Appium Flutter Driver

Appium Flutter Driver is a test automation tool for Flutter apps on multiple platforms/OSes. Appium Flutter Driver is part of the Appium mobile test automation tool maintained by the community. Feel free to create PRs to fix issues/improve this driver.

Flutter Driver vs Appium Flutter Driver

Even though Flutter comes with superb integration test support, Flutter Driver, it does not fit some specific use cases, such as

• Writing tests in other languages than Dart
• Running integration test for Flutter app with embedded webview or native view, or existing native app with embedded Flutter view
• Running tests on multiple devices simultaneously
• Running integration tests on device farms that offer Appium support (Please contact the availability for each vendor)

Under the hood, Appium Flutter Driver uses the Dart VM Service Protocol with extension ext.flutter.driver, similar to Flutter Driver, to control the Flutter app-under-test (AUT).

Appium drivers for Flutter

Appium community currently has two drivers for Flutter environment:

• Appium Flutter driver (this driver)
  • Run Flutter commands over websocket connection against the observaory URL (calls Flutter APIs directly)
  • Base APIs are flutter_driver
• Appium Flutter Integration Driver
  • Run a server on DartVM as part of the application under test in order to call Flutter APIs via the server
  • Base APIs are integration_test

Appium Flutter Driver or Appium UiAutomator2/XCUITest driver

As a baseline, we recommend using official testing tools and strategy to test Flutter apps as possible in Dart.

If you'd like to test a release app, which can be released from app store as-is, Appium UIAutomator2/XCUITest driver is a good choice. Since Flutter 3.19, Flutter apps can expose identifier for SemanticsProperties as resource-id in Android and accessibilityIdentifier in iOS. They should help to achieve automation against release apps with Appium UIAutomator2/XCUITest as blackbox testing.

• Appium Flutter driver has three contexts to manage the application under test and the device under test. To achieve the FLUTTER context, the test package requires testing tools to import. The application under test cannot release as-is.
  • FLUTTER context sends commands to the Dart VM directly over the observatory URL. This allows you to interact with Flutter elements directly.
  • NATIVE_APP context is the same as the regular Appium UIAutomator2/XCUITest driver
  • WEBVIEW context manages the WebView contents over Appium UiAutomator2/XCUITest driver
• (Recommended if possible) Appium UIAutomator2/XCUITest driver directly must be sufficient to achieve automation if the application under test had semanticLabel properly. Then, the accessibility mechanism in each OS can expose elements for Appium through OS's accessibility features.
  • In addition to semanticLabel, Flutter 3.19+ may have identifier for SemanticsProperties (introduced by https://github.com/flutter/flutter/pull/138331). It sets resource-id and accessibilityIdentifier for Android and iOS, then UiAutomator2/XCUITest drivers might also be able to interact with these elements without Appium Flutter Driver.
    • "appium:settings[disableIdLocatorAutocompletion]": true or configuring disableIdLocatorAutocompletion via Settings API would be necessary to make resource-id idea work without any package name prefix like Android compose.
    • e.g. https://github.com/flutter/flutter/issues/17988#issuecomment-1867097631

Installation

Appium Flutter Driver version 3.0.0 requires Appium 3.

The driver package is ESM-only. Appium loads it as an extension automatically; programmatic Node.js consumers must use import or dynamic import() instead of require().

appium driver install --source=npm appium-flutter-driver

As a local:

appium driver install --source local /path/to/appium-flutter-driver/driver

Usage and requirement

If you are unfamiliar with running Appium tests, start with Quickstart Intro first.

Your Flutter application must be compiled in debug or profile mode. The dependency must have flutter_driver package like the below pubspec.yaml example with enableFlutterDriverExtension configuration in the main.dart.

# pubspec.yaml
dev_dependencies:
  flutter_driver:
    sdk: flutter

This snippet, taken from example directory, is a script written as an appium client with webdriverio, and assumes you have appium server (with appium-flutter-driver installed) running on the same host and default port (4723). For more info, see example's README.md

Note

This means this driver depends on flutter_driver. In the past, the Flutter team announced replacing flutter_driver with integration_test, but according to this ticket, this discussion is still ongoing. So flutter_driver would continue to be maintained for now.

Each client needs each finder module to handle Finders. Appium Flutter Driver communicates with the Dart VM directory in the FLUTTER context.

