exyte/Chat



Chat

A SwiftUI Chat UI framework with fully customizable message cells and a built-in media picker

Features

• Displays your messages with pagination and allows you to create and "send" new messages (sending means calling a closure since user will be the one providing actual API calls)

• Allows you to pass a custom view builder for messages and input views

• Has a built-in photo and video library/camera picker for multiple media asset selection

• Sticker keyboard that integrates with Giphy

• Can display a fullscreen menu on long press a message cell (automatically shows scroll for big messages)

• Supports reply, edit, and delete via the message menu

• This library allows to send the following content in messages in any combination:

  • Arbitrarily styled text with AttributedString or markdown
  • Photo/video
  • Audio recording
  • Link with preview
  • Gif/Sticker
  • Custom dictionary of any Sendable

  Coming soon:

  • User's location
  • Documents

Migration to version 3

• enableLoadMore(pageSize...) renamed enableLoadMore(offset...) and its trailing closure doesn't have any arguments
• linkPreviewsDisabled refactored linkPreviewsEnabled
• shouldShowLinkPreview renamed shouldShowPreviewForLink
• messageUseMarkdown and messageUseStyler removed. now messages use markdown and underline links by default. if you'd like to use your own attributes, use Message's init taking AttributedString. storing AttributedString directly instead of storing a string and applying attributes on-the-fly is more efficient.
• The closure arguments of messageBuilder and inputViewBuilder now each consist of a single struct (they are different structs). See ChatBuilderParameters.swift

Usage

Create a chat view like this:

@State var messages: [Message] = []

var body: some View {
    ChatView(messages: messages) { draft in
        yourViewModel.send(draft: draft)
    }
}

where:
messages - list of messages to display
didSendMessage - a closure which is called when the user presses the send button

Message is a type that Chat uses for the internal implementation. In the code above it expects the user to provide a list of Message structs, and it returns a DraftMessage in the didSendMessage closure. You can map it both ways to your own Message model that your API expects or use as is.

Message stores the text in an AttributedString. You can pass your own AttributedString or a simple String, in which case Message's init will apply default attributes: markdown and links underlines.

Available chat types

Chat type - determines the order of messages and direction of new message animation. Available options:

• conversation - the latest message is at the bottom, new messages appear from the bottom
• comments - the latest message is at the top, new messages appear from the top

Reply mode - determines how replying to message looks. Available options:

• quote - when replying to message A, new message will appear as the newest message, quoting message A in its body
• answer - when replying to message A, new message with appear directly below message A as a separate cell without duplicating message A in its body

To specify any of these pass them through init:

ChatView(messages: viewModel.messages, chatType: .comments, replyMode: .answer) { draft in
    yourViewModel.send(draft: draft)
}

Custom UI

You may customize message cells like this:

ChatView(messages: viewModel.messages) { draft in
    viewModel.send(draft: draft)
} messageBuilder: { params in
    let message = params.message
    VStack {
        Text(message.attributedText)
        if !message.attachments.isEmpty {
            ForEach(message.attachments, id: \.id) { at in
                AsyncImage(url: at.thumbnail)
            }
        }
    }
}

To customize only some messages while keeping the default style for others, use messageBuilder and return your custom view for the messages you want to style, and params.defaultMessageView() for the rest. This way you can mix custom message cards with ExyteChat's built-in styling in the same chat.

ChatView(messages: viewModel.messages) { draft in
    viewModel.send(draft: draft)
} messageBuilder: { params in
    if needsCustomUI(params.message) {
        MyCustomMessageView(message: params.message)
    } else {
        params.defaultMessageView()
    }
}

Here params is a MessageBuilderParameters struct, it has the following parameters:

• message - the message containing user info, attachments, etc.
• positionInUserGroup - the position of the message in its continuous collection of messages from the same user
• positionInMessagesSection position of message in the section of messages from that day
• positionInCommentsGroup - position of message in its continuous group of comments (only works for .answer ReplyMode, nil for .quote mode)
• showContextMenuClosure - closure to show message context menu
• messageActionClosure - closure to pass user interaction, .reply for example
• showAttachmentClosure - you can pass an attachment to this closure to use ChatView's fullscreen media viewer

You may customize the input view (a text field with buttons at the bottom) like this:

