mac

Then run gpgconf --kill gpg-agent for the change to take effect.

To use graphical applications on macOS, additional setup is required.

Create $HOME/Library/LaunchAgents/gnupg.gpg-agent.plist with the following contents:

<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE plist PUBLIC "-//Apple//DTD PLIST 1.0//EN" "http://www.apple.com/DTDs/PropertyList-1.0.dtd">
<plist version="1.0">
    <dict>
        <key>Label</key>
        <string>gnupg.gpg-agent</string>
        <key>RunAtLoad</key>
        <true/>
        <key>KeepAlive</key>
        <false/>
        <key>EnvironmentVariables</key>
        <dict>
            <key>PATH</key>
            <string>/opt/homebrew/bin:/usr/local/bin:/usr/bin:/usr/local/MacGPG2/bin:/bin</string>
        </dict>
        <key>ProgramArguments</key>
        <array>
            <string>/usr/bin/env</string>
            <string>gpg-connect-agent</string>
            <string>/bye</string>
        </array>
    </dict>
</plist>

Load it:

launchctl load $HOME/Library/LaunchAgents/gnupg.gpg-agent.plist

Create $HOME/Library/LaunchAgents/gnupg.gpg-agent-symlink.plist with the following contents:

<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE plist PUBLIC "-//Apple//DTD PLIST 1.0//EN" "http://www.apple.com/DTDs/PropertyList-1.0/dtd">
<plist version="1.0">
    <dict>
        <key>Label</key>
        <string>gnupg.gpg-agent-symlink</string>
        <key>ProgramArguments</key>
        <array>
            <string>/bin/sh</string>
            <string>-c</string>
            <string>/bin/ln -sf $HOME/.gnupg/S.gpg-agent.ssh $SSH_AUTH_SOCK</string>
        </array>
        <key>RunAtLoad</key>
        <true/>
    </dict>
</plist>

Load it:

launchctl load $HOME/Library/LaunchAgents/gnupg.gpg-agent-symlink.plist

Reboot to activate changes.

Windows

Windows can already have some virtual smart card readers installed, like the one provided for Windows Hello. To verify YubiKey is the correct one used by scdaemon, add it to its configuration.

Find the YubiKey label using PowerShell:

PS C:\WINDOWS\system32> Get-PnpDevice -Class SoftwareDevice | Where-Object {$_.FriendlyName -like "*YubiKey*"} | Select-Object -ExpandProperty FriendlyName
Yubico YubiKey OTP+FIDO+CCID 0

See How to setup Signed Git Commits with a YubiKey NEO and GPG and Keybase on Windows (2018) for more information.

Edit %APPDATA%/gnupg/scdaemon.conf to add:

reader-port <device name, e.g. Yubico YubiKey OTP+FIDO+CCID 0>

Edit %APPDATA%/gnupg/gpg-agent.conf to add:

enable-ssh-support
enable-putty-support

Restart the agent:

gpg-connect-agent killagent /bye
gpg-connect-agent /bye

Verify YubiKey details:

gpg --card-status

Import the public key and set ultimate trust:

gpg --import <path to public key file>

Retrieve the public key id:

gpg --list-public-keys

Export the SSH public key:

gpg --export-ssh-key <public key id>

Copy the public SSH key to a file - it corresponds to the secret key on YubiKey and can be copied to SSH destination hosts.

Create a shortcut that points to gpg-connect-agent /bye and place it in the startup folder shell:startup to make sure the agent starts after reboot. Modify the shortcut properties so it starts in a "Minimized" window.

PuTTY can now be used for public-key SSH authentication. When the server asks for public-key verification, PuTTY will forward the request to GnuPG, which will prompt for a PIN to authorize the operation.

WSL

The goal is to configure SSH client inside WSL work together with the Windows agent, such as gpg-agent.exe.

See the WSL agent architecture illustration for an overview.

GnuPG forwarding for cryptographic operations is not supported. See vuori/weasel-pageant for more information.

One way to forward is just ssh -A (still need to eval weasel to setup local ssh-agent), and only relies on OpenSSH. In this track, ForwardAgent and AllowAgentForwarding in ssh/sshd config may be involved. However, when using ssh socket forwarding, do not enable ForwardAgent in ssh config. See SSH Agent Forwarding for more information. This requires Ubuntu 16.04 or newer for WSL and Kleopatra.

Download vuori/weasel-pageant.

Add eval $(/mnt/c/<path of extraction>/weasel-pageant -r -a /tmp/S.weasel-pageant) to the shell rc file. Use a named socket here so it can be used in the RemoteForward directive of ~/.ssh/config. Source it with source ~/.bashrc.

Display the SSH key with ssh-add -l.

Edit ~/.ssh/config to add the following for each agent forwarding host:

RemoteForward <remote SSH socket path> /tmp/S.weasel-pageant

The remote SSH socket path can be found with gpgconf --list-dirs agent-ssh-socket

Add the following to the shell rc file:

export SSH_AUTH_SOCK=$(gpgconf --list-dirs agent-ssh-socket)

Add the following to /etc/ssh/sshd_config:

StreamLocalBindUnlink yes

Reload SSH daemon:

sudo service sshd reload

Remove YubiKey and reboot. Log back into Windows, open a WSL console and enter ssh-add -l - no output should appear.