Doctor

Since driver version 2.4.0 you can automate the validation for the most of the above requirements as well as various optional ones needed by driver extensions by running the appium driver doctor flutter server command. The check runs for Android for UIAutomator2 driver and iOS for XCUITest driver.

SKIP_ANDROID or SKIP_IOS environment variable helps to skip these checks.

# skip Android check
SKIP_ANDROID=1 appium driver doctor flutter
# skip iOS check
SKIP_IOS=1 appium driver doctor flutter

Note

• Flutter context does not support page source
  • Please use getRenderTree command instead
• You can send appium-xcuitest-driver/appium-uiautomator2-driver commands in NATIVE_APP context
• scrollUntilVisible command : An expectation for checking that an element, known to be present on the widget tree, is visible. Using waitFor to wait element
• scrollUntilTapable command : An expectation for checking an element is visible and enabled such that you can click it. Using waitTapable to wait element
• driver.activateApp(appId) starts the given app and attaches to the observatory URL in the FLUTTER context. The method may raise an exception if no observaotry URL was found. The typical case is the appId is already running. Then, the driver will fail to find the observatory URL.
• getClipboard and setClipboard depend on each NATIVE_APP context behavior
• Launch via flutter:launchApp or 3rd party tool (via instrument service) and attach to the Dart VM for an iOS real device (profile build)
  1. Do not set app nor bundleId to start a session without launching apps
  2. Start the app process via 3rd party tools such as go-ios to start the app process with debug mode in the middle of the new session process in 1) the above.
     • Then, the appium flutter session establish the WebSocket and proceed the session
• keyboard interaction may not work in Android because of https://github.com/flutter/flutter/issues/15415 that is caused by flutter_driver

Capabilities

For the Appium Flutter Driver only

UIA2/XCUITest driver

Please check each driver's documentation

• https://github.com/appium/appium-uiautomator2-driver
• https://appium.github.io/appium-xcuitest-driver/latest/capabilities/

Context Management

Appium Flutter Driver allows you to send flutter_driver commands to the Dart VM in the FLUTTER context, but it does not support native Android/iOS since the Dart VM can handle in the Dart VM contents. NATIVE_APP context provides you to use the UIA2 driver for Android and the XCUITest driver for iOS automation. WEBVIEW_XXXX context helps WebView testing over the UIA2/XCUITest driver that is not available via the flutter_driver.

Thus, you need to switch proper contexts, FLUTTER, NATIVE_APP or WEBVIEW_XXXX, to automate a proper application target.

Example

# webdriverio
const wdio = require('webdriverio');
const assert = require('assert');
const { byValueKey } = require('appium-flutter-finder');

const osSpecificOps = process.env.APPIUM_OS === 'android' ? {
  'platformName': 'Android',
  'appium:deviceName': 'Pixel 2',
  'appium:app': __dirname +  '/../apps/app-free-debug.apk',
}: process.env.APPIUM_OS === 'ios' ? {
  'platformName': 'iOS',
  'appium:platformVersion': '12.2',
  'appium:deviceName': 'iPhone X',
  'appium:noReset': true,
  'appium:app': __dirname +  '/../apps/Runner.zip',
} : {};

const opts = {
  port: 4723,
  capabilities: {
    ...osSpecificOps,
    'appium:automationName': 'Flutter',
    'appium:retryBackoffTime': 500
  }
};

(async () => {
  const counterTextFinder = byValueKey('counter');
  const buttonFinder = byValueKey('increment');

  const driver = await wdio.remote(opts);

  if (process.env.APPIUM_OS === 'android') {
    await driver.switchContext('NATIVE_APP');
    await (await driver.$('~fab')).click();
    await driver.switchContext('FLUTTER');
  } else {
    console.log('Switching context to `NATIVE_APP` is currently only applicable to Android demo app.')
  }

  assert.strictEqual(await driver.getElementText(counterTextFinder), '0');

  await driver.elementClick(buttonFinder);
  await driver.touchAction({
    action: 'tap',
    element: { elementId: buttonFinder }
  });

  assert.strictEqual(await driver.getElementText(counterTextFinder), '2');

  driver.deleteSession();
})();

Please check example in this repository for more languages.

