jeromeetienne/webaudiox

webaudiox.js is a bunch of helpers for WebAudio API. It isn't a library per se. You can use any of those helpers independantly. This makes it very light to include these in your own code. There is a webaudiox.js which bundle them though. This is provided for convenience. It is just the concatenation of all the helpers.

Usage

Here is a boilerplate, a good example to start with. It initializes the AudioContext, the lineOut and downloads a sound.

<script src='webaudiox.js'></script>
<script>
    // create WebAudio API context
    var context = new AudioContext()

    // Create lineOut
    var lineOut = new WebAudiox.LineOut(context)

    // load a sound and play it immediatly
    WebAudiox.loadBuffer(context, 'sound.wav', function(buffer){
        // init AudioBufferSourceNode
        var source  = context.createBufferSource();
        source.buffer   = buffer
        source.connect(lineOut.destination)

        // start the sound now
        source.start(0);
    });
</script>

Installation

Download the helpers with a usual <script>. the easiest is to get webaudiox.js in /build directory.

<script src='webaudiox.js'></script>

bower is supported if it fit your needs. just use bower install webaudiox

Requirements

No real requirements: there are no external dependancies. Well WebAudio API must be available obviously :) Currently Chrome, Firefox, iOS and Opera support it.

Contributings

Feel free to send pull requests. i love little helpers which are useful :)

ChangeLogs

• v1.0.1 bower support
• you can try with bower install webaudiox
• v1.0.0 initial release

Plugins

• webaudiox.ConvolverHelper is a plugin by @erichlof . It provides a simple mean to use convolvers, thus you can simulate being thru an old telephone, in a hall, or in a tunnel.

API for Each Helpers

Here is all the helpers provided and their respective API. the source contains a jsdoc which is authoritative.

webaudiox.analyser2canvas.js

This helper displays a visualisation of the played sound in real time. It uses the AnalyserNode from Web Audio API. The visualisation is composed of 3 parts: a FFT histogram, a waveform, and a volume. It is useful to debug or simply to display sounds on screen. It has been widely inspired by this post by the excelent @felixturner, be sure to check it out.

Show Don't Tell

• webaudiox.analyser2canvas.js the source itself.
• examples/analyser2canvas.html [view source] : It shows a basic usage of this helper

Usage

First you create the object

var analyser2canvas = new WebAudiox.Analyser2Canvas(analyser, canvas);

Then every time you want to draw on the canvas, just do

analyser2canvas.update()

webaudiox.analyser2volume.js

This helper makes an average on a ByteFrequencyData from an AnalyserNode. Clear ? I guess not. Ok ok audio vocabulary may appear criptic :) Let's rephrase in layman term. In brief, it makes an fft to extract the frequency of the sound, all that in real time. It is often used to detect pulse in some frequency range. like detecting pulse in the low frequencies can be a easy beat detector.

Show Don't Tell

• webaudiox.analyser2volume.js the source itself.
• examples/analyser2volume.html [view source] : It shows a basic usage of this helper

Usage

// create the object
var analyser2Volume = new WebAudiox.Analyser2Volume(analyser)
var rawVolume       = analyser2Volume.rawValue()
var smoothedVolume  = analyser2Volume.smoothedValue()

It is possible to directly compute the raw volume.

var rawVolume   = new WebAudiox.Analyser2Volume.compute(analyser, width, offset);
// rawVolume is a Number of the computed average

width is optional and default to analyser.frequencyBinCount. offset is optional and default to 0.

webaudiox.bytetonormalizedfloat32array.js

This helper converts a byteArray to a normalized Float32Array. The destination array is normalized because its values are garanted to be between 0 and 1. This function is designed to works even if the destination array length is different from the source array's length. This is mainly aimed at convering and normalizing input when you are playing with frequency spectrum or other aspects of AnalyserNode.

Show Don't Tell

• webaudiox.bytetonormalizedfloat32array.js the source itself.
• examples/analyser2canvas.html [view source] : It shows a usage of this helper thru webaudiox.analyser2canvas.js

Usage

Here is a basic usage. Note that dstArray must be reallocated.

WebAudiox.ByteToNormalizedFloat32Array(srcArray, dstArray);

Here is a usage where it is used to normalize an histogram, before displaying it for examples.

