emqx/CocoaMQTT

CocoaMQTT

CocoaMQTT 2.x LTS: This branch contains the latest stable 2.x release line. It preserves the established CocoaAsyncSocket and Starscream transport architecture and receives compatibility, correctness, and security fixes. CocoaMQTT 3 development continues on master. See the 2.x maintenance policy and changelog.

MQTT v3.1.1 and v5.0 client library for iOS/macOS/tvOS/visionOS written with Swift 5. visionOS is supported through Swift Package Manager.

Both Swift Package Manager products can be used by Swift 6 applications and are covered by a Swift 6 compatibility check in CI.

Build

The package manifest requires Swift tools 5.7. Release CI validates the current Xcode toolchain and Swift 6 compatibility; it does not independently exercise the oldest Swift 5.7 compiler. CocoaPods uses Swift 5 language mode.

IOS Target: 12.0 or above OSX Target: 10.13 or above TVOS Target: 12.0 or above with Swift Package Manager or CocoaPods WebSockets; 10.0 or above with CocoaPods Core visionOS Target: 1.0 or above (Swift Package Manager only, compile-verified in CI)

Installation

Swift Package Manager

To integrate CocoaMQTT into your Xcode project using Swift Package Manager, follow these steps:

1. Open your project in Xcode.
2. Go to File > Swift Packages > Add Package Dependency.
3. Enter the repository URL: https://github.com/emqx/CocoaMQTT.git.
4. Choose the latest version or specify a version range.
5. Add the package to your target.

Swift Package Manager supports iOS, macOS, tvOS, and visionOS. Both the CocoaMQTT and CocoaMQTTWebSocket products are compile-verified against the visionOS SDK in CI.

At last, import "CocoaMQTT" to your project:

import CocoaMQTT

CocoaPods

To integrate CocoaMQTT into your Xcode project using CocoaPods, you need to modify you Podfile like the followings:

visionOS: CocoaPods installation is not currently supported because the transitive CocoaPods dependencies do not declare visionOS compatibility. Use Swift Package Manager for visionOS applications.

use_frameworks!

target 'Example' do
    pod 'CocoaMQTT'
end

Then, run the following command:

$ pod install

At last, import "CocoaMQTT" to your project:

import CocoaMQTT

Usage

Create a client to connect MQTT broker:

///MQTT 5.0
let clientID = "CocoaMQTT-" + String(ProcessInfo().processIdentifier)
let mqtt5 = CocoaMQTT5(clientID: clientID, host: "broker.emqx.io", port: 1883)

let connectProperties = MqttConnectProperties()
connectProperties.topicAliasMaximum = 0
connectProperties.sessionExpiryInterval = 0
connectProperties.receiveMaximum = 100
connectProperties.maximumPacketSize = 500
mqtt5.connectProperties = connectProperties

mqtt5.username = "test"
mqtt5.password = "public"
mqtt5.willMessage = CocoaMQTTMessage(topic: "/will", string: "dieout")
mqtt5.keepAlive = 60
mqtt5.delegate = self
mqtt5.connect()

///MQTT 3.1.1
let clientID = "CocoaMQTT-" + String(ProcessInfo().processIdentifier)
let mqtt = CocoaMQTT(clientID: clientID, host: "broker.emqx.io", port: 1883)
mqtt.username = "test"
mqtt.password = "public"
mqtt.willMessage = CocoaMQTTMessage(topic: "/will", string: "dieout")
mqtt.keepAlive = 60
mqtt.delegate = self
mqtt.connect()

Now you can use closures instead of CocoaMQTTDelegate:

mqtt.didReceiveMessage = { mqtt, message, id in
    print("Message received in topic \(message.topic) with payload \(message.string!)")
}

TLS

Publicly trusted server certificate

Enable TLS for a broker whose certificate is rooted in the Apple system trust store. CocoaMQTT verifies the certificate against the broker host by default.

mqtt.enableSSL = true

When connecting to an IP address while the certificate is issued to a DNS name, set the certificate name explicitly:

mqtt.tlsServerName = "broker.example.com"

Private CA or self-signed CA

Load a DER or PEM encoded CA certificate and decide whether the system trust store should also be accepted:

let data = try Data(contentsOf: Bundle.main.url(forResource: "broker-ca", withExtension: "crt")!)
guard let certificate = CocoaMQTTSocket.serverCertificate(from: data) else {
    fatalError("Invalid CA certificate")
}

mqtt.trustedServerCertificates = [certificate]
mqtt.usesSystemTrustStore = false // Trust only this CA.
mqtt.enableSSL = true

For advanced pinning or enterprise policies, set manuallyEvaluateTrust = true and implement the trust delegate method or didReceiveTrust closure. Never accept every certificate in production. The legacy allowUntrustCACertificate property only enables this manual evaluation; it does not safely trust a private CA by itself. Enabling manual evaluation without a trust callback or custom CA certificates rejects the connection.

