SegMap

SegMap is a map representation based on 3D segments allowing for robot localization, environment reconstruction, and semantics extraction. The SegMap code is open-source (BSD License) and has been tested under Ubuntu 14.04, 16.04 and ROS Indigo, Kinetic. Please remember that this is on-going research code which is subject to changes in the future.

Related Publications

R. Dubé, A. Cramariuc, D. Dugas, H. Sommer, M. Dymczyk, J. Nieto, R. Siegwart, and C. Cadena. SegMap: Segment-based mapping and localization using data-driven descriptors The International Journal of Robotics Research (IJRR), 2019 pdf

R. Dubé, A. Cramariuc, D. Dugas, J. Nieto, R. Siegwart, and C. Cadena. "SegMap: 3D Segment Mapping using Data-Driven Descriptors." Robotics: Science and Systems (RSS), 2018. pdf - video

R. Dubé, MG. Gollub, H. Sommer, I. Gilitschenski, R. Siegwart, C. Cadena and , J. Nieto. "Incremental Segment-Based Localization in 3D Point Clouds." IEEE Robotics and Automation Letters, 2018. pdf

R. Dubé, D. Dugas, E. Stumm, J. Nieto, R. Siegwart, and C. Cadena. "SegMatch: Segment Based Place Recognition in 3D Point Clouds." IEEE International Conference on Robotics and Automation, 2017. pdf - video

Features

• 3D CNN encoder – decoder
• ICP based LiDAR odometry
• Dynamic voxel grid
• Single and multi-robot SLAM back-end
• Generic incremental region-growing segmentation
• Incremental geometric verification

Installation

The SegMap repository contains the following modules:

• segmap: The C++ library for 3D segment mapping.
• segmap_ros: ROS interface for segmap.
• segmapper: Example application using segmap and ros.
• laser_slam: Backend for the example application, based on LiDAR sensor data.
• segmappy: Python library for training and evaluating the neural network models.

This section provides a step by step guide to installing the full flavor of SegMap. Advanced: it is also possible to use the SegMap C++ library standalone in a C++ project, or integrate the C++ library and ROS interface in a ROS project.

Dependencies

First install the required system packages:

$ sudo apt-get install python-wstool doxygen python3-pip python3-dev python-virtualenv dh-autoreconf

Set up the workspace configuration:

$ mkdir -p ~/segmap_ws/src
$ cd ~/segmap_ws
$ catkin init
$ catkin config --merge-devel
$ catkin config --cmake-args -DCMAKE_BUILD_TYPE=Release

Then use wstool for fetching catkin dependencies:

$ cd src
$ git clone https://github.com/ethz-asl/segmap.git
$ wstool init
$ wstool merge segmap/dependencies.rosinstall
$ wstool update

Tensorflow

SegMap relies on the package tensorflow_ros_cpp for linking to the tensorflow C++ API. All our code has been tested with Tensorflow 1.8.

$ virtualenv ~/segmappyenv
$ source ~/segmappyenv/bin/activate
(segmappyenv)$ pip install --upgrade pip
(segmappyenv)$ pip install catkin_pkg empy pyyaml
(segmappyenv)$ pip install tensorflow-gpu==1.8.0

Build tensorflow_ros_cpp

For more details on the optional compile flags or in case of issues compiling see the FAQ.

$ cd ~/segmap_ws
$ catkin build tensorflow_ros_cpp

Build SegMap

Finally, build the segmapper package which will compile all dependencies and SegMap modules:

$ cd ~/segmap_ws
$ catkin build segmapper

(Optional) Install SegmapPy python package

Installing segmappy allows you to train data-driven models yourself to use with SegMap.

$ cd src/segmap/segmappy/
$ source ~/segmappyenv/bin/activate
(segmappyenv)$ pip install .

Running segmapper Examples

Make sure to source the SegMap workspace before running the segmapper demonstrations:

$ source ~/segmap_ws/devel/setup.bash

To train new models see intructions here.

Download demonstration files

To download all necessary files, copy the content of the segmap_data into ~/.segmap/. If you installed the segmappy python package you can run the automated download script. Note: These models have been trained using Tensorflow 1.8 and are only guaranteed to work for that version.

Run online SLAM example

An online SLAM example can be run with

$ roslaunch segmapper kitti_loop_closure.launch

Run localization against known map example

A localization example can be run with

$ roslaunch segmapper kitti_localization.launch

Run online SLAM with CNN example

An online SLAM example with data-driven descriptor can be run with

$ roslaunch segmapper cnn_kitti_loop_closure.launch

You can now visualize the reconstructed target map in rviz by subscribing to /segmatch/target_reconstruction.

More details on the demonstrations can be found here.

License

SegMap is released under BSD 3-Clause License

Thank you for citing the related publication if you use SegMap in academic work:

@article{doi:10.1177/0278364919863090,
  title ={SegMap: Segment-based mapping and localization using data-driven descriptors},
  author = {Renaud Dubé and Andrei Cramariuc and Daniel Dugas and Hannes Sommer and Marcin Dymczyk and Juan Nieto and Roland Siegwart and Cesar Cadena},
  journal = {The International Journal of Robotics Research},
  volume = {39},
  number = {2-3},
  pages = {339-355},
  year = {2020},
  doi = {10.1177/0278364919863090}
}

@inproceedings{segmap2018,
  title={{SegMap}: 3D Segment Mapping using Data-Driven Descriptors},
  author={Dub{\'e}, Renaud and Cramariuc, Andrei and Dugas, Daniel and Nieto, Juan and Siegwart, Roland and Cadena, Cesar},
  booktitle={Robotics: Science and Systems (RSS)},
  year={2018}
}

@inproceedings{segmatch2017,
  title={SegMatch: Segment based place recognition in 3d point clouds},
  author={Dub{\'e}, Renaud and Dugas, Daniel and Stumm, Elena and Nieto, Juan and Siegwart, Roland and Cadena, Cesar},
  booktitle={IEEE International Conference on Robotics and Automation (ICRA)},
  pages={5266--5272},
  year={2017},
  organization={IEEE}
}

If you use the incremental version for the segmentation or geometric verification algorithms (used in the provided configuration files), please consider citing the describing paper:

@article{incremental2018,
  title={Incremental Segment-Based Localization in {3D} Point Clouds},
  author={Dub{\'e}, Renaud and Gollub, Mattia G and Sommer, Hannes and Gilitschenski, Igor and Siegwart, Roland and Cadena, Cesar and Nieto, Juan},
  journal={IEEE Robotics and Automation Letters},
  volume={3},
  number={3},
  pages={1832--1839},
  year={2018},
  publisher={IEEE}
}

Contributing to SegMap

We would be very grateful if you would contribute to the code base by reporting bugs, leaving comments and proposing new features through issues and pull requests. Please see the dedicated wiki page on this topic and feel free to get in touch at renaud.dube(at)sevensense(dot)ch, dugasd(at)ethz(dot)ch and crandrei(at)ethz(dot)ch. Thank you!
