pybind/pybind11_abseil

Pybind11 bindings for the Abseil C++ Common Libraries

Github-CI:

OS \ Build system	Bazel	CMake
Linux (amd64)
MacOS (amd64)
MacOS (arm64)
Windows (amd64)

Overview

These adapters make Abseil types work with Pybind11 bindings. For more information on using Pybind11, see g3doc/third_party/pybind11/google3_utils/README.md.

To use the converters listed below, just include the header in the .cc file with your bindings:

#include "pybind11_abseil/absl_casters.h"

Installation

pybind11_abseil can be built with Bazel or CMake. Instructions for both are below.

Bazel

In your BUILD file:

load("@pybind11_bazel//:build_defs.bzl", "pybind_extension")

Bzlmod

You can depend on the Bazel module and dependencies via one of the following commands in your MODULE.bazel:

To depend on a release:

bazel_dep(
    name = "pybind11_abseil",
    version = "<selected_version>",
)

To depend on floating master:

http_archive = use_repo_rule("@bazel_tools//tools/build_defs/repo:http.bzl", "http_archive")

http_archive(
  name = "pybind11_bazel",
  strip_prefix = "pybind11_bazel-master",
  urls = ["https://github.com/pybind/pybind11_bazel/archive/refs/heads/master.tar.gz"],
)

http_archive(
  name = "pybind11",
  build_file = "@pybind11_bazel//:pybind11-BUILD.bazel",
  strip_prefix = "pybind11-master",
  urls = ["https://github.com/pybind/pybind11/archive/refs/heads/master.tar.gz"],
)

http_archive(
  name = "pybind11_abseil",
  strip_prefix = "pybind11_abseil-master",
  urls = ["https://github.com/pybind/pybind11_abseil/archive/refs/heads/master.tar.gz"],
)

WORKSPACE

Bazel workspace support is deprecated and will be removed at a later date.

You will need to depend on pybind11, pybind11_bazel(see doc, and on pybind11_abseil), e.g.

http_archive(
  name = "pybind11_bazel",
  strip_prefix = "pybind11_bazel-master",
  urls = ["https://github.com/pybind/pybind11_bazel/archive/refs/heads/master.tar.gz"],
)

http_archive(
  name = "pybind11",
  build_file = "@pybind11_bazel//:pybind11-BUILD.bazel",
  strip_prefix = "pybind11-master",
  urls = ["https://github.com/pybind/pybind11/archive/refs/heads/master.tar.gz"],
)

http_archive(
  name = "pybind11_abseil",
  strip_prefix = "pybind11_abseil-master",
  urls = ["https://github.com/pybind/pybind11_abseil/archive/refs/heads/master.tar.gz"],
)

CMake

In your project, add a FetchContent for pybind11_abseil. This will also fetch the appropriate versions of Abseil and pybind11 which your project can use (eliminating the need for submoduling Abseil or using find_package).

Add the following to your CMakeLists.txt:

include(FetchContent)
FetchContent_Declare {
  pybind11_abseil
  GIT_REPOSITORY https://github.com/pybind/pybind11_abseil.git
  GIT_TAG master
}
FetchContent_MakeAvailable(pybind11 abseil-cpp pybind11_abseil)

To install the package so that it is accessible from system Python, run cmake with the flag -DCMAKE_INSTALL_PYDIR set to a directory on your PYTHONPATH and subsequently run make install. This also works on projects that include pybind11_abseil via FetchContent.

absl::Duration

absl::Duration objects are converted to/ from python datetime.timedelta objects. Therefore, C code cannot mutate any datetime.timedelta objects from python.

absl::Time

absl::Time objects are converted to/from python datetime.datetime objects. Additionally, datetime.date objects can be converted to absl::Time objects. C code cannot mutate any datetime.datetime objects from python.

Python date objects effectively truncate the time to 0 (i.e., midnight). Python time objects are not supported because absl::Time would implicitly assume a year, which could be confusing.

