NICE-SLAM: Neural Implicit Scalable Encoding for SLAM

Zihan Zhu* · Songyou Peng* · Viktor Larsson · Weiwei Xu · Hujun Bao
Zhaopeng Cui · Martin R. Oswald · Marc Pollefeys

(* Equal Contribution)

CVPR 2022

Paper | Video | Project Page

NICE-SLAM produces accurate dense geometry and camera tracking on large-scale indoor scenes.

(The black / red lines are the ground truth / predicted camera trajectory)

Installation

First you have to make sure that you have all dependencies in place. The simplest way to do so, is to use anaconda.

You can create an anaconda environment called nice-slam. For linux, you need to install libopenexr-dev before creating the environment.

sudo apt-get install libopenexr-dev

conda env create -f environment.yaml
conda activate nice-slam

Visualizing NICE-SLAM Results

We provide the results of NICE-SLAM ready for download. You can run our interactive visualizer as following.

Self-captured Apartment

To visualize our results on the self-captured apartment, as shown in the teaser:

bash scripts/download_vis_apartment.sh
python visualizer.py configs/Apartment/apartment.yaml --output output/vis/Apartment

Note for users from China: If you encounter slow speed in downloading, check in all the scripts/download_*.sh scripts, where we also provide the 和彩云 links for you to download manually.

ScanNet

bash scripts/download_vis_scene0000.sh
python visualizer.py configs/ScanNet/scene0000.yaml --output output/vis/scannet/scans/scene0000_00

You can find the results of NICE-SLAM on other scenes in ScanNet here.

Replica

bash scripts/download_vis_room1.sh
python visualizer.py configs/Replica/room1.yaml --output output/vis/Replica/room1

You can find the results of NICE-SLAM on other scenes in Replica here.

Interactive Visualizer Usage

The black trajectory indicates the ground truth trajectory, abd the red is trajectory of NICE-SLAM.

• Press Ctrl+0 for grey mesh rendering.
• Press Ctrl+1 for textured mesh rendering.
• Press Ctrl+9 for normal rendering.
• Press L to turn off/on lighting.

Command line arguments

• --output $OUTPUT_FOLDER output folder (overwrite the output folder in the config file)
• --input_folder $INPUT_FOLDER input folder (overwrite the input folder in the config file)
• --save_rendering save rendering video to vis.mp4 in the output folder
• --no_gt_traj do not show ground truth trajectory
• --imap visualize results of iMAP*
• --vis_input_frame opens up a viewer to show input frames. Note: you need to download the dataset first. See the Run section below.

Demo

Here you can run NICE-SLAM yourself on a short ScanNet sequence with 500 frames.

First, download the demo data as below and the data is saved into the ./Datasets/Demo folder.

bash scripts/download_demo.sh

Next, run NICE-SLAM. It takes a few minutes with ~5G GPU memory.

python -W ignore run.py configs/Demo/demo.yaml

Finally, run the following command to visualize.

python visualizer.py configs/Demo/demo.yaml

NOTE: This is for demonstration only, its configuration/performance may be different from our paper.

Run

Self-captured Apartment

Download the data as below and the data is saved into the ./Datasets/Apartment folder.

bash scripts/download_apartment.sh

Next, run NICE-SLAM:

python -W ignore run.py configs/Apartment/apartment.yaml

ScanNet

Please follow the data downloading procedure on ScanNet website, and extract color/depth frames from the .sens file using this code.

  DATAROOT
  └── scannet
      └── scans
          └── scene0000_00
              └── frames
                  ├── color
                  │   ├── 0.jpg
                  │   ├── 1.jpg
                  │   ├── ...
                  │   └── ...
                  ├── depth
                  │   ├── 0.png
                  │   ├── 1.png
                  │   ├── ...
                  │   └── ...
                  ├── intrinsic
                  └── pose
                      ├── 0.txt
                      ├── 1.txt
                      ├── ...
                      └── ...

Once the data is downloaded and set up properly, you can run NICE-SLAM:

python -W ignore run.py configs/ScanNet/scene0000.yaml

Replica

Download the data as below and the data is saved into the ./Datasets/Replica folder. Note that the Replica data is generated by the authors of iMAP, so please cite iMAP if you use the data.

bash scripts/download_replica.sh

and you can run NICE-SLAM:

python -W ignore run.py configs/Replica/room0.yaml

The mesh for evaluation is saved as $OUTPUT_FOLDER/mesh/final_mesh_eval_rec.ply, where the unseen regions are culled using all frames.

