typestack/socket-controllers

socket-controllers

Use class-based controllers to handle websocket events. Helps to organize your code using websockets in classes.

Installation

1. Install socket-controllers:

   npm install socket-controllers


2. Install reflect-metadata shim:

   npm install reflect-metadata


   and make sure to import it in a global place, like app.ts:

   import 'reflect-metadata';


3. Install a DI container, for example typedi;

   npm install typedi


Example of usage

1. Create a file MessageController.ts

   import {
     OnConnect,
     SocketController,
     ConnectedSocket,
     OnDisconnect,
     MessageBody,
     OnMessage,
   } from 'socket-controllers';
   import {Service} from 'typedi'; // Only if you are using typedi

   @SocketController()
   @Service() // Only if you are using typedi
   export class MessageController {
     @OnConnect()
     connection(@ConnectedSocket() socket: any) {
       console.log('client connected');
     }

     @OnDisconnect()
     disconnect(@ConnectedSocket() socket: any) {
       console.log('client disconnected');
     }

     @OnMessage('save')
     save(@ConnectedSocket() socket: any, @MessageBody() message: any) {
       console.log('received message:', message);
       console.log('setting id to the message and sending it back to the client');
       message.id = 1;
       socket.emit('message_saved', message);
     }
   }


2. Create a file app.ts

   import 'es6-shim'; // this shim is optional if you are using old version of node
   import 'reflect-metadata'; // this shim is required
   import { SocketControllers } from 'socket-controllers';
   import { MessageController } from './MessageController';
   import {Container} from 'typedi'; // Only if you are using typedi

   new SocketControllers({
     port: 3001,
     container: Container,
     controllers: [MessageController],
   });


3. Now you can send save websocket message using websocket-client.

More usage examples

Run code on socket client connect / disconnect / disconnecting

Controller action marked with @OnConnect() decorator is called once new client connected. Controller action marked with @OnDisconnect() decorator is called once client disconnected. Controller action marked with @OnDisconnecting() decorator is called when the client is disconnecting, before the disconnect event.

import { SocketController, OnConnect, OnDisconnect, OnDisconnecting } from 'socket-controllers';

@SocketController()
export class MessageController {
  @OnConnect()
  save() {
    console.log('client connected');
  }

  @OnDisconnect()
  save() {
    console.log('client disconnected');
  }

  @OnDisconnecting()
  save() {
    console.log('client is disconnecting');
  }
}

@ConnectedSocket() decorator

To get connected socket instance you need to use @ConnectedSocket() decorator.

import { SocketController, OnMessage, ConnectedSocket } from 'socket-controllers';

@SocketController()
export class MessageController {
  @OnMessage('save')
  save(@ConnectedSocket() socket: any) {
    socket.emit('save_success');
  }
}

@MessageBody() decorator

To get received message body use @MessageBody() decorator:

import { SocketController, OnMessage, MessageBody } from 'socket-controllers';

@SocketController()
export class MessageController {
  @OnMessage('save')
  save(@MessageBody() message: any) {
    console.log('received message: ', message);
  }
}

If you specify a class type to parameter that is decorated with @MessageBody(), socket-controllers will use class-transformer to create instance of the given class type with the data received in the message. To disable this behaviour you need to specify { transformOption: { transform: false ] } in SocketControllerOptions when creating a server.

You can define an index to get multiple parameters from the socket event.

import { SocketController, OnMessage, MessageBody } from 'socket-controllers';

@SocketController()
export class MessageController {
  @OnMessage('save')
  save(@MessageBody({index: 0}) param1: any, @MessageBody({index: 1}) param2: any) {
    console.log('received message: ', message1);
    console.log('received message: ', message2);
  }
}

@MessageAck() decorator

To get received message ack use @MessageAck() decorator:

import { SocketController, OnMessage, MessageAck, MessageBody } from 'socket-controllers';

@SocketController()
export class MessageController {
  @OnMessage('save')
  save(@MessageBody() message: any, @MessageAck() ack: Function) {
    console.log('received message: ', message);
    ack('callback message');
  }
}

note: ack must be the last parameter in emit, otherwise it will be null

@SocketQueryParam() decorator

To get received query parameter use @SocketQueryParam() decorator.

import { SocketController, OnMessage, MessageBody } from 'socket-controllers';

@SocketController()
export class MessageController {
  @OnMessage('save')
  save(@SocketQueryParam('token') token: string) {
    console.log('authorization token from query parameter: ', token);
  }
}

Get socket client id using @SocketId() decorator

To get connected client id use @SocketId() decorator.

import { SocketController, OnMessage, MessageBody } from 'socket-controllers';

@SocketController()
export class MessageController {
  @OnMessage('save')
  save(@SocketId() id: string) {}
}