Plug in YubiKey, enter the same command to display the ssh key.

Connect to the remote host and use ssh-add -l to confirm forwarding works.

Agent forwarding may be chained through multiple hosts. Follow the same protocol to configure each host.

An alternate method is the usbipd-win library. If you encounter issues with accessing the YubiKey in WSL after configuring usbipd-win, you may need to add custom polkit rules to ensure proper permissions for the pcscd service. Here's an example configuration using a scard group (the group logic is optional):

Create a new rule file at /etc/polkit-1/rules.d/99-pcscd.rules:

polkit.addRule(function(action, subject) {
    if (action.id == "org.debian.pcsc-lite.access_card" &&
        subject.isInGroup("scard")) {
        return polkit.Result.YES;
    }
});

polkit.addRule(function(action, subject) {
    if (action.id == "org.debian.pcsc-lite.access_pcsc" &&
        subject.isInGroup("scard")) {
        return polkit.Result.YES;
    }
});

Replace agents

To launch gpg-agent for SSH, use gpg-connect-agent /bye or gpgconf --launch gpg-agent commands.

Add the following to the shell rc file:

export GPG_TTY=$(tty)
export SSH_AUTH_SOCK=$(gpgconf --list-dirs agent-ssh-socket)
gpgconf --launch gpg-agent
gpg-connect-agent updatestartuptty /bye > /dev/null

For fish, config.fish should look like this (consider putting them into the is-interactive block):

set -x GPG_TTY (tty)
set -x SSH_AUTH_SOCK (gpgconf --list-dirs agent-ssh-socket)
gpgconf --launch gpg-agent

When using ForwardAgent for ssh-agent forwarding, SSH_AUTH_SOCK only needs to be set on the local host, where YubiKey is connected. On the remote host, ssh will set SSH_AUTH_SOCK to something like /tmp/ssh-mXzCzYT2Np/agent.7541 upon connection. Do not set SSH_AUTH_SOCK on the remote host - doing so will break SSH Agent Forwarding.

For S.gpg-agent.ssh (see SSH Agent Forwarding for more info), SSH_AUTH_SOCK should also be set on the remote. However, GPG_TTY should not be set on the remote, explanation specified in that section.

Copy public key

[!TIP] It is not necessary to import the GnuPG public key in order to use SSH only.

Copy and paste the output from ssh-add to the server's authorized_keys file:

$ ssh-add -L
ssh-rsa AAAAB4NzaC1yc2EAAAADAQABAAACAz[...]zreOKM+HwpkHzcy9DQcVG2Nw== cardno:000605553211

Optional Save the public key for identity file configuration. By default, SSH attempts to use all the identities available via the agent. It's often a good idea to manage exactly which keys SSH will use to connect to a server, for example to separate different roles or to avoid being fingerprinted by untrusted ssh servers. To do this you'll need to use the command line argument -i [identity_file] or the IdentityFile and IdentitiesOnly options in .ssh/config.

The argument provided to IdentityFile is traditionally the path to the private key file (for example IdentityFile ~/.ssh/id_rsa). For YubiKey, IdentityFile must point to the public key file, and ssh will select the appropriate private key from those available via ssh-agent. To prevent ssh from trying all keys in the agent, use IdentitiesOnly yes along with one or more -i or IdentityFile options for the target host.

To reiterate, with IdentitiesOnly yes, ssh will not enumerate public keys loaded into ssh-agent or gpg-agent. This means public-key authentication will not proceed unless explicitly named by ssh -i [identity_file] or in .ssh/config on a per-host basis.

In the case of YubiKey usage, to extract the public key from the ssh agent:

ssh-add -L | grep "cardno:000605553211" > ~/.ssh/id_rsa_yubikey.pub

Then explicitly associate this YubiKey-stored key for use with a host - github.com for example, as follows:

$ cat << EOF >> ~/.ssh/config
Host github.com
  IdentitiesOnly yes
  IdentityFile ~/.ssh/id_rsa_yubikey.pub
EOF

Connect with public key authentication:

$ ssh [email protected] -vvv
[...]
debug2: key: cardno:000605553211 (0x1234567890),
debug1: Authentications that can continue: publickey
debug3: start over, passed a different list publickey
debug3: preferred gssapi-keyex,gssapi-with-mic,publickey,keyboard-interactive,password
debug3: authmethod_lookup publickey
debug3: remaining preferred: keyboard-interactive,password
debug3: authmethod_is_enabled publickey
debug1: Next authentication method: publickey
debug1: Offering RSA public key: cardno:000605553211
debug3: send_pubkey_test
debug2: we sent a publickey packet, wait for reply
debug1: Server accepts key: pkalg ssh-rsa blen 535
debug2: input_userauth_pk_ok: fp e5:de:a5:74:b1:3e:96:9b:85:46:e7:28:53:b4:82:c3
debug3: sign_and_send_pubkey: RSA e5:de:a5:74:b1:3e:96:9b:85:46:e7:28:53:b4:82:c3
debug1: Authentication succeeded (publickey).
[...]