Time zones

Python datetime objects include timezone information, while absl::Time does not. When converting from Python to C++, if a timezone is specified then it will be used to determine the absl::Time instant. If no timezone is specified by the Python datetime object, the local timezone is assumed.

When converting back from C++ to Python, the resultant time will be presented in the local timezone and the tzinfo property set on the datetime object to reflect that. This means that the caller may receive a datetime formatted in a different timezone to the one they passed in. To handle this safely, the caller should take care to check the tzinfo of any returned datetimes.

absl::CivilTime

absl::CivilTime objects are converted to/from Python datetime.datetime objects. Fractional Python datetime components are truncated when converting to less granular C++ types, and time zone information is ignored.

absl::Span

Loading

Some python types can be loaded (Python->C++) without copying or converting the list, while some require copying/ converting the list. The non-converting load methods will be tried first, and, if the span elements are const, the converting load methods will be tried next.

Arguments cast to a span with non-const elements can never be copied/converted. To prevent an argument cast to a span with const elements from being copied or converted, mark it as noconvert() (see go/pybind11-non-converting-arguments).

The following python types can be loaded without copying or converting:

• Numpy array (or anything else that supports buffer protocol) => Span<{const or non-const} T> if all of the following conditions are satisfied:
  • The buffer is 1-D.
  • T is a numeric type.
  • The array dtype matches T exactly.
  • If T is not const, the buffer allows writing.
  • The stride does not indicate to skip elements or go in reverse order.
• Opaque std::vector<T> => Span<{const or non-const} T>.
  • T can be any type, including converted or pointer types, but must match exactly between C++ and python.
  • Opaque vectors are not currently compatible with the smart holder.

The following python types must be copied/converted to be loaded:

• Python sequence of elements that require conversion (numbers, strings, datetimes, etc) => Span<const T>.
  • The elements will be copied/ converted, so that conversion must be legal.
  • T cannot be a pointer.
• Python sequence of elements that do not require conversion (ie, classes wrapped with py::class_) => Span<const T> (elements will be copied) or Span<{const or non-const} T* const> (elements will not be copied).

Specifically, this conversion will fail if any of the following are true:

• noconvert() was specified (see go/pybind11-non-converting-arguments).
• The element conversion is not allowed (eg, floating point to integer).
• The sequence is being loaded into a Span<{non-const} T> or Span<{const or non-const} T* {non-const}>.
• The elements require conversion and the sequence is being loaded into a Span<T*> (regardless of any consts; the element caster which owns the converted value would be destroyed before load is complete, resulting in dangling references).
• The span is nested (ie, absl::Span<absl::Span<T>>, regardless of any consts).

Note: These failure conditions only apply to converted python types.

Casting

Spans are cast (C++->Python) with the standard list caster, which always converts the list. This could be changed in the future (eg, using buffer protocol ) but generally using spans as return values is not recommended.

absl::string_view

Supported exactly the same way pybind11 supports std::string_view.

absl::optional

Supported exactly the same way pybind11 supports std::optional.

absl::flat_hash_map and absl::btree_map

Supported exactly the same way pybind11 supports std::map.

absl::flat_hash_set

Supported exactly the same way pybind11 supports std::set.

absl::Status[Or]

To use the Status[Or] casters:

1. Include the header file pybind11_abseil/status_casters.h in the .cc file with your bindings.
2. Call pybind11::google::ImportStatusModule(); in your PYBIND11_MODULE definition.

(For use outside google3: The path used for the status module may be changed by altering the value of PYBIND11_ABSEIL_STATUS_MODULE_PATH defined in import_status_module.h.)

By default, an ok status will be converted into None, and a non-ok status will raise a status.StatusNotOk exception. This has a status attribute which can be used to access the status object and check the code/ message.

To get a status.Status object rather than having an exception thrown, pass either the Status object or a function returning a Status to pybind11::google::DoNotThrowStatus before casting or binding. This works with references and pointers to absl::Status objects too.

