cameron314/concurrentqueue

moodycamel::ConcurrentQueue

An industrial-strength lock-free queue for C++.

Note: If all you need is a single-producer, single-consumer queue, I have one of those too.

Features

• Knock-your-socks-off blazing fast performance.
• Single-header implementation. Just drop it in your project.
• Fully thread-safe lock-free queue. Use concurrently from any number of threads.
• C++11 implementation -- elements are moved (instead of copied) where possible.
• Templated, obviating the need to deal exclusively with pointers -- memory is managed for you.
• No artificial limitations on element types or maximum count.
• Memory can be allocated once up-front, or dynamically as needed.
• Fully portable (no assembly; all is done through standard C++11 primitives).
• Supports super-fast bulk operations.
• Includes a low-overhead blocking version (BlockingConcurrentQueue).
• Exception safe.

Reasons to use

There are not that many full-fledged lock-free queues for C++. Boost has one, but it's limited to objects with trivial assignment operators and trivial destructors, for example. Intel's TBB queue isn't lock-free, and requires trivial constructors too. There're many academic papers that implement lock-free queues in C++, but usable source code is hard to find, and tests even more so.

This queue not only has less limitations than others (for the most part), but it's also faster. It's been fairly well-tested, and offers advanced features like bulk enqueueing/dequeueing (which, with my new design, is much faster than one element at a time, approaching and even surpassing the speed of a non-concurrent queue even under heavy contention).

In short, there was a lock-free queue shaped hole in the C++ open-source universe, and I set out to fill it with the fastest, most complete, and well-tested design and implementation I could. The result is moodycamel::ConcurrentQueue :-)

Reasons not to use

The fastest synchronization of all is the kind that never takes place. Fundamentally, concurrent data structures require some synchronization, and that takes time. Every effort was made, of course, to minimize the overhead, but if you can avoid sharing data between threads, do so!

Why use concurrent data structures at all, then? Because they're gosh darn convenient! (And, indeed, sometimes sharing data concurrently is unavoidable.)

My queue is not linearizable (see the next section on high-level design). The foundations of its design assume that producers are independent; if this is not the case, and your producers co-ordinate amongst themselves in some fashion, be aware that the elements won't necessarily come out of the queue in the same order they were put in relative to the ordering formed by that co-ordination (but they will still come out in the order they were put in by any individual producer). If this affects your use case, you may be better off with another implementation; either way, it's an important limitation to be aware of.

My queue is also not NUMA aware, and does a lot of memory re-use internally, meaning it probably doesn't scale particularly well on NUMA architectures; however, I don't know of any other lock-free queue that is NUMA aware (except for SALSA, which is very cool, but has no publicly available implementation that I know of).

Finally, the queue is not sequentially consistent; there is a happens-before relationship between when an element is put in the queue and when it comes out, but other things (such as pumping the queue until it's empty) require more thought to get right in all eventualities, because explicit memory ordering may have to be done to get the desired effect. In other words, it can sometimes be difficult to use the queue correctly. This is why it's a good idea to follow the samples where possible. On the other hand, the upside of this lack of sequential consistency is better performance.

High-level design

Elements are stored internally using contiguous blocks instead of linked lists for better performance. The queue is made up of a collection of sub-queues, one for each producer. When a consumer wants to dequeue an element, it checks all the sub-queues until it finds one that's not empty. All of this is largely transparent to the user of the queue, however -- it mostly just works^TM.

One particular consequence of this design, however, (which seems to be non-intuitive) is that if two producers enqueue at the same time, there is no defined ordering between the elements when they're later dequeued. Normally this is fine, because even with a fully linearizable queue there'd be a race between the producer threads and so you couldn't rely on the ordering anyway. However, if for some reason you do extra explicit synchronization between the two producer threads yourself, thus defining a total order between enqueue operations, you might expect that the elements would come out in the same total order, which is a guarantee my queue does not offer. At that point, though, there semantically aren't really two separate producers, but rather one that happens to be spread across multiple threads. In this case, you can still establish a total ordering with my queue by creating a single producer token, and using that from both threads to enqueue (taking care to synchronize access to the token, of course, but there was already extra synchronization involved anyway).

I've written a more detailed overview of the internal design, as well as the full nitty-gritty details of the design, on my blog. Finally, the source itself is available for perusal for those interested in its implementation.