[!TIP] To enable multiple SSH connections, use the ControlMaster option.

Import SSH keys

If there are existing SSH keys to make available via gpg-agent, they will need to be imported. Then, remove the original private keys. When importing the key, gpg-agent uses the key filename as the label - this makes it easier to follow where the key originated from. In this example, we're starting with just the YubiKey in place and importing ~/.ssh/id_rsa:

$ ssh-add -l
4096 SHA256:... cardno:00060123456 (RSA)

$ ssh-add ~/.ssh/id_rsa && rm ~/.ssh/id_rsa

When invoking ssh-add, a prompt for the SSH key passphrase will appear, then the pinentry program will prompt and confirm a new passphrase to encrypt the converted key within the GnuPG key store.

The migrated key will be listed in ssh-add -l:

$ ssh-add -l
4096 SHA256:... cardno:00060123456 (RSA)
2048 SHA256:... /Users/username/.ssh/id_rsa (RSA)

To show MD5 fingerprints, as used by gpg-connect-agent's KEYINFO and DELETE_KEY commands:

$ ssh-add -E md5 -l
4096 MD5:... cardno:00060123456 (RSA)
2048 MD5:... /Users/username/.ssh/id_rsa (RSA)

When using the key pinentry will be invoked to request the key passphrase. The passphrase will be cached for up to 10 idle minutes between uses, up to a maximum of 2 hours.

SSH agent forwarding

[!CAUTION] SSH Agent Forwarding can add additional risk - proceed with caution!

There are two methods for ssh-agent forwarding, one is provided by OpenSSH and the other is provided by GnuPG.

The latter one may be more insecure as raw socket is just forwarded (not like S.gpg-agent.extra with only limited functionality; if ForwardAgent implemented by OpenSSH is just forwarding the raw socket, then they are insecure to the same degree). But for the latter one, one convenience is that one may forward once and use this agent everywhere in the remote. So again, proceed with caution!

For example, tmux does not have environment variables such as $SSH_AUTH_SOCK when connecting to remote hosts and attaching an existing session. For each shell, find the socket and export SSH_AUTH_SOCK=/tmp/ssh-agent-xxx/xxxx.socket. However, with S.gpg-agent.ssh in a fixed place, it can be used as the ssh-agent in shell rc files.

Use ssh-agent

You should now be able to use ssh -A remote on the local host to log into remote host, and should then be able to use YubiKey as if it were connected to the remote host. For example, using e.g. ssh-add -l on that remote host will show the public key from the YubiKey (cardno:). Always use ForwardAgent yes only for a single host, never for all servers.

Use S.gpg-agent.ssh

First you need to go through GnuPG agent forwarding, know the conditions for gpg-agent forwarding and know the location of S.gpg-agent.ssh on both the local and the remote.

You may use the command:

gpgconf --list-dirs agent-ssh-socket

Edit .ssh/config to add the remote host:

Host
  Hostname remote-host.tld
  StreamLocalBindUnlink yes
  RemoteForward /run/user/1000/gnupg/S.gpg-agent.ssh /run/user/1000/gnupg/S.gpg-agent.ssh
  #RemoteForward [remote socket] [local socket]
  #Note that ForwardAgent is not wanted here!

After successfully ssh into the remote host, confirm /run/user/1000/gnupg/S.gpg-agent.ssh exists.

Then in the remote you can type in command line or configure in the shell rc file with:

export SSH_AUTH_SOCK="/run/user/$UID/gnupg/S.gpg-agent.ssh"

After sourcing the shell rc file, ssh-add -l will return the correct public key.

In this process no gpg-agent in the remote is involved, hence gpg-agent.conf in the remote is of no use. Also pinentry is invoked locally.

Chained forwarding

If you use ssh-agent provided by OpenSSH and want to forward it into a third box, you can just ssh -A third on the remote.

Meanwhile, if you use S.gpg-agent.ssh, assume you have gone through the steps above and have S.gpg-agent.ssh on the remote, and you would like to forward this agent into a third box, first you may need to configure sshd_config and SSH_AUTH_SOCK of third in the same way as remote, then in the ssh config of remote, add the following lines

Host third
  Hostname third-host.tld
  StreamLocalBindUnlink yes
  RemoteForward /run/user/1000/gnupg/S.gpg-agent.ssh /run/user/1000/gnupg/S.gpg-agent.ssh
  #RemoteForward [remote socket] [local socket]
  #Note that ForwardAgent is not wanted here!

The path must be set according to gpgconf --list-dirs agent-ssh-socket on remote and third hosts.

GitHub

YubiKey can be used to sign commits and tags, and authenticate SSH to GitHub when configured in Settings.