ChatView(messages: viewModel.messages) { draft in
    viewModel.send(draft: draft)
} inputViewBuilder: { params in
    let action = params.inputViewActionClosure
    Group {
        switch params.inputViewStyle {
        case .message: // input view on chat screen
            VStack {
                HStack {
                    Button("Send") { action(.send) }
                    Button("Attach") { action(.photo) }
                }
                TextField("Write your message", text: params.text)
            }
        case .signature: // input view on photo selection screen
            VStack {
                HStack {
                    Button("Send") { action(.send) }
                }
                TextField("Compose a signature for photo", text: params.text)
                    .background(Color.green)
            }
        }
    }
}

Here params is an InputViewBuilderParameters struct, it has the following parameters:

• textBinding to bind your own TextField
• attachments is a struct containing photos, videos, recordings and a message you are replying to
• inputViewState - the state of the input view that is controlled by the library automatically if possible or through your calls of inputViewActionClosure
• inputViewStyle - .message or .signature (the chat screen or the photo selection screen)
• inputViewActionClosure for calling on taps on your custom buttons. For example, call inputViewActionClosure(.send) if you want to send your message with your own button, then the library will reset the text and attachments and call the didSendMessage sending closure
• dismissKeyboardClosure - call this to dismiss keyboard

Custom message menu

Long tap on a message will display a menu for this message (can be turned off, see Modifiers). To define custom message menu actions declare an enum conforming to MessageMenuAction. Then the library will show your custom menu options on long tap on message instead of default ones, if you pass your enum's name to it (see code sample). Once the action is selected special callback will be called. Here is a simple example:

enum Action: MessageMenuAction {
    case reply, edit, delete

    func title() -> String {
        switch self {
        case .reply:
            "Reply"
        case .edit:
            "Edit"
        case .delete:
            "Delete"
        }
    }

    func icon() -> Image {
        switch self {
        case .reply:
            Image(systemName: "arrowshape.turn.up.left")
        case .edit:
            Image(systemName: "square.and.pencil")
        case .delete:
            Image(systemName: "trash")
        }
    }

    // Optional
    // Return true to show a confirmation alert before calling your messageMenuAction closure.
    // The action will be styled in red in the menu.
    func isDestructive() -> Bool { self == .delete }

    // Optional
    // Implement this method to conditionally include menu actions on a per message basis
    // The default behavior is to include all menu action items
    static func menuItems(for message: ExyteChat.Message) -> [Action] {
        message.user.isCurrentUser ? [.reply, .edit, .delete] : [.reply]
    }
}

ChatView(messages: viewModel.messages) { draft in
    viewModel.send(draft: draft)
} messageMenuAction: { (action: Action, defaultActionClosure, message) in // <-- here: specify the name of your `MessageMenuAction` enum
    switch action {
    case .reply:
        defaultActionClosure(message, .reply)
    case .edit:
        defaultActionClosure(message, .edit { editedText in
            // update this message's text on your BE
            print(editedText)
        })
    case .delete:
        yourViewModel.delete(message: message)
    }
}

messageMenuAction's parameters:

• selectedMenuAction - action selected by the user from the menu. NOTE: when declaring this variable, specify its type (your custom descendant of MessageMenuAction) explicitly
• defaultActionClosure - a closure taking a case of default implementation of MessageMenuAction which provides simple actions handlers; you call this closure passing the selected message and choosing one of the default actions (.copy, .reply, .edit, .share) if you need them; or you can write a custom implementation for all your actions, in that case just ignore this closure
• message - message for which the menu is displayed

When implementing your own MessageMenuActionClosure, write a switch statement passing through all the cases of your MessageMenuAction, inside each case write your own action handler, or call the default one. NOTE: not all default actions work out of the box - e.g. for .edit you'll still need to provide a closure to save the edited text on your BE. Please see CommentsExampleView in ChatExample project for MessageMenuActionClosure usage example.

Small view builders:

These use AnyView, so please try to keep them easy enough

• mainHeaderBuilder - a header for the whole chat, which will scroll together with all the messages and headers
• headerBuilder - date section header builder
• betweenListAndInputViewBuilder - content to display in between the chat list view and the input view

