About
RAWGraphs is an open web tool to create custom vector-based visualizations on top of the amazing d3.js library.
It has been developed by DensityDesign Research Lab (Politecnico di Milano), Calibro and INMAGIK.
Primarily conceived as a tool for designers and vis geeks, RAWGraphs aims at providing a missing link between spreadsheet applications (e.g., LibreOffice Calc, Microsoft Excel, Apple Numbers, Google Docs) and vector graphics editors (e.g., Inkscape, Adobe Illustrator).
RAWGraphs works with tabular data (e.g., spreadsheets and comma-separated values) as well as with copied-and-pasted texts from other applications. Based on the SVG format, visualizations can be easily edited with vector graphics applications for further refinements or directly embedded into web pages.
Knowing the need to work with sensitive information, the data injected into RAWGraphs is processed only by the web browser: no server-side operations or storages are performed. No one will see, touch or copy your data!
RAWGraphs is also highly customizable and extensible, accepting new custom layouts defined by users. For more information about adding or editing layouts, see the Developer Guide.
- App page: app.rawgraphs.io
- Project official page: rawgraphs.io
- Google group: groups.google.com/forum/#!forum/densitydesign-raw
Usage
The easiest way to use RAWGraphs is by accessing the most updated version on the official app page. However, RAWGraphs can also run locally on your machine: see the installation instructions below for know-how.
Installation
If you want to run your instance of RAWGraphs locally on your machine, be sure you have the following requirements installed. The following guide is for intermediate users (you will have to open your console and type some commands, it's better if you know what you are doing).
Requirements
If you want to run your instance of RAWGraphs locally on your machine, be sure you have the following requirements installed.
- Git (it could be used through the interface of GitHub Desktop)
- Node.js (latest tested: 23.6.1)
- Yarn (latest tested: 1.22)
Instructions (macOS)
In the terminal, navigate to the folder where you want to install the app and clone the RAWGraphs-app GitHub repository:
git clone https://github.com/rawgraphs/rawgraphs-app.git
Browse the folder containing the repository:
cd rawgraphs-app
Install the needed dependencies through Yarn:
yarn install
Now you can run the project locally in development mode with the command:
yarn start
Ensure that you're using the legacy OpenSSL providers (to be updated):
export NODE_OPTIONS=--openssl-legacy-provider
You can also build your own version and upload it on your server by running the command:
yarn build
Contributing
Want to contribute to RAWGraphs's development? You are more than welcome! Start by forking the repository (the "Fork" button at the top-right corner of this page) and follow the instructions above to clone it and install dependencies. Then you can use Github's issues and pull requests to discuss and share your work.
You will need to sign a Contributor License Agreement (CLA) before submitting. We adopted CLA to be sure that the project will remain open source. For more information, write us: [email protected].
Publications / Citing RAWGraphs
If you have found RAWGraphs helpful in your research, or if you want to reference it in your work, please consider citing the paper we presented at CHItaly 2017.
you can read the full article in Green Open Access at the following link:
RAWGraphs: A Visualisation Platform to Create Open Outputs
Cite RAWGraphs:
Mauri, M., Elli, T., Caviglia, G., Uboldi, G., & Azzi, M. (2017). RAWGraphs: A Visualisation Platform to Create Open Outputs. In Proceedings of the 12th Biannual Conference on Italian SIGCHI Chapter (p. 28:1–28:5). New York, NY, USA: ACM. https://doi.org/10.1145/3125571.3125585
Bibtex:
@inproceedings{Mauri:2017:RVP:3125571.3125585,
author = {Mauri, Michele and Elli, Tommaso and Caviglia, Giorgio and Uboldi, Giorgio and Azzi, Matteo},
title = {RAWGraphs: A Visualisation Platform to Create Open Outputs},
booktitle = {Proceedings of the 12th Biannual Conference on Italian SIGCHI Chapter},
series = {CHItaly '17},
year = {2017},
isbn = {978-1-4503-5237-6},
location = {Cagliari, Italy},
pages = {28:1--28:5},
articleno = {28},
numpages = {5},
url = {http://doi.acm.org/10.1145/3125571.3125585},
doi = {10.1145/3125571.3125585},
acmid = {3125585},
publisher = {ACM},
address = {New York, NY, USA},
keywords = {Visualization tools, data visualization, open output, visual interface},
}
License
RAWGraphs is provided under the Apache License 2.0:
Copyright (c), 2013-2021 DensityDesign Lab, Calibro, INMAGIK <[email protected]>
Licensed under the Apache License, Version 2.0 (the "License"); you may not use this file except in compliance with the License.
You may obtain a copy of the License at
http://www.apache.org/licenses/LICENSE-2.0
Unless required by applicable law or agreed to in writing, software distributed under the License is distributed on an "AS IS" BASIS, WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
See the License for the specific language governing permissions and limitations under the License.
