Node Resource Interface, Revisited

This project is currently in DRAFT status

Goal

NRI allows plugging domain- or vendor-specific custom logic into OCI- compatible runtimes. This logic can make controlled changes to containers or perform extra actions outside the scope of OCI at certain points in a containers lifecycle. This can be used, for instance, for improved allocation and management of devices and other container resources.

NRI defines the interfaces and implements the common infrastructure for enabling such pluggable runtime extensions, NRI plugins. This also keeps the plugins themselves runtime-agnostic.

The goal is to enable NRI support in the most commonly used OCI runtimes, containerd and CRI-O.

Background

The revisited API is a major rewrite of NRI. It changes the scope of NRI and how it gets integrated into runtimes. It reworks how plugins are implemented, how they communicate with the runtime, and what kind of changes they can make to containers.

NRI v0.1.0 used an OCI hook-like one-shot plugin invocation mechanism where a separate instance of a plugin was spawned for every NRI event. This instance then used its standard input and output to receive a request and provide a response, both as JSON data.

Plugins in NRI are daemon-like entities. A single instance of a plugin is now responsible for handling the full stream of NRI events and requests. A unix-domain socket is used as the transport for communication. Instead of JSON requests and responses NRI is defined as a formal, protobuf-based 'NRI plugin protocol' which is compiled into ttRPC bindings. This should result in improved communication efficiency with lower per-message overhead, and enable straightforward implementation of stateful NRI plugins.

Components

The NRI implementation consists of a number of components. The core of these are essential for implementing working end-to-end NRI support in runtimes. These core components are the actual NRI protocol, and the NRI runtime adaptation.

Together these establish the model of how a runtime interacts with NRI and how plugins interact with containers in the runtime through NRI. They also define under which conditions plugins can make changes to containers and the extent of these changes.

The rest of the components are the NRI plugin stub library and some sample NRI plugins. Some plugins implement useful functionality in real world scenarios. A few others are useful for debugging. All of the sample plugins serve as practical examples of how the stub library can be used to implement NRI plugins.

Protocol, Plugin API

The core of NRI is defined by a protobuf protocol definition of the low-level plugin API. The API defines two services, Runtime and Plugin.

The Runtime service is the public interface runtimes expose for NRI plugins. All requests on this interface are initiated by the plugin. The interface provides functions for

• initiating plugin registration
• requesting unsolicited updates to containers

The Plugin service is the public interface NRI uses to interact with plugins. All requests on this interface are initiated by NRI/the runtime. The interface provides functions for

• configuring the plugin
• getting initial list of already existing pods and containers
• hooking the plugin into pod/container lifecycle events
• shutting down the plugin

An additional interface is provided for validating the changes active plugins have requested to containers. This interface allows one to set up and enforce cluster- or node-wide boundary conditions for changes NRI plugins are allowed to make.

Deprecated Interfaces

StateChange

In the original wire protocol a single StateChange RPC call was used to multiplex most pod and container lifecycle events/requests on the wire. For external plugins this RPC call has been replaced with proper dedicated calls for each request and is now deprecated. For the time being, the runtime adaptation transparently falls back to funneling requests through StateChange for plugins compiled against older versions of the NRI stub package. This support will be removed in a future version of NRI.

Note that transparent fallback is only possible for external binary plugins using ttRPC. Old WASM plugins compiled against an old version of NRI will fail to load with new versions of NRI.

Plugin Registration

Before a plugin can start receiving and processing container events, it needs to register itself with NRI. During registration the plugin and NRI perform a handshake sequence which consists of the following steps:

1. the plugin identifies itself to the runtime
2. NRI provides plugin-specific configuration data to the plugin
3. the plugin subscribes to pod and container lifecycle events of interest
4. NRI sends list of existing pods and containers to plugin
5. the plugin requests any updates deemed necessary to existing containers

The plugin identifies itself to NRI by a plugin name and a plugin index. The plugin index is used by NRI to determine in which order the plugin is hooked into pod and container lifecycle event processing with respect to any other plugins.

The plugin name is used to pick plugin-specific data to send to the plugin as configuration. This data is only present if the plugin has been launched by NRI. If the plugin has been externally started it is expected to acquire its configuration also by external means. The plugin subscribes to pod and container lifecycle events of interest in its response to configuration.

As the last step in the registration and handshaking process, NRI sends the full set of pods and containers known to the runtime. The plugin can request updates it considers necessary to any of the known containers in response.

Once the handshake sequence is over and the plugin has registered with NRI, it will start receiving pod and container lifecycle events according to its subscription.

