ecomfe/vue-echarts

Vue ECharts

Vue.js component for Apache ECharts™.

Still using Vue 2? Read v7 docs here →

Installation & usage

npm

npm install echarts vue-echarts

Example

<template>
  <VChart class="chart" :option="option" />
</template>

<script setup>
import { use } from "echarts/core";
import { CanvasRenderer } from "echarts/renderers";
import { PieChart } from "echarts/charts";
import { TitleComponent, TooltipComponent, LegendComponent } from "echarts/components";
import VChart, { THEME_KEY } from "vue-echarts";
import { ref, provide } from "vue";

use([CanvasRenderer, PieChart, TitleComponent, TooltipComponent, LegendComponent]);

provide(THEME_KEY, "dark");

const option = ref({
  title: {
    text: "Traffic Sources",
    left: "center",
  },
  tooltip: {
    trigger: "item",
    formatter: "{a} <br/>{b} : {c} ({d}%)",
  },
  legend: {
    orient: "vertical",
    left: "left",
    data: ["Direct", "Email", "Ad Networks", "Video Ads", "Search Engines"],
  },
  series: [
    {
      name: "Traffic Sources",
      type: "pie",
      radius: "55%",
      center: ["50%", "60%"],
      data: [
        { value: 335, name: "Direct" },
        { value: 310, name: "Email" },
        { value: 234, name: "Ad Networks" },
        { value: 135, name: "Video Ads" },
        { value: 1548, name: "Search Engines" },
      ],
      emphasis: {
        itemStyle: {
          shadowBlur: 10,
          shadowOffsetX: 0,
          shadowColor: "rgba(0, 0, 0, 0.5)",
        },
      },
    },
  ],
});
</script>

<style scoped>
.chart {
  height: 400px;
}
</style>

On-demand importing

To keep your bundle size small, we recommend manually importing the components and charts you need from ECharts. To make this easier, we’ve created an import code generator. Simply paste your option code into the tool, and it will generate the exact import statements for you.

Try it →

But if you really want to import the whole ECharts bundle without having to import modules manually, just add this in your code:

import "echarts";

CDN

Drop <script> inside your HTML file and access the component via window.VueECharts.

<script src="https://cdn.jsdelivr.net/npm/[email protected]"></script>
<script src="https://cdn.jsdelivr.net/npm/[email protected]"></script>
<script src="https://cdn.jsdelivr.net/npm/[email protected]"></script>

const app = Vue.createApp(...)

// register globally (or you can do it locally)
app.component('VChart', VueECharts)

See more examples here.

Props

• init-options: object

  Optional chart init configurations. See echarts.init's opts parameter here →

  Injection key: INIT_OPTIONS_KEY.

• theme: string | object

  Theme to be applied. See echarts.init's theme parameter here →

  Injection key: THEME_KEY.

• option: object

  ECharts' universal interface. Modifying this prop triggers Vue ECharts to compute an update plan and call setOption. Read more here →

  Smart update

  • If you supply update-options (via prop or injection), Vue ECharts forwards it directly to setOption and skips the planner.
  • Manual setOption calls (only available when manual-update is true) behave like native ECharts, honouring only the per-call override you pass in and are not carried across re-initializations.
  • Otherwise, Vue ECharts analyses the change: removed objects become null, removed arrays become [] with replaceMerge, ID/anonymous deletions trigger replaceMerge, and risky changes fall back to notMerge: true.

• update-options: object

  Options for updating chart option. If supplied (or injected), Vue ECharts forwards it directly to setOption, skipping the smart update. See echartsInstance.setOption's opts parameter here →

  Injection key: UPDATE_OPTIONS_KEY.

• group: string

  Group name to be used in chart connection. See echartsInstance.group here →

• autoresize: boolean | { throttle?: number, onResize?: () => void } (default: false)

  Whether the chart should be resized automatically whenever its root is resized. Use the options object to specify a custom throttle delay (in milliseconds) and/or an extra resize callback function.

• loading: boolean (default: false)

  Whether the chart is in loading state.