Configure the signing key:

git config --global user.signingkey $KEY_ID

Alternatively, if you are using the aforementioned IdentityFile (SSH key) for signing:

git config --global gpg.format ssh
git config --global user.signingkey ~/.ssh/id_rsa_yubikey.pub

Configure the user.name and user.email option to match the email address associated with the identity:

git config --global user.name 'YubiKey User'
git config --global user.email [email protected]

To sign commits or tags, use the -S option, or consider enabling commit and tag signing by default:

git config --global commit.gpgsign true
git config --global tag.gpgSign true

Windows

Configure authentication:

git config --global core.sshcommand "plink -agent"
git config --global gpg.program 'C:\Program Files (x86)\GnuPG\bin\gpg.exe'

Then update the repository URL to [email protected]:USERNAME/repository

GnuPG agent forwarding

YubiKey can be used sign git commits and decrypt files on remote hosts with GnuPG Agent Forwarding. To ssh through another network, especially to push to/pull from GitHub using ssh, see Remote Machines (SSH Agent forwarding).

gpg-agent.conf is not needed on the remote host; after forwarding, remote GnuPG directly communicates with S.gpg-agent without starting gpg-agent on the remote host.

On the remote host, edit /etc/ssh/sshd_config to set StreamLocalBindUnlink yes

Optional Without root access on the remote host to edit /etc/ssh/sshd_config, socket located at gpgconf --list-dir agent-socket on the remote host will need to be removed before forwarding works. See AgentForwarding GNUPG wiki page for more information.

Import the public key on the remote host. On the local host, copy the public keyring to the remote host:

scp ~/.gnupg/pubring.kbx remote:~/.gnupg/

On modern distributions, such as Fedora 30, there is no need to set RemoteForward in ~/.ssh/config

Legacy distributions

On the local host, run:

gpgconf --list-dirs agent-extra-socket

This should return a path to agent-extra-socket - /run/user/1000/gnupg/S.gpg-agent.extra - though on older Linux distros (and macOS) it may be /home/<user>/.gnupg/S.gpg-agent.extra

Find the agent socket on the remote host:

gpgconf --list-dirs agent-socket

This should return a path such as /run/user/1000/gnupg/S.gpg-agent

Finally, enable agent forwarding for a given host by adding the following to the local host's ~/.ssh/config (agent sockets may differ):

Host
  Hostname remote-host.tld
  StreamLocalBindUnlink yes
  RemoteForward /run/user/1000/gnupg/S.gpg-agent /run/user/1000/gnupg/S.gpg-agent.extra
  #RemoteForward [remote socket] [local socket]

It may be necessary to edit gpg-agent.conf on the local host to add the following information:

pinentry-program /usr/bin/pinentry-gtk-2
extra-socket /run/user/1000/gnupg/S.gpg-agent.extra

[!IMPORTANT] The pinentry program starts on the local host, not remote.

Any pinentry program except pinentry-tty or pinentry-curses may be used. This is because local gpg-agent may start headlessly (by systemd without $GPG_TTY set locally telling which tty it is on), thus failed to obtain the pin. Errors on the remote may be misleading saying that there is IO Error. (Yes, internally there is actually an IO Error since it happens when writing to/reading from tty while finding no tty to use, but for end users this is not friendly.)

See Issue 85 for more information and troubleshooting.

Chained GnuPG agent forwarding

Assume you have gone through the steps above and have S.gpg-agent on the remote, and you would like to forward this agent into a third box, first you may need to configure sshd_config of third in the same way as remote, then in the ssh config of remote, add the following lines:

Host third
  Hostname third-host.tld
  StreamLocalBindUnlink yes
  RemoteForward /run/user/1000/gnupg/S.gpg-agent /run/user/1000/gnupg/S.gpg-agent
  #RemoteForward [remote socket] [local socket]

You should change the path according to gpgconf --list-dirs agent-socket on remote and third.

On local you have S.gpg-agent.extra whereas on remote and third, you only have S.gpg-agent.

Using multiple YubiKeys

When a GnuPG key is added to YubiKey using keytocard, the credential is deleted from the keyring and a stub pointing to the YubiKey is added. The stub identifies the GnuPG key ID and YubiKey serial number.

When a Subkey is added to an additional YubiKey, the stub is overwritten and will now point to the latest YubiKey. GnuPG will request a specific YubiKey by serial number, as referenced by the stub, and will not recognize another YubiKey with a different serial number.

To scan an additional YubiKey and recreate the correct stub:

gpg-connect-agent "scd serialno" "learn --force" /bye

Alternatively, use a script to delete the GnuPG shadowed key, where the serial number is stored (see GnuPG #T2291):

mkdir -p ~/scripts && cat >> ~/scripts/remove-keygrips.sh <<EOF
#!/usr/bin/env bash
(( $# )) || { echo "Specify a key." >&2; exit 1; }
KEYGRIPS=$(gpg --with-keygrip --list-secret-keys "$@" | awk '/Keygrip/ { print $3 }')
for keygrip in $KEYGRIPS
do
    rm "$HOME/.gnupg/private-keys-v1.d/$keygrip.key" 2> /dev/null
done

gpg --card-status
EOF

chmod +x ~/scripts/remove-keygrips.sh

~/scripts/remove-keygrips.sh $KEY_ID

See discussion in Issues #19 and #112 for more information and troubleshooting steps.