Pod Data and Available Lifecycle Events

NRI Pod Lifecycle Events

NRI plugins can subscribe to the following pod lifecycle events:

• creation
• stopping
• removal

The following table lists the pod sandbox properties exposed to NRI plugins, together with the first NRI, containerd and CRI-O versions each was available in.

Container Data and Available Lifecycle Events

NRI Container Lifecycle Events

NRI plugins can subscribe to the following container lifecycle events:

• creation (*)
• post-creation
• starting
• post-start
• updating (*)
• post-update
• stopping (*)
• removal

*) Plugins can request adjustment or updates to containers in response to these events.

The following table lists the container properties exposed to NRI plugins, together with the NRI, containerd and CRI-O versions each property was first available in.

Apart from data identifying the container, these pieces of information represent the corresponding data in the container's OCI Spec.

Container Adjustment

The following table lists the container properties a plugin can request changes to during container reation, together with the NRI, containerd and CRI-O versions each property was first available in.

Container Updates

Once a container has been created plugins can request updates to them. These updates can be requested in response to another containers creation request, in response to any containers update request, in response to any containers stop request, or they can be requested as part of a separate unsolicited container update request. The table lists the container properties which can be updated this way, together with the NRI, containerd and CRI-O versions each property was first available in for update.

Container Adjustment Validation

NRI plugins operate as trusted extensions of the container runtime, granting them significant privileges to alter container specs. While this extensibility is powerful with valid use cases, some of the capabilities granted to plugins allow modifying security-sensitive settings of containers. As such they also come with the risk that a plugin could inadvertently or maliciously weaken a container's isolation or security posture, potentially overriding policies set by cluster orchestrators such as K8s.

NRI offers cluster administrators a mechanism to exercise fine-grained control over what changes plugins are allowed to make to containers, allowing cluster administrators to lock down selected features in NRI or allowing them to only be used a subset of plugins. Changes in NRI are made in two phases: “Mutating” plugins propose changes, and “Validating” plugins approve or deny them.

Validating plugins are invoked during container creation after all the changes requested to containers have been collected. Validating plugins receive the changes with extra information about which of the plugins requested what changes. They can then choose to reject the changes if they violate some of the conditions being validated.

For more details, see the Validation Plugins guide.

Validation has transactional semantics. If any validating plugin rejects an adjustment, creation of the adjusted container will fail and none of the other related changes will be made.

Validation Use Cases

Some key validation uses cases include

1. Functional Validators: These plugins care about the final state and consistency. They check if the combined effect of all mutations result in a valid configuration (e.g. are the resource limits sane).

2. Security Validators: These plugins are interested in which plugin is attempting to modify sensitive fields. They use the extra data passed to plugins in addition to adjustments to check if a potentially untrusted plugin tried to modify a restricted field, regardless of the value. Rejection might occur simply because a non-approved plugin touched a specific field. Plugins like this may need to be assured to run, and to have workloads fail-closed if the validator is not running.

3. Mandatory Plugin Validators: These ensure that specific plugins, required for certain workloads have successfully run. They might use the extra metadata passed to validator in addition to adjustments to confirm the mandatory plugin owns certain critical fields and potentially use the list of plugins that processed the container to ensure all mandatory plugins were consulted.

Default Validation

The default built-in validator plugin provides configurable minimal validation. It may be enabled or disabled by configuring the container runtime. It can be selectively configured to

1. Reject OCI Hook injection: Reject any adjustment which tries to inject OCI Hooks into a container.

2. Reject Linux seccomp policy adjustment: Reject any adjustment which tries to set/override Linux seccomp policy of a container. There are separate controls for rejecting adjustment of the seccomp policy profile based on the type of policy profile set for the container. These types include the runtime default seccomp policy profile, a custom policy profile, and unconfined security profiles.

3. Reject Linux Namespace adjustment: Reject any adjustment which tries to alter Linux namespaces of a container.

4. Reject Linux sysctl adjustment: Reject any adjustment which tries to alter Linux sysctl settings of a container.

5. Verify global mandatory plugins: Verify that all configured mandatory plugins are present and have processed a container. Otherwise reject the creation of the container.

6. Verify annotated mandatory plugins: Verify that an annotated set of container-specific mandatory plugins are present and have processed a container. Otherwise reject the creation of the container.

Containers can be annotated to tolerate missing required plugins. This allows one to deploy mandatory plugins as containers themselves.

Default Validation Scope

Currently only OCI hook injection, Linux seccomp policy, Linux namespace and Linux sysctl adjustment can be restricted using the default validator. However, this probably will change in the future. Especially when NRI is extended with control over more container properties. If newly added controls will have security implications, expect corresponding configurable restrictions in the default validator.

