QUEEN - Chess Utilities For Common Lisp

What's in it:

• board representation (0x88 method)
• move generation (passes perft tests)
• FEN/SAN/PGN parser and generator
• basic (weak) evaluation engine (still, it kinda beats me at depth=5)

This is only tested on SBCL, but there is no SBCL-specific code, so it should work on other implementations. I'd love to hear about it.

Synopsis

;; create game
(setf g (make-game))
(reset-game g)

;; print the board with RNBQKP notation
(print-board (game-board g))

;; print board with Unicode chars for pieces
(let ((*unicode* t)) (print-board (game-board g)))

;; generate available moves
(setf moves (game-compute-moves g))

;; print moves
(loop for m in moves
      do (format t "~A~%" (game-san g m)))

;; perft test to depth 6 (~36 sec. on my laptop from start position)
(time (perft g 6))

;; try a move
(with-move (g (car (game-parse-san g "Nf3")))
  (print-board (game-board g)))        ; prints board after Nf3
(print-board (game-board g))           ; back to previous position

;; execute a move
(game-move g (car (game-parse-san g "d4")))
(print-board (game-board g))

;; is the current side in check?
(attacked? g)

;; find best line to depth 5 (default: +MAX-DEPTH+)
(setf line (game-search g 5))
(cond
  ((and (null line) (attacked? g))
   (format t "Checkmate~%"))
  ((null line)
   (format t "Draw~%"))
  (t
   (format t "~A~%" (dump-line g line))))

;; initialize from FEN
(reset-from-fen g "r4rk1/1pp1qppp/p1np1n2/2b1p1B1/2B1P1b1/P1NP1N2/1PP1QPPP/R4RK1 w - - 0 10")
(time (perft g 5))
;; -->
;; Depth: 5, Count: 164075551, Captures: 19528068, Enpa: 122, Checks: 2998608, Promo: 0, Castle: 0
;; Evaluation took:
;;  54.679 seconds of real time

;; find mate in 3
QUEEN> (reset-from-fen g "r4r2/1pNP4/pPk2N1Q/2BR1n2/1P6/8/2p2K1p/8 w - - 0 1")

QUEEN> (let ((*unicode* t)) (print-board (game-board g)))
8 │ ♜ □ □ □ □ ♜ □ □
7 │ □ ♟ ♘ ♙ □ □ □ □
6 │ ♟ ♙ ♚ □ □ ♘ □ ♕
5 │ □ □ ♗ ♖ □ ♞ □ □
4 │ □ ♙ □ □ □ □ □ □
3 │ □ □ □ □ □ □ □ □
2 │ □ □ ♟ □ □ ♔ □ ♟
1 │ □ □ □ □ □ □ □ □
  └─────────────────
    a b c d e f g h

QUEEN> (let ((*unicode* t)) (dump-line g (game-search g 5)))
"1. ♔e1 h1=♛+ 2. ♕xh1 c1=♛+ 3. ♖d1#"

;; test the move generator using perftsuite.epd
(run-perft-tests 5)         ; takes 2 minutes for depth 5

;; play a game against the engine
(play &key fen depth)       ; default depth=5 and start position
;;
;; enter: valid move in SAN notation, or:
;;
;;        go -- force computer to move
;;        exit -- stop game
;;        restart -- restart game to given fen
;;        reset -- start new game
;;        undo -- undo last move
;;        pgn -- show all moves played so far in PGN
;;        fen -- show current position as FEN

Data structures and types

Note: this section documents internals, which might change.

• piece -- an (unsigned-byte 8). We use six bits for the piece and one for the side, as follows:

  ┌─┬─┬─┬─┬─┬─┬─┬─┐ │7│6│5│4│3│2│1│0│ └─┴┬┴┬┴┬┴┬┴┬┴┬┴┬┘ │ │ │ │ │ │ └────── Queen │ │ │ │ │ └──────── Rook │ │ │ │ └────────── Knight │ │ │ └──────────── Bishop │ │ └────────────── Pawn │ └──────────────── King └────────────────── White

  A piece cannot be both a queen and a rook, of course — so we could have used fewer bits — but it's sometimes useful to test whether a piece is either a queen or a rook; by allocating one bit for each piece type, we can do that by AND-ing with 3 (Queen + Rook).

