Nagi-ovo/mjlab-homierl

mjlab-homierl

Screencast from 2026-03-25 19-53-04.webm

mjlab-homierl is an external mjlab task package reproducing the lower-body locomotion RL portion of HOMIE: Humanoid Loco-Manipulation with Isomorphic Exoskeleton Cockpit on Unitree G1 (the robot used by the original OpenHomie release) and Unitree H1. It follows the standard anymal_c_velocity style layout: the repository only contains custom tasks, assets, and the HIM-PPO training stack, while the core simulator/runtime comes from upstream mjlab.

Reward terms, weights, command sampling (1/3 squat, 1/2 walk, 1/6 stand every 4 s), the upper-body disturbance curriculum, and the HIM-PPO hyperparameters follow the OpenHomie reference implementation (HomieRL/legged_gym). Intentional deviations from OpenHomie are:

• Contact-based termination is replaced by contact penalties plus a torso-contact termination (G1), matching MuJoCo Warp's contact model.
• Domain randomization uses mjlab-native dr.* events (PD gains, link mass, payload, CoM offset, encoder bias, foot friction). OpenHomie's per-step torque injection has no mjlab equivalent and is approximated by PD-gain randomization and encoder bias.
• Per-joint action scales are derived from actuator effort/stiffness (0.25 * effort / stiffness), the mjlab convention, instead of a uniform 0.25.
• The HIM estimator's next-step critic observation at termination steps is the post-reset observation (mjlab computes observations after resets).

Which task/checkpoint is the HOMIE reproduction?

• Task: Mjlab-Homie-Unitree-G1 (deployment-grade PD gains, sim2real path). Mjlab-Homie-Unitree-G1-native is the frozen strict-parity preset — the diff between the two configs is the complete, auditable ledger of our deliberate deviations.
• Pretrained checkpoints: Hugging Face — Nagi-ovo/HOMIERL-loco.
• Height convention: our height command is pelvis-to-sole (standing 0.78 m, range 0.28–0.78). OpenHomie's numbers are pelvis-to-ankle (standing 0.74, range 0.24–0.74). Same physical pose and identical 0.50 m travel — subtract ~0.04 m when comparing to OpenHomie figures.
• Deployment-oriented research forks (e.g. commanded torso pitch) are developed on separate branches and intentionally kept off main so this branch stays a faithful reproduction.

Structure

src/mjlab_homierl/
  __init__.py              # entry-point task registration
  homie_env_cfg.py         # base HOMIE task config (OpenHomie rewards/commands)
  env_cfgs.py              # G1 / H1 / H1-with-hands configs
  rl_cfg.py                # HIM-PPO runner config
  mdp/                     # HOMIE commands, rewards, observations, actions
  rl/                      # HIM-PPO algorithm, runner, ONNX export
  robots/
    unitree_h1/            # H1 XML + constants (G1 comes from mjlab's asset zoo)
    robotiq_2f85/          # gripper XML assets

Install

Clone the repository first:

git clone https://github.com/Nagi-ovo/mjlab-homierl.git
cd mjlab-homierl

For GPU training and playback:

uv sync --extra cu128

For CPU-only setups:

uv sync --extra cpu

For local docs builds:

uv sync --extra docs

This package depends on upstream mjlab>=1.5.0,<1.6.0 and registers tasks through the mjlab.tasks entry-point group.

Registered Tasks

• Mjlab-Homie-Unitree-G1 — trains with deployment-grade PD gains (the table HomieDeploy's real-robot low-level controller runs; see robots/unitree_g1_deploy.py) and the deployed pipeline's uniform 0.25 action scale. Use this for sim2real. The effective per-joint stiffness/damping is embedded in the exported ONNX metadata, so deployment code can read the gains from the policy file. Waist defaults to locked: waist_roll/pitch are PD-held at the default pose and excluded from the upper-body disturbance, matching OpenHomie's 27-dof G1 (its URDF welds those two joints) and real-robot deployment, which software-holds them.

All G1 variants below share the base task's observation/action interface, so checkpoints load interchangeably across them (and into the base task):

• Mjlab-Homie-Unitree-G1-free_waist — all three waist joints join the random upper-body disturbance; a strict superset of the original training distribution (the torso can be randomly pitched/rolled).

• Mjlab-Homie-Unitree-G1-with_dex3 — Unitree Dex3 hands mounted as inertial attachments (~0.53 kg each) plus a randomized held-object payload.

• Mjlab-Homie-Unitree-G1-with_inspire — Inspire RH56 hands (RH56DFX spec mass, 0.54 kg each), same treatment. The base task randomizes a wrist payload covering these hand masses, so one checkpoint serves bare wrists and both hand models; these variants are primarily for play/eval with the real hand geometry.

• Mjlab-Homie-Unitree-G1-mjlab_gains — ablation variant with mjlab's first-principles actuator gains (armature × natural frequency); sim-only.

