GokuMohandas/attentional-interfaces

Interpretability via Attentional and Memory-based Interfaces Using TensorFlow

A closer look at the reasoning inside your deep networks.

TLDR: This post will serve as a gentle introduction to attentional and memory-based interfaces in deep neural architectures using TensorFlow. Incorporation of attention mechanisms is very simple and can improve transparency interpretability in our complex models. We will conclude with extensions and caveats of the interfaces. The intended audience for this notebook are developers and researchers who have some basic understanding of Tensorflow and fundamental deep learning concepts. Check out this post for a nice introduction to Tensorflow. Note: This code has been written for TensorFlow v1.0.0

Before running the Jupyter notebook attention.ipynb, you'll need to ensure that your machine is set up to run TensorFlow and install a handful of helpful additional libraries.

Setup

1. Download this entire repo from GitHub

2. Open your terminal and use cd to navigate into the top directory of the repo on your machine

3. Unzip the processed reviews data by entering the following inside the data directory.

unzip processed_reviews.zip

Now, set up your environment by using the Dockerfile included with this repo (option A) or configuring it manually (option B).

Option A: use the Dockerfile configured for this notebook

(Note: For GPU versions, etc. check out TensorFlow's Docker repo.)

4. After downloading this repo to your machine, open your terminal and use cd to navigate to the directory that contains Dockerfile.cpu.

5. To build the Dockerfile, enter

docker build -t dockerfile_cpu -f dockerfile.cpu .

If you get a permissions error on running this command, you may need to run it with sudo:

sudo  build -t dockerfile_cpu -f dockerfile.cpu .

6. Run Docker from the Dockerfile you've just built

docker run -it -p 8888:8888 -p 6006:6006 dockerfile_cpu bash

or

sudo docker run -it -p 8888:8888 -p 6006:6006 dockerfile_cpu bash

if you run into permission problems.

7. Launch Jupyter by entering

jupyter notebook

and, using your browser, navigate to the URL shown in the terminal output (usually http://localhost:8888/)

Option B: set up environment manually on local machine

For instructions on installing TensorFlow, please see TensorFlow's platform-specific installation instructions.

Required:
python 3.3+
pip 9.0.1 (sudo easy_install pip)
virtualenv (pip install virtualenv)
Optional: CUDA enabled GPU (explicity define cpu components (embedding, etc.)

4. Enter the attention directory in your terminal and enter the following commands

make venv
source oreilly-attention-venv/bin/activate
make load-data
ipython3 notebook attention.ipynb

5. Launch Jupyter by entering

jupyter notebook

and, using your browser, navigate to the URL shown in the terminal output (usually http://localhost:8888/)
