FasterXML/jackson-dataformat-xml

Overview

This projects contains Jackson extension component for reading and writing XML encoded data.

Further, the goal is to emulate how JAXB data-binding works with "Code-first" approach (no support is added for "Schema-first" approach). Support for JAXB annotations is provided by JAXB annotation module; this module provides low-level abstractions (XmlParser, ToXmlGenerator, XmlFactory) as well as a small number of higher level overrides needed to make data-binding work.

It is worth noting, however, that the goal is NOT to be full JAXB clone; or to be a general purpose XML toolkit.

Specifically:

• While XML serialization should ideally be similar to JAXB output, deviations are not automatically considered flaws (there are reasons for some differences)
• What should be guaranteed is that any XML written using this module must be readable using module as well ("read what I wrote"): that is, we do aim for full round-trip support
• From above: there are XML constructs that this module will not be able to handle; including some cases JAXB (and other Java XML libraries) support
• This module also supports constructs and use cases JAXB does not handle: specifically, rich type and object id support of Jackson are supported.

Status

Type	Status
Build (CI)
Artifact
OSS Sponsorship
Javadocs
Code coverage (3.x)
OpenSSF Score
Fuzzing

Branches

3.x branch is for developing the next major Jackson version -- 3.2 -- but there are active maintenance branches for LTS releases:

• 3.1
• 2.21
• 2.18

Older branches are usually not changed but are available for historic reasons. All released versions have matching git tags (jackson-dataformat-xml-2.17.1).

License

All modules are licensed under Apache License 2.0.

Maven dependency

To use Jackson 3.x compatible version of this extension on Maven-based projects, use following dependency:

Maven:

<dependency>
  <groupId>tools.jackson.dataformat</groupId>
  <artifactId>jackson-dataformat-xml</artifactId>
  <version>3.1.1</version>
</dependency>

Gradle:

dependencies {
    implementation 'tools.jackson.dataformat:jackson-dataformat-xml:3.1.1'
}

To use Jackson 2.x compatible version of this extension on Maven-based projects, use following dependency:

Maven:

<dependency>
  <groupId>com.fasterxml.jackson.dataformat</groupId>
  <artifactId>jackson-dataformat-xml</artifactId>
  <version>2.21.2</version>
</dependency>

Gradle:

dependencies {
    implementation 'com.fasterxml.jackson.dataformat:jackson-dataformat-xml:2.21.2'
}

(or whatever version is most up-to-date at the moment)

Also: you usually also want to make sure the XML library in use is Woodstox since it is not only faster than Stax implementation JDK provides, but also works better and avoids some known issues like adding unnecessary namespace prefixes. You can do this by adding this in your pom.xml:

Maven:

<dependency>
  <groupId>com.fasterxml.woodstox</groupId>
  <artifactId>woodstox-core</artifactId>
  <version>6.5.0</version>
</dependency>

Gradle:

dependencies {
    implementation 'com.fasterxml.woodstox:woodstox-core:6.5.0'
}

Usage

Although this module implements low-level (JsonFactory / JsonParser / JsonGenerator) abstractions, most usage is through data-binding level. This is because a small number of work-arounds have been added at data-binding level, to work around XML peculiarities: that is, the stream of JsonTokens that the parser produces has idiosyncracies that need special handling.

Usually you either create XmlMapper simply by:

XmlMapper mapper = new XmlMapper();

but in case you need to configure settings, you will want to use the Builder (added in Jackson 2.10) style construction:

XmlMapper mapper = XmlMapper.builder()
   .defaultUseWrapper(false)
   // enable/disable Features, change AnnotationIntrospector
   .build();

Alternatively, sometimes you may want/need to configure low-level XML processing details controlled by underlying Stax library (Woodstox, Aalto or JDK-default Oracle implementation). If so, you will need to construct XmlMapper with properly configured underlying factories. This usually looks something like:

XMLInputFactory ifactory = new WstxInputFactory(); // Woodstox XMLInputFactory impl
ifactory.setProperty(WstxInputProperties.P_MAX_ATTRIBUTE_SIZE, 32000);
// configure
XMLOutputFactory ofactory = new WstxOutputFactory(); // Woodstox XMLOutputfactory impl
ofactory.setProperty(WstxOutputProperties.P_OUTPUT_CDATA_AS_TEXT, true);
XmlFactory xf = XmlFactory.builder()
    .xmlInputFactory(ifactory) // note: in 2.12 and before "inputFactory()"
    .xmlOutputFactory(ofactory) // note: in 2.12 and before "outputFactory()"
    .builder();
XmlMapper mapper = new XmlMapper(xf); // there are other overloads too

For configurable properties, you may want to check out Configuring Woodstox XML parser

As the well as the Woodstox properties specified above, you can also call WstxInputFactory#getConfig() and modify the ReaderConfig. One useful setting is the maxElementDepth.

Android quirks

Use of this library on Android is supported since version 2.15.0 (partly via fix of #533).

