florent37/DiagonalLayout

DiagonalLayout

With Diagonal Layout explore new styles and approaches on material design

Usage

<com.github.florent37.diagonallayout.DiagonalLayout
        android:layout_width="match_parent"
        android:layout_height="250dp"
        diagonal:diagonal_angle="10"
        diagonal:diagonal_position="left / right / top / bottom"
        diagonal:diagonal_direction="left / right"
        android:elevation="10dp"
        >

        <!-- YOUR CONTENT -->

</com.github.florent37.diagonallayout.DiagonalLayout>

Sample

Bottom

<com.github.florent37.diagonallayout.DiagonalLayout
        android:layout_width="match_parent"
        android:layout_height="250dp"
        android:elevation="10dp"
        app:diagonal_angle="20"
        diagonal:diagonal_direction="left"
        diagonal:diagonal_position="bottom">

        <ImageView
            android:layout_width="match_parent"
            android:layout_height="match_parent"
            android:scaleType="centerCrop"
            android:src="@drawable/mountains" />

</com.github.florent37.diagonallayout.DiagonalLayout>

Top

<com.github.florent37.diagonallayout.DiagonalLayout
        android:layout_width="match_parent"
        android:layout_height="250dp"
        android:elevation="10dp"
        app:diagonal_angle="20"
        app:diagonal_position="top"
        app:diagonal_direction="right">

        <ImageView
            android:layout_width="match_parent"
            android:layout_height="match_parent"
            android:scaleType="centerCrop"
            android:src="@drawable/mountains" />

</com.github.florent37.diagonallayout.DiagonalLayout>

Position / Direction

Elevation

Do not forget to add elevation with android:elevation="**dp"

KenBurns

Using https://github.com/flavioarfaria/KenBurnsView

<com.github.florent37.diagonallayout.DiagonalLayout
        android:id="@+id/diagonalLayout"
        android:layout_width="match_parent"
        android:layout_height="250dp"
        diagonal:diagonal_angle="10"
        diagonal:diagonal_position="left"
        android:elevation="30dp"
        >

        <com.flaviofaria.kenburnsview.KenBurnsView
            android:layout_width="match_parent"
            android:layout_height="match_parent"
            android:scaleType="centerCrop"
            android:src="@drawable/background"
            />

        ...

</com.github.florent37.diagonallayout.DiagonalLayout>

Inspirations

Exploration of some new styles and approaches on material design. This one here is a user profile for Hollywood personas

https://material.uplabs.com/posts/user-profile-concept

Download

In your module

compile 'com.github.florent37:diagonallayout:1.0.9'

Logs

1.0.1

• Added Elevation

1.0.2

• Can setup the diagonal on top or bottom
• Fixed angle calculation
• Added flag attributes top|bottom|left|right

1.0.3

Thanks to ZieIony

• Changed clipping method
• Changed shadow casting method
• Removed unnecessary content layout
• added support for padding

1.0.4

• Removed :gravity
• Added :position & direction

Credits

Author: Florent Champigny Blog : http://www.tutos-android-france.com/

Fiches Plateau Moto : https://www.fiches-plateau-moto.fr/

License

Copyright 2016 florent37, Inc.

Licensed under the Apache License, Version 2.0 (the "License");
you may not use this file except in compliance with the License.
You may obtain a copy of the License at

   http://www.apache.org/licenses/LICENSE-2.0

Unless required by applicable law or agreed to in writing, software
distributed under the License is distributed on an "AS IS" BASIS,
WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
See the License for the specific language governing permissions and
limitations under the License.
