wasabeef/Takt

Takt is Android library for measuring the FPS using Choreographer.

Screenshot

How do I use it?

Setup

Dependencies

repositories {
  mavenCentral()
}

dependencies {
  releaseImplementation 'jp.wasabeef:takt-no-op:2.1.1'
  debugImplementation 'jp.wasabeef:takt:2.1.1'
}

Functions

There is a simple initialization step which occurs in your Application class:
Simple

class MyApplication : Application() {
  override fun onCreate() {
    super.onCreate()
    Takt.stock(this)
  }
}

Options

• seat(Seat seat) is a position
• interval(int ms) is a interval
• color(int color) is a text color.
• size(int size) is a text size
• alpha(float alpha) is a text alpha
• listener(Audience audience) is a Listener
• useCustomControl to manually start/stop Takt (disabled by default)
• showOverlaySetting to enable/disable showing system overlay setting (enabled by default)

Takt.stock(this)
  .seat(Seat.BOTTOM_RIGHT)
  .interval(250)
  .color(Color.WHITE)
  .size(14f)
  .alpha(.5f)
  .listener { fps ->
    Log.d("Excellent!", fps.toString() + " fps")

    // Logcat
    // jp.wasabeef.example.takt D/Excellent!﹕ 59.28853754940712 fps
    // jp.wasabeef.example.takt D/Excellent!﹕ 59.523809523809526 fps
    // jp.wasabeef.example.takt D/Excellent!﹕ 59.05511811023622 fps
    // jp.wasabeef.example.takt D/Excellent!﹕ 55.33596837944664 fps
    // jp.wasabeef.example.takt D/Excellent!﹕ 59.523809523809526 fps
  }

Position

Takt.stock(this)
  .seat(Seat.RIGHT_CENTER)

  /**
   * TOP_RIGHT,
   * TOP_LEFT,
   * TOP_CENTER,
   *
   * CENTER,
   * RIGHT_CENTER,
   * LEFT_CENTER,
   *
   * BOTTOM_RIGHT,
   * BOTTOM_LEFT,
   * BOTTOM_CENTER
   */

Hide fps label

Takt.stock(this)
  .hide()
  .listener { fps -> Log.d("Excellent!", fps.toString() + " fps") }

Requirements

Android 4.1+ (using the Choreographer)

Developed By

Daichi Furiya (Wasabeef) - [email protected]
