=== ZiYa by Fernand Galiana git://github.com/derailed/ziya.git

== DESCRIPTION:

ZiYa allows you to easily create interactive charts, gauges and maps for your web applications. ZiYa leverages flash which offload heavy server side processing to the client. At the root ZiYa allows you to easily generate an XML files that will be downloaded to the client for rendering. Using this gem, you will be able to easily create great looking charts for your application. You will also be able to use the charts, gauges and maps has a navigation scheme by embedding various link in the graphical components thus bringing to the table an ideal scheme for reporting and dashboard like applications. Your manager will love you for it !!

Sample site   : http://ziya.liquidrail.com
Documentation : http://ziya.liquidrail.com/docs
Forum         : http://groups.google.com/group/ziya-plugin
Repositories  : git://github.com/derailed/ziya.git

== FEATURES:

• Supports a wide variety of chart/gauge types, sure to fit your needs.
• Geographical maps. Maps can be drillable and refreshable
• Relieves your server load by generating the actual chart on the client side.
• Provides for cascading like css-styles for your charts using YAML files.
• Themes support. You can change the appearance and behavior of any charts by introducing new themes

== REQUIREMENTS:

ZiYa depends on the following gems

• logging
• color
• builder

ZiYa comes pre-bundled with the following packages:

• XML/SWF charts Version 5.07 (http://www.maani.us/xml_charts/index.php)
• XML/SWF gauges Version 1.6 (http://www.maani.us/gauge/index.php)
• DIY Maps (http://backspace.com/mapapp/)

XML/SWF * XML/SWF charts are free of charge unless you need to use special features such as embedded links and printing.

  The package cost $45 per domain, including localhost and is well worth the investment.
  A similar fee applies to the gauge framework.

DIY Map * This package is free for use in non-commercial applications. For commercial applications, there is a $20.00 license per domain. I have chosen this package over others, as it supports the interaction and configuration I was looking for, it seems stable and packs lots of features for a reasonable price.

== INSTALL:

gem install ziya

cd to your application directory and issue the following command

ziyafy --charts

This will copy the necessary themes and flash files to run ZiYa in your application public/charts directory. You can install maps and gauges components as well. Type in

ziyafy --help

To see all available options.

== SYNOPSIS:

This gem version requires a client update to flash 10.0 and possibly you will need to get a new license from XML/SWF >= 5.0, if you want to use advanced features suck as links and live updates.

== Creating a ZiYa chart in a Rails 3.0 application

1 - Edit your Gemfile and add the followings: gem 'ziya', '2.3.0' gem 'color' gem 'logging' gem 'builder'

2 - Create a ziya.rb file under config/initializers

  ziya.rb:

    require 'ziya'

    # Initializes the ZiYa Framework
    Ziya.initialize(
      :logger     => Rails.logger,
      :themes_dir => File.join( File.dirname(__FILE__), %w[.. .. public charts themes])
    )

   This will initialize the gem. You can log the output to stdout using the ZiYa bundled logger
   or specify a file ie File.join( File.dirname(__FILE__), %w[.. log ziya.log]. If you choose to use the
   ZiYa logger, you can specify the :log_level option to either :warn :info :debug or :error.
   You will need to specify your themes directory typically located under public/charts/themes or any location
   you'll like to choose.


3 - Create a chart controller

  blee_controller.rb:

   class BleeController < ApplicationController
    helper Ziya::HtmlHelpers::Charts, Ziya::YamlHelpers::Charts

    # Callback from the flash movie to get the chart's data
    def load_chart
      # Create a bar chart with 2 series composed of 3 data points each.
      # Chart will be rendered using the default look and feel
      chart = Ziya::Charts::Bar.new
      chart.add( :axis_category_text, %w[2006 2007 2008] )
      chart.add( :series, "Dogs", [10,20,30] )
      chart.add( :series, "Cats", [5,15,25] )
      respond_to do |fmt|
        fmt.xml { render :xml => chart.to_xml }
      end
    end
  end

4 - Create a view

  blee/index.html.erb:

    # Defines the necessary tag to embed a flash movie in your html page.
    # This will callback to your controller to fetch the necessary xml.
    <%= ziya_chart load_chart_url(:xml) -%>

  NOTE: You must now specify the xml format for correct rendering!


5 - Create a named route

  config/routes.rb:

   match 'blee'       => "blee#index"
   match 'load_chart' => "blee#load_chart"

== Creating a ZiYa chart in a Rails 2.3 application

1 - Create a ziya.rb file under config/initializers

  ziya.rb:

    # Pull in the ZiYa gem framework
    gem 'derailed-ziya', '= 2.1.0'
    require 'ziya'

    # Initializes the ZiYa Framework
    Ziya.initialize(
      :logger     => RAILS_DEFAULT_LOGGER,
      :themes_dir => File.join( File.dirname(__FILE__), %w[.. .. public charts themes])
    )

   This will initialize the gem. You can log the output to stdout using the ZiYa bundled logger
   or specify a file ie File.join( File.dirname(__FILE__), %w[.. log ziya.log]. If you choose to use the
   ZiYa logger, you can specify the :log_level option to either :warn :info :debug or :error.
   You will need to specify your themes directory typically located under public/charts/themes or any location
   you'll like to choose.


