Urkel
An optimized and cryptographically provable key-value store. Written in C.
Design
The urkel tree is implemented as a base-2 merkelized radix tree. It builds
on earlier research done by Bram Cohen and Amaury Séchet in order to
create an alternative to Ethereum's base-16 trie.
Nodes are stored in a series of append-only files for snapshotting and crash
consistency capabilities. Due to these presence of these features, Urkel has
the ability to expose a fully transactional database.
Urkel is its own database. This is in contrast to earlier authenticated data
structures which were typically implemented on top of an existing data store
like LevelDB.
The urkel tree is currently used in production for the Handshake protocol.
Features
- Transactions - Fully atomic and transactional API.
- Snapshots - Transactions can also behave as snapshots, pointing to a
historical root hash.
- Iteration - Full tree iteration¹.
- Compact Proofs - Small proof size, with proof nodes averaging ~34 bytes in
size.
- History Independence - Deterministic root hash calculation regardless of
insertion/removal order.
- Crash Consistency -
kill -9'able.
- Cross Platform - Runs on Windows XP and up, as well as any POSIX.1-2001
compatible OS.
- WASM Support - Builds with both Emscripten as well as the WASI SDK.
- Note that range iteration is not particularly useful for our use case.
Example Usage
#include <assert.h>
#include <stdlib.h>
#include <string.h>
#include <urkel.h>
int main(void) {
unsigned char key[32];
unsigned char val[4] = {0xde, 0xad, 0xbe, 0xef};
unsigned char key_out[32];
unsigned char val_out[1023]; /* Max size (currently). */
size_t val_len;
urkel_t *db;
urkel_tx_t *tx;
/* Open database. */
db = urkel_open("/path/to/db");
assert(db != NULL);
/* Create transaction. */
tx = urkel_tx_create(db, NULL);
assert(tx != NULL);
/* Hash key. */
urkel_hash(key, "my key", 6);
/* Insert record. */
assert(urkel_tx_insert(tx, key, val, sizeof(val)));
/* Retrieve record. */
assert(urkel_tx_get(tx, val_out, &val_len, key));
assert(val_len == sizeof(val));
assert(memcmp(val_out, val, val_len) == 0);
/* Commit transaction. */
assert(urkel_tx_commit(tx));
{
unsigned char root[32];
unsigned char *proof_raw;
size_t proof_len;
int exists;
/* Compute root. */
urkel_tx_root(tx, root);
/* Create proof. */
assert(urkel_tx_prove(tx, &proof_raw, &proof_len, key));
/* Verify proof. */
assert(urkel_verify(&exists, val_out, &val_len,
proof_raw, proof_len, key, root));
/* Returns our value. */
assert(exists == 1);
assert(val_len == sizeof(val));
assert(memcmp(val_out, val, val_len) == 0);
urkel_free(proof_raw);
}
{
/* Create an iterator. */
urkel_iter_t *iter = urkel_iter_create(tx);
size_t i = 0;
assert(iter != NULL);
/* Iterate over our single record. */
while (urkel_iter_next(iter, key_out, val_out, &val_len)) {
assert(memcmp(key_out, key, 32) == 0);
assert(val_len == sizeof(val));
assert(memcmp(val_out, val, val_len) == 0);
i += 1;
}
assert(urkel_errno == URKEL_EITEREND);
assert(i == 1);
urkel_iter_destroy(iter);
}
/* Cleanup. */
urkel_tx_destroy(tx);
urkel_close(db);
return 0;
}
Compile with:
$ cc -o example example.c -lurkel
CLI Usage
The default build will provide you with an urkel executable. This allows
very simple manipulation of an urkel database from the command line.
Example
Data manipulation:
$ urkel create
$ urkel root
0000000000000000000000000000000000000000000000000000000000000000
$ urkel insert foo 'deadbeef' -H
$ urkel root
1da2776eaa254ef65aeeee1f37f61c06bac2e82e221d37da21190191218f6631
$ urkel insert bar '01020304' -H
$ urkel root
497b751637ff244ab969a965f8d9dc7623f18d649d012276dfb317b0e38b9bec
$ urkel get bar -H
01020304
$ urkel remove bar -H
$ urkel root
1da2776eaa254ef65aeeee1f37f61c06bac2e82e221d37da21190191218f6631
$ urkel remove foo -H
$ urkel root
0000000000000000000000000000000000000000000000000000000000000000
Creating and verifying a proof:
$ urkel root
497b751637ff244ab969a965f8d9dc7623f18d649d012276dfb317b0e38b9bec
$ urkel prove foo -H
03c00100800280a6386fa1781a92e3905f718d4e0ea0d757abe962eefdd52a23d2ad6e1409fd8a0400deadbeef
$ urkel verify foo -H \
'03c00100800280a6386fa1781a92e3905f718d4e0ea0d757abe962eefdd52a23d2ad6e1409fd8a0400deadbeef' \
--root '497b751637ff244ab969a965f8d9dc7623f18d649d012276dfb317b0e38b9bec'
deadbeef
Usage
Usage: urkel [options] [action] [args]
Actions:
create create a new database
destroy destroy database
info print database information
root print root hash
get <key> retrieve value
insert <key> <value> insert value
remove <key> remove value
list list all keys
prove <key> create proof
verify <key> <proof> verify proof (requires --root)
Options:
-p, --path <path> path to database (default: $URKEL_PATH)
-r, --root <hash> root hash to use for snapshots
-H, --hash hash key with BLAKE2b-256
-h, --help output usage information
Environment Variables:
URKEL_PATH path to database (default: ./)
Benchmarks
Benchmarks were run on a high-end but consumer-grade laptop, containing a Intel
Core i7-8550U 1.80GHz and an NVMe PCIe SSD.
Benchmarking insert...
Operations: 100000
Nanoseconds: 176354477
Seconds: 0.176354
Ops/Sec: 567039.758225
Sec/Op: 0.000002
Benchmarking get (cached)...
Operations: 100000
Nanoseconds: 91769518
Seconds: 0.091770
Ops/Sec: 1089686.446866
Sec/Op: 0.000001
Benchmarking commit...
Operations: 1
Nanoseconds: 121798848
Seconds: 0.121799
Ops/Sec: 8.210258
Sec/Op: 0.121799
Benchmarking get (uncached)...
Operations: 100000
Nanoseconds: 300755918
Seconds: 0.300756
Ops/Sec: 332495.535466
Sec/Op: 0.000003
Benchmarking remove...
Operations: 100000
Nanoseconds: 88950509
Seconds: 0.088951
Ops/Sec: 1124220.660727
Sec/Op: 0.000001
Benchmarking commit...
Operations: 1
Nanoseconds: 30168275
Seconds: 0.030168
Ops/Sec: 33.147404
Sec/Op: 0.030168
Benchmarking commit (nothing)...
Operations: 1
Nanoseconds: 24088
Seconds: 0.000024
Ops/Sec: 41514.447028
Sec/Op: 0.000024
Benchmarking prove...
Operations: 100000
Nanoseconds: 327144781
Seconds: 0.327145
Ops/Sec: 305675.058286
Sec/Op: 0.000003
Benchmarking verify...
Operations: 100000
Nanoseconds: 330230736
Seconds: 0.330231
Ops/Sec: 302818.572285
Sec/Op: 0.000003
Platforms without memory-mapped file support will suffer in performance (this
includes Emscripten and WASI).