Mutual TLS

For TCP, create CocoaMQTT or CocoaMQTT5 normally. For WSS, use the MQTT 3.1.1 WebSocket client or MQTT 5 WebSocket client example. CocoaMQTTWebSocket automatically uses Apple's URLSessionWebSocketTask on macOS 10.15, iOS 13, tvOS 13, visionOS 1, and later; no transport selection is required. Older supported OS versions automatically fall back to Starscream, where clientIdentity does not participate in the TLS handshake. Before calling connect(), apply either the PEM/DER configuration or PKCS#12 configuration. Both configuration functions work with MQTT 3.1.1 and MQTT 5 over TCP or WSS using URLSessionWebSocketTask, and configure the client identity and broker trust separately. Use their tlsServerName parameter when the connection host differs from the DNS name in the broker certificate.

certificateData accepts a DER certificate, a single PEM certificate, or a PEM bundle with the leaf first followed by its intermediates. privateKeyData accepts RSA PKCS#1 (RSA PRIVATE KEY) or unencrypted RSA PKCS#8 (PRIVATE KEY) input. Encrypted and EC PEM private keys are not currently supported. The intermediate array is flattened in the supplied order after any certificates in the leaf bundle; duplicates and a repeated leaf are ignored. Pass the leaf issuer first and normally exclude the root. It is independent from trustedServerCertificates, which validates the broker. The PEM/DER importer requires macOS 10.14, iOS 12, tvOS 12, or visionOS 1. This API applies to the built-in TCP transport and the Apple URLSessionWebSocketTask transport. The older Starscream WebSocket fallback does not support client identities. Custom transports can opt in by conforming to CocoaMQTTClientIdentityConfiguring.

URLSessionWebSocketTask client identities are scoped to the original WebSocket host and port. A client-certificate challenge is cancelled when no clientIdentity is configured or after a cross-host redirect.

The same high-level TLS settings—tlsServerName, trustedServerCertificates, usesSystemTrustStore, manuallyEvaluateTrust, and clientIdentity—are available to the built-in TCP and URLSessionWebSocketTask transports while preserving each transport's existing callback flow. sslSettings remains a TCP-only low-level escape hatch. Client identity and server trust remain independent. For WebSocket connections, tlsServerName overrides certificate identity verification; the WebSocket URL host still controls routing and TLS SNI.

PKCS#12 is a password-protected identity container supported by Apple's SecPKCS12Import. The example imports its identity and certificate chain, then uses the same clientIdentity API as the PEM/DER path.

Do not ship a production unencrypted PEM private key in the application bundle. Do not embed a PKCS#12 file together with its password either. Obtain credentials through secure provisioning or user input, and keep long-lived secrets in Keychain-backed storage. The file format itself does not determine App Store eligibility; use supported Security framework APIs and protect the private key.

MQTT over WebSocket

CocoaMQTT supports connecting to MQTT brokers over WebSocket.

If you integrated by Swift Package Manager, follow these steps:

1. Open your project in Xcode.
2. Go to File > Swift Packages > Add Package Dependency.
3. Enter the repository URL: https://github.com/emqx/CocoaMQTT.git.
4. Choose the latest version or specify a version range.
5. Add the CocoaMQTT and CocoaMQTTWebSocket products to your target.

Import the CocoaMQTT products into your project:

import CocoaMQTT
import CocoaMQTTWebSocket

If you integrated by CocoaPods, update your Podfile as follows and run pod install again:

use_frameworks!

target 'Example' do
    pod 'CocoaMQTT/WebSockets'
end

If you're using CocoaMQTT in a project with only a .podspec and no Podfile, e.g. in a module for React Native, add this line to your .podspec:

Pod::Spec.new do |s|
  ...
  s.dependency "CocoaMQTT/WebSockets"
end

Then, create an MQTT instance over WebSocket:

///MQTT 5.0
let websocket = CocoaMQTTWebSocket(uri: "/mqtt")
let mqtt5 = CocoaMQTT5(clientID: clientID, host: host, port: 8083, socket: websocket)
let connectProperties = MqttConnectProperties()
connectProperties.topicAliasMaximum = 0
// ...
mqtt5.connectProperties = connectProperties
// ...

