fatedier/fft

fft

fft is a distributed file transfer tool designed to accelerate the transfer of large files. It achieves this by utilizing multiple relay nodes in parallel, effectively overcoming the bandwidth limitations of a single server.

Purpose

Transferring large files reliably between two machines, especially when they are behind NATs or firewalls, often requires a relay server with high bandwidth. However, high-bandwidth servers can be expensive.

On the other hand, there are many low-bandwidth servers (e.g., 1MBps) that often sit idle, their resources underutilized.

The goal of fft is to leverage these underutilized low-bandwidth servers. By enabling senders and receivers to transfer files through multiple relay nodes simultaneously, fft aggregates the bandwidth of these nodes, allowing for faster transfer speeds than would be possible with a single relay. This approach avoids the bottleneck of a single server's bandwidth capacity.

fft focuses specifically on the task of file transfer, which typically involves a unidirectional flow of a large amount of data. Once this project matures, the plan is to integrate its capabilities into frp, a fast reverse proxy, to enhance its services by removing bandwidth limitations imposed by a single relay server.

Architecture

The fft system consists of three main components:

• ffts (Server Control Node): This is the central coordinator of the system.

  • It manages the registration of fftw worker nodes.
  • It facilitates the matching of sending and receiving fft clients.
  • When a sender initiates a file transfer, it contacts ffts.
  • When a receiver wants to download a file, it also contacts ffts using a transfer ID provided by the sender.
  • ffts then assigns available fftw worker nodes to the transfer, enabling the parallel data streams.
  • ffts does not handle any of_the actual file data_ itself; it only manages control signals and metadata.

• fftw (Worker Node): These nodes are responsible for relaying the actual file data.

  • Multiple fftw instances can be deployed on various servers.
  • Each fftw registers itself with the ffts server, making itself available for relaying transfers.
  • Upon instruction from ffts, an fftw node will accept data from a sending fft client and forward it to the receiving fft client.
  • The more fftw nodes available and assigned to a transfer, the higher the potential aggregate bandwidth and thus faster transfer speeds.

• fft (Client): This is the command-line tool used by end-users to send or receive files.

  • Sender: When sending a file, the fft client:
    1. Contacts the ffts server to announce a new transfer and receives a unique transfer ID.
    2. Communicates this transfer ID to the intended recipient (e.g., via email, messaging).
    3. Upon ffts matching it with a receiver and assigning fftw nodes, the client splits the file data and sends parts of it in parallel to the assigned fftw nodes.
  • Receiver: When receiving a file, the fft client:
    1. Contacts the ffts server using the transfer ID obtained from the sender.
    2. ffts matches the receiver with the sender and provides the list of fftw nodes involved in the transfer.
    3. The client then receives data in parallel from these fftw nodes and reassembles the original file.

The overall interaction is as follows:

1. fftw nodes start up and register with ffts.
2. An fft client (sender) initiates a transfer by contacting ffts. ffts provides a transfer ID.
3. The sender shares this transfer ID with another fft client (receiver).
4. The fft client (receiver) contacts ffts with the transfer ID.
5. ffts matches the sender and receiver and allocates a set of registered fftw nodes for the transfer. It informs both clients about these worker nodes.
6. The fft client (sender) then starts sending file data in parallel streams to the allocated fftw nodes.
7. The fftw nodes relay this data to the fft client (receiver).
8. The fft client (receiver) reassembles the data from the parallel streams to reconstruct the original file.

This architecture allows fft to achieve high-speed file transfers by distributing the load across multiple relay servers (fftws), orchestrated by the central ffts controller.

Development Status

fft is currently in the early stages of development. Features are still being added, and it is primarily intended for testing purposes.

The master branch is used for stable releases, while the dev branch is for ongoing development. You can try the latest release for testing.

The current communication protocol may change at any time and backward compatibility is not guaranteed. Please check the release notes when upgrading to a new version.

Usage Example

• ffts: The server control node. Deploy one instance of this.
• fftw: Worker nodes that relay traffic. Deploy multiple instances of these. More worker nodes can increase file transfer speed.
• fft: The client, used for sending and receiving files.

Each program's usage parameters can be viewed by running it with the -h flag.

ffts and fftw need to be deployed on machines with public IP addresses, and their respective ports must be open for fft clients to access.

By default, fftw and fft will attempt to connect to the ffts service at fft.gofrp.org:7777. If you wish to use your own ffts instance, you can specify its address using the -s {server-addr} option.

Sending a File

./fft -i 123 -l ./filename

• -i 123: Specifies the transfer request ID. This should be a unique custom value. The receiver will use this ID to accept the file.
• -l ./filename: Specifies the path to the local file to be transferred.

Receiving a File

./fft -i 123 -t ./

• -i 123: Specifies the ID of the transfer request to accept.
• -t ./: Specifies the local path to save the received file. If it's a directory, the sender's original filename will be used and the file saved in that directory. Otherwise, a new file will be created with the specified name.
