Tile38 is an open source (MIT licensed), in-memory geolocation data store, spatial index, and realtime geofencing server.
It supports a variety of object types including lat/lon points, bounding boxes, XYZ tiles, Geohashes, and GeoJSON.
This README is quick start document. You can find detailed documentation at https://tile38.com.
Features
Spatial index with search methods such as Nearby, Within, and Intersects.
Realtime geofencing through webhooks or pub/sub channels.
Object types of lat/lon, bbox, Geohash, GeoJSON, QuadKey, and XYZ tile.
Support for lots of Clients Libraries written in many different languages.
Variety of protocols, including http (curl), websockets, telnet, and the Redis RESP.
Server responses are RESP or JSON.
Full command line interface.
Leader / follower replication.
In-memory database that persists on disk.
Components
tile38-server: The server
tile38-cli: Command line interface tool
tile38-benchmark: Server benchmark tool
Getting Started
Getting Tile38
Perhaps the easiest way to get the latest Tile38 is to use one of the pre-built release binaries which are available for OSX, Linux, FreeBSD, and Windows. Instructions for using these binaries are on the GitHub releases page.
Docker
To run the latest stable version of Tile38:
docker pull tile38/tile38
docker run -p 9851:9851 tile38/tile38
Visit the Tile38 hub page for more information.
Homebrew (macOS)
Install Tile38 using Homebrew
brew install tile38
tile38-server
Building Tile38
Tile38 can be compiled and used on Linux, OSX, Windows, FreeBSD, and probably others since the codebase is 100% Go. We support both 32 bit and 64 bit systems. Go must be installed on the build machine.
To build everything simply:
$ make
To test:
$ make test
Running
For command line options invoke:
$ ./tile38-server -h
To run a single server:
$ ./tile38-server
# The tile38 shell connects to localhost:9851
$ ./tile38-cli
> help
Prometheus Metrics
Tile38 can natively export Prometheus metrics by setting the --metrics-addr command line flag (disabled by default). This example exposes the HTTP metrics server on port 4321:
# start server and enable Prometheus metrics, listen on local interface only
./tile38-server --metrics-addr=127.0.0.1:4321
# access metrics
curl http://127.0.0.1:4321/metrics
If you need to access the /metrics endpoint from a different host you'll have to set the flag accordingly, e.g. set it to 0.0.0.0:<<port>> to listen on all interfaces.
Use the redis_exporter for more advanced use cases like extracting key values or running a lua script.
Playing with Tile38
Basic operations:
$ ./tile38-cli
# add a couple of points named 'truck1' and 'truck2' to a collection named 'fleet'.
> set fleet truck1 point 33.5123 -112.2693 # on the Loop 101 in Phoenix
> set fleet truck2 point 33.4626 -112.1695 # on the I-10 in Phoenix
# search the 'fleet' collection.
> scan fleet # returns both trucks in 'fleet'
> nearby fleet point 33.462 -112.268 6000 # search 6 kilometers around a point. returns one truck.
# key value operations
> get fleet truck1 # returns 'truck1'
> del fleet truck2 # deletes 'truck2'
> drop fleet # removes all
Tile38 has a ton of great commands.
Fields
Fields are extra data that belongs to an object. A field is always a double precision floating point. There is no limit to the number of fields that an object can have.
To set a field when setting an object:
> set fleet truck1 field speed 90 point 33.5123 -112.2693
> set fleet truck1 field speed 90 field age 21 point 33.5123 -112.2693
To set a field when an object already exists:
> fset fleet truck1 speed 90
To get a field when an object already exists:
> fget fleet truck1 speed
Searching
Tile38 has support to search for objects and points that are within or intersects other objects. All object types can be searched including Polygons, MultiPolygons, GeometryCollections, etc.
Within
WITHIN searches a collection for objects that are fully contained inside a specified bounding area.
Intersects
INTERSECTS searches a collection for objects that intersect a specified bounding area.
Nearby
NEARBY searches a collection for objects that intersect a specified radius.
Search options
WHERE - This option allows for filtering out results based on field values. For example nearby fleet where speed 70 +inf point 33.462 -112.268 6000 will return only the objects in the 'fleet' collection that are within the 6 km radius and have a field named speed that is greater than 70.
Multiple WHEREs are concatenated as and clauses. WHERE speed 70 +inf WHERE age -inf 24 would be interpreted as speed is over 70 and age is less than 24.
The default value for a field is always 0. Thus if you do a WHERE on the field speed and an object does not have that field set, the server will pretend that the object does and that the value is Zero.
WHERE expressions support the =~ operator for regex matching. It uses Go's re2 regular expression engine to match string values in fields or GeoJSON properties within objects. For example, WHERE properties.name =~ 'truck.*' filters objects where the 'name' property matches the pattern, and WHERE field_name =~ 'value.*' works similarly for fields.
MATCH - MATCH is similar to WHERE except that it works on the object id instead of fields. nearby fleet match truck* point 33.462 -112.268 6000 will return only the objects in the 'fleet' collection that are within the 6 km radius and have an object id that starts with truck. There can be multiple MATCH options in a single search. The MATCH value is a simple glob pattern.
CURSOR - CURSOR is used to iterate though many objects from the search results. An iteration begins when the CURSOR is set to Zero or not included with the request, and completes when the cursor returned by the server is Zero.
NOFIELDS - NOFIELDS tells the server that you do not want field values returned with the search results.
LIMIT - LIMIT can be used to limit the number of objects returned for a single search request.
