eerimoq/moblin

Moblin - IRL Streaming

A free iOS app for IRL streaming. Mainly targeting Twitch, but can stream to YouTube, Kick, Facebook and OBS Studio as well (and probably more).

Discord: https://discord.gg/kh3KMng4JV

Github: https://github.com/eerimoq/moblin

TestFlight: https://testflight.apple.com/join/PDpxEaGh

Privacy policy: https://eerimoq.github.io/moblin/privacy-policy/en.html

Features

Main app

• Stream using RTMP, RTMPS, SRT, SRTLA, RIST or WHIP (WebRTC) to any platform that supports them.
• H.264/AVC and H.265/HEVC video codecs.
• Up to 4K resolution and 60 FPS. Use 120 FPS at your own risk.
• SRTLA and RIST.
  • Can use one cellular, one WiFi and multiple Ethernet connections simultaneously. Often called bonding.
  • Upload statistics per active connection.
• Twitch integration.
  • Number of viewers.
  • Chat.
    • Announcements.
    • /me styling.
    • Ban.
    • Timeout.
    • Delete message.
    • Gray out or hide deleted messages.
    • Show reply.
  • Optional login.
    • Follow, subscribe and raid alerts.
    • Set stream title and category.
    • Start ads.
    • Hype train.
    • Cheered bits in chat.
• Kick integration.
  • Number of viewers.
  • Subscription, host, and kicks.
  • Chat.
    • Set stream title and category.
    • Ban.
    • Timeout.
    • Delete message.
    • Gray out or hide deleted messages.
    • Show reply.
• YouTube integration.
  • Chat.
• SOOP integration.
  • Scuffed chat.
• Basic scenes.
  • Alerts widget.
    • Trigged by Twitch events and chat messages.
  • Image widget. Show an image on stream.
  • Text widget.
    • Any text.
    • Weather conditions.
    • Temperature.
    • Timer.
    • Stopwatch.
    • Country.
    • City.
    • Subtitles. Speech to text.
    • Local time.
    • Speed.
    • Altitude.
    • Distance. Reset manually.
    • Debug information.
    • Muted.
    • Checkboxes.
    • Ratings.
    • Date.
    • G-force.
    • ...
  • Browser widget. Show a web page on stream.
    • Optional style sheet.
  • Map widget with location.
  • QR code widget.
  • Scene widget.
  • Video soure widget (for multi cam).
  • Scoreboard widget.
    • Padel.
    • Golf.
    • Volleyball.
    • ...
  • ...
• Back, front or multi camera.
  • Front camera mirrored on screen for natural experience.
• Low energy triple and dual cameras.
• Back, front, top, bottom or external mic.
  • Automatically changes to external mic when connected.
• Video stabilization.
• Zoom.
  • Pinch-to-zoom.
  • Configurable presets.
• Back camera lens selection.
• Record to disk (MP4-file).
  • Configurable bitrate, video codec and key frame interval.
• RTMP, SRT(LA), RIST, RTSP and WHIP (WebRTC) ingests.
• Localization. Supports many languages, for example English, French, German, Spanish, Polish, Chinese (Simplified) and Swedish.
• Tap screen for manual focus.
  • Return to auto focus with long press.
• Stream connection status and uptime.
• OBS WebSocket (remote control)
  • See current scene, streaming state and recoring state.
  • Change scene.
  • Start and stop the stream.
  • Snapshot.
  • Audio levels.
  • Set audio sync.
  • Mute/unmute audio inputs.
• Make phone screen black by pressing a button.
• Supports UVC (USB-C) cameras on iPad.
• Basic support for Mac.
• Video effects.
  • Grayscale.
  • Movie. Paint top and bottom of 16:9 video black to look like 2.35:1.
