seaweedfs/seaweed-up

seaweed-up

Bootstrap and manage SeaweedFS clusters over SSH.

Install

git clone https://github.com/seaweedfs/seaweed-up.git
cd seaweed-up
go install

Cluster topology

A typical SeaweedFS deployment has three layers, plus an optional monitoring stack. seaweed-up knows how to deploy and operate all of them from a single YAML file.

The admin server, workers, and monitoring stack are not on the data path — restarting them does not interrupt reads or writes. Monitoring is optional; see Monitoring below.

Configuration examples

Two example specs live under examples/:

• examples/minimum.yaml — single-host all-in-one, useful for local smoke tests.
• examples/typical.yaml — production-shaped topology with 3 masters, 3 volume servers, 3 filers (PostgreSQL metadata), 2 S3 gateways, 1 admin, 2 workers, and a co-located Prometheus + Grafana monitoring stack.

Shared config defaults

Cluster-wide values are written once and inherited by each entry, so you don't repeat them per server:

• global.s3_config — the s3.json (IAM identities) every s3_servers entry uses. Define it once under global; the secret lives in one place.
• s3_servers[].filer — defaults to the first filer_servers entry.
• worker_servers[].admin — defaults to the first admin_servers entry.

So a multi-gateway / multi-worker spec is just a list of IPs:

global:
  s3_config:
    identities:
      - name: app
        credentials: [{ accessKey: APP_KEY, secretKey: CHANGE_ME }]
        actions: [Read, Write, List, Tagging]

s3_servers:        # filer + s3_config inherited
  - { ip: 10.0.0.51 }
  - { ip: 10.0.0.52 }

worker_servers:    # admin inherited from admin_servers[0]
  - { ip: 10.0.0.71 }
  - { ip: 10.0.0.72 }

Set any of these per entry to override the default (e.g. point a gateway at a co-located filer, or a worker at a different admin).

Deploy

seaweed-up cluster deploy -f examples/typical.yaml

Deploy only a specific component:

seaweed-up cluster deploy -f cluster.yaml --component=admin
seaweed-up cluster deploy -f cluster.yaml --component=worker

Supported --component values: master, volume, filer, s3, sftp, envoy, admin, worker, monitoring.

Bastion / jump host

When the cluster nodes only have private addresses reachable through a public jump host (the classic ssh bastion then ssh 10.0.0.x pattern), declare the bastion under global.bastion. Every connection — deploy, preflight, lifecycle, upgrade, prepare — is tunnelled through it, so you can run seaweed-up from your laptop:

global:
  bastion:
    host: 203.0.113.10      # public jump host; "host" or "host:port"
    user: chris             # optional, defaults to the current OS user
    identity: ~/.ssh/id_rsa # optional, falls back to the ssh agent
    port: 22                # optional, defaults to 22

The master_servers / volume_servers IPs are then the private addresses as seen from the bastion. The --user / --identity flags still apply to the nodes themselves; the bastion: block holds the jump host's own credentials. Omit the block for direct connections.

SSH host-key verification

By default seaweed-up does not verify SSH host keys. To enforce a real trust boundary (against a man-in-the-middle on the path to the bastion or the nodes), set global.ssh_host_key_check:

global:
  ssh_host_key_check: accept-new   # ignore (default) | accept-new | strict

Rust volume server

A volume server can run the standalone Rust weed-volume binary instead of the Go weed volume. Both register with the same masters, read the same options file, and share the on-disk format, so they coexist in one cluster — set engine per volume server:

volume_servers:
  - ip: 10.0.0.21          # Go weed volume (default)
  - ip: 10.0.0.22
    engine: rust           # standalone weed-volume binary

engine accepts go/weed (default) or rust/weed-volume. For the rust engine, seaweed-up downloads weed-volume_large_disk_linux_<arch>.tar.gz (plus .md5) from the release for --version — the asset published by SeaweedFS's rust_binaries_release.yml. With --enterprise it pulls weed-volume-enterprise_large_disk_linux_<arch>.tar.gz from the artifactory release instead, so the rust engine works for both editions.

• ignore (default) — no verification; preserves historical behavior.
• accept-new — trust-on-first-use: unknown hosts are learned and appended to ~/.ssh/known_hosts, but a host whose key has changed is rejected. Good for first deploys.
• strict — every host (bastion and nodes) must already be in ~/.ssh/known_hosts; anything else is refused.

The policy applies to both the direct node connections and the bastion hop.

Monitoring (Prometheus + Grafana)

Declare a monitoring: block and cluster deploy will stand up the full observability stack as part of the cluster: node_exporter on every master/volume/filer host, Prometheus and Grafana on the monitoring host, the SeaweedFS metrics ports auto-enabled on master/volume/filer, and the bundled SeaweedFS dashboard pre-loaded against a provisioned Prometheus datasource.

monitoring:
  host: 10.0.0.1               # runs Prometheus + Grafana
  bind: 127.0.0.1             # localhost by default — reach Grafana via SSH tunnel
  grafana_admin_user: admin
  grafana_admin_password: CHANGE_ME
  # prometheus_port: 9090     # optional
  # grafana_port: 3000        # optional
  # retention: 15d            # optional Prometheus retention
  # node_exporter: true       # optional (default true)

seaweed-up cluster deploy -f cluster.yaml                 # whole cluster + monitoring
seaweed-up cluster deploy -f cluster.yaml --component=monitoring   # just the stack

With bind: 127.0.0.1 (the default) Grafana isn't exposed publicly — reach it over a tunnel:

ssh -L 3000:localhost:3000 chris@<monitoring-host>   # then open http://localhost:3000

(Grafana binds to 127.0.0.1 on the monitoring host, so the tunnel must terminate there; add -J chris@<bastion> if the host is only reachable through a jump host.)

Monitoring participates in the lifecycle commands too:

seaweed-up cluster restart -f cluster.yaml --component=monitoring

The lower-level building blocks remain available if you run your own Prometheus/Grafana: cluster prometheus-config, cluster node-exporter install, and cluster dashboard install.

Metrics ports are assigned automatically when monitoring is enabled: each master/volume/filer gets one (unique per host, starting at 9324), weed is started with -metricsPort so it serves /metrics, and the scrape config points at the same ports. To pin a specific port — e.g. for fixed firewall rules — set metrics_port: on a master_servers / volume_servers / filer_servers entry; explicit values are kept as-is.

Lifecycle

Start, stop, or restart every service in the cluster, or scope the operation to a single component:

seaweed-up cluster start   -f cluster.yaml
seaweed-up cluster stop    -f cluster.yaml --component=worker
seaweed-up cluster restart -f cluster.yaml --component=admin

Other operations

# Prepare hosts (ulimits, sysctls, firewall, time sync)
seaweed-up cluster prepare -f cluster.yaml

# Check cluster status
seaweed-up cluster status my-cluster

# Rolling upgrade
seaweed-up cluster upgrade my-cluster -f cluster.yaml --version=latest

# Scale out / in
seaweed-up cluster scale out my-cluster --add-volume=2
seaweed-up cluster scale in  my-cluster --remove-node=10.0.0.23

# List and destroy
seaweed-up cluster list
seaweed-up cluster destroy my-cluster --remove-data

Erasure coding

With enough volume servers, enable erasure coding for better durability at lower storage overhead. For example, with 8 volume servers you can run EC 5+3 (5 data + 3 parity shards) and tolerate up to 3 volume server failures at 1.6x overhead, versus 3x for full replication.
