nicobailon/visual-explainer

visual-explainer

An agent skill that turns complex terminal output into styled HTML pages you actually want to read.

Ask your agent to explain a system architecture, review a diff, or compare requirements against a plan. Instead of ASCII art and box-drawing tables, it generates a self-contained HTML page and opens it in your browser.

> draw a diagram of our authentication flow
> /diff-review
> /plan-review ~/docs/refactor-plan.md

https://github.com/user-attachments/assets/55ebc81b-8732-40f6-a4b1-7c3781aa96ec

Why

Every coding agent defaults to ASCII art when you ask for a diagram. Box-drawing characters, monospace alignment hacks, text arrows. It works for trivial cases, but anything beyond a 3-box flowchart turns into an unreadable mess.

Tables are worse. Ask the agent to compare 15 requirements against a plan and you get a wall of pipes and dashes that wraps and breaks in the terminal. The data is there but it's painful to read.

This skill fixes that. Real typography, dark/light themes, interactive Mermaid diagrams with zoom and pan. No build step, no dependencies beyond a browser.

Install

Claude Code (marketplace):

/plugin marketplace add nicobailon/visual-explainer
/plugin install visual-explainer@visual-explainer-marketplace

Note: Claude Code plugins namespace commands as /visual-explainer:command-name.

Pi:

pi install git:github.com/nicobailon/visual-explainer

Or from a local checkout:

git clone --depth 1 https://github.com/nicobailon/visual-explainer.git
pi install ./visual-explainer

The package manifest advertises the canonical skill, command templates, and Pi tool:

"pi": {
  "extensions": ["./plugins/visual-explainer/extension.ts"],
  "skills": ["./plugins/visual-explainer"],
  "prompts": ["./plugins/visual-explainer/commands"]
}

The Pi extension registers one native visual_explainer tool. Use action: "prepare" to plan a visual explanation after generating or reviewing a substantial plan, architecture, diff, or implementation, and action: "render" to write complete HTML pages to ~/.agent/diagrams/. /generate-web-diagram remains the bundled prompt template command.

If you previously used the old curl/manual installer, remove those copied files before using pi install; otherwise Pi will report skill and prompt conflicts because the user-level copies shadow the package resources:

rm -rf ~/.pi/agent/skills/visual-explainer
rm -f ~/.pi/agent/prompts/{diff-review,fact-check,generate-slides,generate-visual-plan,generate-web-diagram,plan-review,project-recap}.md
rm -f ~/.pi/agent/prompts/s[h]are*.md

The legacy installer still works if you prefer copied skill and prompt files over package management, but it does not install the native Pi tool:

curl -fsSL https://raw.githubusercontent.com/nicobailon/visual-explainer/main/install-pi.sh | bash

Codex CLI:

git clone --depth 1 https://github.com/nicobailon/visual-explainer.git /tmp/visual-explainer

mkdir -p ~/.codex/skills ~/.codex/prompts
cp -R /tmp/visual-explainer/plugins/visual-explainer ~/.codex/skills/visual-explainer

# Optional, only if your Codex build supports prompt templates:
cp /tmp/visual-explainer/plugins/visual-explainer/commands/*.md ~/.codex/prompts/

rm -rf /tmp/visual-explainer

Invoke with $visual-explainer or ask Codex to use the visual-explainer skill. If prompts are installed and supported, use /prompts:diff-review, /prompts:plan-review, etc.

OpenCode/opencode:

git clone --depth 1 https://github.com/nicobailon/visual-explainer.git /tmp/visual-explainer

mkdir -p ~/.config/opencode/skill ~/.config/opencode/command
cp -R /tmp/visual-explainer/plugins/visual-explainer ~/.config/opencode/skill/visual-explainer

# Optional command templates:
cp /tmp/visual-explainer/plugins/visual-explainer/commands/*.md ~/.config/opencode/command/

rm -rf /tmp/visual-explainer

Activate it by asking OpenCode to use the visual-explainer skill. Command-template behavior depends on the installed OpenCode/opencode build.

Cursor:

Add configs/cursor/visual-explainer.mdc to your Cursor rules, or copy its contents into the project rules UI. This is rules-based guidance that points Cursor at the canonical skill; it does not claim native Agent Skills support.

OpenClaw:

Use configs/openclaw/AGENTS.md as lightweight project guidance and copy or reference plugins/visual-explainer/ as the canonical skill source. No native OpenClaw plugin adapter is included.

Commands

The agent also kicks in automatically when it's about to dump a complex table in the terminal (4+ rows or 3+ columns) — it renders HTML instead.

Slide Deck Mode

Any command that produces a scrollable page supports --slides to generate a slide deck instead:

/diff-review --slides
/project-recap --slides 2w

https://github.com/user-attachments/assets/342d3558-5fcf-4fb2-bc03-f0dd5b9e35dc

How It Works

.claude-plugin/
├── plugin.json           ← marketplace identity
└── marketplace.json      ← plugin catalog
plugins/
└── visual-explainer/
    ├── .claude-plugin/
    │   └── plugin.json   ← plugin manifest
    ├── SKILL.md           ← workflow + design principles
    ├── extension.ts       ← Pi native tool
    ├── commands/          ← slash commands
    ├── references/        ← agent reads before generating
    │   ├── css-patterns.md   (layouts, animations, theming)
    │   ├── libraries.md      (Mermaid, Chart.js, fonts)
    │   ├── responsive-nav.md (sticky TOC for multi-section pages)
    │   └── slide-patterns.md (slide engine, transitions, presets)
    └── templates/         ← reference templates with different palettes
        ├── architecture.html
        ├── mermaid-flowchart.html
        ├── data-table.html
        └── slide-deck.html

Output: ~/.agent/diagrams/filename.html → opens in browser. In Pi package installs, agents can offer visual_explainer with action: "prepare" after generating or reviewing a substantial plan, architecture, diff, or implementation when a visual explanation would help, then call it with action: "render" as the final write/open step.

The skill routes to the right approach automatically: Mermaid for flowcharts and diagrams, CSS Grid for architecture overviews, HTML tables for data, Chart.js for dashboards.

Limitations

• Generated HTML is portable and self-contained, but auto-opening depends on the harness, browser access, and sandbox rules.
• All harnesses write visual output to ~/.agent/diagrams/ unless the user asks for a different path.
• Switching OS theme requires a page refresh for Mermaid SVGs.
• Results vary by model capability.

Credits

Borrows ideas from Anthropic's frontend-design skill and interface-design.

License

MIT