3 - Create a chart controller

  blee_controller.rb:

   class BleeController < ApplicationController
    helper Ziya::HtmlHelpers::Charts, Ziya::YamlHelpers::Charts

    # Callback from the flash movie to get the chart's data
    def load_chart
      # Create a bar chart with 2 series composed of 3 data points each.
      # Chart will be rendered using the default look and feel
      chart = Ziya::Charts::Bar.new
      chart.add( :axis_category_text, %w[2006 2007 2008] )
      chart.add( :series, "Dogs", [10,20,30] )
      chart.add( :series, "Cats", [5,15,25] )
      respond_to do |fmt|
        fmt.xml { render :xml => chart.to_xml }
      end
    end
  end

4 - Create a view

  blee/index.html.erb:

    # Defines the necessary tag to embed a flash movie in your html page.
    # This will callback to your controller to fetch the necessary xml.
    <%= ziya_chart load_chart_url -%>

5 - Create a named route

  config/routes.rb:

   map.load_chart '/blee/load_chart', :controller => 'blee', :action => 'load_chart'

== Styling a chart

=== Basic Theme

1 - Create a directory fred in public/charts/themes 2 - Create a file called column_chart.yml under the fred directory 2 - Edit column_chart.yml and add the following lines mind the yaml 2 space indentation!

<%= chart :column %> <%=comp :axis_category %> color: ff0000

3 - In fred_controller add the following directive to the chart to associate your new theme with the chart

chart.add( :theme, 'fred' )

4 - reload the page and you should now see the red x axis label

=== Cascading themes

To override the default column chart theme, you may now create an instance theme.

1 - Create fred.yml in public/chart/themes/fred

2 - Edit fred.yml as follows

<%= chart :column %> <%=comp :axis_category %> color: 00ff00

3 - Edit your controller to indicate the instance theme name

chart = Ziya::Charts.Column.new( nil, 'fred' )

4 - Reload the page - The x axis category labels should now be green.

NOTE: There are lots of setup example for themes in the ziya-galeria app at git://github.com/derailed/ziya-galeria.git. The themes component follows the xml/swf xml settings for configuration which are documented here http://www.maani.us/xml_charts/index.php?menu=Reference

=== Using theme helpers

Just like rails view template helpers, ZiYa support helpers for theme stylesheets. In order to use a helper for your chart you will need to use the following steps:

1 - Create a ziya directory under app/helpers 2 - Create a file called fred_helper.rb 3 - Edit fred_helper.rb and add the following lines

module Ziya::FredHelper def random_color %w[ffaa00 aaff00 aabbff][rand(3)] end end

4 - Edit you theme stylesheet to call the helper method

In fred.yml

<%= chart :column %> <%=comp :axis_category %> color: <%= random_color %>

5 - Edit you config/initializer/ziya.rb and add the following line

  # Initializes the ZiYa Framework
  Ziya.initialize( :logger => RAILS_DEFAULT_LOGGER,
    :helpers_dir    => File.join( File.dirname(__FILE__), %w[.. .. app helpers ziya] ), # <-- New line !!
    :themes_dir     => File.join( File.dirname(__FILE__), %w[.. .. public charts themes])
  )

6 - Restart your app server 7 - Reload the page serveral time and watch the x axis label color change

== Creating a gauge for a rails application

You will need to modify the ziya initializer and add the following directive

Ziya.initialize(
  :logger      => RAILS_DEFAULT_LOGGER,
  :designs_dir => File.join( File.dirname(__FILE__), %w[.. .. public gauges designs] ), # => Add this !!
  :themes_dir  => File.join( File.dirname(__FILE__), %w[.. .. public charts themes]) )


• fred_controller.rb

  class FredController < ApplicationController def load_gauge gauge = Ziya::Gauges::Base.new( LICENCE_KEY, 'my_gauge' ) respond_to do |fmt| fmt.xml => { render :xml => gauge.to_xml } end end
  end

• fred/index.html.erb

<%= ziya_gauge load_gauge_url -%>

• config/routes.rb

Creates a named route for the chart.

map.load_gauge '/fred/load_gauge', :controller => 'fred', :action => 'load_gauge'

• public/gauges/designs/my_gauge.yml

In the design file you will leverage the components defined in the Ziya::Gauges::Support package to create your gauge desgins. You gauges can be animated using rotate, scale and move operations. In this example we will create a volume control that will rotate to the desired position. In real life you will fetch the volume level from your models to set the desired position. Take a look at the ZiYa sample application for the various possibilities. You can think of a gauge as a portable canvas element where you can draw you own designs using the various components provided ZiYa components ( No need to worry about various browsers' canvas support )

<%= gauge :base %>
# specifies the number of ticks to draw in a circular fashion <%= dial :radial_ticks, :volume %> x: 100 y: 75 radius: 35 length: 4 start_angle: 235 end_angle: 485 ticks: 10 thickness: 2 color: 000000 # rotates the volume to the desired position. <%= dial :rotate, :volume_setting %> x: 100 y: 75 start: 300 span: 160 step: 5 skake_span: 20 shadow_alpha: 20 shadow_x_offset: 3 shadow_y_offset: 3 <%= dials %> <%= dial :circle, :circle_1 %> x: 100 y: 75 radius: 30 fill_color: 777777 line_thickness: 5 line_alpha: 75
<%= dial :circle, :circle_2 %> x: 100 y: 55 radius: 5 fill_alpha: 80
