naver/egjs-infinitegrid

@egjs/infinitegrid



Demo / Documentation / Other components

A module used to arrange elements including content infinitely according to grid type. With this module, you can implement various grids composed of different card elements whose sizes vary. It guarantees performance by maintaining the number of DOMs the module is handling under any circumstance
📱💻🖥

Supported Frameworks


---

✨ Features

• Use it in a framework you like.
  • We supports all major JS frameworks like React, Vue, Angular
• Restore state like position and active slide with persist
• Supports both Desktop & Mobile
• Support Dynamic Options
• Rich API

📖 Articles

• InfiniteGrid 4 Release!!

⚙️ Installation

npm

$ npm install --save @egjs/infinitegrid

CDN

• jsDelivr: https://cdn.jsdelivr.net/npm/@egjs/infinitegrid/dist/
• unpkg: https://unpkg.com/@egjs/infinitegrid/dist/
• cdnjs: https://cdnjs.com/libraries/egjs-infinitegrid

🏃 Quick Start

HTML

<div class="container"></div>

ES Modules

import { MasonryInfiniteGrid } from "@egjs/infinitegrid";

const ig = new MasonryInfiniteGrid(".container", { gap: 5 });

With CDN

<!-- Packaged with all dependencies -->
<!-- https://naver.github.io/egjs-infinitegrid/release/latest/dist/infinitegrid.min.js -->
<script src="https://unpkg.com/@egjs/infinitegrid/dist/infinitegrid.min.js"></script>

var ig = new InfiniteGrid.MasonryInfiniteGrid(".container", { gap: 5 });

import { MasonryInfiniteGrid } from "@egjs/infinitegrid";

function getItems(nextGroupKey, count) {
  const nextItems = [];

  for (let i = 0; i < count; ++i) {
    const num = nextGroupKey * count + i;
    nextItems.push(`<div class="item"></div>`);
  }
  return nextItems;
}
const ig = new MasonryInfiniteGrid(".container", {
  gap: 5,
});

ig.on("requestAppend", (e) => {
  const nextGroupKey = (+e.groupKey || 0) + 1;

  ig.append(getItems(nextGroupKey, 10), nextGroupKey);
});
ig.renderItems();

Use Faster & Lazy Rendering

• When the loading="lazy" or data-grid-lazy="true"(external lazy loading) attribute is used, Rendering of the items occurs immediately. When items are loaded, they are rendered sequentially.

<img src="..." />
<img src="..." />
<img src="..." loading="lazy" />
<img data-grid-lazy="true" />

• If you use data-grid-width and data-grid-height attributes, the size of self, child image, and video elements is automatically adjusted until loading is complete.

<div data-grid-width="100" data-grid-height="100">
   <img src="..." />
   <img src="..." />
   <img src="..." />
</div>

• If you use data-grid-skip="true" attribute, you can omit it even if there are images in itself and child image, and video elements.

<div data-grid-skip="true">
   <img src="..." />
   <img src="..." />
   <img src="..." />
</div>

Detect resize of Container & Children

InfiniteGrid calculates the size of container and children by window resizing event. However, even if the size of the window does not change, the size of the event container and children can change. Most of the first rendering issues are also like this.

In this case, I recommend ResizeObserver for you.

Provides useResizeObserver option to detect size change of container and observeChildren option to detect size change of children.

import { MasonryInfiniteGrid, JustifiedInfiniteGrid, FrameInfiniteGrid, PackingInfiniteGrid } from "@egjs/infinitegrid";


// InfiniteGrid.MasonryInfiniteGrid
const grid = new MasonryInfiniteGrid(container, {
  gap: 5,
  useResizeObserver: true,
  observeChildren: true,
});

grid.renderItems();

Pre-guess size for performance or invisible items.

What if all items were the same size?

If you use the isEqualSize option, all items are considered to be the same size. Each resize only calculates the size of one item. Add data-grid-not-equal-size="true" attribute if there is an exceptional item whose size needs to be calculated while using isEqualSize.

<div class="item item1"></div>
<div class="item item1"></div>
<div class="item item1"></div>
<!--item2 is a different size than item1.-->
<div class="item item2" data-grid-not-equal-size="true"></div>

What if a size group exists?

isEqualSize assumes all items are equal. But if there are more than two size-groups, use data-grid-size-group.

<!--item1 has the same size.-->
<div class="item item1" data-grid-size-group="1"></div>
<div class="item item1" data-grid-size-group="1"></div>
<!--item2 has the same size.-->
<div class="item item2" data-grid-size-group="2"></div>
<div class="item item2" data-grid-size-group="2"></div>

What if all items don't change size?

If all items do not have a constant size, use the isConstantSize option. Resizing doesn't calculate the item's size. If you want to recalculate, use .updateItems(items, { useOrgResize: true }) method or .renderItems({ useOrgResize: true }) method.

📦 Packages

🌐 Supported Browsers

📼 Demos

Check our Demos.

📖 Documentation

See Documentation page.

🙌 Contributing

See CONTRIBUTING.md.

📝 Feedback

Please file an Issue.

🛣️ Roadmap

See our Roadmap.

📜 License

@egjs/infinitegrid is released under the MIT license.
