SwiftCov
A tool to generate test code coverage information for Swift.
This project has been entirely obsoleted by the native code coverage generation support available in Swift 2 onwards. It is therefore no longer maintained or supported.
Installation
Install the swiftcov command line tool by running git clone for this repo followed by make install in the root directory.
Usage
$ swiftcov help
Available commands:
generate Generate test code coverage files for your Swift tests
help Display general or command-specific help
version Display the current version of SwiftCov
generate
Run the tests and generate code coverage files. You can write any xcodebuild command as arguments for testing your project.
$ swiftcov generate
Usage: swiftcov generate [swiftcov options] xcodebuild [xcodebuild options] (-- [swift files])
$ swiftcov generate \
xcodebuild test \
-project Example.xcodeproj -scheme 'Example' \
-configuration Release -sdk iphonesimulator
Use the --output parameter to specify a destination directory for the coverage files.
If you think the coverage generation process is slow, you can specify the threshold option. It makes running faster to limit the count of the number of executions.
Currently, the default value of threshold option is 1 for performance reasons. Since some test cases may take a very long time generating coverage data, especially if some code paths are frequently hit (as is the case with loops).
$ swiftcov generate --output ./coverage --threshold 1 \
xcodebuild test \
-project Example.xcodeproj -scheme 'Example' \
-configuration Release -sdk iphonesimulator
Options
-
--output OUTPUT_DIR specify output directory for generated coverage files.
-
--threshold LIMIT_COUNT specify the maximum number of hits you wish to measure. Reducing this number can drastically speed up SwiftCov.
-
--debug Output very verbose progress messages.
-
-- [swift files] Pass a space-separated list of files for which to measure code coverage, with either relative or absolute paths, after the -- at the end of your command.
e.g.
$ swiftcov generate --output ./coverage --threshold 1 \
xcodebuild test \
-project Example.xcodeproj -scheme 'Example' \
-configuration Release -sdk iphonesimulator \
-- ./ExampleFramework/*.swift
help
Display general or command-specific help.
version
Display the current version.
How to run example project
$ make install
$ cd Examples/ExampleFramework/
$ swiftcov generate --output coverage_ios \
xcodebuild test \
-project ExampleFramework.xcodeproj \
-scheme ExampleFramework-iOS \
-sdk iphonesimulator \
-configuration Release
Please see the generated coverage file!
Advanced usage
Convert to HTML output with Gcovr
$ gcovr --root . --use-gcov-files --html --html-details --output coverage.html --keep
See the generated coverage file.
Send coverage information to codecov.io.
Use codecov-bash global uploader.
# cirlce.yml
test:
override:
- sudo chown :wheel /Library/Developer/CoreSimulator/Profiles/Runtimes/iOS\ *.simruntime/Contents/Resources/RuntimeRoot/usr/lib/dyld_sim
- xcodebuild test -project Example.xcodeproj -scheme 'Example' -configuration Release -sdk iphonesimulator
- swiftcov generate --output coverage xcodebuild test -project Example.xcodeproj -scheme 'Example' -configuration Release -sdk iphonesimulator
post:
- bash <(curl -s https://codecov.io/bash)
Send coverage information to coveralls.io.
- realm/SwiftCov | Coveralls - Test Coverage History & Statistics
Use coveralls-gcov.
# Gemfile
source "https://rubygems.org"
gem "coveralls-gcov"
# cirlce.yml
dependencies:
override:
- bundle install
test:
override:
- sudo chown :wheel /Library/Developer/CoreSimulator/Profiles/Runtimes/iOS\ *.simruntime/Contents/Resources/RuntimeRoot/usr/lib/dyld_sim
- xcodebuild test -project Example.xcodeproj -scheme 'Example' -configuration Release -sdk iphonesimulator
- swiftcov generate --output coverage xcodebuild test -project Example.xcodeproj -scheme 'Example' -configuration Release -sdk iphonesimulator
post:
- bundle exec coveralls-gcov --repo-token REPO_TOKEN --no-gcov
How SwiftCov works
SwiftCov traces the execution of your test code using LLDB by following these steps:
- Set breakpoints in all lines of target's source code.
(Those breakpoints only record when they are triggered. They do not stop the tests from running.)
- Run the tests with LLDB attached.
- After the tests have completed, collect the number of times each breakpoint was hit and generate
.gcov files from those results.
Limitations
- Running on iOS devices is not supported (Simulator or OS X only)
- Application projects are not supported (Framework projects only)
- Running on Travis CI is not supported (It works on Circle CI!)
- Debugging SwiftCov is not supported. If you launch SwiftCov from Xcode, it may fail. https://github.com/realm/SwiftCov/issues/6
- Make sure you do not debug for the same target. It may fail since multiple debuggers cannot attach same target.
License
MIT licensed.