Several ways to start an application

You have a couple of methods to start the application under test by establishing the Dart VM connection as below:

1. Start with app in the capabilities
   1. The most standard method. You may need to start a new session with app capability. Then, appium-flutter-driver will start the app, and establish a connection with the Dart VM immediately.
2. Start with activate_app: for users who want to start the application under test in the middle of a session
   1. Start a session without app capability
   2. Install the application under test via driver.install_app or mobile:installApp command
   3. Activate the app via driver.activate_app or mobile:activateApp command
      • Then, appium-flutter-driver establish a connection with the Dart VM
3. Launch the app outside the driver: for users who want to manage the application under test by yourselves
   1. Start a session without app capability
   2. Install the application under test via driver.install_app or mobile:installApp command etc
   3. Calls flutter:connectObservatoryWsUrl command to keep finding an observatory URL to the Dart VM
   4. (at the same time) Launch the application under test via outside the appium-flutter-driver
      • e.g. Launch an iOS process via ios-go, iproxy or tidevice
   5. Once flutter:connectObservatoryWsUrl identify the observatory URL, the command will establish a connection to the Dart VM
4. Launch the app with flutter:launchApp for iOS and attach to the Dart VM: for users whom application under test do not print the observatory url via regular launch/activate app method
   1. Start a session without app capability
   2. Install the application under test via driver.install_app or mobile:installApp command etc
   3. Calls flutter:launchApp command to start an iOS app via instrument service
      • driver.execute_script 'flutter:launchApp', 'com.example.bundleId', {arguments: ['arg1'], environment: {ENV1: 'env'}} is example usage
      • This launching method is the same as the above 3rd party method, but does the same thing only via the appium flutter driver.

Please make sure the target app process stops before starting the target app with the above.

Changelog

• appium-flutter-driver
• each finder

Commands for NATIVE_APP/WEBVIEW context

Please check each driver's documentation

• https://github.com/appium/appium-uiautomator2-driver
• https://appium.github.io/appium-xcuitest-driver/latest

Commands for FLUTTER context

Legend:

Finders

Commands

The below WebDriver example is by webdriverio. flutter: prefix commands are mobile: command in appium for Android and iOS. Please replace them properly with your client.

Flutter Visibility Assertions for Appium

This module extends the appium-flutter-driver with custom visibility-related commands using driver.execute().

✅ Supported Shortcut Commands

🔍 Input Formats

Each assertion supports the following input formats:

• { key: 'valueKey' }
• { text: 'Text on widget' }
• { label: 'Tooltip text' }

These map to Flutter finders:

• byValueKey
• byText
• byTooltip

📦 Integration

These commands are typically invoked using a client helper method like:

// TypeScript
await assertVisible(driver, { key: 'submit_button' });

Or as a flutter command.

# ruby
driver.execute_script 'flutter:assertVisible', {text: 'Tap me!'}, 10000

# This is equivalent to
text_finder = by_text 'Tap me!'
driver.execute_script 'flutter:assertVisible', text_finder, 10000
# or
driver.execute_script 'flutter:waitFor', text_finder, 10000

NOTE

flutter:launchApp launches an app via instrument service. mobile:activateApp and driver.activate_app are via XCTest API. They are a bit different.

isolate handling

Change the flutter engine attach to

1. Get available isolate ids
   • id key in the value of isolates by flutter:getVMInfo
2. Set the id via setIsolateId

# ruby
info = driver.execute_script 'flutter:getVMInfo'
# Change the target engine to "info['isolates'][0]['id']"
driver.execute_script 'flutter:setIsolateId', info['isolates'][0]['id']

Check current isolate, or a particular isolate

1. Get available isolates
   • driver.execute('flutter:getVMInfo').isolates (JS)
2. Get a particular isolate or current isolate
   • Current isolate: driver.execute('flutter:getIsolate') (JS)
   • Particular isolate: driver.execute('flutter:getIsolate', 'isolates/2978358234363215') (JS)

Commands across contexts

These Appium commands can work across context

• deleteSession
• setContext
• getCurrentContext
• getContexts
• activateApp('appId')/mobile:activateApp
  • mobile:activateApp has skipAttachObservatoryUrl key to not try to attach to an observatory url. e.g. driver.execute_script 'mobile:activateApp', {skipAttachObservatoryUrl: true, appId: 'com.android.chrome'}
• mobile:launchApp (iOS)
  • Relaunches the app with arguments/environment via XCUITest, then attaches to the observatory url (skipAttachObservatoryUrl is honored as well). Use it instead of activateApp when the app needs launch arguments again, e.g. with appium:dartVmServicePort: driver.execute_script 'mobile:launchApp', {bundleId: 'com.example.bundleId', arguments: ['--vm-service-port=8283', '--disable-service-auth-codes']}
• terminateApp('appId')/mobile:terminateApp
• installApp(appPath, options)
• getClipboard
• setClipboard