Basic use

The entire queue's implementation is contained in one header, concurrentqueue.h. Simply download and include that to use the queue. The blocking version is in a separate header, blockingconcurrentqueue.h, that depends on concurrentqueue.h and lightweightsemaphore.h. The implementation makes use of certain key C++11 features, so it requires a relatively recent compiler (e.g. VS2012+ or g++ 4.8; note that g++ 4.6 has a known bug with std::atomic and is thus not supported). The algorithm implementations themselves are platform independent.

Use it like you would any other templated queue, with the exception that you can use it from many threads at once :-)

Simple example:

#include "concurrentqueue.h"

moodycamel::ConcurrentQueue<int> q;
q.enqueue(25);

int item;
bool found = q.try_dequeue(item);
assert(found && item == 25);

Description of basic methods:

• ConcurrentQueue(size_t initialSizeEstimate) Constructor which optionally accepts an estimate of the number of elements the queue will hold
• enqueue(T&& item) Enqueues one item, allocating extra space if necessary
• try_enqueue(T&& item) Enqueues one item, but only if enough memory is already allocated
• try_dequeue(T& item) Dequeues one item, returning true if an item was found or false if the queue appeared empty

Note that it is up to the user to ensure that the queue object is completely constructed before being used by any other threads (this includes making the memory effects of construction visible, possibly via a memory barrier). Similarly, it's important that all threads have finished using the queue (and the memory effects have fully propagated) before it is destructed.

There's usually two versions of each method, one "explicit" version that takes a user-allocated per-producer or per-consumer token, and one "implicit" version that works without tokens. Using the explicit methods is almost always faster (though not necessarily by a huge factor). Apart from performance, the primary distinction between them is their sub-queue allocation behaviour for enqueue operations: Using the implicit enqueue methods causes an automatically-allocated thread-local producer sub-queue to be allocated. Explicit producers, on the other hand, are tied directly to their tokens' lifetimes (but are recycled internally).

In order to avoid the number of sub-queues growing without bound, implicit producers are marked for reuse once their thread exits. However, this is not supported on all platforms. If using the queue from short-lived threads, it is recommended to use explicit producer tokens instead.

Full API (pseudocode):

# Allocates more memory if necessary
enqueue(item) : bool
enqueue(prod_token, item) : bool
enqueue_bulk(item_first, count) : bool
enqueue_bulk(prod_token, item_first, count) : bool

# Fails if not enough memory to enqueue
try_enqueue(item) : bool
try_enqueue(prod_token, item) : bool
try_enqueue_bulk(item_first, count) : bool
try_enqueue_bulk(prod_token, item_first, count) : bool

# Attempts to dequeue from the queue (never allocates)
try_dequeue(item&) : bool
try_dequeue(cons_token, item&) : bool
try_dequeue_bulk(item_first, max) : size_t
try_dequeue_bulk(cons_token, item_first, max) : size_t

# If you happen to know which producer you want to dequeue from
try_dequeue_from_producer(prod_token, item&) : bool
try_dequeue_bulk_from_producer(prod_token, item_first, max) : size_t

# A not-necessarily-accurate count of the total number of elements
size_approx() : size_t

Blocking version

As mentioned above, a full blocking wrapper of the queue is provided that adds wait_dequeue and wait_dequeue_bulk methods in addition to the regular interface. This wrapper is extremely low-overhead, but slightly less fast than the non-blocking queue (due to the necessary bookkeeping involving a lightweight semaphore).

There are also timed versions that allow a timeout to be specified (either in microseconds or with a std::chrono object).

The only major caveat with the blocking version is that you must be careful not to destroy the queue while somebody is waiting on it. This generally means you need to know for certain that another element is going to come along before you call one of the blocking methods. (To be fair, the non-blocking version cannot be destroyed while in use either, but it can be easier to coordinate the cleanup.)

