pbatard/Mosby

Mosby - More Secure Secure Boot

Description

Mosby (mos⸱bee), which stands for More Secure Secure Boot, for You, is a UEFI Shell application designed to easily create and install a more secure (and more up to date) default set of UEFI Secure Boot keys that includes your own Secure Boot signing credentials, as well as a unique, non-exploitable, machine Primary Key (PK).

The motivations behind this are as follows:

1. Two of the Secure Boot whitelisting (DB) certificates, commonly used for Secure Boot validation (Microsoft Windows Production PCA 2011 and Microsoft Corporation UEFI CA 2011) as well as Microsoft's main Key Exchange Key (KEK) certificate (Microsoft Corporation KEK CA 2011) are set to expire in the second half of 2026.
   Whereas, in itself, this will not prevent existing Secure Boot signed bootloaders from validating (as long as they haven't been revoked through other means) it will however prevent any newer UEFI bootloader from doing so which basically means that, if your OS or OS installer was produced after those DB certificates expire, and you don't have the additional 2023 DB certificates installed (see below), then, come the second half of 2026, you will not be able to boot or even install a Secure Boot compatible OS in a Secure Boot enabled environment!
   This application can remedy that.
2. In 2023, because of the expiration of the certificates listed above, Microsoft introduced one new KEK and two new DB certificates, that are therefore not commonly found in your system manufacturer's default key (especially if your system has not received any firmware update since 2024) and that (because a KEK can only be installed through updates that are signed by the platform manufacturer) can be problematic to update from the OS itself, even if the OS is Secure Boot compatible or comes from Microsoft.
   This application can remedy that.
3. As of the second half of 2024, and due to many, many vulnerabilities uncovered in the UEFI Windows bootloaders, Microsoft is in the process of completely removing one of the base DB certificates (The Microsoft Windows Production PCA 2011 certificate mentioned above).
   Once Microsoft produces installation media that no longer uses this certificate, this application will make sure that this DB certificate is properly removed (as opposed to what would happen if you use the native Secure Boot key restoration from your UEFI firmware).
4. In 2024, it was discovered that some PC manufacturers played fast and loose with the Primary Key (PK) shipped with their hardware, basically meaning that malicious actors could gain access to the secret key, and therefore gain full trusted access of the affected machines. It is also very likely (though of course it is in their interest not to reveal it) that, PC manufacturers have had more PK private key exfiltered into the hand of malicious actors (or, if you are living under an authoritative regime, have been forced to hand them over to said regime), leading to the same very real risk of a third parties exploiting this data to install UEFI rootkits on users' computers.
   With its default settings, this application can fully remedy that.
5. As part of the 2023 certificate update, Microsoft is also introducing a new dedicated Secure Boot certificate for Option ROMs, which older UEFI firmwares do not have and which may prevent add-on cards from being able to initialize in a Secure Boot environment. This application can remedy that.
6. OS manufacturers, such as Microsoft, have long taken a very user-adverse stance against the ability of individuals to ultimately be in control the UEFI boot signing process, by, to name just a few instances, using fake rhetoric against some software licenses in order to arbitrarily deny common Linux bootloaders such as GRUB from being Secure Boot signed, trying to lock down hardware so that Secure Boot could not ever been disabled by the user, making a two-tier version of Secure Boot signatures with one exclusive tier for Windows and a lower tier for other OSes and application or, up until recently, even trying to prevent anybody that wasn't an OS or hardware manufacturer from being allowed to redistribute UEFI revocation lists...
   The end result is that it has become a lot more convoluted and daunting than it should really be for end-users, to make Secure Boot work in their favour.
   This application can also remedy that.
7. Figuring out SBAT, SkuSiPolicy as well as Microsoft's new SVN DBX based revocation updates is currently a mess, as you need to wade through many different sources to try to ensure that your system is actually up to date with them (because if they aren't, an attacker can easily bypass Secure Boot on your system).
   This application can remedy that.

In short, while making sure that all the Secure Boot keys used by your platform are up to date, the whole point of this application is to give control of the whole Secure Boot process back to YOU, like it should always have been, instead of leaving it in control of a select few, who may not have your interests in mind, and, over and over, have demonstrated behaviour that should not warrant your blind trust.

And it does so by making incredibly easy to install your own set of Secure Boot keys.

Usage

1. Create a UEFI Shell bootable media.
   If you don't have such a media, you can easily create one on Windows through Rufus by using the SELECT/DOWNLOAD split button and then choosing UEFI Shell in the download selection:
   https://raw.githubusercontent.com/wiki/pbatard/rufus/images/download.gif

2. Extract all the content from the latest Mosby download archive at the top level of the boot media you created in the previous step.

3. Boot the computer where you want to install the keys into the UEFI firmware settings and make sure that your platform is in Setup Mode. Please refer to your manufacturer's documentation if you don't know how to enable Setup Mode.

4. Boot into the UEFI Shell media you created and type: Mosby (without any extension). The executable relevant to your platform will automatically launch and will guide you through the installation of the UEFI Secure Boot keys.

5. Once the installation is complete, reboot into UEFI firmware settings, and make sure that Secure Boot is enabled.

If needed, you can also provide your own DB/DBX/DBT/KEK/PK/MOK binaries in DER, PEM, ESL or signed ESL format, by using something like -db canonical_ca.cer to point a Secure Boot variable to the data you want to install for it.