// bytesFreq is from a analyser.getByteFrequencyData(bytesFreq)
// histogram is destination array, e.g. new Float32Array(10)
WebAudiox.ByteToNormalizedFloat32Array(bytesFreq, histogram)

webaudiox.lineout.js

This helper provides a main line out with the good practices from "Developing Game Audio with the Web Audio API" on html5rocks. So it provides a clipping detection and a dynamic compressor to reduce clipping to improve sound quality.

Additionaly it provides some tools useful in real-life cases. Such as the ability for the user to mute the sound. Its is useful when the user is at the office or any place where it isn't polite to have a loud computer :) Another thing, there is a muteIfHidden feature. so if the browser tab is hidden, the sound is mute using PageVisibility API. and obviously ability to tune the volume globally for all sounds.

Show Don't Tell

• webaudiox.lineout.js the source itself.
• examples/lineout.html [view source] : It shows a basic usage of this helper. TODO: this link is broken

Now let's see it's API

create a lineOut

var lineOut = new WebAudiox.LineOut(context)

to set the volume/gain

lineOut.volume  = 0.8;

To connect a sound to your lineOut

use lineOut.destination as you would use context.destination.

source.connect(lineOut.destination)

test if currently muted by user

if( lineOut.isMuted === true ){
    console.log('sound has been muted by user')
}

toggle mute status

typically when the user click on the mute button, you want to toggle the mute status.

lineOut.toggeMute()

webaudiox.shim.js

This helper does a shim which handle the vendor prefix, so you don't have to. Typically it contains code like

window.AudioContext = window.AudioContext || window.webkitAudioContext;

Show Don't Tell

• webaudiox.shim.js the source itself.
• examples/jsfx.html [view source] : It shows a basic usage of this helper.

webaudiox.jsfx.js

jsfx.js is a library to generate procedural sound, very 8-bit kindof sound. See jsfx demo page for details on this fun library by @egonelbre. It is usefull because you can generate lots of different sound easily without downloading anything.

Show Don't Tell

• webaudiox.jsfx.js the source itself.
• examples/jsfx.html [view source] : It shows several sounds generated by this extension.
• examples/jsfx-basic.html [view source] : It shows a basic usage of this helper

Usage

Let's see how to use it. First you create a Audio Context like this.

var context = new AudioContext()

now you get the famous lib parameter from jsfx. You can generate some on its demo page. From lib, you will generate a Audio Buffer .

var lib     = ["square",0.0000,0.4000,0.0000,0.3200,0.0000,0.2780,20.0000,496.0000,2400.0000,0.4640,0.0000,0.0000,0.0100,0.0003,0.0000,0.0000,0.0000,0.0235,0.0000,0.0000,0.0000,0.0000,1.0000,0.0000,0.0000,0.0000,0.0000]
var buffer  = WebAudiox.getBufferFromJsfx(context, lib)

Now we are all ready to play a sound! So let's do that.

var source  = context.createBufferSource()
source.buffer   = buffer
source.connect(context.destination)
source.start(0)

webaudiox.loadbuffer.js

This helper loads sound. It is a function which load the sound from an url and decode it.

Show Don't Tell

• webaudiox.loadbuffer.js the source itself.
• examples/lineout.html [view source] : It shows a basic usage of this helper. TODO this link is broken

Usage

WebAudiox.loadBuffer(context, url, function(buffer){
    // notified when the url has been downloaded and the sound decoded.
}, function(){
    // notified if an error occurs
});

Scheduling Download

In real-life cases, like game, you want to be sure all your sounds are ready to play before the user start playing. So here is way to schedule your sound downloads simply. There is global onLoad callback WebAudiox.loadBuffer.onLoad This function is notified everytime .loadBuffer() load something. you can overload it to fit your need. here for an usage example.

// context is the webaudio API context
// url is where to download the sound
// buffer is the just loaded buffer
WebAudiox.loadBuffer.onLoad = function(context, url, buffer){
    // put your own stuff here
    // ...
}

Additionally there is WebAudiox.loadBuffer.inProgressCount. it is counter of all the .loadBuffer in progress. it useful to know is all your sounds as been loaded.