• loading-options: object

  Configuration item of loading animation. See echartsInstance.showLoading's opts parameter here →

  Injection key: LOADING_OPTIONS_KEY.

• manual-update: boolean (default: false)

  Handy for performance-sensitive charts (large or high-frequency updates). When set to true, Vue only uses the option prop for the initial render; later prop changes do nothing and you must drive updates via setOption on a template ref. If the chart re-initializes (for example due to init-options changes, flipping manual-update, or a remount), the manual state is discarded and the chart is rendered again from the current option value.

Events

You can bind events with Vue's v-on directive.

<template>
  <VChart :option="option" @highlight="handleHighlight" />
</template>

[!NOTE] Only the .once event modifier is supported as other modifiers are tightly coupled with the DOM event system.

Vue ECharts support the following events:

• highlight →
• downplay →
• selectchanged →
• legendselectchanged →
• legendselected →
• legendunselected →
• legendselectall →
• legendinverseselect →
• legendscroll →
• datazoom →
• datarangeselected →
• timelinechanged →
• timelineplaychanged →
• restore →
• dataviewchanged →
• magictypechanged →
• geoselectchanged →
• geoselected →
• geounselected →
• axisareaselected →
• brush →
• brushEnd →
• brushselected →
• globalcursortaken →
• rendered →
• finished →
• Mouse events
  • click →
  • dblclick →
  • mouseover →
  • mouseout →
  • mousemove →
  • mousedown →
  • mouseup →
  • globalout →
  • contextmenu →
• ZRender events
  • zr:click
  • zr:mousedown
  • zr:mouseup
  • zr:mousewheel
  • zr:dblclick
  • zr:contextmenu

See supported events in the ECharts API reference →

Native DOM events

As Vue ECharts binds events to the ECharts instance by default, there is some caveat when using native DOM events. You need to prefix the event name with native: to bind native DOM events.

<template>
  <VChart @native:click="handleClick" />
</template>

Event handlers passed via attrs are reactive by default. Updating onClick, onZr:*, or onNative:* handlers will rebind them automatically.

Provide / inject

Vue ECharts provides provide/inject API for theme, init-options, update-options and loading-options to help configuring contextual options. eg. for theme you can use the provide API like this:

import { THEME_KEY } from "vue-echarts";
import { provide } from "vue";

provide(THEME_KEY, "dark");

// or provide a ref
const theme = ref("dark");
provide(THEME_KEY, theme);

// getter is also supported
provide(THEME_KEY, () => theme.value);

import { THEME_KEY } from 'vue-echarts'
import { computed } from 'vue'

export default {
  {
    provide: {
      [THEME_KEY]: 'dark'
    }
  }
}

// Or make injections reactive
export default {
  data() {
    return {
      theme: 'dark'
    }
  },
  provide() {
    return {
      [THEME_KEY]: computed(() => this.theme)
    }
  }
}

Methods

• setOption →
• getWidth →
• getHeight →
• getDom →
• getOption →
• resize →
• dispatchAction →
• convertToPixel →
• convertFromPixel →
• containPixel →
• getDataURL →
• getConnectedDataURL →
• clear →
• dispose →

[!NOTE] The following ECharts instance methods aren't exposed because their functionality is already provided by component props:

• showLoading / hideLoading: use the loading and loading-options props instead.
• setTheme: use the theme prop instead.

Slots

Vue ECharts supports three slot categories:

• Callback slots for tooltip.formatter.
• Callback slots for toolbox.feature.dataView.optionToContent.
• Optional #graphic slot (enabled by importing vue-echarts/graphic) for building option.graphic declaratively with G* components.

Callback slot naming convention (tooltip* / dataView*)

These naming rules apply to callback slots only. The graphic slot name is always #graphic.

• Slot names begin with tooltip/dataView, followed by hyphen-separated path segments to the target.
• Each segment corresponds to an option property name or an array index (for arrays, use the numeric index).
• The constructed slot name maps directly to the nested callback it overrides.