Command Extension (Flutter Driver)

This is a command extension for Flutter Driver, utilizing the CommandExtension-class within ext.flutter.driver

Available commands:

• dragAndDropWithCommandExtension – performs a drag-and-drop action on the screen by specifying the start and end coordinates and the action duration.
• getTextWithCommandExtension - get text data from Text widget that contains TextSpan widgets.

How to use

Copy the sample dart files to the lib folder of your project. Please note that you don't need to copy all files, just copy the file matched with the command you need.

• dragAndDropWithCommandExtension: drag_commands.dart
• getTextWithCommandExtension: get_text_command.dart

The entry point must include the List<CommandExtension>? commands argument in either main.dart or test_main.dart to properly handle the command extension.

import 'drag_commands.dart';
import 'get_text_command.dart';

void main() {
  enableFlutterDriverExtension(
      commands: [DragCommandExtension(), GetTextCommandExtension()]);
  runApp(const MyApp());
}

Simple examples in Python

# Extended commands: flutter:dragAndDropWithCommandExtension
coord_item_1 = driver.execute_script("flutter:getCenter", item_1)
coord_item_2 = driver.execute_script("flutter:getCenter", item_2)
start_x = coord_item_1["dx"]
start_y = coord_item_1["dy"]
end_y = coord_item_2["dy"]

payload = {
    "startX": start_x,
    "startY": start_y,
    "endX": "0",
    "endY": end_y,
    "duration": "15000" # minimum 15000ms needed to drag n drop
}

driver.execute_script("flutter:dragAndDropWithCommandExtension", payload)

# Extended commands: flutter:getTextWithCommandExtension
text_finder = finder.by_value_key('amount')
get_text_payload = {
    'findBy': text_finder,
}
result = driver.execute_script('flutter:getTextWithCommandExtension', payload)
print(result)

Simple examples in nodejs

// Extended commands: flutter:dragAndDropWithCommandExtension
const payload = {
  "startX": "100",
  "startY": "100",
  "endX": "100",
  "endY": "600",
  "duration": "15000"
}
const result = await driver.execute("flutter:dragAndDropWithCommandExtension", payload);
console.log(JSON.stringify(result));

// Extended commands: flutter:getTextWithCommandExtension
import {byValueKey} from "appium-flutter-finder";
const payload = {
    'findBy': byValueKey('amount'),
  };
const getTextResult = await driver.execute('flutter:getTextWithCommandExtension', payload);
console.log(JSON.stringify(getTextResult));

For debugging or testing in other programming languages, you can use the APK available in this repository or build an IPA.

Troubleshooting

• Input texts https://github.com/appium/appium-flutter-driver/issues/417
• Looks hanging in click https://github.com/appium/appium-flutter-driver/issues/181#issuecomment-1323684510
  • flutter:setFrameSync may help
• flutter:waitFor would help to handle "an element does not exist/is not enabled" behavior. example issue
• Appium Inspector does not work with FLUTTER context
• enableFlutterDriverExtension() must be called before calling WidgetsFlutterBinding.ensureInitialized to avoid Binding is already initialized to WidgetsFlutterBinding error which could cause "ext.flutter.driver" is not found in "extensionRPCs" error. issue

TODO?

• switching context between Flutter and AndroidView
• switching context between Flutter and UiKitView
• Web: FLUTTER_WEB context?
• macOS: with https://github.com/appium/appium-mac2-driver
• Windws?
• Linux?

Release appium-flutter-driver

$ cd driver
$ sh release.sh
$ npm version <major|minor|patch>
# update changelog
$ git commit -am 'chore: bump version'
$ git tag <version number> # e.g. git tag v0.0.32
$ git push origin v0.0.32
$ git push origin main

Then, trigger publish.yml workflow to publish the package to npm.

Java implementation

• https://github.com/appium/appium-flutter-driver/tree/main/finder/kotlin via jitpack
• https://github.com/ashwithpoojary98/javaflutterfinder
• https://github.com/5v1988/appium-flutter-client
