dgtlmoon/sockpuppetbrowser

Sock Puppet(eer) Browser.

What is this?

This is a high-performance proxy for Chrome so that you can drive many simultaneous Chrome browsers easily and efficiently.

When you connect on ws://127.0.0.1:3000 as your "CDP Chrome Browser URL" URL it will always spin up a new fresh Chrome instance.

This project is the OpenSource'ed browser back-end for the amazing opensource web page change detection project.

When a request for a new Chrome CDP starts, this software will launch an individual isolated-ish Chrome process for just that request (This is a Chrome CDP "Proxy")

It is based on the excellent https://github.com/Zenika/alpine-chrome, and we add our own wrapper to launch individual chrome instances on demand.

When ever something requiring puppeteer connects via ws://.. it will spin up a new Chrome browser instance and connect you through (proxy you through) to that Chrome's DevTools connection.

It also handles throttling, scaling, and accepting extra Chrome settings on the connection query.

Under-the-hood it is a simple Python websockets wrapper using a puppeteer image, so that we can be sure that all the basic configuration required for Chrome to work will function well.

Why do I need this?

This provides a Chrome interface to applications that need it, usually for example as required when using Playwright - Playwright will launch a node instance and start issuing CDP (Chrome protocol) commands to drive the actual project. So you need this project.

(Playwright gives a high-level command set, which talks to node, that node then does the low-level CDP commands to drive Chrome directly)

It is also more efficient to not need that extra node process like with some other systems (you would end up with two node processes).

playwright -> node -> [sockpuppetserver] -> CDP protocol todo the browser business

Because this method is always built ontop of the latest puppeteer release, it's a lot more secure and reliable than relying on projects to invidually update their Chrome browsers and configurations.

You can skip the whole python -> node mess by using https://github.com/pyppeteer/pyppeteer and talk to this container directly.

How to run

wget https://raw.githubusercontent.com/dgtlmoon/sockpuppetbrowser/refs/heads/master/chrome.json
docker run --rm --security-opt seccomp=$(pwd)/chrome.json -p 127.0.0.1:3000:3000 dgtlmoon/sockpuppetbrowser

seccomp security setting is highly recommended https://github.com/Zenika/alpine-chrome?tab=readme-ov-file#-the-best-with-seccomp

Headful Mode with Virtual Display

By default, Chrome runs in headless mode for maximum performance. However, you can enable "headful" mode which runs Chrome with a virtual X server (Xvfb) for scenarios requiring visual rendering or when certain websites detect headless browsers.

Enable headful mode:

ws://127.0.0.1:3000/?headful=true

Or via environment variable:

docker run --rm -e CHROME_HEADFUL=true --security-opt seccomp=$(pwd)/chrome.json -p 127.0.0.1:3000:3000 dgtlmoon/sockpuppetbrowser

Headful mode features:

• Each Chrome instance gets its own isolated virtual display using xvfb-run -a
• Automatic display allocation and cleanup when Chrome exits
• Scales efficiently - hundreds of concurrent headful browsers supported
• Better compatibility with websites that detect automation
• Supports visual rendering, screenshots, and DOM operations that require a display

Performance considerations:

• Headless mode: ~150+ concurrent browsers per 16-core CPU
• Headful mode: Slightly higher memory usage due to Xvfb processes, but still scales well

Statistics

Access http://127.0.0.1:8080/stats or which ever hostname you bind to, use --sport to specify something other than 8080

{
  "active_connections": 158,
  "connection_count_total": 8383,
  "mem_use_percent": 46.9,
  "special_counter_len": 0
}

You can also add this to your fetch and access 'special_counter_len' at the /stats URL, this is good for adding at the end of your scripts so you know the actual script ran all steps.

        try:
            await self.page._client.send("SOCKPUPPET.specialcounter")
        except:
            pass

Debug CDP session logs

Sometimes you need to examine the low-level Chrome CDP protocol interaction, enable ALLOW_CDP_LOG=yes environment variable and add &log-cdp=/path/somefile.txt to the connection URL.

Then the log will contain the CDP session, for example:

1712224824.5491815 - Attempting connection to ws://localhost:56745/devtools/browser/899f78ce-e7c8-4ad1-b8c9-a7aa449a93ef
1712224824.5528538 - Connected to ws://localhost:56745/devtools/browser/899f78ce-e7c8-4ad1-b8c9-a7aa449a93ef
1712224824.5529754 - Puppeteer -> Chrome: {"method": "Target.getBrowserContexts", "params": {}, "id": 1}
1712224824.553542 - Chrome -> Puppeteer: {"id":1,"result":{"browserContextIds":[]}}
...

Setting Viewport Size

Control the browser viewport dimensions for screenshots and page rendering:

Via connection URL (recommended):

When running from in thedocker-compose.yml of changedetection.io project. ( https://github.com/dgtlmoon/changedetection.io/blob/dev/docker-compose.yml#L21 )

- PLAYWRIGHT_DRIVER_URL=ws://browser-sockpuppet-chrome:3000/?--window-size=1920,1080

Or configured from inside the changedetection.io interface as a [Extra Browsers] from the settings tab. (when run from the same docker-compose.yml)

<img src=docs/cdio-config-extra-browsers.png alt="Setup and choose mobile browser and other dimensions">

Then you can select the viewport size you like in the browser for checking the web-page for changes.

<img src=docs/cdio-browser-selection.png alt="Choosing a different size browser for checking a page for changes.">

Or, via environment variables:

You can run this container with a different default size.

docker run -e SCREEN_WIDTH=1920 -e SCREEN_HEIGHT=1080 --security-opt seccomp=$(pwd)/chrome.json -p 127.0.0.1:3000:3000 dgtlmoon/sockpuppetbrowser

If neither is specified, Chrome will use its default viewport size.

Tuning

Some tips on high-concurrency scraping and tuning where you have a lot of chrome browsers running simultaneously

• Understand different Chrome command line options https://github.com/GoogleChrome/chrome-launcher/blob/main/docs/chrome-flags-for-tools.md and specify them on the connection URL
• Set your inotify values higher https://stackoverflow.com/questions/32281277/too-many-open-files-failed-to-initialize-inotify-the-user-limit-on-the-total
• Don't burn out your disk!! Mount the path for --user-data-dir as a RAM Disk/tmpfs disk ! This will also help to speed up Chrome

On a Intel(R) Xeon(R) E-2288G CPU @ 3.70GHz (16 core), it will sustain 150 concurrent browser sessions with a load average of about 65-70 (about 3-4 browsers per CPU core it means).

Most of the CPU load seems to occur when starting a browser, maybe in the future 1 browser could processes multiple requests.

Docker healthcheck

Add this to your docker-compose.yml, it will check port 3000 answers and that the /stats endpoint on port 8080 responds

    healthcheck:
      test: "python3 /usr/src/app/docker-health-check.py --host http://localhost"
      interval: 30s
      timeout: 5s
      retries: 3
      start_period: 10s

To review deeper docker container information about the containers health

docker inspect --format='{{json .State.Health}}' browser-sockpuppetbrowser-1

Future ideas

• Some super cool "on the wire" hacks to add custom functionality to CDP, like issuing single commands to download files (PDF) to location https://github.com/dgtlmoon/changedetection.io/issues/2019

Have fun!