  The idea with the seemingly arbitrary ordering was to be able to represent pieces that we can promote to in 4 bits (Q, R, N, B), and pieces that can be captured in 5 (Q, R, N, B, P) — so the king is last.

• board -- a simple-array of 120 piece elements (of which only 64 are used). A zero element means the field is empty.

• board-index -- an integer between 0 and 119 (index in the board array). An integer value is a valid index if by AND-ing it with 0x88 we get zero (i.e. on other values we never store pieces, even if they still fall between 0 and 119).

• move -- an (unsigned-byte 30):

  3 3 2 2 2 2 2 2 2 2 2 2 1 1 1 1 1 1 1 1 1 1 0 0 0 0 0 0 0 0 0 0 1 0 9 8 7 6 5 4 3 2 1 0 9 8 7 6 5 4 3 2 1 0 9 8 7 6 5 4 3 2 1 0 ╭─┬─┬─┬─┬─┬─┬─┬─┬─┬─┬─┬─┬─┬─┬─┬─┬─┬─┬─┬─┬─┬─┬─┬─┬─┬─┬─┬─┬─┬─┬─┬─╮ │ │ │x│x│x│x│x│=│=│=│=│p│p│p│p│p│p│p│R│R│R│+│C│C│C│R│R│R│E│C│C│C│ ╰─┴─┴┬┴─┴─┴─┴┬┴┬┴─┴─┴┬┴┬┴─┴─┴─┴─┴─┴┬┴┬┴─┴┬┴┬┴┬┴─┴┬┴┬┴─┴┬┴┬┴┬┴─┴┬╯ ╰───┬───╯ ╰──┬──╯ ╰─────┬─────╯ ╰─┬─╯ │ ╰─┬─╯ ╰─┬─╯ │ ╰─┬─╯ │ │ │ │ │ │ ╰───┼───┴────╴ FROM │ │ │ │ │ │ ╰────────╴ ENPA │ │ │ ╰───┼───┴──────────────────╴ TO │ │ │ ╰──────────────────────╴ CHECK │ │ ╰────────────────────────────────────╴ PIECE │ ╰───────────────────────────────────────────────╴ PROMOTION ╰────────────────────────────────────────────────────────╴ CAPTURE

  R : row, 3 bits (integer 0 7) C : col, 3 bits (integer 0 7) p : piece moved, 7 bits (including side: bit 20 is 1 for white moves) = : piece promoted to, 4 bits (same side as p) x : captured piece, 5 bits (opposite side from p) E : 1 if en-passant move, 0 otherwise

  • : 1 if checking move, 0 otherwise

  Moves are created with the game-compute-moves function. While you can create an (unsigned-byte 32) manually, or maybe via the make-move function, there is no guarantee that that move is valid in the context of an existing game.

• game -- a structure containing a board and other features that determine the current situation of a game: the side to move, the en-passant target field, the castling conditions, and the number of full-moves / half-moves. Currently a game struct does not maintain a list of moves played so far (this might change).

Game functions

• (make-game) -- instantiate a game struct

• (game-board game) -- the board array

• (game-state game) -- the castling state

• (game-side game) -- the current side to play (+WHITE+ or +BLACK+)

• (game-enpa game) -- the index of the en-passant target field (or NIL)

• (game-fullmove game) -- the current move number

• (game-halfmove game) -- the "halfmove" number (number of moves since the last pawn or capturing move)

• (reset-from-fen game fen) -- reset a game from a FEN string or input stream

• (reset-game game) -- reset a game to starting position

• (game-fen game) -- return the current game position as a FEN string

• (game-move game move &optional quick) -- execute the given move. When quick is true, skip updating the fullmove/halfmove counts.

• (with-move (game move &optional quick) &body body) -- macro; execute the move and perform body, then take back the move.

• (king-index game &optional side) -- return the board-index of the king for the given side (default to current side to play).