Email

YubiKey can be used to decrypt and sign emails and attachments using Thunderbird, Enigmail and Mutt. Thunderbird supports OAuth 2 authentication and can be used with Gmail. See this EFF guide for more information. Mutt has OAuth 2 support since version 2.0.

Thunderbird

Follow instructions on the mozilla wiki to setup YubiKey with Thunderbird using the external GPG provider.

[!NOTE] Thunderbird will fail to decrypt emails if the ASCII armor option is enabled in gpg.conf. If you see the error gpg: [don't know]: invalid packet (ctb=2d) or message cannot be decrypted (there are unknown problems with this encrypted message) simply remove this option.

Mailvelope

Mailvelope allows YubiKey to be used with Gmail and others.

[!NOTE] Mailvelope does not work with the throw-keyids option set in gpg.conf

On macOS, install gpgme using Homebrew:

brew install gpgme

To allow Chrome to run gpgme, edit ~/Library/Application\ Support/Google/Chrome/NativeMessagingHosts/gpgmejson.json to add:

{
    "name": "gpgmejson",
    "description": "Integration with GnuPG",
    "path": "/usr/local/bin/gpgme-json",
    "type": "stdio",
    "allowed_origins": [
        "chrome-extension://kajibbejlbohfaggdiogboambcijhkke/"
    ]
}

Edit the default path to allow Chrome to find GnuPG:

sudo launchctl config user path /usr/local/bin:/usr/bin:/bin:/usr/sbin:/sbin

Finally, install the Mailvelope extension from the Chrome web store.

Mutt

Mutt has both CLI and TUI interfaces - the latter provides powerful functions for processing email. In addition, PGP can be integrated such that cryptographic operations can be done without leaving TUI.

To enable GnuPG support, copy /usr/share/doc/mutt/samples/gpg.rc

Edit the file to enable options pgp_default_key, pgp_sign_as and pgp_autosign

source the file in muttrc

[!NOTE] pinentry-tty set as the pinentry program (in gpg-agent.conf) is reported to cause problems with Mutt TUI, because it uses curses; use pinentry-curses or other graphic pinentry program instead.

Keyserver

Public keys can be uploaded to a public server for discoverability:

gpg --send-key $KEY_ID
gpg --keyserver keys.gnupg.net --send-key $KEY_ID
gpg --keyserver hkps://keyserver.ubuntu.com:443 --send-key $KEY_ID

Or if uploading to keys.openpgp.org:

gpg --export $KEY_ID | curl -T - https://keys.openpgp.org

The public key URL can also be added to YubiKey (based on Shaw 2003):

URL="hkps://keyserver.ubuntu.com:443/pks/lookup?op=get&search=${KEY_ID}"

Edit YubiKey with gpg --edit-card and the Admin PIN:

gpg/card> admin

gpg/card> url
URL to retrieve public key: hkps://keyserver.ubuntu.com:443/pks/lookup?op=get&search=0xFF00000000000000

gpg/card> quit

Updating keys

PGP does not provide forward secrecy, meaning a compromised key may be used to decrypt all past messages. Although keys stored on YubiKey are more difficult to exploit, it is not impossible: the key and PIN could be physically compromised, or a vulnerability may be discovered in firmware or in the random number generator used to create keys, for example. Therefore, it is recommended practice to rotate Subkeys periodically.

When a Subkey expires, it can either be renewed or replaced. Both actions require access to the Certify key.

• Renewing Subkeys by updating expiration indicates continued custody of the Certify key and is generally more convenient.

• Replacing Subkeys is less convenient, but potentially more secure: new Subkeys will not be able to decrypt previous messages, nor authenticate with SSH, etc. Recipients will need the updated public key. Any encrypted secrets must be decrypted and re-encrypted to new Subkeys. This process is functionally equivalent to losing the YubiKey and provisioning a new one.

Neither rotation method is superior and it is up to personal philosophy on identity management and individual threat modeling to decide which one to use, or whether to expire Subkeys at all. Ideally, Subkeys would be ephemeral: used only once for each unique encryption, signature and authentication event, however in practice that is not really practical nor worthwhile with YubiKey. Advanced users may dedicate an air-gapped machine for frequent credential rotation.

To renew or rotate Subkeys, follow the same process as generating keys: boot to a secure environment, install required software and disable networking.

Connect the portable storage device with the Certify key and identify the device path.

