NVlabs/tiny-cuda-nn

Tiny CUDA Neural Networks

This is a small, self-contained framework for training and querying neural networks. Most notably, it contains a lightning fast "fully fused" multi-layer perceptron (technical paper), a versatile multiresolution hash encoding (technical paper), as well as support for various other input encodings, losses, and optimizers.

Performance

Fully fused networks vs. TensorFlow v2.5.0 w/ XLA. Measured on 64 (solid line) and 128 (dashed line) neurons wide multi-layer perceptrons on an RTX 3090. Generated by benchmarks/bench_ours.cu and benchmarks/bench_tensorflow.py using data/config_oneblob.json.

Usage

Tiny CUDA neural networks have a simple C++/CUDA API:

#include <tiny-cuda-nn/common.h>

// Configure the model
nlohmann::json config = {
	{"loss", {
		{"otype", "L2"}
	}},
	{"optimizer", {
		{"otype", "Adam"},
		{"learning_rate", 1e-3},
	}},
	{"encoding", {
		{"otype", "HashGrid"},
		{"n_levels", 16},
		{"n_features_per_level", 2},
		{"log2_hashmap_size", 19},
		{"base_resolution", 16},
		{"per_level_scale", 2.0},
	}},
	{"network", {
		{"otype", "FullyFusedMLP"},
		{"activation", "ReLU"},
		{"output_activation", "None"},
		{"n_neurons", 64},
		{"n_hidden_layers", 2},
	}},
};

using namespace tcnn;

auto model = create_from_config(n_input_dims, n_output_dims, config);
model->set_jit_fusion(supports_jit_fusion()); // Optional: accelerate with JIT fusion

// Train the model (batch_size must be a multiple of tcnn::BATCH_SIZE_GRANULARITY)
GPUMatrix<float> training_batch_inputs(n_input_dims, batch_size);
GPUMatrix<float> training_batch_targets(n_output_dims, batch_size);

for (int i = 0; i < n_training_steps; ++i) {
	generate_training_batch(&training_batch_inputs, &training_batch_targets); // <-- your code

	float loss;
	model.trainer->training_step(training_batch_inputs, training_batch_targets, &loss);
	std::cout << "iteration=" << i << " loss=" << loss << std::endl;
}

// Use the model
GPUMatrix<float> inference_inputs(n_input_dims, batch_size);
generate_inputs(&inference_inputs); // <-- your code

GPUMatrix<float> inference_outputs(n_output_dims, batch_size);
model.network->inference(inference_inputs, inference_outputs);

JIT fusion

JIT fusion is a new, optional feature with tiny-cuda-nn v2.0 and later. It is almost always recommended to enable automatic JIT fusion for a performance boost of 1.5x to 2.5x, depending on the model and GPU. Newer GPUs exhibit larger speedups.

If your model has very large hash grids (~20 million+ parameters) or MLPs (layer sizes larger than 128 neurons), or when your GPU is an RTX 3000 series or earlier, JIT fusion can slow down training. Rarely inference, too. It this case, it is recommended to try enabling JIT fusion separately for training and inference to measure whether it is faster.

Please open an issue if you encounter a slowdown in a different situation or other problems with JIT fusion enabled.

Automatic JIT fusion

To enable JIT fusion, set the jit_fusion property of your model to true. All future uses of the model, whether inference or training, will then use JIT mode. Note that if there is an error during JIT compilation, a warning will be emitted and JIT compilation mode automatically turned off. Your code will still run using the tiny-cuda-nn 1.X code path.

auto model = tcnn::create_from_config(...);
model->set_jit_fusion(tcnn::supports_jit_fusion()); // Enable JIT if the system supports it

JIT fusion can also be enabled via the PyTorch bindings but the speed-up will be lower, particularly during training. This is because the JIT compiler does not have access to the whole compute graph and can therefore fuse and optimize less.

import tinycudann as tcnn

model = tcnn.NetworkWithInputEncoding(...) # Or any other tcnn model
model.jit_fusion = tcnn.supports_jit_fusion() # Enable JIT if the system supports it

Manual JIT fusion

Even larger speed-ups are possible when applications integrate more tightly with JIT fusion. For example, Instant NGP achieves a 5x speedup by fusing the entire NeRF ray marcher into a single kernel.

JIT fusion works by converting a given tiny-cuda-nn model to a CUDA device function and then compiling it into a kernel using CUDA's runtime compilation (RTC) feature.