  • 4:3. Paint left and right of 16:9 video black to look like 4:3.
  • Seipa.
  • Noise reduction.
  • Random. A single effect that applies a random effect.
  • Triple. Show center of image three times. Experimental.
  • ...
• Alerts.
  • Optional text to speech (TTS).
    • Many voices.
  • Text message colors, font weight, font design and more.
  • Select sound and image per alert.
  • Image placement relative to your face or scene.
• Chat.
  • Alerts filter.
  • Send messages to Twitch.
  • Highlight important events.
  • Optional text to speech (TTS).
    • Optionally subscribers only.
    • Many voices.
    • Detect language per message.
    • Optionally use TTS.Monster.
  • Colors, background, border and bold.
  • Twitch, Kick, BTTV, FFZ and 7TV emotes.
  • Optionally animated emotes.
  • Optionally remove old messages.
  • Width and height.
  • Optional message timestamp.
• Color spaces (for devices that supports them).
  • sRGB.
  • P3 D65.
  • Apple Log.
• Bundled and custom 3D LUT effects.
  • Especially useful when using Apple Log.
• Battery indicator.
  • Charging icon.
  • Optionally with percentage.
• Web browser.
  • Only visible to the streamer.
• Game controllers for remote control.
  • Zoom in and out.
  • Change scene.
  • Torch.
  • Mute.
  • ...
• Moblink for more connection.
• Low light boost.
• Cosmetics.
  • Select Moblin icon to show in app and on home screen.
  • Optionally purchase additional Moblin icons to support developers.
• Configure stream resolution, FPS, video codec, bitrate and more.
• Configurable bitrate presets.
• Adaptive bitrate for SRT(LA).
• Optionally remote control the streamer's Moblin app over the network.
  • Shows basic status information.
  • Change scene.
  • Change mic.
  • Change bitrate.
  • Change zoom.
  • Show logs.
  • ...
• Torch.
• Mute audio.
• Deep link settings (moblin://).
  • Including a deep link creator for service providers.
• Landscape.
  • Both 0 and 180 degrees orientation. Video always with gravity down (never upside down).
• Portrait.
  • UI in portrait, but video in landscape. To be improved.
• Background streaming.
  • With audio.
  • Video will be a freezed frame as video cannot be captured in background.
• Simple poll.
  • Chat types 1, 2 or 3.
• Chat bot.
  • Commands.
    • Turn chat text to speech on an off.
    • Fix OBS.
    • Map zoom out.
    • Trigger alerts.
    • Fax.
    • Turn filters on and off.
    • Let chat take snapshot.
    • ...
  • Send low battery warning to chat periodically.
• Screen capture as video source.
• Basic video player as video source and mic.
• DJI camera Bluetooth controller.
  • Automatically start DJI camera live stream.
  • Tested with OA4, OA3 and OP3.
• GoPro QR-code creator.
• Show grid for easier positioning.
• Camera settings (on some cameras).
  • Exposure bias.
  • White balance.
  • ISO.
  • Focus.
• Cat printer.
  • Print chat and faxes (images).
  • Optional meow sound when printing.
• Take snapshots.
  • And optionally automatically upload to your Discord server.
• Save and play replays.
• Tesla vehicle status and control.
• Support for DockKit gimbals.
• Cycling power monitor.
• Heart rate monitor.
• Show video on external dispaly. Aka clean HDMI out.
• Basic VTuber and PNGTuber.
• Auto scene switcher.
• RTMP(S) multi streaming.

