microsoft/data-formulator

  Data Formulator: AI-powered Data Visualization

🪄 Explore data with visualizations, powered by AI agents.



       

Why Data Formulator?

Your data lives everywhere — databases, warehouses, BI tools, files. Coding agents can help, but only after someone wires them up, and answers come back as walls of code or text that are hard to follow, refine, or share.

Data Formulator makes it simple: connect any data, ask anything, get charts you can edit, branch, and share — all on one interactive, visual canvas.

• Data & platform teams: wire up your databases, warehouses, and BI sources once, and give the whole org an AI-powered data exploration layer.
• Analysts & users: ask, edit, branch, share. It's so easy to get insights from good-looking charts.

https://github.com/user-attachments/assets/8e4f8a08-6423-4227-a1f7-559e0126ce31

[!TIP] Love the charts? They're built on Flint — our open-source visualization language that compiles compact, semantic chart specs into polished Vega-Lite, ECharts, and Chart.js. Explore the project site or drop it into your own app.

News 🔥🔥🔥

[07-23-2026] Data Formulator 0.8 alpha (a1–a4, latest: 0.8.0a4) includes:

• Conversational database loading. Agents can discover relevant tables, propose filters, preview results, and revise a loading plan through conversation before importing data.
• Unified Data Thread. Questions, clarifications, explanations, tables, and charts share one conversation history, with branching from earlier steps into new questions, calculated columns, or visualizations.
• Expanded chart gallery, powered by Flint. New bullet, connected scatter, ECDF, Gantt, range area, slope, sparkline, and violin charts, along with improved chart recommendations. Try the open-source Flint chart language in your own applications.
• Persistent analyst attachments. CSV, JSON, Excel, and other attached files remain available to the analyst throughout an exploration instead of being embedded once in a prompt.
• Databricks connector. Browse Unity Catalog catalogs, schemas, and tables, then load Databricks data into the exploration workflow.
• Microsoft authentication for enterprise connectors. SQL Server supports passwordless Microsoft Entra ID authentication through az login, including an in-app flow for local deployments. Kusto supports delegated Microsoft sign-in alongside Azure default identity and service principal authentication.
• Connector setup and diagnostics. Connection forms separate connection, scope, and source-specific authentication options. Persistent server logs and an in-app log viewer help diagnose failures.

Preview with pip install --pre data_formulator==0.8.0a4 or uvx [email protected].

Install the latest stable release (0.7) with pip install data_formulator or run instantly with uvx data_formulator.

Previous Updates

Here are milestones that lead to the current design:

• v0.7 (05-28-2026): Turn ANY data into insights in five steps — connect governed data sources, load via agents, explore with the unified DataAgent + Data Thread, refine 30+ chart types (semantic chart engine powered by Flint) with a style-refinement agent, and share as reports. Plus persistent sessions & workspaces and a multilingual (English/Chinese) UI.
• v0.7 alpha 2 (05-11-2026): Early preview of data connectors, the unified DataAgent with thread memory, persistent workspaces, the semantic chart engine, and experimental knowledge distillation.
• v0.6 (Demo): Real-time insights from live data — connect to URLs and databases with automatic refresh
• uv support: Faster installation with uv — uvx data_formulator or uv pip install data_formulator
• v0.5.1 (Demo): Community data loaders, US Map & Pie Chart, editable reports, snappier UI
• v0.5: Vibe with your data, in control — agent mode, data extraction, reports
• v0.2.2 (Demo): Goal-driven exploration with agent recommendations and performance improvements
• v0.2.1.3/4 (Readme | Demo): External data loaders (MySQL, PostgreSQL, MSSQL, Azure Data Explorer, S3, Azure Blob)
• v0.2 (Demos): Large data support with DuckDB integration
• v0.1.7 (Demos): Dataset anchoring for cleaner workflows
• v0.1.6 (Demo): Multi-table support with automatic joins
• Model Support: OpenAI, Azure, Ollama, Anthropic via LiteLLM (feedback)
• Python Package: Easy local installation (try it)
• Visualization Challenges: Test your skills (challenges)
• Data Extraction: Parse data from images and text (demo)
• Initial Release: Blog | Video

Overview

Data Formulator is a Microsoft Research project for data exploration with visualizations powered by AI agents. It combines UI interactions with natural language so analysts can communicate intent, branch into alternative analyses, and share results — starting from any data format (screenshot, text, CSV, or database).

Get Started

Play with Data Formulator with one of the following options.

• Option 1: Install via uv (recommended)

  uv is an extremely fast Python package manager. If you have uv installed, you can run Data Formulator directly without any setup:

  uvx data_formulator


  Run uvx data_formulator --help to see all available options, such as custom port, sandboxing mode, and data storage location.

• Option 2: Install via pip

  Use pip for installation (recommend: install it in a virtual environment).

  pip install data_formulator # install
  python -m data_formulator # run


  Data Formulator will be automatically opened in the browser at http://localhost:5567.

• Option 3: Run with Docker

  docker compose up --build


  Open http://localhost:5567 in your browser. To stop, press Ctrl+C or run docker compose down.

• Option 4: Codespaces

  You can run Data Formulator in Codespaces; we have everything pre-configured. For more details, see CODESPACES.md.



• Option 5: Working as developer

  You can build Data Formulator locally and develop your own version. Check out details in DEVELOPMENT.md.

Using Data Formulator

Besides uploading csv, tsv or xlsx files that contain structured data, you can ask Data Formulator to extract data from screenshots, text blocks or websites, or load data from databases use connectors. Then you are ready to explore. Ask visualizaiton questions, edit charts, or delegate some exploration tasks to agents. Then, create reports to share your insights.

https://github.com/user-attachments/assets/164aff58-9f93-4792-b8ed-9944578fbb72