• Mjlab-Homie-Unitree-G1-native — frozen OpenHomie-parity preset. The diff between this cfg and the default task is the authoritative ledger of our deliberate deviations (torso payload DR narrowed to (-1, +5) kg, wrist payload DR widened to (0, 1.5) kg, hip/knee ground-contact penalty added — OpenHomie's penalize_contacts_on is dead code). Reference baseline; never iterated on.

• Mjlab-Homie-Unitree-H1 — trains with Unitree's official RL-stack PD gains (unitree_rl_gym h1_config.py; see robots/unitree_h1_deploy.py) and the uniform 0.25 action scale.

• Mjlab-Homie-Unitree-H1-mjlab_gains — H1 ablation variant with first-principles gains; sim-only.

• Mjlab-Homie-Unitree-H1-with_hands — deploy gains, with Robotiq 2F85 grippers mounted.

Usage

Pretrained locomotion checkpoints are available at Hugging Face if you want to skip training and go straight to playback.

List available environments:

uv run list-envs

Train:

uv run train Mjlab-Homie-Unitree-G1 --env.scene.num-envs 4096
uv run train Mjlab-Homie-Unitree-H1 --env.scene.num-envs 4096

The runner config sets upload_model=False: metrics are logged to W&B (when the wandb logger is selected) but checkpoints and ONNX exports stay local. Use --agent.logger tensorboard to skip W&B entirely.

Note: the HIM-PPO algorithm is single-GPU; the upstream --gpu-ids multi-GPU path is not supported.

Play:

uv run play Mjlab-Homie-Unitree-G1 --checkpoint-file /path/to/model.pt --viewer viser

More explicit playback examples:

uv run play Mjlab-Homie-Unitree-G1 \
  --checkpoint-file /path/to/model.pt \
  --num-envs 30 \
  --viewer viser \
  --device cuda:0

Sanity-check the MDP before training:

uv run play Mjlab-Homie-Unitree-G1 --agent zero
uv run play Mjlab-Homie-Unitree-G1 --agent random

Play holds the upper body at its default pose by default (isolating the lower-body gait). To preview deployment-like upper-body disturbances instead:

HOMIE_PLAY_UPPER_RATIO=1.0 uv run play Mjlab-Homie-Unitree-G1 --checkpoint-file ...

Real-robot deployment (G1)

src/mjlab_homierl/scripts/deploy_g1_homie.py runs an exported policy ONNX on the real robot over DDS, reading every convention (joint order, PD gains, obs layout, command ranges) from the ONNX metadata. The real path needs only numpy + onnxruntime + unitree_sdk2py — no mjlab/torch on the robot-side machine. One-time environment setup (builds cyclonedds 0.10.2 and works around three upstream packaging defects — see the script header):

bash scripts/setup_deploy_env.sh

Then (robot in debug/low-level mode, harnessed):

.venv-deploy/bin/python src/mjlab_homierl/scripts/deploy_g1_homie.py \
  --onnx <run_dir>/<run>.onnx --net <iface>

START moves to the default pose, A starts the policy, sticks drive vx/vy/wz, dpad up/down slews the height command, SELECT exits to damping. --sim (in the training venv: uv run --extra deploy ... --sim) validates the deploy-side observation builder bit-for-bit against the mjlab plant before any hardware session.

Interactive sim teleop (keyboard, classic MuJoCo)

uv run python -m mjlab_homierl.scripts.teleop_sim_g1 --onnx <run>.onnx

Real-time keyboard teleop in a plain CPU MuJoCo window, driving the policy through the same runtime.py pipeline as the real robot and the BiGym plugin — physics independent of the training engine (sim2sim). WASD = vx/vy, Q/E = yaw, arrows = height, Space = stop, Backspace = reset; Ctrl+drag shoves the robot. --smoke runs a 5 s headless self-test. Note for anyone building a classic-MuJoCo harness from the raw asset-zoo spec: it compiles with NO actuators, NO keyframe, and zero armature (mjlab injects all three at Entity build time), and the default Euler integrator is unstable at knee kp = 300 — this script re-injects all four (see build_model).

Notes

• The repository no longer vendors the mjlab framework itself.
• HIM-PPO remains package-local under mjlab_homierl.rl.himppo. Left/right mirror maps for its symmetry augmentation are derived from joint names, so any humanoid with left_*/right_* joint naming works.
• Mjlab-Homie-Unitree-H1-with_hands mounts the 2F85 grippers with hand collisions disabled by default. For HOMIE this keeps the hands as inertial / disturbance attachments instead of contact-rich manipulation tools.
• uv run play ... uses a HOMIE-specific actor-only inference path. The play env strips critic observations, rewards, and curriculum to reduce playback overhead.
• The custom inference helper is exposed as:

uv run infer-homie-lowerbody --help

Development

Run the package regression tests:

uv run pytest tests -q

Build the docs locally:

uv run --extra docs sphinx-build docs docs/_build