Decrypt and mount the encrypted volume:

sudo cryptsetup luksOpen /dev/sdc1 gnupg-secrets
sudo mkdir -p /mnt/encrypted-storage
sudo mount /dev/mapper/gnupg-secrets /mnt/encrypted-storage

Mount the non-encrypted public partition:

sudo mkdir -p /mnt/public
sudo mount /dev/sdc2 /mnt/public

Copy the original private key materials (after updating the encrypted storage directory name) to a temporary working directory:

export GNUPGHOME=$(mktemp -d "${TMPDIR:-/tmp}/$(date +%Y.%m.%d)-XXXXXXXX")
cp -avi /mnt/encrypted-storage/2026.*/* $GNUPGHOME/

Confirm the identity is available, set the key ID and fingerprint values:

gpg -K
export KEY_FP=$(gpg -k --with-colons $IDENTITY | awk -F: '/^fpr:/ { print $10; exit }')
export KEY_ID="${KEY_FP: -16}"
printf "\nKey ID/Fingerprint:\t%s\n%s\n\n" "$KEY_ID" "$KEY_FP"

Recall the Certify key passphrase and set it, for example:

export CERTIFY_PASS="ABCD-0123-IJKL-4567-QRST-UVWX"

Renew Subkeys

Set the updated expiration date:

export KEY_EXPIRATION=2028-09-01

Renew the Subkeys:

printf '%s' "$CERTIFY_PASS" |
  gpg --batch --pinentry-mode loopback \
      --passphrase-fd 0 --quick-set-expire "$KEY_FP" "$KEY_EXPIRATION" \
    $(gpg -K --with-colons |
      awk -F: '$1=="fpr" { if (++n > 1) printf "%s ", $10 } END { print "" }')

Export the updated public key:

gpg --armor --export $KEY_ID | sudo tee /mnt/public/$KEY_ID-$(date +%F).asc

Transfer the public key to the destination host and import it:

gpg --import /mnt/public/*.asc

Alternatively, publish to a public key server and download it:

gpg --send-key $KEY_ID
gpg --recv $KEY_ID

The validity of the GnuPG identity will be extended, enabling encryption and signature operations.

The SSH public key does not need to be updated on remote hosts.

Rotate Subkeys

Follow the original procedure to Create Subkeys.

Previous Subkeys can be deleted from the identity.

Finish by transferring new Subkeys to YubiKey.

Copy the new temporary working directory to encrypted storage, which is still mounted:

sudo cp -avi $GNUPGHOME /mnt/encrypted-storage

Unmount and close the encrypted volume:

sudo umount /mnt/encrypted-storage
sudo cryptsetup luksClose gnupg-secrets

Export the updated public key:

sudo mkdir -p /mnt/public
sudo mount /dev/sdc2 /mnt/public
gpg --armor --export $KEY_ID | sudo tee /mnt/public/$KEY_ID-$(date +%F).asc
sudo umount /mnt/public

Remove the storage device and follow the original steps to transfer new Subkeys (4, 5 and 6) to YubiKey, replacing existing ones.

Reboot or securely erase the GnuPG temporary working directory.

Reset YubiKey

If PIN attempts are exceeded, the YubiKey is locked and must be Reset and set up again using the encrypted backup.

Copy the following to a file and run gpg-connect-agent -r $file, then reinsert the YubiKey to complete reset.

/hex
scd serialno
scd apdu 00 20 00 81 08 40 40 40 40 40 40 40 40
scd apdu 00 20 00 81 08 40 40 40 40 40 40 40 40
scd apdu 00 20 00 81 08 40 40 40 40 40 40 40 40
scd apdu 00 20 00 81 08 40 40 40 40 40 40 40 40
scd apdu 00 20 00 83 08 40 40 40 40 40 40 40 40
scd apdu 00 20 00 83 08 40 40 40 40 40 40 40 40
scd apdu 00 20 00 83 08 40 40 40 40 40 40 40 40
scd apdu 00 20 00 83 08 40 40 40 40 40 40 40 40
scd apdu 00 e6 00 00
scd apdu 00 44 00 00
/echo Card has been successfully reset.
/bye

Or use ykman (sometimes in ~/.local/bin/):

$ ykman openpgp reset
WARNING! This will delete all stored OpenPGP keys and data and restore factory settings? [y/N]: y
Resetting OpenPGP data, don't remove your YubiKey...
Success! All data has been cleared and default PINs are set.
PIN:         123456
Reset code:  NOT SET
Admin PIN:   12345678

Optional hardening

The following steps may improve the security and privacy of YubiKey.

Improving entropy

Generating cryptographic keys requires high-quality randomness, measured as entropy. Most operating systems use software-based pseudorandom number generators or CPU-based hardware random number generators (HRNG).

Optionally, a device such as OneRNG may be used to increase the speed and possibly the quality of available entropy.

Before creating keys, configure rng-tools:

sudo apt -y install at rng-tools python3-gnupg openssl
wget https://github.com/OneRNG/onerng.github.io/raw/master/sw/onerng_3.7-1_all.deb

Verify the package:

sha256sum onerng_3.7-1_all.deb

The value must match:

b7cda2fe07dce219a95dfeabeb5ee0f662f64ba1474f6b9dddacc3e8734d8f57

Install the package:

sudo dpkg -i onerng_3.7-1_all.deb
echo "HRNGDEVICE=/dev/ttyACM0" | sudo tee /etc/default/rng-tools

Insert the device and restart rng-tools:

sudo atd
sudo service rng-tools restart

Enable KDF

[!IMPORTANT] This feature may not be compatible with older GnuPG versions, especially mobile clients. These incompatible clients will not function because the PIN will always be rejected.