Parameters

Main parameters

• -h: Display the application parameters and exit.
• -i: Display information about the embedded data installable by the application, as well as the current SBAT data from the system (if SBAT is set) and manufacturer defaults.
• -r: Try to reinstall the manufacturer's default PK/KEK/DB certs, if available.
• -s: Silent option (Removes some of the early and late prompts).
• -t: Test mode. Disables some checks and enables the internal low security Random Number Generator, if no other Random Number Generator can be found.
• -u: Update only: Only update the revocation databases and SBAT as needed.
• -v: Display the application version and exit.
• -x: Install the Microsoft update that invalidates Microsoft Windows Production PCA 2011. You should only use this if you know what you are doing, as you you may not be able to boot or reinstall Windows otherwise. You have been warned!

You can also point to files using the -pk, -kek, -db, -dbx, -mok, -dbt and -sbat parameters.

Additional parameters

• --create-nopk: Create a NoPK.auth PK deletion package (that can be used with KeyTool).
• --no-log: Disable file logging (Output will not be logged into Mosby.log).
• --no-mosby-db: Don't install the MosbyKey DB credentials for bootloader signing.

Compilation

Because Mosby depends on OpenSSL to provide the various cryptography function it needs, and OpenSSL is integrated by default into EDK2, only EDK2 is supported for compilation.

Additionally, some very limited patching of EDK2 is required to enable some of the standard OpenSSL providers, that take care of the importing/exporting of keys and certificates, and that are not currently enabled by EDK2. So you should first apply Add-extra-PKCS-encoding-and-decoding-to-OpensslLibFull.patch to the EDK2 submodule.

If compiling for ARM or RISCV-64 some additional patching of OpenSSL is required, that can be found in OpenSSL-submodule-fixes-for-<PLATFORM>-compilation.patch.

Once that is done, you can compile Mosby as you would any regular EDK2 module, by issuing something like:

cd <directory where you cloned Mosby>
git submodule update --init
export WORKSPACE=$PWD
export PACKAGES_PATH=$WORKSPACE:$WORKSPACE/edk2
source edk2/edksetup.sh
build -a X64 -b RELEASE -t GCC5 -p MosbyPkg.dsc

Note that, if you have bash with curl, OpenSSL and sed installed, you can recreate data.c by running the following command in the src/ directory:

./gen_data.sh

Mini FAQ

ERROR: This platform does not meet the minimum security requirements

If you are getting the error above, it usually means that your system is lacking a proper random number generator, which is essential for the generation of a Secure Boot signing key that can't be easily cracked by an attacker.

Mosby first attempts to use the OpenSSL provided random number generator or, if that is not available, it falls back to using the UEFI platform's random number generator both of which are considered safe for the generation of signing keys.

If none of the above are available, then Mosby can also use its own internal random number generator, however because of the algorithm being used, this generator should be considered unsafe and therefore can only be used when running Mosby with the "test" (-t) option.

How do I use the generated Secure Boot key to sign a UEFI bootloader?

• On Windows, use signtool.exe with the .pfx. For example, to sign bootx64.efi:

signtool sign /f MosbyKey.pfx /fd SHA256 bootx64.efi

Note that you can download signtool.exe with the command:

curl.exe -L -A "Microsoft-Symbol-Server/10.0.0.0" https://msdl.microsoft.com/download/symbols/signtool.exe/910D667173000/signtool.exe -o signtool.exe

• On Linux, use sbsign from the sbsigntool package with the .pem and .crt. For example, to sign bootx64.efi:

sbsign --key MosbyKey.pem --cert MosbyKey.crt bootx64.efi --output bootx64.efi

If asked for a passphrase, just press Enter.

How can you state that your application makes Secure Boot more Secure?

Easy. If you had used Mosby then even on a PC where the default UEFI keys were subject to this vulnerability, the vulnerability would have been fully closed and rendered inexploitable.

Why do I get a Security Violation when trying to reuse the manufacturer's PK?

If using option -r to re-install the default's PK, KEK and DB certs, you may find that whereas the extra KEK and DB certs provided by the manufacturer will be added successfully, the PK installation will fail with Security Violation and Mosby will fall back to using its uniquely generated PK. This is because, most platforms that follow the UEFI specs expect the PK certificate installation package to be signed with the private key that matches the cert, and, whereas we might be access the cert, if a PKDefault variable exists, we obviously do not have access to the manufacture's private key.

Why isn't the Secure Boot private key generated by this application password protected?

Because the key is unique, and, in most usage scenarios (individuals securing a very limited number of machines) unlikely to be easy to exploit (since the attacker would already need to have found a vulnerability to locate and access the key from where it is stored). On the other hand, we want to make it easy for people to be able to sign their UEFI bootloaders as they need it, because vetting bootloaders for Secure Boot should not be a daunting prospect.

At any rate, if you do want a Secure Boot signing key that is protected by a password, you can easily generate one with OpenSSL, and then point to its matching certificate when running Mosby.

How can I trust that Mosby is not doing something malicious behind the scenes?

1. It's public source, using a license that explicitly prevents the inclusion of anything in the final binary for which you cannot access the source.
2. It's built in a transparent manner through GitHub Actions, and binary validation can be enacted in a similar way as what applies to our UEFI-Shell binaries.
3. It's published by the same developer as the person behind Rufus, which is a rather popular and trusted application, that, for more than 10 years now, has helped countless people install bootloaders and run privileged code on their computer. In short if the ultimate goal of the developer of Mosby was to gain the ability to exploit your computer, they would have had plenty of other opportunities to do so over the last decade, and, more importantly, would long have been reported if they ever did so.
