mob-sakai/UnmaskForUGUI

Unmask For UGUI

Reverse mask for uGUI element in Unity.

<< Description | WebGL Demo | Installation | Usage | Contributing >>

Description

Unmask provides the following features:

1. Reverse mask
2. Ray through the unmasked rectangle
3. Following another object
4. Support nesting

Component	Features	Screenshot
Unmask	Reverse masking for parent Mask component. Fit Target / Fit On Late Update: Fit graphic's transform to target transform on LateUpdate. Only For Children: Unmask affects only for children. Show Unmask Graphic: Show the graphic that is associated with the unmask render area.
UnmaskRaycastFilter	The ray Passes through the unmasked rectangle. You can click on the unmasked button on the back side.

Demo

WebGL Demo

Installation

Requirement

Using OpenUPM

This package is available on OpenUPM.
You can install it via openupm-cli.

openupm add com.coffee.unmask

Using Git

Find the manifest.json file in the Packages folder of your project and edit it to look like this:

{
  "dependencies": {
    "com.coffee.unmask": "https://github.com/mob-sakai/UnmaskForUGUI.git",
    ...
  },
}

To update the package, change suffix #{version} to the target version.

• e.g. "com.coffee.unmask": "https://github.com/mob-sakai/UnmaskForUGUI.git#2.0.0",

Or, use UpmGitExtension to install and update the package.

For Unity 2018.2 or earlier

1. Download a source code zip file from Releases page
2. Extract it
3. Import it into the following directory in your Unity project
   • Packages (It works as an embedded package. For Unity 2018.1 or later)
   • Assets (Legacy way. For Unity 2017.1 or later)

How to play demo

• For Unity 2019.1 or later
  • Open Package Manager window and select UI Unmask package in package list and click Demo > Import in project button
• For Unity 2018.4 or earlier
  • Click Assets/Samples/UI Unmask/Import Demo from menu

The assets will be imported into Assets/Samples/UI Unmask/{version}/Demo.
Open UIUnmask_Demo scene and play it.

Usage

Create Object From Menu (GameObject > UI > Unmask > ***)

Menu	Screenshot
Tutorial Button
Iris Shot

Example of using

Case	Description	Screenshot
Unmasked text	Black screen is cut out with unmasked text.
Hole	Black screen is cut out with unmasked Image.
Tutorial button	In tutorial, only specific button can be pressed.
Iris in/out	Transition effect with iris in/out.

Contributing

Issues

Issues are very valuable to this project.

• Ideas are a valuable source of contributions others can make
• Problems show where this project is lacking
• With a question you show where contributors can improve the user experience

Pull Requests

Pull requests are, a great way to get your ideas into this repository.
See CONTRIBUTING.md and develop branch..

Support

This is an open source project that I am developing in my spare time.
If you like it, please support me.
With your support, I can spend more time on development. :)

License

• MIT
• © UTJ/UCL

Author

mob-sakai