This step must be completed before changing PINs or moving keys or an error will occur: gpg: error for setup KDF: Conditions of use not satisfied

Key Derived Function (KDF) enables YubiKey to store the hash of PIN, preventing the PIN from being passed as plain text.

Enable KDF using the default Admin PIN of 12345678:

gpg --command-fd 0 --pinentry-mode loopback --card-edit <<EOF
admin
kdf-setup
12345678
EOF

Network considerations

This section is primarily focused on Debian/Ubuntu systems, but the concepts apply to any system connected to a network.

Whether using a VM, installing on dedicated hardware, or running a Live OS temporarily, start without a network connection and disable any unnecessary services listening on all interfaces before connecting to the network.

This is because services like cups or avahi can be listening by default. While this isn't an immediate problem it simply broadens the attack surface. Not everyone will have a dedicated subnet or trusted network equipment they can control, and for the purposes of this guide, these steps treat any network as untrusted / hostile.

Disable listening services

• Ensures only essential network services are running
• If the service doesn't exist you'll get a "Failed to stop" which is fine
• Only disable Bluetooth if you don't need it

sudo systemctl stop bluetooth exim4 cups avahi avahi-daemon sshd

Firewall

Enable a basic firewall policy of deny inbound, allow outbound. Note that Debian does not come with a firewall, simply disabling the services in the previous step is fine. The following options have Ubuntu and similar systems in mind.

On Ubuntu, ufw is built in and easy to enable:

sudo ufw enable

On systems without ufw, nftables is replacing iptables. The nftables wiki has examples for a baseline deny inbound, allow outbound policy. The fw.inet.basic policy covers both IPv4 and IPv6.

Download this README and any other resources to another external drive when creating the bootable media, to have this information ready to use offline.

Regardless of which policy you use, write the contents to a file (e.g. nftables.conf) and apply the policy with the following command:

sudo nft -f ./nftables.conf

Review system state

NetworkManager should be the only listening service on port 68/udp to obtain a DHCP lease (and 58/icmp6 if you have IPv6).

If you want to look at every process's command line arguments you can use ps axjf. This prints a process tree which may have a large number of lines but should be easy to read on a live image or fresh install.

# Dump network state information
sudo ss -anp -A inet

# List all processes in a process tree
ps axjf

# BSD syntax, list all processes but no process tree
ps aux

If you find any additional processes listening on the network that aren't needed, take note and disable them with one of the following:

# Stop services managed by systemctl
sudo systemctl stop <process-name>

# Terminate the process by matching its command line string
sudo pkill -f '<process-name-or-command-line-string>'

# Obtain the process ID
pgrep -f '<process-name-or-command-line-string>'

# Terminate the process ID
sudo kill <pid>

Now connect networking.

Notes

1. YubiKey has two configurations, invoked with either a short or long press. By default, the short-press mode is configured for HID OTP; a brief touch will emit an OTP string starting with cccccccc. OTP mode can be swapped to the second configuration via the YubiKey Personalization tool or disabled entirely using YubiKey Manager: ykman config usb -d OTP

2. Using YubiKey for GnuPG does not prevent use of other features, such as WebAuthn and OTP.

3. Add additional identities to a Certify key with the adduid command during setup, then trust it ultimately with trust and 5 to configure for use.

4. To switch between YubiKeys, remove the first YubiKey and restart gpg-agent, ssh-agent and pinentry with pkill "gpg-agent|ssh-agent|pinentry" ; eval $(gpg-agent --daemon --enable-ssh-support) then insert the other YubiKey and run gpg-connect-agent updatestartuptty /bye

5. To use YubiKey on multiple computers, import the corresponding public keys, then confirm YubiKey is visible with gpg --card-status. Trust the imported public keys ultimately with trust and 5, then gpg --list-secret-keys will show the correct and trusted key.

6. When the Certify key is offline, caveat emptor: If you wish to participate in keysigning parties, you'll find signing others' imported public keys requires first setting up a secure enclave such as the ephemeral environment described above and importing your Certify key into that enclave. A signing subkey cannot be used to sign others' imported public keys.

Troubleshooting

• Use man gpg to understand GnuPG options and command-line flags.

• To get more information on potential errors, restart the gpg-agent process with debug output to the console with pkill gpg-agent; gpg-agent --daemon --no-detach -v -v --debug-level advanced --homedir ~/.gnupg.

• A lot of issues can be fixed by removing and reinserting YubiKey, or restarting the gpg-agent process.

• If you receive the error, Yubikey core error: no yubikey present - make sure the YubiKey is inserted correctly. It should blink once when plugged in.

• If you still receive the error, Yubikey core error: no yubikey present - you likely need to install newer versions of yubikey-personalize as outlined in Install software.

• If you see General key info..: [none] in card status output - import the public key.

• If you receive the error, gpg: decryption failed: secret key not available - you likely need to install GnuPG version 2.x. Another possibility is that there is a problem with the PIN, e.g., it is too short or blocked.

• If you receive the error, Yubikey core error: write error - YubiKey is likely locked. Install and run yubikey-personalization-gui to unlock it.