To integrate a tiny-cuda-nn model with a larger kernel in your app, you need to

1. turn your kernel into a string,
2. prepend the tiny-cuda-nn model's device function,
3. pass the result to tiny-cuda-nn's runtime compilation API.

Here is an example that implements a minimal kernel using a tiny-cuda-nn model with 32 input dimensions and 16 output dimensions:

#include <tiny-cuda-nn/rtc_kernel.h>

auto model = tcnn::create_from_config(32 /* input dims */, 16 /* output dims */, ...);
auto fused_kernel = tcnn::CudaRtcKernel(
    "your_kernel",
    fmt::format(R"
        {MODEL_DEVICE_FUNCTION}
        __global__ void your_kernel(...) {
            // Get input to model from either registers or memory.
            tcnn::hvec<32> input = ...;
            // Call tiny-cuda-nn model. All 32 threads of the warp must be active here.
            tcnn::hvec<16> output = model_fun(nerf_in, params);
            // Do something with the model output.
        }",
        fmt::arg("MODEL_DEVICE_FUNCTION", model->generate_device_function("model_fun")),
    )
);

uint32_t blocks = 1;
uint32_t threads = 128; // Must be multiple of 32 for neural networks to work.
uint32_t shmem_size = 0; // Can be any size that your_kernel needs.
cudaStream_t stream = nullptr; // Can be any stream.
fused_kernel.launch(blocks, threads, shmem_size, stream, ... /* params of your_kernel */);

And here is Instant NGP's NeRF integration with the JIT compiler for reference:

• src/testbed_nerf.cu
• include/neural-graphics-primitives/fused_kernels/render_nerf.cuh

Example: learning a 2D image

We provide a sample application where an image function (x,y) -> (R,G,B) is learned. It can be run via

tiny-cuda-nn$ ./build/mlp_learning_an_image data/images/albert.jpg data/config_hash.json

producing an image every couple of training steps. Each 1000 steps should take a bit over 1 second with the default configuration on an RTX 4090.

Requirements

• An NVIDIA GPU; tensor cores increase performance when available. All shown results come from an RTX 3090.
• A C++17 capable compiler. The following choices are recommended and have been tested:
  • Windows: Visual Studio 2019 or 2022
  • Linux: GCC/G++ 8 or higher
• A recent version of CUDA. The following choices are recommended and have been tested:
  • Windows: CUDA 11.5 or higher
  • Linux: CUDA 10.2 or higher
• CMake v3.21 or higher.
• The fully fused MLP component of this framework requires a very large amount of shared memory in its default configuration. It will likely only work on an RTX 3090, an RTX 2080 Ti, or higher-end GPUs. Lower end cards must reduce the n_neurons parameter or use the CutlassMLP (better compatibility but slower) instead.

If you are using Linux, install the following packages

sudo apt-get install build-essential git

We also recommend installing CUDA in /usr/local/ and adding the CUDA installation to your PATH. For example, if you have CUDA 12.6.3, add the following to your ~/.bashrc

export PATH="/usr/local/cuda-12.6.3/bin:$PATH"
export LD_LIBRARY_PATH="/usr/local/cuda-12.6.3/lib64:$LD_LIBRARY_PATH"

Compilation (Windows & Linux)

Begin by cloning this repository and all its submodules using the following command:

$ git clone --recursive https://github.com/nvlabs/tiny-cuda-nn
$ cd tiny-cuda-nn

Then, use CMake to build the project: (on Windows, this must be in a developer command prompt)

tiny-cuda-nn$ cmake . -B build -DCMAKE_BUILD_TYPE=RelWithDebInfo
tiny-cuda-nn$ cmake --build build --config RelWithDebInfo -j

If compilation fails inexplicably or takes longer than an hour, you might be running out of memory. Try running the above command without -j in that case.

PyTorch extension

tiny-cuda-nn comes with a PyTorch extension that allows using the fast MLPs and input encodings from within a Python context. These bindings can be significantly faster than full Python implementations; in particular for the multiresolution hash encoding.

The overheads of Python/PyTorch can nonetheless be extensive if the batch size is small. For example, with a batch size of 64k, the bundled mlp_learning_an_image example is ~2x slower through PyTorch than native CUDA. With a batch size of 256k and higher (default), the performance is much closer.