OfflineAudioContext for fast decoding

With the normal AudioContext decoding e.g. an mp3 file takes just as long as the mp3 file lasts. So if your mp3 file's duration is 1.5 minutes then your decompression (or analyzation, etc.) takes 1.5 minutes, which might be unbearable for your app. OfflineAudioContext allows faster than realtime decompression, for example:

var AudioContext = window.AudioContext || window.webkitAudioContext;
var OfflineAudioContext = window.OfflineAudioContext || window.webkitOfflineAudioContext;
this._context = new AudioContext();
this._loaderContext = new OfflineAudioContext(2, 1024, 44100); //22050 to 96000, CD = 44100

See the W3C docs for OfflineAudioContext

webaudiox.three.js

This is useful lf you have a three.js scene and would like to play spacial sound in it. When a sound is played in 3d space, there are 2 actors: the listener which hears the sound and the sound source which emits the sound. Each of them must be localised in 3d space.

In practice when you use it with three.js you need to constantly update the position of the listener and all the sound sources. First in your init, you instance the updater objects. Then at each iteration of your rendering loop, you update all the positions.

Show Don't Tell

• webaudiox.three.js the source itself.
• examples/threejs.html [view source] : It shows a basic usage of this helper.
• examples/threejs-panner.html [view source] : It shows a basic usage of this helper.

Usage

Here is the API details.

listener localisation

First let's localise the listener. most of the time it will be the the viewer camera. So you create a ListenerObject3DUpdater for that

// context is your WebAudio context
// object3d is the object which represent the listener
var listenerUpdater = new WebAudiox.ListenerObject3DUpdater(context, object3d)

then you call .update() everytime you update the position of your object3d listener.

// delta is the time between the last update in seconds
// now is the absolute time in seconds
listenerUpdater.update(delta, now)

sound source localisation

Now let's localise a sound source. A sound source is localised only if it has a panner node.

if you want a sound to follow a Object3D

So you create a PannerObject3DUpdater for that

// panner is the panner node from WebAudio API
// object3d is the object which represent the sound source in space
var pannerUpdater = new WebAudiox.PannerObject3DUpdater(panner, object3d)

then you call .update() everytime you update the position of your object3d listener

// delta is the time between the last update in seconds
// now is the absolute time in seconds
pannerUpdater.update(delta, now)

if you want a sound to be played at a given position

var panner  = context.createPanner()
var position    = new THREE.Vector3(1,0,0)
WebAudiox.PannerSetPosition(panner, position)

if you want a sound to be played from a THREE.Object3D

var panner  = context.createPanner()
var object3d    = new THREE.Object3D
WebAudiox.PannerSetObject3D(panner, object3d)

webaudiox.gamesounds.js

It aims at making Web Audio Api easy to use for gamedevs. It aims to provide easy-to-use API for the common cases seen by gamedevs. Yet, by exposing its internals, it conserves the flexibility to fit your own needs.

Show Don't Tell

• webaudiox.gamesounds.js the source itself.
• examples/gamesounds.html [view source] : It shows a simple usages of gamesounds

Basic Usage

First, we init gameSounds.

var sounds  = new WebAudiox.GameSounds()

Then we create a sound and load it from a url.

sounds.createClip().load('mysound.ogg', function(soundClip){
    // here the sound is loaded
})

We are all ready to play a sound. So let's do it.

soundClip.play();

This will create a source, i.e. an source of our soundclip, a playing version of our sound. Each source is independant. Thus you got the flexibility to change its parameters during the playing of it. e.g. change its location, its volume, whatever you want.

WebAudiox.GameSounds

First thing is to instanciate the object itself. It will keep the WebAudio API context.

var gameSounds  = new WebAudiox.GameSounds()

It has a line out to the speakers which implement the current best practice according to "Developing Game Audio with the Web Audio API" article on HTML5Rock. It will expose the following properties:

• .lineOut is a WebAudiox.LineOut. It has a master volume, a mute that you can toggle. It will automatically mute the sound if the page is not visible.
• .context is a AudioContext from Web Audio API.

gameSounds.update(delta)

It updates the gameSounds. delta is the number of seconds since the last update. It is needed to update gameSounds. It is used to update 3d listener. It is used to update all registered WebAudiox.GameSound too.