• (attacked? game &optional side index) -- return T if the given index/side is under attack. Default arguments are the current side to play, and the king index.

• (game-compute-moves game) -- return the list of legal moves for the current side to play.

• (game-parse-san game san &optional moves) -- parse a move in SAN notation. If moves is not passed, it defaults to (game-compute-moves game). This function returns a list of move elements; if SAN is valid, this list should contain exactly one move, but when it's not valid or ambiguous it might have zero or more elements. SAN should be a string or an input stream.

• (game-san game move &optional moves) -- return a move in SAN notation. moves defaults to (game-compute-moves game).

• (draw-by-material? game) -- return T if the current position is a draw because of insufficient material.

• (perft game depth &optional count-mates) -- return PERFT results for the current game, to the given depth. Pass true for count-mates if you'd like to count checkmates as well (slightly increases the run time).

• (divide game depth) -- used for debugging; see [1] for more information about PERFT and DIVIDE.

PGN parser

(parse-pgn data) -- where data is a string or an input stream. Returns a plist like this:

(:headers HEADERS
 :moves MOVES
 :game GAME)

HEADERS is an alist associating header name (as string) with the value (also a string).

MOVES is a list of moves/comments/result found in the PGN data, in the order they are encountered. It has this form:

((:move . NUMBER) ... (:comment . "text") ... (:result . "1-0"))

The moves are in numerical representation described above.

GAME is a game instance in the final position.

Example:

QUEEN> (parse-pgn "[White \"Foo\"]
[Black \"Bar\"]

1.d4 d5 2.c4 {Queen's gambit} dxc4 {accepted}")

==>

(:HEADERS (("White" . "Foo")
           ("Black" . "Bar"))
 :MOVES ((:MOVE . 329419)
         (:MOVE . 67827)
         (:MOVE . 329354)
         (:COMMENT . "Queen's gambit")
         (:MOVE . 134284963)
         (:COMMENT . "accepted"))
 :GAME #S(GAME
          :BOARD #(...)
          :STATE 15
          :SIDE 64
          :ENPA NIL
          :FULLMOVE 3
          :HALFMOVE 0))

Piece functions

A piece is an 8 bit unsigned integer (only 7 bits are used).

• constants: +PAWN+, +KNIGHT+, +BISHOP+, +ROOK+, +QUEEN+, +KING+ +WPAWN+, +WKNIGHT+, +WBISHOP+, +WROOK+, +WQUEEN+, +WKING+ +WHITE+, +BLACK+

• (is-pawn? p), (is-knight? p), (is-bishop? p), (is-rook? p), (is-queen? p), (is-king? p) -- predicates that receive one argument (unsigned-byte 8) and return T if it's the respective piece.

• (is-white? p), (is-black? p) -- receive an (unsigned-byte 8) and return T if it's the respective color.

• (piece-side p) -- return the side of the piece (+WHITE+ or +BLACK+)

• (same-side? p1 p2) -- return T if the pieces are same color

• (piece-char p) -- return the piece as a character in standard chess notation, e.g.:

  R, N, B, Q, K, P for white pieces r, n, b, q, k, p for black pieces

  When unicode is T, use Unicode chess chars instead.

• (char-piece p) -- the inverse of piece-char

Board functions

A board is stored in a simple array of 120 piece-s.

• (board-index row col) -- return the index of the field with the given coords

• (field-index field) -- return the index of the named field.

  QUEEN> (field-index "d2")
  19
  QUEEN> (board-index 1 3)
  19
  QUEEN> $d2   ;; when using queen::syntax named readtable
  19


• (index-row index), (index-col index) -- return the coords (0..7)

• (index-field index) -- return the field name, e.g. "d2"

• (index-valid? index) -- return T if the index is valid, that is, it's an integer between 0 and 119 and it has the fourth and eighth bit clear. More exactly, a valid index looks like this:

  ┌─┬─┬─┬─┬─┬─┬─┬─┐ │0│R│R│R│0│C│C│C│ └─┴─┴─┴─┴─┴─┴─┴─┘

  Bits 0, 1, 2 are for the column, and 4, 5, 6 for the row.

