Xilinx/embeddedsw

embeddedsw.git - repo for standalone software

The standalone software is divided into following directories: - lib contains bsp, software apps and software services - license.txt contains information about the various licenses and copyrights - doc/ChangeLog Contains change log information for releases - XilinxProcessorIPLib/drivers contains all drivers - ThirdParty software from third party like light weight IP stack - mcap/linux software for using MCAP interface on Ultra Scale boards to program 2nd level bitstream

Every driver, sw_apps and sw_services has one or more of these sub-directories:

1. data - contains tcl, mdd, testapp tcl or header files used in Vitis
2. doc - documentation of source code in form of pdf or html
3. examples - illustrating different use cases of driver
4. src - driver interface code implementing functionality of IP

|-LICENSES | |-ThirdParty | |- bsp | |- freertos10_xilinx | |- data |- examples | |- src | |- License | |- Source | |- sw_services | |- libmetal | |- lwip141 | |- lwip202 | |- openamp | |-XilinxProcessorIPLib | |- drivers | |- avbuf | |- ... | |- ... | |- zdma | |-doc |-lib | |- bsp | |- standalone | |- data | |- doc | |- src | |- arm | |- common | |- ARMv8 | |- cortexa9 | |- cortexr5 | |- common | |- microblaze | |- profile | |- sw_apps | |- ddr_self_refresh | |- .... | |- .... | |- .... | |- .... | |- zynqmp_fsbl [described below] | |- zynqmp_pmufw [described below] | |- versal_plm [described below] | |- versal_psmfw [described below] | |- sw_services | |- xilffs | |- xilflash | |- xilfpga | |- xilisf | |- xilmfs | |- xilpm | |- xilrsa | |- xilsecure | |- xilskey | | Note - All these are libraries and utilize drivers | |-mcap | |-linux

Building FSBL from git:

FSBL(zynq_fsbl/zynqmp_fsbl) has 3 directories. 1. data - It contains files for Vitis 2. src - It contains the FSBL source files 3. misc - It contains miscellaneous files required to compile FSBL. For zynq (zynq_fsbl), builds for zc702, zc706, zed are supported. It also contains the ps7_init_gpl.[c/h] with gpl header in respective board directories. For zynqmp (zynqmp_fsbl), builds for zcu102,zcu102-es2 board are supported.

How to compile FSBL: Zynq: Please refer to the steps in Readme.txt which is at lib/sw_apps/zynq_fsbl/misc/ directory

ZynqMP
Please refer to the steps in Readme.txt which is at lib/sw_apps/zynqmp_fsbl/misc/ directory

Building PMUFW from git:

Please refer to the steps in Readme.txt which is at lib/sw_apps/zynqmp_pmufw/misc/ directory

Building Versal PLM from git:

Please refer to the steps in Readme.txt which is at lib/sw_apps/versal_plm/misc/ directory

Building Versal PSMFW from git:

Please refer to the steps in Readme.txt which is at lib/sw_apps/versal_psmfw/misc/ directory