Get access to using socket.io instance using @SocketIO() decorator

import { SocketController, OnMessage, MessageBody } from 'socket-controllers';

@SocketController()
export class MessageController {
  @OnMessage('save')
  save(@SocketIO() io: any) {
    // now you can broadcast messages to specific rooms or namespaces using io instance
  }
}

Send message back to client after method execution

You can use @EmitOnSuccess decorator:

import { SocketController, OnMessage, EmitOnSuccess } from 'socket-controllers';

@SocketController()
export class MessageController {
  @OnMessage('save')
  @EmitOnSuccess('save_successfully')
  save() {
    // after this controller executed "save_successfully" message will be emitted back to the client
  }
}

If you return something, it will be returned in the emitted message data:

import { SocketController, OnMessage, EmitOnSuccess } from 'socket-controllers';

@SocketController()
export class MessageController {
  @OnMessage('save')
  @EmitOnSuccess('save_successfully')
  save() {
    // after this controller executed "save_successfully" message will be emitted back to the client with message object
    return {
      id: 1,
      text: 'new message',
    };
  }
}

You can also control what message will be emitted if there is error/exception during execution:

import { SocketController, OnMessage, EmitOnSuccess, EmitOnFail } from 'socket-controllers';

@SocketController()
export class MessageController {
  @OnMessage('save')
  @EmitOnSuccess('save_successfully')
  @EmitOnFail('save_error_range', {errorType: RangeError})
  @EmitOnFail('save_error_type', {errorType: TypeError})
  @EmitOnFail('save_error')
  save() {
    if (1 === 1) {
      throw new Error('One is equal to one! Fatal error!');
    }
    return {
      id: 1,
      text: 'new message',
    };
  }
}

In this case save_error message will be sent to the client with One is equal to one! Fatal error! error message. The order is important when defining multiple @EmitOnFail() decorators, the first matching errorType will be served

Sometimes you may want to not emit success/error message if returned result is null or undefined. In such cases you can use @SkipEmitOnEmptyResult() decorator.

import { SocketController, OnMessage, EmitOnSuccess, EmitOnFail, SkipEmitOnEmptyResult } from 'socket-controllers';

@SocketController()
export class MessageController {
  @OnMessage('get')
  @EmitOnSuccess('get_success')
  @SkipEmitOnEmptyResult()
  get(): Promise<Message[]> {
    return this.messageRepository.findAll();
  }
}

In this case if findAll will return undefined, get_success message will not be emitted. If findAll will return array of messages, they will be emitted back to the client in the get_success message. This example also demonstrates Promises support. If promise returned by controller action, message will be emitted only after promise will be resolved.

Using exist server instead of creating a new one

If you need to create and configure socket.io server manually, you can pass it to the SocketControllers constructor. Here is example of creating socket.io server and configuring it with express:

import 'reflect-metadata'; // this shim is required
import { SocketControllers } from 'socket-controllers';
import { Server } from 'socket.io';
import { Container } from 'typedi'; // Only if you are using typedi

const app = require('express')();
const server = require('http').Server(app);
const io = new Server(server);

server.listen(3001);

app.get('/', function (req: any, res: any) {
  res.send('hello express');
});

io.use((socket: any, next: Function) => {
  console.log('Custom middleware');
  next();
});
new SocketControllers({io, container: Container});

Load all controllers from the given directory

You can load all controllers in once from specific directories, by specifying array of directories via options in createSocketServer or useSocketServer:

import 'reflect-metadata'; // this shim is required
import { SocketControllers } from 'socket-controllers';
import { Container } from 'typedi'; // Only if you are using typedi

new SocketControllers({
  port: 3000,
  container: Container,
  controllers: [__dirname + '/controllers/*.js'],
}); // registers all given controllers

Using socket.io namespaces

To listen to messages only of the specific namespace you can mark a controller with namespace:

@SocketController('/messages')
export class MessageController {
  // ...
}

Also you can use dynamic namespace, like express router patterns:

@SocketController('/messages/:userId')
export class MessageController {
  // ...
}

Using middlewares

Middlewares are the functions passed to the socketIo.use method. Middlewares allows you to define a logic that will be executed each time client connected to the server. To create your middlewares use @Middleware decorator:

import { Middleware, MiddlewareInterface } from 'socket-controllers';

@Middleware()
export class CompressionMiddleware implements MiddlewareInterface {
  use(socket: any, next: (err?: any) => any) {
    console.log('do something, for example get authorization token and check authorization');
    next();
  }
}

You can limit middlewares to namespaces providing either a string, RegExp or Array<string | RegExp> to the namespace parameter:

import { Middleware, MiddlewareInterface } from 'socket-controllers';