Modifiers

isListAboveInputView - messages table above the input field view or not
showScrollToBottomButton - little arrow button appearing when offset != 0
showNetworkConnectionProblem - display network error on/off
showDateHeaders - show section headers with dates between days, default is true
isScrollEnabled - forbid scrolling for messages' UITableView
keyboardDismissMode - set keyboard dismiss mode for the chat list (.interactive, .onDrag, or .none), default is .none
autoFocusTextInputOnChatOpen - automatically focus the inputTextView when the chat view is opened, default is false showMessageMenuOnLongPress - turn menu on long tap on/off
showShareAttachmentButton - show/hide the share button in the fullscreen attachment viewer, default is true
messageMenuAnimationDuration - control how fast/snappy the message menu animations feel
contentInsets - set additional content insets for the messages list
onContentOffsetChange - get table's content offset updates
scrollTo - scroll to messageID, certain pixels offset, top or bottom onWillDisplayCell - UITableView's will display cell delegate calls this closure
enableLoadMore(offset: Int = 0, _ handler: @escaping ()->()) - when user scrolls up to offset-th message from the end, call the handler function, so user can load more messages
localization - can be localized in the Localizable.strings files

Update transactions

updateTransaction - awaitable updates helper similar in usage to tableView.performBatchUpdates

await updateTransaction(animationMode: .natural) {
    self.messages.append(nextMessage)
    self.currentTableContentOffset = offset
}

available modes are:

• none - no animations
• natural - standard UITableView's animations
• keepStable - no animations + if you insert rows to the "front" of the table - it keeps the current scroll position (normally it would jump because contentSize and contentOffset changed)

Delete action (default menu)

If you use the default message menu (no custom MessageMenuAction enum), you can add a "Delete" button with a confirmation alert using:

ChatView(messages: viewModel.messages) { draft in
    viewModel.send(draft: draft)
}
.deleteMenuActionClosure(activeFor: { $0.user.isCurrentUser }) { message in
    yourViewModel.delete(message: message)
}

• activeFor - optional predicate; when provided, the Delete button only appears for messages where it returns true
• The closure is called only after the user confirms the alert

If you define your own MessageMenuAction enum with a .delete case marked isDestructive(), use that instead — the confirmation alert is handled automatically there too.

Reactions

messageReactionDelegate - provide a custom reaction delegate for handling and configuring message reactions
onMessageReaction - configure reactions using closures (didReactTo, canReactTo, available reactions, emoji search, overview, etc.)

Custom swipe actions

// Example: Adding Swipe Actions to your ChatView
ChatView(messages: viewModel.messages) { draft in
    viewModel.send(draft: draft)
}
.swipeActions(edge: .leading, performsFirstActionWithFullSwipe: false, items: [
    // SwipeActions are similar to Buttons, they accept an Action and a ViewBuilder
    SwipeAction(action: onDelete, activeFor: { $0.user.isCurrentUser }, background: .red) {
        swipeActionButtonStandard(title: "Delete", image: "xmark.bin")
    },
    // Set the background color of a SwipeAction in the initializer,
    // instead of trying to apply a background color in your ViewBuilder
    SwipeAction(action: onReply, background: .blue) {
        swipeActionButtonStandard(title: "Reply", image: "arrowshape.turn.up.left")
    },
    // SwipeActions can also be selectively shown based on the message,
    // here we only show the Edit action when the message is from the current sender
    SwipeAction(action: onEdit, activeFor: { $0.user.isCurrentUser }, background: .gray) {
        swipeActionButtonStandard(title: "Edit", image: "bubble.and.pencil")
    }
])

swipeActions's parameters:

• edge - either the leading or trailing edge of the Message
• performsFirstActionWithFullSwipe - if true, a full swipe will trigger the first SwipeAction provided in the items list
• items - list of SwipeActions to include

makes sense only for built-in message view

showMessageTimeView - show timestamp in a corner of the message
showUsername - show username on top of message messageLinkPreviewLimit - limit the maximum number of link previews per message
linkPreviewsEnabled - enable or disable message link previews globally
shouldShowPreviewForLink - provide custom logic to decide whether a specific URL should show a preview
setMessageFont - pass custom font to use for messages

showAvatar - show user avatars
avatarSize - the default avatar is a circle, you can specify its diameter here
tapAvatarClosure - closure to call on avatar tap
avatarBuilder - custom avatar view builder. NOTE: this view is not autosizing, avatarSize will still be applied, since it needs to be fixed and same for all user avatars

makes sense only for built-in input view

inputViewText - binding to current text in the default input text field
setAvailableInputs - construct an array of these:
- .text
- .media
- .audio
- .giphy
setRecorderSettings - customize audio recorder settings
audioRecordingMode - choose how audio recording is triggered:
- .holdToRecord (default) - hold the mic button to record; slide up to lock into hands-free mode
- .tapToToggle - tap the mic button once to start recording, tap the stop button to finish. No lock capsule
assetsPickerLimit - set a limit for MediaPicker built into the library
setMediaPickerSelectionParameters - a struct holding MediaPicker selection parameters (selection limit, media type, selection style, etc.)
setMediaPickerParameters - configure low-level MediaPicker parameters
orientationHandler - handle screen rotation during media picking
photoPickerBackend - choose which photo/video picker is presented when the user taps to attach media:
- .custom (default) - ExyteMediaPicker fully customizable built-in media picker
- .system - Apple's native PhotosPicker for apps that don't need a customized picker UI. Selected items are shown as a removable thumbnail strip above the input field, and camera capture always uses the ExyteMediaPicker regardless of this setting.