TUM RGB-D

Download the data as below and the data is saved into the ./Datasets/TUM-RGBD folder

bash scripts/download_tum.sh

Now run NICE-SLAM:

python -W ignore run.py configs/TUM_RGBD/freiburg1_desk.yaml

Co-Fusion

First, download the dataset. This script should download and unpack the data automatically into the ./Datasets/CoFusion folder.

bash scripts/download_cofusion.sh

Run NICE-SLAM:

python -W ignore run.py configs/CoFusion/room4.yaml

Use your own RGB-D sequence from Kinect Azure

python -W ignore run.py configs/Own/sample.yaml

bash scripts/download_open3d.sh

# specify scene ID
sceneid=0
cd 3rdparty/Open3D-0.13.0/examples/python/reconstruction_system/
# record and save to .mkv file
python sensors/azure_kinect_recorder.py --align_depth_to_color --output scene$sceneid.mkv
# extract frames
python sensors/azure_kinect_mkv_reader.py --input  scene$sceneid.mkv --output dataset/scene$sceneid

python run_system.py dataset/scene$sceneid/config.json --make --register --refine --integrate
# back to main folder
cd ../../../../../

python src/tools/prep_own_data.py --scene_folder 3rdparty/Open3D-0.13.0/examples/python/reconstruction_system/dataset/scene$sceneid --ouput_config configs/Own/scene$sceneid.yaml

python -W ignore run.py configs/Own/scene$sceneid.yaml

iMAP*

We also provide our re-implementation of iMAP (iMAP*) for use. If you use the code, please cite both the original iMAP paper and NICE-SLAM.

Usage

iMAP* shares a majority part of the code with NICE-SLAM. To run iMAP*, simply use *_imap.yaml in the config file and also add the argument --imap in the command line. For example, to run iMAP* on Replica room0:

python -W ignore run.py configs/Replica/room0_imap.yaml --imap

To use our interactive visualizer:

python visualizer.py configs/Replica/room0_imap.yaml --imap

To evaluate ATE:

python src/tools/eval_ate.py configs/Replica/room0_imap.yaml --imap

Evaluation

Average Trajectory Error

To evaluate the average trajectory error. Run the command below with the corresponding config file:

python src/tools/eval_ate.py configs/Replica/room0.yaml

Reconstruction Error

To evaluate the reconstruction error, first download the ground truth Replica meshes where unseen region have been culled.

bash scripts/download_cull_replica_mesh.sh

Then run the command below (same for NICE-SLAM and iMAP*). The 2D metric requires rendering of 1000 depth images, which will take some time (~9 minutes). Use -2d to enable 2D metric. Use -3d to enable 3D metric.

# assign any output_folder and gt mesh you like, here is just an example
OUTPUT_FOLDER=output/Replica/room0
GT_MESH=cull_replica_mesh/room0.ply
python src/tools/eval_recon.py --rec_mesh $OUTPUT_FOLDER/mesh/final_mesh_eval_rec.ply --gt_mesh $GT_MESH -2d -3d

We also provide code to cull the mesh given camera poses. Here we take culling of ground truth mesh of Replica room0 as an example.

python src/tools/cull_mesh.py --input_mesh Datasets/Replica/room0_mesh.ply --traj Datasets/Replica/room0/traj.txt --output_mesh cull_replica_mesh/room0.ply

Acknowledgement

We adapted some codes from some awesome repositories including convolutional_occupancy_networks, nerf-pytorch, lietorch, and DIST-Renderer. Thanks for making codes public available. We also thank Edgar Sucar for allowing us to make the Replica Dataset available.

Citation

If you find our code or paper useful, please cite

@inproceedings{Zhu2022CVPR,
  author    = {Zhu, Zihan and Peng, Songyou and Larsson, Viktor and Xu, Weiwei and Bao, Hujun and Cui, Zhaopeng and Oswald, Martin R. and Pollefeys, Marc},
  title     = {NICE-SLAM: Neural Implicit Scalable Encoding for SLAM},
  booktitle = {Proceedings of the IEEE/CVF Conference on Computer Vision and Pattern Recognition (CVPR)},
  year      = {2022}
}

Contact

Contact Zihan Zhu and Songyou Peng for questions, comments and reporting bugs.