• If you receive the error, Key does not match the card's capability - you likely need to use 2048-bit RSA key sizes.

• If you receive the error, sign_and_send_pubkey: signing failed: agent refused operation - make sure you replaced ssh-agent with gpg-agent as noted above.

• If you still receive the error, sign_and_send_pubkey: signing failed: agent refused operation - run the command gpg-connect-agent updatestartuptty /bye

• If you still receive the error, sign_and_send_pubkey: signing failed: agent refused operation - edit ~/.gnupg/gpg-agent.conf to set a valid pinentry program path. gpg: decryption failed: No secret key could also indicate an invalid pinentry path

• If you still receive the error, sign_and_send_pubkey: signing failed: agent refused operation - it is a known issue that openssh 8.9p1 and higher has issues with YubiKey. Adding KexAlgorithms [email protected] to /etc/ssh/ssh_config often resolves the issue.

• If you receive the error, The agent has no identities from ssh-add -L, make sure you have installed and started scdaemon

• If you receive the error, Error connecting to agent: No such file or directory from ssh-add -L, the UNIX file socket that the agent uses for communication with other processes may not be set up correctly. On Debian, try export SSH_AUTH_SOCK="/run/user/$UID/gnupg/S.gpg-agent.ssh". Also see that gpgconf --list-dirs agent-ssh-socket is returning single path, to existing S.gpg-agent.ssh socket.

• If you receive the error, Permission denied (publickey), increase ssh verbosity with the -v flag and verify the public key from the card is being offered: Offering public key: RSA SHA256:abcdefg... cardno:00060123456. If it is, verify the correct user the target system - not the user on the local system. Otherwise, be sure IdentitiesOnly is not enabled for this host.

• If SSH authentication still fails - add up to 3 -v flags to the ssh command to increase verbosity.

• If it still fails, it may be useful to stop the background sshd daemon process service on the server (e.g. using sudo systemctl stop sshd) and instead start it in the foreground with extensive debugging output, using /usr/sbin/sshd -eddd. Note that the server will not fork and will only process one connection, therefore has to be restarted after every ssh test.

• If you receive the error, Please insert the card with serial number see Using Multiple Keys.

• If you receive the error, There is no assurance this key belongs to the named user or encryption failed: Unusable public key or No public key use gpg --edit-key to set trust to 5 = I trust ultimately

• If, when you try the above command, you get the error Need the secret key to do this - specify trust for the identity by using the trust-key [key ID] directive.

• If, when using a previously provisioned YubiKey on a new computer with pass, you see the following error on pass insert, you need to adjust the trust associated with the identity. See the previous note.

gpg: 0x0000000000000000: There is no assurance this key belongs to the named user
gpg: [stdin]: encryption failed: Unusable public key

• If you receive the error, gpg: 0x0000000000000000: skipped: Unusable public key, signing failed: Unusable secret key, or encryption failed: Unusable public key the Subkey may be expired and can no longer be used to encrypt nor sign messages. It can still be used to decrypt and authenticate, however.

• If the pinentry graphical dialog does not show and this error appears: sign_and_send_pubkey: signing failed: agent refused operation, install the dbus-user-session package and restart for the dbus user session to be fully inherited. This is because pinentry complains about No $DBUS_SESSION_BUS_ADDRESS found, falls back to curses but doesn't find the expected tty

• If, when you try the above --card-status command, you receive the error, gpg: selecting card failed: No such device or gpg: OpenPGP card not available: No such device, it's possible that the latest release of pcscd now requires polkit rules to operate properly. Create the following file to allow users in the wheel group to use the card. Restart pcscd to apply the new rules.

cat << EOF >  /etc/polkit-1/rules.d/99-pcscd.rules
polkit.addRule(function(action, subject) {
        if (action.id == "org.debian.pcsc-lite.access_card" &&
                subject.isInGroup("wheel")) {
                return polkit.Result.YES;
        }
});
polkit.addRule(function(action, subject) {
        if (action.id == "org.debian.pcsc-lite.access_pcsc" &&
                subject.isInGroup("wheel")) {
                return polkit.Result.YES;
        }
});
EOF

• If the public key is lost, follow this guide to recover it from YubiKey.

Alternative solutions

• vorburger/ed25519-sk.md - use YubiKey for SSH without GnuPG
• smlx/piv-agent - SSH and GnuPG agent which can be used with PIV devices
• keytotpm - use GnuPG with TPM systems

Additional resources

• Yubico - PGP
• Yubico - YubiKey Personalization
• A Visual Explanation of GPG Subkeys (2022)
• dhess/nixos-yubikey
• lsasolutions/makegpg
• Trammell Hudson - Yubikey (2020)
• Yubikey forwarding SSH keys (2019)
• GPG Agent Forwarding (2018)
• Stick with security: YubiKey, SSH, GnuPG, macOS (2018)
• PGP and SSH keys on a Yubikey NEO (2015)
• Offline GnuPG Master Key and Subkeys on YubiKey NEO Smartcard (2014)
• Creating the perfect GPG keypair (2013)