Earlier versions had problem due to Stax API being unavailable on the Android platform, and attempts to declare an explicit dependency on the Stax API library resulting in errors at build time (since the inclusion of the javax.* namespace in apps is restricted). For more on this old issue, see:

• https://stackoverflow.com/questions/31360025/using-jackson-dataformat-xml-on-android
• https://www.docx4java.org/blog/2012/05/jaxb-can-be-made-to-run-on-android/

Serializing POJOs as XML

Serialization is done very similar to JSON serialization: all that needs to change is ObjectMapper instance to use:

// Important: create XmlMapper; it will use proper factories, workarounds
ObjectMapper xmlMapper = new XmlMapper();
String xml = xmlMapper.writeValueAsString(new Simple());
// or
xmlMapper.writeValue(new File("/tmp/stuff.xml"), new Simple());

and with POJO like:

public class Simple {
    public int x = 1;
    public int y = 2;
}

you would get something like:

<Simple>
  <x>1</x>
  <y>2</y>
</Simple>

(except that by default output is not indented: you can enabled indentation using standard Jackson mechanisms)

Deserializing POJOs from XML

Similar to serialization, deserialization is not very different from JSON deserialization:

ObjectMapper xmlMapper = new XmlMapper();
Simple value = xmlMapper.readValue("<Simple><x>1</x><y>2</y></Simple>", Simple.class);

Incremental/partial reading/writing (2.4+)

It is also possible to do incremental writes. This is done by creating Stax XMLInputFactory separately (similar to how with JSON you would create JsonGenerator), and then:

// First create Stax components we need
XMLInputFactory xmlInputFactory = XMLInputFactory.newFactory();
XMLOutputFactory xmlOutputFactory = XMLOutputFactory.newFactory();
StringWriter out = new StringWriter();
XMLStreamWriter sw = xmlOutputFactory.createXMLStreamWriter(out);

// then Jackson components
XmlMapper mapper = new XmlMapper(xmlInputFactory);

sw.writeStartDocument();
sw.writeStartElement("root");

// Write whatever content POJOs...
SomePojo value1 = ...;
OtherPojo value2 = ...;
mapper.writeValue(sw, value1);
mapper.writeValue(sw, value2);
// and/or regular Stax output
sw.writeComment("Some insightful commentary here");
sw.writeEndElement();
sw.writeEndDocument();

Similarly it is possible to read content, sub-tree by sub-tree; assuming similar XML content we would use

XMLInputFactory f = XMLInputFactory.newFactory();
File inputFile = ...;
XMLStreamReader sr = f.createXMLStreamReader(new FileInputStream(inputFile));

XmlMapper mapper = new XmlMapper();
sr.next(); // to point to <root>
sr.next(); // to point to root-element under root
SomePojo value1 = mapper.readValue(sr, SomePojo.class);
// sr now points to matching END_ELEMENT, so move forward
sr.next(); // should verify it's either closing root or new start, left as exercise
OtherPojo value = mapper.readValue(sr, OtherPojo.class);
// and more, as needed, then
sr.close();

Additional annotations

In addition to standard Jackson annotations and optional JAXB (javax.xml.bind.annotation), this project also adds a couple of its own annotations for convenience, to support XML-specific details:

• @JacksonXmlElementWrapper allows specifying XML element to use for wrapping List and Map properties
• @JacksonXmlProperty allows specifying XML namespace and local name for a property; as well as whether property is to be written as an XML element or attribute.
• @JacksonXmlRootElement allows specifying XML element to use for wrapping the root element (default uses 'simple name' of the value class)
• @JacksonXmlText allows specifying that value of one property is to be serialized as "unwrapped" text, and not in an element.
• @JacksonXmlCData allows specifying that the value of a property is to be serialized within a CData tag.

for a longer description, check out XML module annotations.

Known Limitations

Currently, following limitations exist beyond general Jackson (JSON) limitations:

• Streaming model is only meant to be used through databinding: direct usage is possible but not supported
• Tree Model (JsonNode, ObjectMapper.readTree()) is based on JSON content model and it does not match exactly with XML infoset
  • Mixed content (both textual content and elements as children of an element) not supported: text, if any, will be lost
  • Prior to 2.12, handling of repeated XML elements was problematic (it could only retain the last element read), but #403 improves handling
• Root value should be a POJO (that is, a Java value expressed as a set of properties (key/value pairs)); and specifically following types can be serialized as properties but may not work as intended as root values
  • Primitive/Wrapper values (like java.lang.Integer)
  • Strings (and types that serialize as Strings such as Timestamps, Date/Time values)
  • Enums
  • Java arrays
  • java.util.Collection values (Lists, Sets)
  • Note: over time some level of support has been added, and Collections, for example, often work.
• Lists and arrays are "wrapped" by default, when using Jackson annotations, but unwrapped when using JAXB annotations (if supported, see below)
  • @JacksonXmlElementWrapper.useWrapping can be set to 'false' to disable wrapping
  • JacksonXmlModule.setDefaultUseWrapper() can be used to specify whether "wrapped" or "unwrapped" setting is the default
• Polymorphic Type Handling works, but only some inclusion mechanisms are supported (WRAPPER_ARRAY, for example is not supported due to problems with reference to mapping of XML, Arrays)
  • JAXB-style "compact" Type Id where property name is replaced with Type Id is not supported.
• Mixed Content (elements and text in same element) is not supported in databinding: child content must be either text OR element(s) (attributes are fine)
• While XML namespaces are recognized, and produced on serialization, namespace URIs are NOT verified when deserializing: only local names are matched
  • This also means that elements that only differ by namespace cannot be used.
• Root name wrapping support is incomplete (SerializationFeature.WRAP_ROOT_VALUE / DeserializationFeature.UNWRAP_ROOT_VALUE, so that:
  • Serialization DOES NOT add wrapping (at least up to and including 2.13)
  • Deserialization DOES unwrap root element (except for Jackson 2.12.x that temporarily removed support altogether -- fixed in 2.13.0)

Support

Community support

Jackson components are supported by the Jackson community through mailing lists, Gitter forum, Github issues. See Participation, Contributing for full details.

Enterprise support

Available as part of the Tidelift Subscription.

The maintainers of jackson-dataformat-xml and thousands of other packages are working with Tidelift to deliver commercial support and maintenance for the open source dependencies you use to build your applications. Save time, reduce risk, and improve code health, while paying the maintainers of the exact dependencies you use. Learn more.

See Also

• XML module wiki page for more information
• Using XML with DropWizard? Check out this extension!