Blocking example:

#include "blockingconcurrentqueue.h"

moodycamel::BlockingConcurrentQueue<int> q;
std::thread producer([&]() {
    for (int i = 0; i != 100; ++i) {
        std::this_thread::sleep_for(std::chrono::milliseconds(i % 10));
        q.enqueue(i);
    }
});
std::thread consumer([&]() {
    for (int i = 0; i != 100; ++i) {
        int item;
        q.wait_dequeue(item);
        assert(item == i);

        if (q.wait_dequeue_timed(item, std::chrono::milliseconds(5))) {
            ++i;
            assert(item == i);
        }
    }
});
producer.join();
consumer.join();

assert(q.size_approx() == 0);

Advanced features

Tokens

The queue can take advantage of extra per-producer and per-consumer storage if it's available to speed up its operations. This takes the form of "tokens": You can create a consumer token and/or a producer token for each thread or task (tokens themselves are not thread-safe), and use the methods that accept a token as their first parameter:

moodycamel::ConcurrentQueue<int> q;

moodycamel::ProducerToken ptok(q);
q.enqueue(ptok, 17);

moodycamel::ConsumerToken ctok(q);
int item;
q.try_dequeue(ctok, item);
assert(item == 17);

If you happen to know which producer you want to consume from (e.g. in a single-producer, multi-consumer scenario), you can use the try_dequeue_from_producer methods, which accept a producer token instead of a consumer token, and cut some overhead.

Note that tokens work with the blocking version of the queue too.

When producing or consuming many elements, the most efficient way is to:

1. Use the bulk methods of the queue with tokens
2. Failing that, use the bulk methods without tokens
3. Failing that, use the single-item methods with tokens
4. Failing that, use the single-item methods without tokens

Having said that, don't create tokens willy-nilly -- ideally there would be one token (of each kind) per thread. The queue will work with what it is given, but it performs best when used with tokens.

Note that tokens aren't actually tied to any given thread; it's not technically required that they be local to the thread, only that they be used by a single producer/consumer at a time.

Bulk operations

Thanks to the novel design of the queue, it's just as easy to enqueue/dequeue multiple items as it is to do one at a time. This means that overhead can be cut drastically for bulk operations. Example syntax:

moodycamel::ConcurrentQueue<int> q;

int items[] = { 1, 2, 3, 4, 5 };
q.enqueue_bulk(items, 5);

int results[5];     // Could also be any iterator
size_t count = q.try_dequeue_bulk(results, 5);
for (size_t i = 0; i != count; ++i) {
    assert(results[i] == items[i]);
}

Preallocation (correctly using try_enqueue)

try_enqueue, unlike just plain enqueue, will never allocate memory. If there's not enough room in the queue, it simply returns false. The key to using this method properly, then, is to ensure enough space is pre-allocated for your desired maximum element count.

The constructor accepts a count of the number of elements that it should reserve space for. Because the queue works with blocks of elements, however, and not individual elements themselves, the value to pass in order to obtain an effective number of pre-allocated element slots is non-obvious.

First, be aware that the count passed is rounded up to the next multiple of the block size. Note that the default block size is 32 (this can be changed via the traits). Second, once a slot in a block has been enqueued to, that slot cannot be re-used until the rest of the block has been completely filled up and then completely emptied. This affects the number of blocks you need in order to account for the overhead of partially-filled blocks. Third, each producer (whether implicit or explicit) claims and recycles blocks in a different manner, which again affects the number of blocks you need to account for a desired number of usable slots.

Suppose you want the queue to be able to hold at least N elements at any given time. Without delving too deep into the rather arcane implementation details, here are some simple formulas for the number of elements to request for pre-allocation in such a case. Note the division is intended to be arithmetic division and not integer division (in order for ceil() to work).

For explicit producers (using tokens to enqueue):

(ceil(N / BLOCK_SIZE) + 1) * MAX_NUM_PRODUCERS * BLOCK_SIZE

For implicit producers (no tokens):

(ceil(N / BLOCK_SIZE) - 1 + 2 * MAX_NUM_PRODUCERS) * BLOCK_SIZE

When using mixed producer types:

((ceil(N / BLOCK_SIZE) - 1) * (MAX_EXPLICIT_PRODUCERS + 1) + 2 * (MAX_IMPLICIT_PRODUCERS + MAX_EXPLICIT_PRODUCERS)) * BLOCK_SIZE

If these formulas seem rather inconvenient, you can use the constructor overload that accepts the minimum number of elements (N) and the maximum number of explicit and implicit producers directly, and let it do the computation for you.