Example mappings:

• tooltip → option.tooltip.formatter
• tooltip-baseOption → option.baseOption.tooltip.formatter
• tooltip-xAxis-1 → option.xAxis[1].tooltip.formatter
• tooltip-series-2-data-4 → option.series[2].data[4].tooltip.formatter
• dataView → option.toolbox.feature.dataView.optionToContent
• dataView-media-1-option → option.media[1].option.toolbox.feature.dataView.optionToContent

The slot props correspond to the first parameter of the callback function.

<template>
  <VChart :option="chartOptions">
    <!-- Global `tooltip.formatter` -->
    <template #tooltip="params">
      <div v-for="(param, i) in params" :key="i">
        <span v-html="param.marker" />
        <span>{{ param.seriesName }}</span>
        <span>{{ param.value[0] }}</span>
      </div>
    </template>

    <!-- Tooltip on xAxis -->
    <template #tooltip-xAxis="params">
      <div>X-Axis : {{ params.value }}</div>
    </template>

    <!-- Data View Content -->
    <template #dataView="option">
      <table>
        <thead>
          <tr>
            <th v-for="(t, i) in option.dataset[0].source[0]" :key="i">
              {{ t }}
            </th>
          </tr>
        </thead>
        <tbody>
          <tr v-for="(row, i) in option.dataset[0].source.slice(1)" :key="i">
            <th>{{ row[0] }}</th>
            <td v-for="(v, i) in row.slice(1)" :key="i">{{ v }}</td>
          </tr>
        </tbody>
      </table>
    </template>
  </VChart>
</template>

[!NOTE] Slots take precedence over the corresponding callback defined in props.option.

Graphic slot

import { GGroup, GRect, GText } from "vue-echarts/graphic";

Available components:

• GGroup
• GRect
• GCircle
• GText
• GLine
• GPolyline
• GPolygon
• GImage
• GSector
• GRing
• GArc
• GBezierCurve
• GCompoundPath

Read more at ECharts option.graphic →

[!NOTE]

• Graphic element events additionally support dblclick and contextmenu.
• Event listeners support the .once modifier.
• #graphic overrides option.graphic. In manual-update mode, call chartRef.setOption(...) to apply changes.

<script setup lang="ts">
import { ref } from "vue";
import type { ElementEvent } from "echarts/core";

const option = {
  xAxis: { type: "category", data: ["Mon", "Tue", "Wed"] },
  yAxis: { type: "value" },
  series: [{ type: "line", data: [120, 200, 150] }],
};

const overlay = ref({ x: 84, y: 22 });

function onDrag(event: ElementEvent) {
  overlay.value.x = event.offsetX - 44;
  overlay.value.y = event.offsetY - 14;
}
</script>

<template>
  <VChart :option="option">
    <template #graphic>
      <GGroup id="drag-handle" :x="overlay.x" :y="overlay.y">
        <GRect :width="88" :height="28" :r="6" fill="#5470c6" draggable @drag="onDrag" />
        <GText
          :x="10"
          :y="8"
          :text="`x: ${Math.round(overlay.x)} y: ${Math.round(overlay.y)}`"
          text-fill="#fff"
        />
      </GGroup>
    </template>
  </VChart>
</template>

Static methods

Static methods can be accessed from echarts itself.

CSP: style-src or style-src-elem

If you are both enforcing a strict CSP that prevents inline <style> injection and targeting browsers that don't support the CSSStyleSheet() constructor, you need to manually include vue-echarts/style.css.

Migration to v8

[!NOTE] Please make sure to read the upgrade guide for ECharts 6 as well.

The following breaking changes are introduced in vue-echarts@8:

• Vue 2 support is dropped: If you still need to stay on Vue 2, use vue-echarts@7.

• Browser compatibility changes: We no longer provide compatibility for browsers without native class support. If you need to support legacy browsers, you must transpile the code to ES5 yourself.

• CSP entry point removed: The entry point vue-echarts/csp is removed. Use vue-echarts instead. You only need to manually include vue-echarts/style.css if you are both enforcing a strict CSP that prevents inline <style> injection and targeting browsers that don't support the CSSStyleSheet() constructor.

Local development

pnpm i
pnpm dev

Open http://localhost:5173 to see the demo.

For testing and CI details, see tests/TESTING.md.