Begin by setting up a Python 3.X environment with a recent, CUDA-enabled version of PyTorch. Then, invoke

pip install git+https://github.com/NVlabs/tiny-cuda-nn/#subdirectory=bindings/torch

Alternatively, if you would like to install from a local clone of tiny-cuda-nn, invoke

tiny-cuda-nn$ cd bindings/torch
tiny-cuda-nn/bindings/torch$ python setup.py install

By default, the extension automatically enables half precision (FP16) on GPUs with good support (Volta, Turing, Ampere, etc.) and disables it on older architectures or those with slow FP16 (e.g., Pascal/GTX 10-series).

If you wish to override this behavior (e.g., to force FP16 on unsupported hardware or disable it for debugging), set the TCNN_HALF_PRECISION environment variable before installation:

Disable FP16: 0 Enable FP16: 1

Example:

# Linux / macOS (Disable FP16)
export TCNN_HALF_PRECISION=0
pip install git+https://github.com/NVlabs/tiny-cuda-nn/#subdirectory=bindings/torch

Upon success, you can use tiny-cuda-nn models as in the following example:

import commentjson as json
import tinycudann as tcnn
import torch

with open("data/config_hash.json") as f:
	config = json.load(f)

# Option 1: efficient Encoding+Network combo.
model = tcnn.NetworkWithInputEncoding(
	n_input_dims, n_output_dims,
	config["encoding"], config["network"]
)

# Option 2: separate modules. Slower but more flexible.
encoding = tcnn.Encoding(n_input_dims, config["encoding"])
network = tcnn.Network(encoding.n_output_dims, n_output_dims, config["network"])
model = torch.nn.Sequential(encoding, network)

model.jit_fusion = tcnn.supports_jit_fusion() # Optional: accelerate with JIT fusion

See samples/mlp_learning_an_image_pytorch.py for an example.

Components

Following is a summary of the components of this framework. The JSON documentation lists configuration options.

License and Citation

This framework is licensed under the BSD 3-clause license. Please see LICENSE.txt for details.

If you use it in your research, we would appreciate a citation via

@software{tiny-cuda-nn,
	author = {M\"uller, Thomas},
	license = {BSD-3-Clause},
	month = {4},
	title = {{tiny-cuda-nn}},
	url = {https://github.com/NVlabs/tiny-cuda-nn},
	version = {2.0},
	year = {2021}
}

For business inquiries, please visit our website and submit the form: NVIDIA Research Licensing

Publications & Software

Among others, this framework powers the following publications:

Instant Neural Graphics Primitives with a Multiresolution Hash Encoding
Thomas Müller, Alex Evans, Christoph Schied, Alexander Keller
ACM Transactions on Graphics (SIGGRAPH), July 2022
Website / Paper / Code / Video / BibTeX

Extracting Triangular 3D Models, Materials, and Lighting From Images
Jacob Munkberg, Jon Hasselgren, Tianchang Shen, Jun Gao, Wenzheng Chen, Alex Evans, Thomas Müller, Sanja Fidler
CVPR (Oral), June 2022
Website / Paper / Video / BibTeX

Real-time Neural Radiance Caching for Path Tracing
Thomas Müller, Fabrice Rousselle, Jan Novák, Alexander Keller
ACM Transactions on Graphics (SIGGRAPH), August 2021
Paper / GTC talk / Video / Interactive results viewer / BibTeX

NVGS: Neural Visibility for Occlusion Culling in 3D Gaussian Splatting
Brent Zoomers, Florian Hahlbohm, Joni Vanherck, Lode Jorissen, Marcus Magnor, Nick Michiels
CVPR, June 2026
Website / Paper / Code / BibTex

As well as the following software:

NerfAcc: A General NeRF Accleration Toolbox
Ruilong Li, Matthew Tancik, Angjoo Kanazawa
https://github.com/KAIR-BAIR/nerfacc

Nerfstudio: A Framework for Neural Radiance Field Development
Matthew Tancik*, Ethan Weber*, Evonne Ng*, Ruilong Li, Brent Yi, Terrance Wang, Alexander Kristoffersen, Jake Austin, Kamyar Salahi, Abhik Ahuja, David McAllister, Angjoo Kanazawa
https://github.com/nerfstudio-project/nerfstudio

Please feel free to make a pull request if your publication or software is not listed.

Acknowledgments

Special thanks go to the NRC authors for helpful discussions and to Nikolaus Binder for providing part of the infrastructure of this framework, as well as for help with utilizing TensorCores from within CUDA.