gameSounds.createClip(options)

This will create a sound. options is the default options for THREEx.GameSource. This is a simple alias for

function createClip(options){
        return new WebAudiox.GameSoundClip(this, options)
}

WebAudiox.GameSoundListener

It is used for sound localisation. It is setting the position of the listener. First you create the object like this

var soundListener   = new WebAudiox.GameSoundListener(gameSounds)

Then you periodically update it like that

soundListener.update(delta)

soundListener.at(position)

This is a sounds localisation function. It will place the audio listener at position. If it is a THREE.Vector3, it will directly use this position. If it is a THREE.Object3d, it will use the position of this object.

gameListener.startFollow(object3d)

This is a sounds localisation function. The listener will start follow this THREE.Object3D

gameListener.stopFollow()

the listener will stop following the object3d.

WebAudiox.GameSoundClip(gamesounds, options)

The arguments of the constructor are :

• gameSounds is a WebAudiox.GameSounds instance.
• options is the THREEx.GameSoundSource options. This is optional.

soundClip.load(url, onLoad, onError)

This load a sounds from an url. Once the sound is loaded, onLoad(gameSound) is notified. If an error occurs during the load, onLoad() is notified. It exposes gameSound.loaded Boolean. if it is true, the sound is loaded, false otherwise. It exposes gameSound.buffer. It is the loaded buffer once it is loaded, or null otherwise.

soundClip.update(delta)

It updates the sound. It is currently needed only if you use 3d localisation for this sounds. delta is the number of seconds since the last iteration of the rendering loop.

soundClip.register(label)

Register this sound into the bank of gameSounds with this label. Every label is unique into a gameSounds. soundClip.unregister() unregisters the sound from gameSounds bank. This will cause this sound to be automatically updated by gameSounds.

soundClip.createSource(options)

This will create a THREEx.GameSoundSource using this options

soundClip.play(options)

This will create a THREEx.GameSoundSource using this options and then call .play() on this soundSource

WebAudiox.GameSoundSource(soundClip, options)

It will one source for this soundclip. It will be played only once. Everytime you play a gamesound, it is handled by an independant source. This you can controls them independantly. e.g. You can have various volume how strong is an impact, You can play sound at various fixed locations, or following different 3d objects.

Here are all the options you can set

• options.volume controls the volume of this utterance. it will create a utterance.gainNode. If you wish, you can access .gainNode directly change the gain during the utterance.
• options.at: receives a three.js position. It may be THREE.Object3D or directly a THREE.Vector3. The utterance will be played at this position It will create a PannerNode if needed, and update it according to the 3d object position.
• options.follow: receives a THREE.Object3D as arguments. This 3d object will be followed by the utterance. It will create a PannerNode if needed, and update it according to the 3d object position. Additionnaly It exposes utterance.stopFollow() to stop following a 3d object.
• options.loop: set the .loop parameter in the SourceBuffer

soundSource.play(delay)

It will start play the sound in delay millisecond, default to 0-ms

soundSource.stop(delay)

It will stop playing the sound in delay millisecond, default to 0-ms.

Dependancies

webaudiox.gamesounds.js is included in webaudiox.js build. It you wish not to use this build. This file depends on webaudiox.lineout.js, webaudiox.loadbuffer.js and webaudiox.three.js if you want to use the sound localisation.

Other Examples

here are the various examples:

• a possible way to handle soundback: here
• how to load and play a sound only with the API: here
• how to use it with beatdetektor.js: here

TODO

• http://webaudiodemos.appspot.com/
• http://webaudioapi.com/
• port examples from webaudio.js
• QF-MichaelK: jetienne: http://www.youtube.com/watch?v=Nwuwg_tkHVA it's the rainbow one in the middle...
• QF-MichaelK: http://www.smartjava.org/content/exploring-html5-web-audio-visualizing-sound
• http://chromium.googlecode.com/svn/trunk/samples/audio/samples.html
• [2:14pm] QF-MichaelK: here's one I guess http://airtightinteractive.com/demos/js/reactive/
• done QF-MichaelK: this is neat too http://www.bram.us/2012/03/21/spectrogram-canvas-based-musical-spectrum-analysis/