It isn't possible to specify separate return value policies for a StatusOr object and its payload. Since StatusOr is processed and not ever actually represented in Python, the return value policy applies to the payload. E.g., if you return a StatusOr<MyObject*> (note the * is inside the StatusOr) with a take_ownership return val policy and the status is OK (i.e., it has a payload) , Python will take ownership of that payload and free it when it is garbage collected.

However, if you return a StatusOr<MyObject>* (note: the * is outside the StatusOr rather than inside it now) with a take_ownership return val policy, Python does not take ownership of the StatusOr and will not free it (because again, that policy applies to MyObject, not StatusOr).

See status_utils.cc in this directory for details about what methods are available in wrapped absl::Status objects.

Example:

#include "pybind11_abseil/status_casters.h"

absl::Status StatusReturningFunction() {
  return absl::Status(...);
}

pybind11::object StatusHandlingFunction() {
  return pybind11::cast(pybind11::google::DoNotThrowStatus(StatusReturningFunction()));
}

PYBIND11_MODULE(test_bindings, m) {
  pybind11::google::ImportStatusModule();

  m.def("return_status", &StatusReturningFunction,
        "Return None if StatusCode is OK, otherwise raise an error.");
  m.def("make_status", google::DoNotThrowStatus(&StatusReturningFunction),
        "Return a wrapped status object without raising an error.");
  m.def("status_handling_function", &StatusHandlingFunction,
        "Same effect as make_status, but cast is done internally.");
};

Python:

from pybind11_abseil import status
import test_bindings

my_status = make_status()
if my_status.code():
  ...

try:
  return_status()
except status.StatusNotOk as e:
  print(e.status)

absl::StatusOr

absl::StatusOr objects behave exactly like absl::Status objects, except:

• There is no support for passing StatusOr objects. You can only return them.
• Instead of returning None or a wrapped status with OK, this casts and returns the payload when there is no error.

As with absl::Status, the default behavior is to throw an error when casting a non-ok status. You may pass a StatusOr object or StatusOr returning function to pybind11::google::DoNotThrowStatus in exactly the same way as with absl::Status to change this behavior.

absl::StatusOr objects must be returned by value (not reference or pointer). Why? Because the implementation takes advantage of the fact that python is a dynamically typed language to cast and return the payload or the absl::Status object (or raise an exeception). Python has no concept of a absl::StatusOr object, so it's also impossible to apply the return_value_policy to a absl::StatusOr. Therefore returning a reference or pointer to a absl::StatusOr is meaningless.

Pointers can be used as the payload type, and the return_value_policy will be applied to the payload if the status is OK. However, references cannot be used as the payload type, because that's a restriction on absl::StatusOr in general, not pybind11 (see https://yaqs/5903163345338368).

This can handle any type of payload that pybind knows about. unique_ptrs (i.e., absl::StatusOr<std::unique_ptr<...>>) to wrapped classes or structs (i.e., any type which you created bindings for using pybind11::class_<...>) can be used, but unique_ptrs to converted types (e.g., int, string, absl::Time, absl::Duration, etc.) cannot be used.

absl::StatusCode

The status module provides pybind11::enum_ bindings for absl::StatusCode. These use python constant style, e.g. status.StatusCode.OK, status.StatusCode.CANCELLED, etc.

Warning: Pybind enums are their own type, and will never compare equally to integers due to being a different type, regardless of their value. In particular , note that the status proto code field is an integer, so it will never directly compare as equal to a StatusCode. To fix this, convert an integer to a StatusCode or vice-versa.

status_code = 0  # An integer.

if status_code == status.StatusCode.OK:  # Wrong: always evaluates to false.
  ...

if status.StatusCode(status_code) == status.StatusCode.OK:  # Correct.
  ...

if status_code == int(status.StatusCode.OK):  # Also correct.
  ...
