android10/android-trinity

android-trinity

This is tiny framework with much of the scaffolding code (with some nice utilities and prepared source code) required to start a new Android Application.

Background 📦

Yes, android studio might create a project for you, but there are missing parts, which I ALWAYS end up adding to every single project I create. This tiny Framework (I would say still scaffolding code) aims to solve this by making easy and fast to create an android project with the fundamental building blocks. Check the TODO section below for more information on the evolution and progress.

What does android-trinity provide? 🎨

Freedom. It uses standard tools but organized in such a way that facilitates android development. You can refactor or change anything but the idea is to have a robust starting point. All the wiring is done for you with the flexibility of being modified according to your needs.

• Kotlin DSL by default at Gradle build system leve.
• Static Analisis Code Report (Detekt).
• Code Coverage Report (Jacoco).
• Base Classes: BaseActivity and BaseFragments.
• Toolbar with styles pre-defined.
• Pre-setup Test clases: UnitTest, AndroidTest, AcceptanceTest.
• Pre-compiled Gradle Scripts (buildScr folder) organized by aspects:
  • compilation.gradle.kts
  • infrastructure.gradle.kts
  • quality.gradle.kts
  • variants.gradle.kts
• Dependencies Management in one place: Dependencies.kt
• LeakCanary for leaks detection.
• Pre-defined Build Variants (check variants.gradle.kts file)
  • Build Types:
    • DEBUG
    • RELEASE
  • Product Flavors:
    • DEV
    • INTERNAL
    • PUBLIC
• Kotlin Coroutines
• A Compact Feature Flags Framework

What does android-trinity NOT INCLUDE? (likely to change if necessary in future versions)

• DI. You should choose your Dependency Injection Framework.
• NO Navigation Framework.
• NO LiveData and ViewModel libraries since some Engineers might use other approaches at UI level like MVI, MVP, etc.
• NO Kotlin Flow.
• NO UI Layouts for Tablet or Android TV support.

Pre-defined Gradle Tasks

• ./gradlew runStaticAnalysis
• ./gradlew runTestCoverage
• ./gradlew runUnitTests
• ./gradlew runAcceptanceTests
• ./gradlew compileApp
• ./gradlew runApp

How to use it 👣

At the time being there are a couple of manual steps involved since we are at a very early stage. But we believe in sofware evolution right? So stay tuned and check both the How to Contribute and TODO List sections.

• STEP 1: Click on to create a new repo.
• STEP 2: Import the project in Android Studio
• STEP 3: Rename packages according to your needs. com.fernandocejas.sample by default.

Using Test Helpers

Let's say you want to write tests (and you should ALWAYS do), As mentioned there are 3 classes which come into play and here examples of their usage:

• UnitTest.kt: Unit Test base class which setup mocks for you (You only use the @Mockk annotation)

class FeatureFlagTest : UnitTest() {

    @Mockk prival val yourMock

    @Test
    fun `given a feature flag, when it is activated, then executes given logic block`() {
        val activeFlag = ActiveFeatureFlag()
        val fakeNavigator = mockk<Navigator>(relaxed = true)

        activeFlag whenActivated {
            fakeNavigator.doSomething()
            fakeNavigator.navigateToActiveFeature()
            fakeNavigator.doSomething()
        }

        verify(exactly = 1) { fakeNavigator.navigateToActiveFeature() }
        verify(exactly = 2) { fakeNavigator.doSomething() }
    }

• AndroidTest.kt: Integration Test base class which setup mocks for you (You only use the @Mockk annotation). You might use this classes when they are Android Components involved. It is backed up by Robolectric.

class YourTestClass : AndroidTest() {

    @Mockk prival val yourMock

    @Test
    fun `given something, when something happens, then do something`() {
        TODO()
    }

• AcceptanceTest.kt: UI Test base class which setup Espresso for you

class MainActivityTest: AcceptanceTest(MainActivity::class.java) {

    @Test
    fun checkToolBarTest() {
        onView(withId(R.id.toolbar)).check(matches(isDisplayed()))
    }
}

Feature Flags

Android-trinity includes a simple offline feature flags framework with a very simple api generated at compile time. If you want more information, refer to the introduced pull request. (TODO: Add more documentation)

Example of its usage:

Flag.Hello whenActivated { displayGreeting(R.string.hello) }

Quality Reports: Static Analysis

• The tool chosen here is Detekt due to its nature for Kotlin.
• The gradlew task and its configuration could be found inside quality.gradle.kts file.
• cconfiguration Rules are in config/detekt/detekt.yml.

Quality Reports: Code Coverage

• The tool chosen here is Jacoco due to its nature and popularity in the community.
• The gradlew task and its configuration could be found inside quality.gradle.kts file.

TODO List

• Gradle Tasks for Publishing to Google Play: App Bundles.
• Automate the process from How to Use section: Idea: ./gradlew setupProject
• Local Feature Flags.
• Rename default packages to io.android-trinity or io.android.trinity.
• ???
• ???

How to Contribute

Nothing is set in stone here and things can change and evolve based on the community work and requirements. So if you want to contribute, feel free to open an issue and label it properly: Bug, Enhancement, etc.. or send a PR. Please both with a good descriptions of the intention, in order to facilitate review