• (board-get board index) -- return the piece at the given index (zero when the field is empty)

• (board-set board index piece) -- set the piece at the given index

• (board-get-rc board row col) -- return the piece at the given coords

• (board-set-rc board row col piece) -- set the piece at the given coords

• (board-foreach board fn) -- calls the given function for every piece of the board (skips empty fields). The function is called with four arguments: piece, row, col and index.

• (print-board board :key (output t)) -- print the board to the given stream (by default it goes to standard output).

Move functions

You should not need to create move-s manually; obtain a list of moves via game-compute-moves. You can use the following accessors on a move (which is just a 32 bit unsigned integer):

• (move-from move), (move-to move) -- return as board-index the move from/to fields

• (move-piece move) -- returns the moved piece

• (move-white? move), (move-black? move) -- return T if the moved piece is of the respective color

• (move-side move) -- return the move side (+WHITE+ or +BLACK+)

• (move-capture? move) -- return T if it's a capturing move

• (move-captured-piece move) -- returns the captured piece, or NIL if it's a non-capturing move

• (move-promote? move) -- return T if it's a promoting move

• (move-promoted-piece move) -- return the promoted piece, or NIL if it's not the case

• (move-check? move) -- return T if it's a checking move

• (move-enpa? move) -- return T if it's an en-passant move

• (move-captured-index move) -- return the index of the captured piece if it's a capturing move, NIL otherwise. This can be different from (move-to move) in the case of en-passant moves.

• (move-oo? move) -- return T if it's a king-side castling move

• (move-ooo? move) -- return T if it's a queen-side castling move

• (move-castle? move) -- return T if it's a castling move

Evaluation

I wrote this just for fun, and it's outside the scope of this library. I don't reasonably expect to produce a strong chess engine, compared to what's available these days, but if nothing else, this helped me learn a lot about optimizing Common Lisp code. Before working on evaluation, (perft 6) ran in 12 minutes. After optimization it's down to under 40 seconds [*]. Luckily, this didn't require large refactoring of the code -- just inline trivial functions, add type declarations, (declare (optimize speed)) to certain key functions, and listen to advice from SBCL (which is impressively smart).

[*] For comparison, Crafty runs perft 6 in 4 seconds on my machine. Now Crafty is a venerable, strong chess engine, written in hand-optimized C and using bitboards for move generation (the fastest known method; I couldn't wrap my brains around it). I'd say 10x slower is Okay.

  I'm interested in the performance of other array-based move generators
  (i.e. not bitboards), if you know any please tell me.

Main entry point:

(game-search game &optional (depth +MAX-DEPTH+))

It returns two values:

• a list of moves -- the "best line" that the algorithm could see. Executed in sequence, these moves lead to the position that produces the best static evaluation score (see below) for the side to play, at the given depth (default: 5).

• the score for the final position.

What's implemented:

• NegaScout search algorithm (see [2]). It's not exactly "principal variation search" yet, because we don't keep a history of researched positions and their score (which means our evaluation is prone to repetitions)

  (pvs game depth α β pline)

  It returns a score for the current position, and the best variant in pline (pass a (cons nil nil) and get the list of moves in the car).

• Quiescence search -- when NegaScout reaches depth zero, we try all capturing moves

  (quies game α β moves pline)

  This is called by pvs when it reaches depth=0.

The static evaluation function is based on [3]. It's symmetrical, in that it cares for pieces of both sides — for example (static-value game) for the start position returns zero. A score bigger than zero means that the current side to play looks better than the opponent.

The value is calculated by adding up the score for all our pieces, and subtracting the score for all opponent pieces. A piece has a material value (the +MATx+ constants) and a certain score depending on where it's located on the board (see scores in eval.lisp).

                               * * *

[1] https://chessprogramming.wikispaces.com/Perft [2] https://en.wikipedia.org/wiki/Principal_variation_search [3] https://chessprogramming.wikispaces.com/Simplified+evaluation+function

                               * * *

(c) Mihai Bazon 2016 License: MIT