Geofencing
A geofence is a virtual boundary that can detect when an object enters or exits the area. This boundary can be a radius, bounding box, or a polygon. Tile38 can turn any standard search into a geofence monitor by adding the FENCE keyword to the search.
Tile38 also allows for Webhooks to be assigned to Geofences.
A simple example:
> nearby fleet fence point 33.462 -112.268 6000
This command opens a geofence that monitors the 'fleet' collection. The server will respond with:
{"ok":true,"live":true}
And the connection will be kept open. If any object enters or exits the 6 km radius around 33.462,-112.268 the server will respond in realtime with a message such as:
The server will notify the client if the command is del | set | drop.
del notifies the client that an object has been deleted from the collection that is being fenced.
drop notifies the client that the entire collection is dropped.
set notifies the client that an object has been added or updated, and when it's position is detected by the fence.
The detect may be one of the following values.
inside is when an object is inside the specified area.
outside is when an object is outside the specified area.
enter is when an object that was not previously in the fence has entered the area.
exit is when an object that was previously in the fence has exited the area.
cross is when an object that was not previously in the fence has entered and exited the area.
These can be used when establishing a geofence, to pre-filter responses. For instance, to limit responses to enter and exit detections:
> nearby fleet fence detect enter,exit point 33.462 -112.268 6000
Pub/sub channels
Tile38 supports delivering geofence notifications over pub/sub channels.
To create a static geofence that sends notifications when a bus is within 200 meters of a point and sends to the busstop channel:
> setchan busstop nearby buses fence point 33.5123 -112.2693 200
Subscribe on the busstop channel:
> subscribe busstop
Object types
All object types except for XYZ Tiles and QuadKeys can be stored in a collection. XYZ Tiles and QuadKeys are reserved for the SEARCH keyword only.
Lat/lon point
The most basic object type is a point that is composed of a latitude and a longitude. There is an optional z member that may be used for auxiliary data such as elevation or a timestamp.
set fleet truck1 point 33.5123 -112.2693 # plain lat/lon
set fleet truck1 point 33.5123 -112.2693 225 # lat/lon with z member
Bounding box
A bounding box consists of two points. The first being the southwestern most point and the second is the northeastern most point.
set fleet truck1 bounds 30 -110 40 -100
Geohash
A geohash is a string representation of a point. With the length of the string indicating the precision of the point.
set fleet truck1 hash 9tbnthxzr # this would be equivalent to 'point 33.5123 -112.2693'
GeoJSON
GeoJSON is an industry standard format for representing a variety of object types including a point, multipoint, linestring, multilinestring, polygon, multipolygon, geometrycollection, feature, and featurecollection.
* All ignored members will not persist.
Important to note that all coordinates are in Longitude, Latitude order.
set city tempe object {"type":"Polygon","coordinates":[[[0,0],[10,10],[10,0],[0,0]]]}
XYZ Tile
An XYZ tile is rectangle bounding area on earth that is represented by an X, Y coordinate and a Z (zoom) level.
Check out maptiler.org for an interactive example.
QuadKey
A QuadKey used the same coordinate system as an XYZ tile except that the string representation is a string characters composed of 0, 1, 2, or 3. For a detailed explanation checkout The Bing Maps Tile System.
Network protocols
It's recommended to use a client library or the Tile38 CLI, but there are times when only HTTP is available or when you need to test from a remote terminal. In those cases we provide an HTTP and telnet options.
HTTP
One of the simplest ways to call a tile38 command is to use HTTP. From the command line you can use curl. For example:
# call with request in the body
curl --data "set fleet truck3 point 33.4762 -112.10923" localhost:9851
# call with request in the url path
curl localhost:9851/set+fleet+truck3+point+33.4762+-112.10923
Websockets
Websockets can be used when you need to Geofence and keep the connection alive. It works just like the HTTP example above, with the exception that the connection stays alive and the data is sent from the server as text websocket messages.
Telnet
There is the option to use a plain telnet connection. The default output through telnet is RESP.
telnet localhost 9851
set fleet truck3 point 33.4762 -112.10923
+OK
The server will respond in JSON or RESP depending on which protocol is used when initiating the first command.
HTTP and Websockets use JSON.
Telnet and RESP clients use RESP.
Tile38 Client Libraries
The following clients are built specifically for Tile38.
Clients that support most Tile38 features are marked with a ⭐️.
⭐️ Go: xjem/t38c
⭐️ Node.js: node-tile38 (example code)
⭐️ Python: pyle38
⭐️ TypeScript: tile38-ts
Go: cjkreklow/t38c
Python: pytile38
Rust: nazar
Swift: Talon
Java: tile38-client-java
Java: tile38-client
Redis Client Libraries
Tile38 uses the Redis RESP protocol natively.
Therefore most clients that support basic Redis commands will also support Tile38.
C: hiredis
C#: StackExchange.Redis
C++: redox
Clojure: carmine
Common Lisp: CL-Redis
Erlang: Eredis
Go: go-redis (example code)
Go: redigo (example code)
Haskell: hedis
Java: lettuce (example code)
Node.js: node_redis (example code)
Perl: perl-redis
PHP: tinyredisclient (example code)
PHP: phpredis
Python: redis-py (example code)
Ruby: redic (example code)
Ruby: redis-rb (example code)
Rust: redis-rs
Scala: scala-redis
Swift: Redbird
Contact
Josh Baker @tidwall
License
Tile38 source code is available under the MIT License.
