nicolaka/netshoot

netshoot: a Docker + Kubernetes network trouble-shooting swiss-army container

                    dP            dP                           dP
                    88            88                           88
88d888b. .d8888b. d8888P .d8888b. 88d888b. .d8888b. .d8888b. d8888P
88'  `88 88ooood8   88   Y8ooooo. 88'  `88 88'  `88 88'  `88   88
88    88 88.  ...   88         88 88    88 88.  .88 88.  .88   88
dP    dP `88888P'   dP   `88888P' dP    dP `88888P' `88888P'   dP

Quick Start

# Share a running container's network namespace
docker run -it --net container:<container_name> nicolaka/netshoot

# Use the host's network namespace
docker run -it --net host nicolaka/netshoot

# Ephemeral debug container in Kubernetes
kubectl debug <pod> -it --image=nicolaka/netshoot

Why netshoot

Docker and Kubernetes isolate every container in its own network namespace — its own interfaces, routes, and IP stack. netshoot exploits the fact that you can enter any namespace without modifying what's running inside it.

• Debug a container without installing tools into its image
• Debug a host without installing anything on it
• Debug in Kubernetes as an ephemeral container, throwaway pod, or sidecar

Launch Options

Docker

# Enter a specific container's namespace
docker run -it --net container:<container_name> nicolaka/netshoot

# Enter the host's namespace
docker run -it --net host nicolaka/netshoot

# Enter a Docker bridge network's namespace via nsenter
docker run -it --rm \
  -v /var/run/docker/netns:/var/run/docker/netns \
  --privileged \
  nicolaka/netshoot
# then: nsenter --net=/var/run/docker/netns/<id> sh

Docker Compose

version: "3.6"
services:
  netshoot:
    image: nicolaka/netshoot
    depends_on:
      - nginx
    command: tcpdump -i eth0 -w /data/nginx.pcap
    network_mode: service:nginx        # shares nginx's network namespace
    volumes:
      - $PWD/data:/data

  nginx:
    image: nginx:alpine
    ports:
      - 80:80

Kubernetes

# Ephemeral container in a running pod (non-destructive)
kubectl debug <pod> -it --image=nicolaka/netshoot

# Throwaway pod
kubectl run tmp-shell --rm -i --tty --image nicolaka/netshoot

# Throwaway pod on the host's network namespace
kubectl run tmp-shell --rm -i --tty \
  --overrides='{"spec": {"hostNetwork": true}}' \
  --image nicolaka/netshoot

# Sidecar in a Deployment — see configs/netshoot-sidecar.yaml
kubectl apply -f configs/netshoot-sidecar.yaml
kubectl exec -it <pod> -c netshoot -- zsh

kubectl plugin

The kubectl-netshoot plugin wraps the above into ergonomic subcommands:

kubectl netshoot run tmp-shell          # throwaway pod
kubectl netshoot debug my-pod           # ephemeral container
kubectl netshoot debug node/my-node     # node debug session

---

Troubleshooting Scenarios

DNS resolution failures

Pod can't reach a service by name, or DNS lookups are slow/timing out.

# 1. Check what DNS server the container is using
cat /etc/resolv.conf

# 2. Resolve a Kubernetes service name
drill kubernetes.default.svc.cluster.local

# 3. Query the cluster DNS directly (bypass resolv.conf)
drill @10.96.0.10 kubernetes.default.svc.cluster.local

# 4. Capture DNS traffic to see what's actually going over the wire
tcpdump -i eth0 -n port 53

# 5. Check for NXDOMAIN vs timeout — different root causes
drill -V 5 my-service.my-namespace.svc.cluster.local

---

Latency, packet loss, and throughput

Intermittent timeouts, high p99, or slow transfers between pods or nodes.

# Visual traceroute with latency per hop
mtr --report --report-cycles 10 <destination>

# Or use trippy for an interactive TUI traceroute
trip <destination>

# Measure raw TCP throughput between two pods:
# On pod A (server):
iperf3 -s

# On pod B (client):
iperf3 -c <pod-A-ip> -t 30

# Measure UDP throughput and jitter
iperf3 -c <pod-A-ip> -u -b 1G

---

Service reachability and firewall rules

Can pod A reach pod B on port X? Is something blocking traffic?

# Quick TCP connectivity check
nc -vz <host> <port>

# Scan a port range across a host
nmap -p 8080-8090 <host>

# Trace the full TCP path to a port (combines traceroute + TCP)
tcptraceroute <host> <port>

# Send a single TCP/UDP packet with custom payload
nping --tcp -p 443 <host>

# Check active connections and listening ports
ss -tulnp

---

Packet capture and deep inspection

Need to see the actual bytes — wrong headers, unexpected resets, TLS issues.

# Capture traffic on eth0 to a file
tcpdump -i eth0 -w /tmp/capture.pcap

# Live capture filtered by host and port
tcpdump -i eth0 -nn host <ip> and port 80

# Grep for a string in live traffic (e.g. HTTP Host headers)
ngrep -q -W byline "Host:" port 80

# Interactive TUI for live capture or reading a pcap
termshark -i eth0
termshark -r /tmp/capture.pcap

# Full protocol dissection with tshark
tshark -i eth0 -Y "http.request" -T fields -e http.host -e http.request.uri

---

gRPC and HTTP load testing

Validate a gRPC endpoint, hammer an HTTP service, check TLS.

# List gRPC services on a server
grpcurl <host>:<port> list

# Call a gRPC method
grpcurl -d '{"key":"value"}' <host>:<port> my.Service/Method

# Make an HTTP request with verbose output
http GET https://<host>/api/v1/items

# Load test: 100 QPS for 30s
fortio load -qps 100 -t 30s http://<host>/api/v1/items

# Check TLS certificate details
openssl s_client -connect <host>:443 </dev/null | openssl x509 -noout -text

---

Routing and ARP

Wrong route selected, ARP table stale, traffic going out the wrong interface.

# Show routing table
ip route show

# Show ARP/neighbour table
ip neigh show

# Trace which route a packet would take
ip route get <destination-ip>

# Show interface stats (drops, errors)
ip -s link show eth0

# Test ICMP reachability to multiple hosts at once
fping -a -g 10.0.0.1 10.0.0.254

---

SMTP testing

Validate mail relay, test TLS, confirm AUTH works.

swaks \
  --to [email protected] \
  --from [email protected] \
  --server mail.example.com:587 \
  --tls \
  --auth PLAIN \
  --auth-user [email protected] \
  --auth-password s3cr3t \
  --header "Subject: netshoot probe" \
  --body "SMTP connectivity test"

---

Container and network performance overview

# Top-like view of container CPU, memory, net, and I/O
docker run -it --rm \
  -v /var/run/docker.sock:/var/run/docker.sock \
  nicolaka/netshoot ctop

---

Included Tools

Network analysis

DNS

Performance

Security & scanning

HTTP / gRPC / SMTP

Routing & interfaces

Kubernetes / Calico

Debug & tracing

---

Contributing

PRs are welcome. Before opening one:

• Explain why the tool isn't redundant with something already in the image
• Update the Dockerfile to add the package, or add a get_<tool>() function to build/fetch_binaries.sh for pre-built binaries
• Add the tool to the Included Tools table and a Troubleshooting Scenarios block with a real workflow
• For multi-platform tools, confirm linux/amd64 and linux/arm64 both work