The attach button on the left opens a popup menu to choose between Media and GIF when both are available via setAvailableInputs. If photoPickerBackend is .system, a separate Camera entry is also added to the menu, since Apple's native PhotosPicker can't capture photos/video itself; with the default .custom backend, camera capture is reachable from within the media picker itself, so no separate entry is needed. If there's only one attachment option in total, tapping the button triggers it directly with no popup. The right side of the input field shows a clear ("x") button to quickly clear typed text once the field is non-empty.

Customize default colors and images

You can use chatTheme to customize colors and images of default UI. You can pass all/some colors and images:

.chatTheme(
    ChatTheme(
        colors: .init(
            mainBackground: .red,
            buttonBackground: .yellow,
            addButtonBackground: .purple
        ),
        images: .init(
            camera: Image(systemName: "camera")
        )
    )
)

// chat view with a full background image
.chatTheme(
    ChatTheme(
        colors: .init(
            buttonBackground: .yellow,
            addButtonBackground: .purple
        ),
        images: .init(
            background: ChatTheme.Images.Background(
                portraitBackgroundLight: Image("chatBackgroundLight"),
                portraitBackgroundDark: Image("chatBackgroundDark"),
                landscapeBackgroundLight: Image("chatBackgroundLandscapeLight"),
                landscapeBackgroundDark: Image("chatBackgroundLandscapeDark")
            )
    )
)

By default the built-in MediaPicker will be auto-customized using the most logical colors from chatTheme. But you can always use mediaPickerTheme in a similar fashion to set your own colors.

Large Attachment Support

The library provides full support for uploading multiple attachments larger than 100 MB and for reporting upload status on both the sender’s and receiver’s message views. It offers flexibility in how much progress tracking functionality the client implements, allowing developers to omit percentage-based updates if desired. Sending percentage updates to the receiver requires careful handling, as it involves multiple WebSocket calls to synchronize status between sender and receiver.

Option 1

No status is passed to an Attachment. This is the default behavior and shows no progress indicators. If the full attachment is uploaded to a resource server before the message is sent to the receiver, use this method, as it is the simplest and requires no progress tracking.

Attachment(
  fullUploadStatus: Attachment.UploadStatus? = nil
)

Option 2

A progress indicator is displayed without a percentage. Most chat applications handle multiple large (100 MB+) files, which may take several minutes to upload. In these cases, Option 1 results in a poor user experience because the receiver has no indication that the files are being uploaded. Option 2 allows both the sender and receiver to see a generic progress indicator during the upload.

Attachment(
  fullUploadStatus: Attachment.UploadStatus? = Attachment.UploadStatus.inProgress(nil)
)

Option 3:

A progress indicator is displayed with a percentage. This option provides the best user experience, as it shows the progress of the upload. However, it adds implementation complexity: both the sender and receiver must remain synchronized through multiple WebSocket updates (e.g., 10%, 20%, …). For production-quality chat applications, implementing this option is recommended.

Attachment(
  fullUploadStatus: Attachment.UploadStatus? = Attachment.UploadStatus.inProgress(0)
)

When implementing status updates via Option 2/3 the following status updates need to be handled by the client:

// When the upload completes, send a final message to stop displaying the progress indicator.
let completeUpload = Attachment(fullUploadStatus: Attachment.UploadStatus.complete)
sendToServer(initialProgress)

// If the user cancels an attachment upload, report this to the receiver.
let cancelUpload = Attachment(fullUploadStatus: Attachment.UploadStatus.cancelled)
sendToServer(cancelUpload)

// If the upload to the resource server fails, send an error status to the receiver.
let errorUpload = Attachment(fullUploadStatus: Attachment.UploadStatus.error)
sendToServer(errorUpload)

Attachment Sharing

Users can share attachments out of the chat via the system share sheet. There are two entry points:

• Fullscreen media viewer - tapping an image/video attachment opens the fullscreen viewer, which shows a share button that shares the currently displayed attachment. Toggle it with showShareAttachmentButton (see Modifiers), default is true.
• Message context menu - long tap on a message shows a Share action (DefaultMessageMenuAction.share) whenever the message has at least one attachment that finished uploading. Selecting it shares all of that message's attachments together in a single share sheet. This action is only included for DefaultMessageMenuAction; if you supply your own MessageMenuAction enum (see Custom message menu) you decide whether to include a share action.

