linkerd/linkerd-tcp

linkerd-tcp

A TCP load balancer for the linkerd service mesh.

Status: beta

Features

• Lightweight, native TCP and TLS load balancer built on tokio.
  • Weighted-least-loaded P2C load balancing.
  • Minimal resource utilization: typically <.5 cores with ~2MB RSS.
• Tightly integrated with the linkerd service mesh.
  • Supports endpoint weighting (i.e. for "red line" testing).
• Modern Transport Layer Security via rustls:
  • TLS1.2 and TLS1.3 (draft 18) only.
  • ECDSA or RSA server authentication by clients.
  • RSA server authentication by servers.
  • Forward secrecy using ECDHE; with curve25519, nistp256 or nistp384 curves.
  • AES128-GCM and AES256-GCM bulk encryption, with safe nonces.
  • Chacha20Poly1305 bulk encryption.
  • ALPN support.
  • SNI support.

Quickstart

1. Install Rust and Cargo.
2. Run namerd. ./namerd.sh fetches, configures, and runs namerd using a local-fs-backed discovery (in ./tmp.discovery).
3. From this repository, run: cargo run -- example.yml

We :heart: pull requests! See CONTRIBUTING.md for info on contributing changes.

Usage

linkerd-tcp 0.1.0
A native TCP proxy for the linkerd service mesh

USAGE:
    linkerd-tcp <PATH>

FLAGS:
    -h, --help       Prints help information
    -V, --version    Prints version information

ARGS:
    <PATH>    Config file path

Example configuration

# Administrative control endpoints are exposed on a dedicated HTTP server. Endpoints
# include:
# - /metrics -- produces a snapshot of metrics formatted for prometheus.
# - /shutdown -- POSTing to this endpoint initiates graceful shutdown.
# - /abort -- POSTing to this terminates the process immediately.
admin:
  port: 9989

  # By default, the admin server listens only on localhost. We can force it to bind
  # on all interfaces by overriding the IP.
  ip: 0.0.0.0

  # Metrics are snapshot at a fixed interval of 10s.
  metricsIntervalSecs: 10

# A process exposes one or more 'routers'. Routers connect server traffic to
# load balancers.
routers:

  # Each router has a 'label' for reporting purposes.
  - label: default

    # Each router is configured to resolve names.
    # Currently, only namerd's HTTP interface is supported:
    interpreter:
      kind: io.l5d.namerd.http
      baseUrl: http://localhost:4180
      namespace: default
      periodSecs: 20

    servers:

      # Each router has one or more 'servers' listening for incoming connections.
      # By default, routers listen on localhost. You need to specify a port.
      - port: 7474
        dstName: /svc/default
        # You can limit the amount of time that a server will wait to obtain a
        # connection from the router.
        connectTimeoutMs: 500

      # By default each server listens on 'localhost' to avoid exposing an open
      # relay by default. Servers may be configured to listen on a specific local
      # address or all local addresses (0.0.0.0).
      - port: 7575
        ip: 0.0.0.0
        # Note that each server may route to a different destination through a
        # single router:
        dstName: /svc/google
        # Servers may be configured to perform a TLS handshake.
        tls:
          defaultIdentity:
            privateKey: private.pem
            certs:
              - cert.pem
              - ../eg-ca/ca/intermediate/certs/ca-chain.cert.pem

    # Clients may also be configured to perform a TLS handshake.
    client:
      kind: io.l5d.static
      # We can also apply linkerd-style per-client configuration:
      configs:
        - prefix: /svc/google
          connectTimeoutMs: 400
          # Require that the downstream connection be TLS'd, with a
          # `subjectAltName` including the DNS name _www.google.com_
          # using either our local CA or the host's default openssl
          # certificate.
          tls:
            dnsName: "www.google.com"
            trustCerts:
              - ../eg-ca/ca/intermediate/certs/ca-chain.cert.pem
              - /usr/local/etc/openssl/cert.pem

Logging

Logging may be enabled by setting RUST_LOG=linkerd_tcp=info on the environment. When debugging, set RUST_LOG=trace.

Docker

To build the linkerd/linkerd-tcp docker image, run:

./dockerize latest

Replace latest with the version that you want to build.

Try running the image with:

docker run -v `pwd`/example.yml:/example.yml linkerd/linkerd-tcp:latest /example.yml