Apple Watch companion app

• Stream preview.
• Show audio level.
• Show bitrate.
• Show iPhone thermal state.
• Chat.
  • Limited to 50 messages.
• Control.
  • Zoom using digital crown and presets.
  • Switch scene.
  • Go live.
  • Record.
  • Mute.
  • Skip current TTS message.
• Watch face complication.

Import settings using moblin:// (custom URL)

Examples

New stream

An example creating a new stream is

moblin://?{"streams":[{"name":"BELABOX%20UK","url":"srtla://uk.srt.belabox.net:5000?streamid=9812098rh9hf8942hid","video":{"codec":"H.265/HEVC"},"obs":{"webSocketUrl":"ws://123.22.32.112:5465","webSocketPassword":"foobar"}}]}

where the URL decoded pretty printed JSON blob is

{
  "streams": [
    {
      "name": "BELABOX UK",
      "url": "srtla://uk.srt.belabox.net:5000?streamid=9812098rh9hf8942hid",
      "video": {
        "codec": "H.265/HEVC"
      },
      "obs": {
        "webSocketUrl": "ws://123.22.32.112:5465",
        "webSocketPassword": "foobar"
      }
    }
  ]
}

Quick button settings

An example with only two quick buttons enabled is

moblin://?{"quickButtons":{"twoColumns":false,"showName":true,"enableScroll":true,"disableAllButtons":true,"buttons":[{"type":"Mute","enabled":true},{"type":"Draw","enabled":true}]}}

where the URL decoded pretty printed JSON blob is

{
  "quickButtons": {
    "twoColumns": false,
    "showName": true,
    "enableScroll": true,
    "disableAllButtons": true,
    "buttons": [
      {
        "type": "Mute",
        "enabled": true
      },
      {
        "type": "Draw",
        "enabled": true
      }
    ]
  }
}

Specification

Format: moblin://?<URL encoded JSON blob>

The MoblinSettingsUrl class in MoblinSettingsUrl.swift defines the JSON blob format. Class members are JSON object keys. Members with ? after the type are optional.

Browser widget JavaScript API

Get access to various data in your Browser widget.

NOTE: You must enable Settings -> Scenes -> My browser widget -> Moblin access to give the website access to the Browser widget JavaScript API.

Example

Add this code to your website to receive chat messages with prefix !.

moblin.subscribe({ chat: { prefix: "!" } });
moblin.onmessage = (message) => {
  if (message.chat !== undefined) {
    console.log(message.chat.message);
  }
};

Add this code to your website to receive the speech to text transcript. You must enable Settings -> Scenes -> My browser widget -> Speech to text as well. text is a sliding window of the latest transcript and position is the offset of its first character, counted from when speech to text started. The transcript is cleared after a few seconds of silence.

moblin.subscribe({ speechToText: {} });
moblin.onmessage = (message) => {
  if (message.speechToText !== undefined) {
    console.log(message.speechToText.position, message.speechToText.text);
  }
  if (message.speechToTextClear !== undefined) {
    console.log("Transcript cleared");
  }
};

Specification

Topics to subscribe to are defined by SubscribeTopic in BrowserEffectServer.swift.

Messages passed to onmessage are defined by Message in BrowserEffectServer.swift.

Similar software

• https://irlpro.app/
• Twitch app.
• https://softvelum.com/larix/ios/

Development environment setup

Build the project

Roughly the steps to setup Moblin's developement environment.

1. Install Xcode with iOS and MacOS simulators on your Mac.

2. Open a terminal.

3. Clone Moblin.

   git clone https://github.com/eerimoq/moblin.git

4. Enter Moblins repository.

   cd moblin

5. Create Config/User.xcconfig. This file contains user specific settings and is not under version control.

   cp User.template.xcconfig Config/User.xcconfig

6. Open the Moblin project in Xcode. Wait for the dependencies to load.

   open Moblin.xcodeproj

7. Modify Config/User.xcconfig in Xcode.

8. Press Command + B to build Moblin.

9. Enable developer mode in your iPhone/iPad.

10. Select you iPhone/iPad as Run Destination in Xcode (at the top in the middle).

11. Build and run by pressing Command + R.

12. Done!

Styling, linting and more

1. Install tools.

   brew install swiftlint
   brew install swiftformat
   brew install codespell
   brew install oxfmt
   brew install oxlint
   brew install python3.14
   python3.14 -m venv .venv
   source .venv/bin/activate
   pip install -r requirements.txt -U


2. Perform styling, linting and more.

   source .venv/bin/activate       # Once per shell is enough.
   make style lint spell-check


3. Done!

Web remote control frontend

It's built with SolidJS.

1. Install dependencies.

   make web-remote-control-frontend-prepare

2. Modify files in WebRemoteControlFrontend/.

3. Build to update files in Moblin/RemoteControl/Web/*.

   make web-remote-control-frontend-build

4. Done!