In addition to blocks, there are other internal data structures that require allocating memory if they need to resize (grow). If using try_enqueue exclusively, the initial sizes may be exceeded, causing subsequent try_enqueue operations to fail. Specifically, the INITIAL_IMPLICIT_PRODUCER_HASH_SIZE trait limits the number of implicit producers that can be active at once before the internal hash needs resizing. Along the same lines, the IMPLICIT_INITIAL_INDEX_SIZE trait limits the number of unconsumed elements that an implicit producer can insert before its internal hash needs resizing. Similarly, the EXPLICIT_INITIAL_INDEX_SIZE trait limits the number of unconsumed elements that an explicit producer can insert before its internal hash needs resizing. In order to avoid hitting these limits when using try_enqueue, it is crucial to adjust the initial sizes in the traits appropriately, in addition to sizing the number of blocks properly as outlined above.

Finally, it's important to note that because the queue is only eventually consistent and takes advantage of weak memory ordering for speed, there's always a possibility that under contention try_enqueue will fail even if the queue is correctly pre-sized for the desired number of elements. (e.g. A given thread may think that the queue's full even when that's no longer the case.) So no matter what, you still need to handle the failure case (perhaps looping until it succeeds), unless you don't mind dropping elements.

Exception safety

The queue is exception safe, and will never become corrupted if used with a type that may throw exceptions. The queue itself never throws any exceptions (operations fail gracefully (return false) if memory allocation fails instead of throwing std::bad_alloc).

It is important to note that the guarantees of exception safety only hold if the element type never throws from its destructor, and that any iterators passed into the queue (for bulk operations) never throw either. Note that in particular this means std::back_inserter iterators must be used with care, since the vector being inserted into may need to allocate and throw a std::bad_alloc exception from inside the iterator; so be sure to reserve enough capacity in the target container first if you do this.

The guarantees are presently as follows:

• Enqueue operations are rolled back completely if an exception is thrown from an element's constructor. For bulk enqueue operations, this means that elements are copied instead of moved (in order to avoid having only some objects moved in the event of an exception). Non-bulk enqueues always use the move constructor if one is available.
• If the assignment operator throws during a dequeue operation (both single and bulk), the element(s) are considered dequeued regardless. In such a case, the dequeued elements are all properly destructed before the exception is propagated, but there's no way to get the elements themselves back.
• Any exception that is thrown is propagated up the call stack, at which point the queue is in a consistent state.

Note: If any of your type's copy constructors/move constructors/assignment operators don't throw, be sure to annotate them with noexcept; this will avoid the exception-checking overhead in the queue where possible (even with zero-cost exceptions, there's still a code size impact that has to be taken into account).

Traits

The queue also supports a traits template argument which defines various types, constants, and the memory allocation and deallocation functions that are to be used by the queue. The typical pattern to providing your own traits is to create a class that inherits from the default traits and override only the values you wish to change. Example:

struct MyTraits : public moodycamel::ConcurrentQueueDefaultTraits
{
	static const size_t BLOCK_SIZE = 256;		// Use bigger blocks
};

moodycamel::ConcurrentQueue<int, MyTraits> q;

How to dequeue types without calling the constructor

The normal way to dequeue an item is to pass in an existing object by reference, which is then assigned to internally by the queue (using the move-assignment operator if possible). This can pose a problem for types that are expensive to construct or don't have a default constructor; fortunately, there is a simple workaround: Create a wrapper class that copies the memory contents of the object when it is assigned by the queue (a poor man's move, essentially). Note that this only works if the object contains no internal pointers. Example:

struct MyObjectMover {
    inline void operator=(MyObject&& obj) {
        std::memcpy(data, &obj, sizeof(MyObject));

        // TODO: Cleanup obj so that when it's destructed by the queue
        // it doesn't corrupt the data of the object we just moved it into
    }

    inline MyObject& obj() { return *reinterpret_cast<MyObject*>(data); }

private:
    align(alignof(MyObject)) char data[sizeof(MyObject)];
};

A less dodgy alternative, if moves are cheap but default construction is not, is to use a wrapper that defers construction until the object is assigned, enabling use of the move constructor:

struct MyObjectMover {
    inline void operator=(MyObject&& x) {
        new (data) MyObject(std::move(x));
        created = true;
    }

    inline MyObject& obj() {
        assert(created);
        return *reinterpret_cast<MyObject*>(data);
    }

    ~MyObjectMover() {
        if (created)
            obj().~MyObject();
    }

private:
    align(alignof(MyObject)) char data[sizeof(MyObject)];
    bool created = false;
};

Samples

There are some more detailed samples here. The source of the unit tests and benchmarks are available for reference as well.

