yubikey-agent
yubikey-agent is a seamless ssh-agent for YubiKeys.
- Easy to use. A one-command setup, one environment variable, and it just runs in the background.
- Indestructible. Tolerates unplugging, sleep, and suspend. Never needs restarting.
- Compatible. Provides a public key that works with all services and servers.
- Secure. The key is generated on the YubiKey and can't be extracted. Every session requires the PIN, every login requires a touch. Setup takes care of PUK and management key.
Written in pure Go, it's based on github.com/go-piv/piv-go and golang.org/x/crypto/ssh.
Installation
macOS
brew install yubikey-agent
brew services start yubikey-agent
yubikey-agent -setup # generate a new key on the YubiKey
Then add the following line to your ~/.zshrc and restart the shell.
export SSH_AUTH_SOCK="$(brew --prefix)/var/run/yubikey-agent.sock"
Linux
Arch
On Arch, use the yubikey-agent package from the AUR.
git clone https://aur.archlinux.org/yubikey-agent.git
cd yubikey-agent && makepkg -si
systemctl daemon-reload --user
sudo systemctl enable --now pcscd.socket
systemctl --user enable --now yubikey-agent
export SSH_AUTH_SOCK="${XDG_RUNTIME_DIR}/yubikey-agent/yubikey-agent.sock"
NixOS / nixpkgs
On NixOS unstable and 20.09 (unreleased at time of writing), you can
add this to your /etc/nixos/configuration.nix:
services.yubikey-agent.enable = true;
This installs yubikey-agent and sets up a systemd unit to start
yubikey-agent for you.
On other systems using nix, you can also install from nixpkgs:
nix-env -iA nixpkgs.yubikey-agent
This installs the software but does not install a systemd unit. You
will have to set up service management manually (see below).
Other systemd-based Linux systems
On other systemd-based Linux systems, follow the manual installation instructions.
Packaging contributions are very welcome.
FreeBSD
Install the yubikey-agent port.
Windows
Windows support is currently WIP.
Advanced topics
Coexisting with other ssh-agents
It's possible to configure ssh-agents on a per-host basis.
For example to only use yubikey-agent when connecting to example.com, you'd add the following lines to ~/.ssh/config instead of setting SSH_AUTH_SOCK.
Host example.com
IdentityAgent /usr/local/var/run/yubikey-agent.sock
To use yubikey-agent for all hosts but one, you'd add the following lines instead. In both cases, you can keep using ssh-add to interact with the main ssh-agent.
Host example.com
IdentityAgent $SSH_AUTH_SOCK
Host *
IdentityAgent /usr/local/var/run/yubikey-agent.sock
Conflicts with gpg-agent and Yubikey Manager
yubikey-agent takes a persistent transaction so the YubiKey will cache the PIN after first use. Unfortunately, this makes the YubiKey PIV and PGP applets unavailable to any other applications, like gpg-agent and Yubikey Manager. Our upstream is investigating solutions to this annoyance.
If you need yubikey-agent to release its lock on the YubiKey, send it a hangup signal or use ssh-add's "delete all identities" flag. Likewise, you might have to kill gpg-agent after use for it to release its own lock.
ssh-add -D
This does not affect the FIDO2 functionality.
Changing PIN and PUK
Use YubiKey Manager to change the PIN and PUK.
yubikey-agent -setup sets the PUK to the same value as the PIN.
killall -HUP yubikey-agent
ykman piv access change-pin
ykman piv access change-puk
Unblocking the PIN with the PUK
If the wrong PIN is entered incorrectly three times in a row, YubiKey Manager can be used to unlock it.
yubikey-agent -setup sets the PUK to the same value as the PIN.
ykman piv access unblock-pin
If the PUK is also entered incorrectly three times, the key is permanently irrecoverable. The YubiKey PIV applet can be reset with yubikey-agent --setup --really-delete-all-piv-keys.
Manual setup and technical details
yubikey-agent only officially supports YubiKeys set up with yubikey-agent -setup.
In practice, any PIV token with an RSA or ECDSA P-256 key and certificate in the Authentication slot should work, with any PIN and touch policy. Simply skip the setup step and use ssh-add -L to view the public key.
yubikey-agent -setup generates a random Management Key and stores it in PIN-protected metadata.
Alternatives
Native FIDO2
Recent versions of OpenSSH support using FIDO2 tokens directly. Since those are their own key type, they require server-side support, which has only recently reached Debian and GitHub.
FIDO2 SSH keys by default don't require a PIN, and require a private key file, acting more like a second factor. yubikey-agent keys always require PINs and can be ported to a different machine simply by plugging in the YubiKey. (With recent enough tokens such as a YubiKey 5, a similar setup can be achieved by using the verify-required and resident options, after setting a FIDO2 PIN with YubiKey Manager: the private key file will still be required, but it can be regenerated from the YubiKey.)
gpg-agent
gpg-agent can act as an ssh-agent, and it can use keys stored on the PGP applet of a YubiKey.
This requires a finicky setup process dealing with PGP keys and the gpg UX, and seems to lose track of the YubiKey and require restarting all the time. Frankly, I've also had enough of PGP and GnuPG.
ssh-agent and PKCS#11
ssh-agent can load PKCS#11 applets to interact with PIV tokens directly. There are two third-party PKCS#11 providers for YubiKeys (OpenSC and ykcs11) and one that ships with macOS (man 8 ssh-keychain).
The UX of this solution is poor: it requires calling ssh-add to load the PKCS#11 module and to unlock it with the PIN (as the agent has no way of requesting input from the client during use, a limitation that yubikey-agent handles with pinentry), and needs manual reloading every time the YubiKey is unplugged or the machine goes to sleep.
The ssh-agent that ships with macOS (which is pretty cool, as it starts on demand and is preconfigured in the environment) also has restrictions on where the .so modules can be loaded from. It can see through symlinks, so a Homebrew-installed /usr/local/lib/libykcs11.dylib won't work, while a hard copy at /usr/local/lib/libykcs11.copy.dylib will.
/usr/lib/ssh-keychain.dylib works out of the box, but only with RSA keys. Key generation is undocumented.
Secretive and SeKey
Secretive and SeKey are similar projects that use the Secure Enclave to store the private key and Touch ID for authorization. The Secure Enclave has so far a worse security track record compared to YubiKeys.
pivy-agent
pivy-agent is part of a suite of tools to work with PIV tokens. It's similar to yubikey-agent, and inspired its design.
The main difference is that it requires unlocking via ssh-add -X rather than using a graphical pinentry, and it caches the PIN in memory rather than relying on the device PIN policy. It's also written in C.
yubikey-agent also aims to provide an even smoother setup process.
