MetaCubeX/ClashMetaForAndroid

Clash Meta for Android

A Graphical user interface of Clash.Meta for Android

Feature

Feature of Clash.Meta

Requirement

• Android 5.0+ (minimum)
• Android 7.0+ (recommend)
• armeabi-v7a , arm64-v8a, x86 or x86_64 Architecture

Build

1. Update submodules

   git submodule update --init --recursive


2. Install OpenJDK 11, Android SDK, CMake and Golang

3. Create local.properties in project root with

   sdk.dir=/path/to/android-sdk


4. (Optional) Custom app package name. Add the following configuration to local.properties.

   # config your ownn applicationId, or it will be 'com.github.metacubex.clash'
   custom.application.id=com.my.compile.clash
   # remove application id suffix, or the applicaion id will be 'com.github.metacubex.clash.alpha'
   remove.suffix=true



5. Create signing.properties in project root with

   keystore.path=/path/to/keystore/file
   keystore.password=<key store password>
   key.alias=<key alias>
   key.password=<key password>


6. Build

   ./gradlew app:assembleAlphaRelease


Automation

APP package name is com.github.metacubex.clash.meta

• Toggle Clash.Meta service status
  • Send intent to activity com.github.kr328.clash.ExternalControlActivity with action com.github.metacubex.clash.meta.action.TOGGLE_CLASH
• Start Clash.Meta service
  • Send intent to activity com.github.kr328.clash.ExternalControlActivity with action com.github.metacubex.clash.meta.action.START_CLASH
• Stop Clash.Meta service
  • Send intent to activity com.github.kr328.clash.ExternalControlActivity with action com.github.metacubex.clash.meta.action.STOP_CLASH
• Import a profile
  • URL Scheme clash://install-config?url=<encoded URI> or clashmeta://install-config?url=<encoded URI>

Contribution and Project Maintenance

Meta Kernel

• CMFA uses the kernel from android-real branch under MetaCubeX/Clash.Meta, which is a merge of the main Alpha branch and android-open.
  • If you want to contribute to the kernel, make PRs to Alpha branch of the Meta kernel repository.
  • If you want to contribute Android-specific patches to the kernel, make PRs to android-open branch of the Meta kernel repository.

Maintenance

• When MetaCubeX/Clash.Meta kernel is updated to a new version, the Update Dependencies actions in this repo will be triggered automatically.
  • It will pull the new version of the meta kernel, update all the golang dependencies, and create a PR without manual intervention.
  • If there is any compile error in PR, you need to fix it before merging. Alternatively, you may merge the PR directly.
• Manually triggering Build Pre-Release actions will compile and publish a PreRelease version.
• Manually triggering Build Release actions will compile, tag and publish a Release version.
  • You must fill the blank Release Tag with the tag you want to release in the format of v1.2.3.
  • versionName and versionCode in build.gradle.kts will be automatically bumped to the tag you filled above.
