thingsboard/thingsboard-python-client-sdk

pip3 install tb-mqtt-client

from tb_device_mqtt import TBDeviceMqttClient, TBPublishInfo


telemetry = {"temperature": 41.9, "enabled": False, "currentFirmwareVersion": "v1.2.2"}

# Initialize ThingsBoard client
client = TBDeviceMqttClient("127.0.0.1", username="A1_TEST_TOKEN")
# Connect to ThingsBoard
client.connect()
# Sending telemetry without checking the delivery status
client.send_telemetry(telemetry)
# Sending telemetry and checking the delivery status (QoS = 1 by default)
result = client.send_telemetry(telemetry)
# get is a blocking call that awaits delivery status
success = result.get() == TBPublishInfo.TB_ERR_SUCCESS
# Disconnect from ThingsBoard
client.disconnect()

from tb_device_mqtt import TBDeviceMqttClient
import socket


client = TBDeviceMqttClient(socket.gethostname())
client.connect(tls=True,
               ca_certs="mqttserver.pub.pem",
               cert_file="mqttclient.nopass.pem")
client.disconnect()

from tb_device_http import TBHTTPDevice


client = TBHTTPDevice('https://thingsboard.example.com', 'secret-token')
client.connect()
client.send_telemetry({'temperature': 41.9}, queued=False)

import time
from tb_device_mqtt import TBDeviceMqttClient


def on_attributes_change(result, *args):
    print(result)


client = TBDeviceMqttClient("127.0.0.1", username="A1_TEST_TOKEN")
client.connect()
client.subscribe_to_attribute("uploadFrequency", on_attributes_change)
client.subscribe_to_all_attributes(on_attributes_change)
while True:
    time.sleep(1)

import time
from tb_device_http import TBHTTPClient


client = TBHTTPClient('https://thingsboard.example.com', 'secret-token')

def callback(data):
    print(data)
    # ...

# Subscribe
client.subscribe('attributes', callback)
while True:
    time.sleep(1)

from tb_device_mqtt import TBDeviceMqttClient, TBPublishInfo
import time


telemetry_with_ts = {"ts": int(round(time.time() * 1000)), "values": {"temperature": 42.1, "humidity": 70}}
client = TBDeviceMqttClient("127.0.0.1", username="A1_TEST_TOKEN")
# we set maximum amount of messages sent to send them at the same time. it may stress memory but increases performance
client.max_inflight_messages_set(100)
client.connect()
results = []
result = True
for i in range(0, 100):
    results.append(client.send_telemetry(telemetry_with_ts))
for tmp_result in results:
    result &= tmp_result.get() == TBPublishInfo.TB_ERR_SUCCESS
print("Result " + str(result))
client.disconnect()

import time
from tb_device_mqtt import TBDeviceMqttClient


IS_ATTR_RECEIVED = False

def on_attributes_change(result, *args):
    global IS_ATTR_RECEIVED

    print('Received attribute: ', result)
    IS_ATTR_RECEIVED = True


client = TBDeviceMqttClient("127.0.0.1", username="A1_TEST_TOKEN")
client.connect()
client.request_attributes(["configuration", "targetFirmwareVersion"], callback=on_attributes_change)
while not IS_ATTR_RECEIVED:
    time.sleep(1)

from tb_device_http import TBHTTPClient


client = TBHTTPClient('https://thingsboard.example.com', 'secret-token')

client_keys = ['attr1', 'attr2']
shared_keys = ['shared1', 'shared2']
data = client.request_attributes(client_keys=client_keys, shared_keys=shared_keys)
print('Received attributes: ', data)

import time

from tb_device_mqtt import TBDeviceMqttClient

try:
    import psutil
except ImportError:
    print("Please install psutil using 'pip install psutil' command")
    exit(1)

# dependently of request method we send different data back
def on_server_side_rpc_request(request_id, request_body):
    print(request_id, request_body)
    if request_body["method"] == "getCPULoad":
        client.send_rpc_reply(request_id, {"CPU percent": psutil.cpu_percent()})
    elif request_body["method"] == "getMemoryUsage":
        client.send_rpc_reply(request_id, {"Memory": psutil.virtual_memory().percent})

client = TBDeviceMqttClient("127.0.0.1", username="A1_TEST_TOKEN")
client.set_server_side_rpc_request_handler(on_server_side_rpc_request)
client.connect()
while True:
    time.sleep(1)

import time
from tb_device_http import TBHTTPClient


client = TBHTTPClient('https://thingsboard.example.com', 'secret-token')

def callback(data):
    rpc_id = data['id']
    # ... do something with data['params'] and data['method']...
    response_params = {'result': 1}
    client.send_rpc(name='rpc_response', rpc_id=rpc_id, params=response_params)

# Subscribe
client.subscribe('rpc', callback)

while True:
    time.sleep(1)

import time
from tb_gateway_mqtt import TBGatewayMqttClient


gateway = TBGatewayMqttClient("127.0.0.1", username="TEST_GATEWAY_TOKEN")
gateway.connect()
gateway.gw_connect_device("Test Device A1")

gateway.gw_send_telemetry("Test Device A1", {"ts": int(round(time.time() * 1000)), "values": {"temperature": 42.2}})
gateway.gw_send_attributes("Test Device A1", {"firmwareVersion": "2.3.1"})

gateway.gw_disconnect_device("Test Device A1")
gateway.disconnect()

import time
from tb_gateway_mqtt import TBGatewayMqttClient


def callback(result, exception):
    if exception is not None:
        print("Exception: " + str(exception))
    else:
        print(result)


gateway = TBGatewayMqttClient("127.0.0.1", username="TEST_GATEWAY_TOKEN")
gateway.connect()
gateway.gw_request_shared_attributes("Test Device A1", ["temperature"], callback)

while True:
    time.sleep(1)

import time

from tb_gateway_mqtt import TBGatewayMqttClient

try:
    import psutil
except ImportError:
    print("Please install psutil using 'pip install psutil' command")
    exit(1)


def rpc_request_response(request_id, request_body):
    # request body contains id, method and other parameters
    print(request_body)
    method = request_body["data"]["method"]
    device = request_body["device"]
    req_id = request_body["data"]["id"]
    # dependently of request method we send different data back
    if method == 'getCPULoad':
        gateway.gw_send_rpc_reply(device, req_id, {"CPU load": psutil.cpu_percent()})
    elif method == 'getMemoryLoad':
        gateway.gw_send_rpc_reply(device, req_id, {"Memory": psutil.virtual_memory().percent})
    else:
        print('Unknown method: ' + method)


gateway = TBGatewayMqttClient("127.0.0.1", username="TEST_GATEWAY_TOKEN")
gateway.connect()
# now rpc_request_response will process rpc requests from servers
gateway.gw_set_server_side_rpc_request_handler(rpc_request_response)
# without device connection it is impossible to get any messages
gateway.gw_connect_device("Test Device A1")
while True:
    time.sleep(1)