Remote attachments (non-file:// URLs) are downloaded to a temporary file before sharing so that actions like Save Image/Video and AirDrop work with real file data instead of just a link.

Sticker Keyboard

You can pick and send animated gifs via the integrated sticker keyboard. In order to use this functionality a client id must be granted via the Giphy Developers site.

To include the sticker keyboard:

.setAvailableInputs([.text, .giphy])
.giphyConfig(
    GiphyConfiguration(
        giphyKey: "client id",
        mediaTypeConfig: [.recents, .gifs, .stickers, .clips],
        showAttributionMark: true
    )
)

To approve a production client Id for your app, Giphy requires that you include a "Powered By GIPHY" attribution mark, see attribution mark requirement. Setting the showAttributionMark in the GiphyConfiguration struct will include a small overlay image on the giphy picker which meets the requirement needed for a production client key.

Localization

You can localize the inputs using the standard SwiftUI localization process, add the input strings to each languages Localizable.strings file.
The library uses the following text that can be localized:

• Type a message...
• Add signature...
• Cancel
• Recents
• Waiting for network
• Recording...
• Reply to

Image Caching with Cache Keys

The Chat framework uses Kingfisher for efficient image caching. You can provide custom cache keys. By default, the cache key is the URL of the image.

User Avatar Cache Keys

When creating a User, you can specify a custom cache key for the avatar image:

let user = User(
    id: "user123",
    name: "John Doe",
    avatarURL: URL(string: "https://example.com/avatar.jpg"),
    avatarCacheKey: "user_avatar_123", // Custom cache key
    isCurrentUser: false
)

Attachment Cache Keys

For Attachment objects, you can specify separate cache keys for thumbnail and full-size images:

let attachment = Attachment(
    id: "attachment456",
    thumbnail: URL(string: "https://example.com/thumb.jpg"),
    full: URL(string: "https://example.com/full.jpg"),
    type: .image,
    thumbnailCacheKey: "thumb_456", // Cache key for thumbnail
    fullCacheKey: "full_456"        // Cache key for full image
)

Examples

There are 2 example projects:

• One has a simple bot posting random text/media messages every 2 seconds. It has no back end and no local storage. Every new start is clean and fresh.
• Another has an integration with Firestore data base. It has all the necessary back end support, including storing media and audio messages, unread messages counters, etc. You'll have to create your own Firestore app and DB. Also replace GoogleService-Info with your own. After that you can test on multiple sims/devices.

To set up the Firestore example:

1. Create your Firebase app at https://console.firebase.google.com/
2. Create a Firestore database (for lightweight text data) - see https://firebase.google.com/docs/firestore/manage-data/add-data
3. Create a Cloud Storage bucket (for images and voice recordings) - see https://firebase.google.com/docs/storage/web/start

Running the Examples

To try the Chat examples:

• Clone the repo https://github.com/exyte/Chat.git
• Open ChatExample.xcodeproj or ChatFirestoreExample.xcodeproj in Xcode
• Try it!

Installation

Swift Package Manager

dependencies: [
    .package(url: "https://github.com/exyte/Chat.git")
]

Requirements

• iOS 17+
• Xcode 15+

Our other open source SwiftUI libraries

PopupView - Toasts and popups library
AnchoredPopup - Anchored Popup grows "out" of a trigger view (similar to Hero animation)
Grid - The most powerful Grid container
ScalingHeaderScrollView - A scroll view with a sticky header which shrinks as you scroll
AnimatedTabBar - A tabbar with a number of preset animations
MediaPicker - Customizable media picker
CalendarView - Calendar view with fully customizable month/day cells
OpenAI Wrapper lib for OpenAI REST API
AnimatedGradient - Animated linear gradient
ConcentricOnboarding - Animated onboarding flow
FloatingButton - Floating button menu
ActivityIndicatorView - A number of animated loading indicators
ProgressIndicatorView - A number of animated progress indicators
FlagAndCountryCode - Phone codes and flags for every country
SVGView - SVG parser
LiquidSwipe - Liquid navigation animation