_ = mqtt5.connect()

///MQTT 3.1.1
let websocket = CocoaMQTTWebSocket(uri: "/mqtt")
let mqtt = CocoaMQTT(clientID: clientID, host: host, port: 8083, socket: websocket)

// ...

_ = mqtt.connect()

The built-in Apple URLSessionWebSocketTask transport fails a receive when one WebSocket message reaches its 1 MiB buffering limit. Set a value greater than the largest expected WebSocket message before connecting, or use 0 to remove the limit:

let websocket = CocoaMQTTWebSocket(uri: "/mqtt")
websocket.maximumMessageSize = 10 * 1024 * 1024 + 1 // Accept up to 10 MiB.

This setting is independent of MQTT 5 Maximum Packet Size. It is not used by the older Starscream fallback, and custom connection builders must configure their own transport. Use 0 only when message sizes are otherwise controlled, because it permits unbounded buffering.

If you want to add additional custom header to the connection, you can use the following:

let websocket = CocoaMQTTWebSocket(uri: "/mqtt")
websocket.headers = [
            "x-api-key": "value"
        ]
        websocket.enableSSL = true

let mqtt = CocoaMQTT(clientID: clientID, host: host, port: 8083, socket: websocket)

// ...

_ = mqtt.connect()

If you want to connect using WebSocket Secure (wss), you can use the following example:

import CocoaMQTT
import CocoaMQTTWebSocket

class WebSocketManager {

    private var mqttClient: CocoaMQTT?
    var message: String = ""
    var token: String = ""

    func setupMQTTClient(with token: String) {
        let socket = CocoaMQTTWebSocket(uri: "/mqtt")
        socket.enableSSL = true
        mqttClient = CocoaMQTT(clientID: token, host: "host", port: 443, socket: socket)
        mqttClient?.delegate = self
    }

    func connect() {
        guard let mqttClient = mqttClient else { return }
        mqttClient.connect()
    }

}

extension WebSocketManager: CocoaMQTTDelegate {

    func mqtt(_ mqtt: CocoaMQTT, didPublishAck id: UInt16) {
        print("Published message with ID: \(id)")
    }

    func mqtt(_ mqtt: CocoaMQTT, didUnsubscribeTopics topics: [String]) {
        print("Unsubscribed from topics: \(topics)")
    }

    func mqttDidPing(_ mqtt: CocoaMQTT) {
        print("MQTT did ping")
    }

    func mqttDidReceivePong(_ mqtt: CocoaMQTT) {
        print("MQTT did receive pong")
    }

    func mqttDidDisconnect(_ mqtt: CocoaMQTT, withError err: (any Error)?) {
        print("Disconnected from MQTT broker with error: \(String(describing: err))")
    }

    func mqtt(_ mqtt: CocoaMQTT, didConnectAck ack: CocoaMQTTConnAck) {
        print("Connected to MQTT broker with acknowledgment: \(ack)")
    }

    func mqtt(_ mqtt: CocoaMQTT, didReceiveMessage message: CocoaMQTTMessage, id: UInt16) {
        if let messageString = message.string {
            DispatchQueue.main.async {
                self.message = messageString
            }
            print("Received message: \(messageString) on topic: \(message.topic)")
        }
    }

    func mqtt(_ mqtt: CocoaMQTT, didPublishMessage message: CocoaMQTTMessage, id: UInt16) {
        print("Published message: \(message.string ?? "") with ID: \(id)")
    }

    func mqtt(_ mqtt: CocoaMQTT, didSubscribeTopics success: NSDictionary, failed: [String]) {
        print("Subscribed to topics: \(success), failed to subscribe to: \(failed)")
    }

    func mqtt(_ mqtt: CocoaMQTT, didDisconnectWithError err: Error?) {
        print("Disconnected from MQTT broker with error: \(String(describing: err))")
    }

}

Large outgoing messages

Socket writes have a five-second deadline by default. Increase it before publishing large messages on slower connections:

mqtt.socketWriteTimeout = 30

Set socketWriteTimeout to 0 or a negative value to disable the deadline. This setting applies to MQTT 3.1.1 and MQTT 5 over the built-in TCP and WebSocket transports. It does not override the broker's packet-size limit or the MQTT 5 Server Maximum Packet Size. Prefer binary payloads or application-level chunking when messages are large; Base64 increases their encoded size.

Example App

You can follow the Example App to learn how to use it. But we need to make the Example App works first:

$ cd Examples

Then, open the Example.xcodeproj by Xcode and start it!

Dependencies

These third-party functions are used:

GCDAsyncSocket

• MqttCocoaAsyncSocket
• Starscream (legacy WebSocket fallback for older Apple OS versions)

LICENSE

MIT License (see LICENSE)