Runtime Adaptation

The NRI runtime adaptation package is the interface runtimes use to integrate to NRI and interact with NRI plugins. It implements basic plugin discovery, startup and configuration. It also provides the functions necessary to hook NRI plugins into lifecycle events of pods and containers from the runtime.

The package hides the fact that multiple NRI plugins might be processing any single pod or container lifecycle event. It takes care of invoking plugins in the correct order and combining responses by multiple plugins into a single one. While combining responses, the package detects any unintentional conflicting changes made by multiple plugins to a single container and flags such an event as an error to the runtime.

Wrapped OCI Spec Generator

The OCI Spec generator package wraps the corresponding package and adds functions for applying NRI container adjustments and updates to OCI Specs. This package can be used by runtime NRI integration code to apply NRI responses to containers.

Plugin Stub Library

The plugin stub hides many of the low-level details of implementing an NRI plugin. It takes care of connection establishment, plugin registration, configuration, and event subscription. All sample plugins are implemented using the stub. Any of these can be used as a tutorial on how the stub library should be used.

Sample Plugins

The following sample plugins exist for NRI:

• logger
• differ
• device injector
• network device injector
• network logger
• OCI hook injector
• ulimit adjuster
• NRI v0.1.0 plugin adapter
• WebAssembly plugin
• RDT
• template

Please see the documentation of these plugins for further details about what and how each of these plugins can be used for.

Ready-built container images for these plugins are available at ghcr.io/containerd/nri/plugins/.

Minimal kustomize overlays for deploying the sample are available at contrib/kustomize. See plugin-specific documentation for detailed examples.

[!CAUTION] Use at your own risk. The kustomize overlays provided in this repository is offered as a convenience for testing and demonstration purposes.

WebAssembly support

The NRI supports WebAssembly plugins through a SDK provided by knqyf263/go-plugin. This method works natively from go version 1.24 and works like any other binary plugin by supporting the same protocol definition. An example plugin outlining the most basic functionality can be found in plugins/wasm. There is no middle layer (stub) implemented like for the ttRPC plugins for simplicity reasons. If logging from the WebAssembly plugin is required, then the NRI provides a host function helper Log for that.

WebAssembly support is enabled by default. It can be disabled at compile time using the nri_no_wasm build tag.

Security Considerations

From a security perspective NRI plugins should be considered part of the container runtime. NRI does not implement granular access control to the functionality it offers. Access to NRI is controlled by restricting access to the systemwide NRI socket. If a process can connect to the NRI socket and send data, it has access to the full scope of functionality available via NRI.

In particular this includes

• injection of OCI hooks, which allow for arbitrary execution of processes with the same privilege level as the container runtime
• arbitrary changes to mounts, including new bind-mounts, changes to the proc, sys, mqueue, shm, and tmpfs mounts
• the addition or removal of arbitrary devices
• arbitrary changes to the limits for memory, CPU, block I/O, and RDT resources available, including the ability to deny service by setting limits very low

The same precautions and principles apply to protecting the NRI socket as to protecting the socket of the runtime itself. Unless it already exists, NRI itself creates the directory to hold its socket with permissions that allow access only for the user ID of the runtime process. By default this limits NRI access to processes running as root (UID 0). Changing the default socket permissions is strongly advised against. Enabling more permissive access control to NRI should never be done without fully understanding the full implications and potential consequences to container security.

Plugins as Kubernetes DaemonSets

When the runtime manages pods and containers in a Kubernetes cluster, it is convenient to deploy and manage NRI plugins using Kubernetes DaemonSets. Among other things, this requires bind-mounting the NRI socket into the filesystem of a privileged container running the plugin. Similar precautions apply and the same care should be taken for protecting the NRI socket and NRI plugins as for the kubelet DeviceManager socket and Kubernetes Device Plugins.

The cluster configuration should make sure that unauthorized users cannot bind-mount host directories and create privileged containers which gain access to these sockets and can act as NRI or Device Plugins. See the related documentation and best practices about Kubernetes security.

API Stability

NRI APIs should not be considered stable yet. We try to avoid unnecessarily breaking APIs, especially the Stub API which plugins use to interact with NRI. However, before NRI reaches a stable 1.0.0 release, this is only best effort and cannot be guaranteed. Meanwhile we do our best to document any API breaking changes for each release in the release notes.

The current target for a stable v1 API through a 1.0.0 release is the end of this year.

Project details

nri is a containerd sub-project, licensed under the Apache 2.0 license. As a containerd sub-project, you will find the:

• Project governance,
• Maintainers,
• and Contributing guidelines

information in our containerd/project repository.