Benchmarks

See my blog post for some benchmark results (including versus boost::lockfree::queue and tbb::concurrent_queue), or run the benchmarks yourself (requires MinGW and certain GnuWin32 utilities to build on Windows, or a recent g++ on Linux):

cd build
make benchmarks
bin/benchmarks

The short version of the benchmarks is that it's so fast (especially the bulk methods), that if you're actually using the queue to do anything, the queue won't be your bottleneck.

Tests (and bugs)

I've written quite a few unit tests as well as a randomized long-running fuzz tester. I also ran the core queue algorithm through the CDSChecker C++11 memory model model checker. Some of the inner algorithms were tested separately using the Relacy model checker, and full integration tests were also performed with Relacy. I've tested on Linux (Fedora 19) and Windows (7) on x86 processors (Intel and AMD), and the GitHub Actions CI now also cross-compiles and runs the unit tests for riscv64 Linux under QEMU. The code was written to be platform-independent, and should work across all processors and OSes.

Due to the complexity of the implementation and the difficult-to-test nature of lock-free code in general, there may still be bugs. If anyone is seeing buggy behaviour, I'd like to hear about it! (Especially if a unit test for it can be cooked up.) Just open an issue on GitHub.

Using vcpkg

You can download and install moodycamel::ConcurrentQueue using the vcpkg dependency manager:

git clone https://github.com/Microsoft/vcpkg.git
cd vcpkg
./bootstrap-vcpkg.sh
./vcpkg integrate install
vcpkg install concurrentqueue

The moodycamel::ConcurrentQueue port in vcpkg is kept up to date by Microsoft team members and community contributors. If the version is out of date, please create an issue or pull request on the vcpkg repository.

License

I'm releasing the source of this repository (with the exception of third-party code, i.e. the Boost queue (used in the benchmarks for comparison), Intel's TBB library (ditto), CDSChecker, Relacy, and Jeff Preshing's cross-platform semaphore, which all have their own licenses) under a simplified BSD license. I'm also dual-licensing under the Boost Software License. See the LICENSE.md file for more details.

Note that lock-free programming is a patent minefield, and this code may very well violate a pending patent (I haven't looked), though it does not to my present knowledge. I did design and implement this queue from scratch.

Diving into the code

If you're interested in the source code itself, it helps to have a rough idea of how it's laid out. This section attempts to describe that.

The queue is formed of several basic parts (listed here in roughly the order they appear in the source). There's the helper functions (e.g. for rounding to a power of 2). There's the default traits of the queue, which contain the constants and malloc/free functions used by the queue. There's the producer and consumer tokens. Then there's the queue's public API itself, starting with the constructor, destructor, and swap/assignment methods. There's the public enqueue methods, which are all wrappers around a small set of private enqueue methods found later on. There's the dequeue methods, which are defined inline and are relatively straightforward.

Then there's all the main internal data structures. First, there's a lock-free free list, used for recycling spent blocks (elements are enqueued to blocks internally). Then there's the block structure itself, which has two different ways of tracking whether it's fully emptied or not (remember, given two parallel consumers, there's no way to know which one will finish first) depending on where it's used. Then there's a small base class for the two types of internal SPMC producer queues (one for explicit producers that holds onto memory but attempts to be faster, and one for implicit ones which attempt to recycle more memory back into the parent but is a little slower). The explicit producer is defined first, then the implicit one. They both contain the same general four methods: One to enqueue, one to dequeue, one to enqueue in bulk, and one to dequeue in bulk. (Obviously they have constructors and destructors too, and helper methods.) The main difference between them is how the block handling is done (they both use the same blocks, but in different ways, and map indices to them in different ways).

Finally, there's the miscellaneous internal methods: There's the ones that handle the initial block pool (populated when the queue is constructed), and an abstract block pool that comprises the initial pool and any blocks on the free list. There's ones that handle the producer list (a lock-free add-only linked list of all the producers in the system). There's ones that handle the implicit producer lookup table (which is really a sort of specialized TLS lookup). And then there's some helper methods for allocating and freeing objects, and the data members of the queue itself, followed lastly by the free-standing swap functions.