@Middleware({namespace: '/test'})
export class CompressionMiddleware implements MiddlewareInterface {
  use(socket: any, next: (err?: any) => any) {
    console.log('do something, for example get authorization token and check authorization');
    next();
  }
}

Don't forget to load your controllers and middlewares

Controllers and middlewares should be loaded:

import 'reflect-metadata';
import { SocketControllers } from 'socket-controllers';
import { MessageController } from './MessageController';
import { MyMiddleware } from './MyMiddleware'; // here we import it
import { Container } from 'typedi'; // Only if you are using typedi
const server = new SocketControllers({
  port: 3000,
  container: Container,
  controllers: [MessageController],
  middlewares: [MyMiddleware],
});

Also you can load them from directories. Also you can use glob patterns:

import 'reflect-metadata';
import { SocketControllers } from 'socket-controllers';
import { Container } from 'typedi'; // Only if you are using typedi
const server = new SocketControllers({
   port: 3000,
   container: Container,
   controllers: [__dirname + '/controllers/**/*.js'],
   middlewares: [__dirname + '/middlewares/**/*.js'],
});

Using DI container

socket-controllers supports a DI container out of the box. You can inject your services into your controllers and middlewares. Container must be setup during application bootstrap. Here is example how to integrate socket-controllers with typedi:

import 'reflect-metadata';
import { SocketControllers } from 'socket-controllers';
import { Container } from 'typedi';

// create and run socket server
const server = new SocketControllers({
  port: 3000,
  container: Container,
  controllers: [__dirname + '/controllers/*.js'],
  middlewares: [__dirname + '/middlewares/*.js'],
});

That's it, now you can inject your services into your controllers:

@Service()
@SocketController()
export class MessageController {
  constructor(private messageRepository: MessageRepository) {}

  // ... controller actions
}

Note: TypeDI won't create instances for unknown classes since 0.9.0, you have to decorate your Class as a Service() as well.

Scoped controllers

You can enable scoped controllers by providing a scopedContainerGetter function in SocketServerOptions. This function should return a new container that will be used to instantiate the controller and its dependencies.

You will get a new instance for each event in the controller.

The scopedContainerGetter function receives the SocketEventContext.

The scopedContainerDisposer function receives the container instance you created with scopedContainerGetter after the socket action is finished. Use this function to dispose the container if needed.

import 'reflect-metadata';
import { SocketControllers, SocketEventContext } from 'socket-controllers';
import { Container, ContainerInstance, Token } from "typedi";

const myDiToken = new Token();

// create and run socket server
const server = new SocketControllers({
   port: 3000,
   container: Container,
   scopedContainerGetter: (args: SocketEventContext) => {
      const container = Container.of(YOUR_REQUEST_CONTEXT);
      container.set(myDiToken, 'MY_VALUE');
      return container;
   },
   scopedContainerDisposer: (container: ContainerInstance) => {
     container.dispose();
   },
   controllers: [__dirname + '/controllers/*.js'],
   middlewares: [__dirname + '/middlewares/*.js'],
});

Interceptors

Interceptors allow you to wrap your event handlers in higher order functions. With interceptors you can add logging or modify the incoming or outgoing data for event handlers.

import {
   SocketController,
   OnMessage,
   EmitOnSuccess,
   EmitOnFail,
   SkipEmitOnEmptyResult,
   UseInterceptor,
   MessageBody
} from 'socket-controllers';

const interceptor: InterceptorInterface = {
   use: (ctx: SocketEventContext, next: () => any) => {
     ctx.messageArgs[0] = 'modified message from controller - ' + ctx.messageArgs[0];
     const resp = next();
     return 'modified response from controller - ' + resp; // modified response from controller - modified response from method - reponse
   },
};

@Service()
class Interceptor implements InterceptorInterface {
   async use(ctx: SocketEventContext, next: () => any) {
     ctx.messageArgs[0] = 'modified message from method - ' + ctx.messageArgs[0];
     const resp = await next();
     return 'modified response from method - ' + resp; // modified response from method - reponse
   }
}

@SocketController()
@UseInterceptor(interceptor)
export class MessageController {
   @OnMessage('get')
   @EmitOnSuccess('get_success')
   @SkipEmitOnEmptyResult()
   @UseInterceptor(Interceptor)
   get(@MessageBody() message: string): Promise<Message[]> {
     console.log(message); // modified message from controller - modified message from method - original message
     return 'response';
   }
}

Interceptors are executed in order of definition, starting with the controller interceptors.

Decorators Reference

Samples

Take a look on samples in ./sample for more examples of usage.

Related projects

• If you are interested to create controller-based express or koa server use routing-controllers module.
• If you need to use dependency injection in use typedi module.
