openwrt/asu

Attended Sysupgrade Server

This project simplifies the sysupgrade process for upgrading the firmware of devices running OpenWrt or distributions based on it. These tools offer an easy way to reflash the router with a new firmware version (including all packages) without the need to use opkg.

ASU is based on an API to request custom firmware images with any selection of packages pre-installed. This avoids the need to set up a build environment, and makes it possible to create a custom firmware image even using a mobile device.

Clients of the Sysupgrade Server

OpenWrt Firmware Selector

Simple web interface using vanilla JavaScript currently developed by @mwarning. It offers a device search based on model names and shows links either to official images or requests images via the asu API. Please join in the development at the GitHub repository.

• https://firmware-selector.openwrt.org

LuCI app

The package luci-app-attendedsysupgrade offers a simple tool under System > Attended Sysupgrade. It requests a new firmware image that includes the current set of packages, waits until it's built and flashes it. If "Keep Configuration" is checked in the GUI, the device upgrades to the new firmware without any need to re-enter any configuration or re-install any packages.

CLI

With OpenWrt SNAPSHOT-r26792 or newer (and in the 24.10 release) the CLI app auc was replaced with owut as a more comprehensive CLI tool to provide an easy way to upgrade your device.

Server

The server listens for image requests and, if valid, automatically generates them. It coordinates several OpenWrt ImageBuilders and caches the resulting images in a Redis database. If an image is cached, the server can provide it immediately without rebuilding.

Active servers

[!NOTE] Official server using ImageBuilder published on OpenWrt Downloads.

• sysupgrade.openwrt.org

[!NOTE] Unofficial servers, may run modified ImageBuilder

• ImmortalWrt
• LibreMesh
• sysupgrade.guerra24.net
• sysupgrade.antennine.org
• Create a pull request to add your server here

Run your own server

For security reasons each build happens inside a container so that one build can't affect another. A Podman socket is used so workers can execute builds inside containers.

Installation

The server uses podman-compose to manage the containers. On a Debian based system, install the following packages:

sudo apt install podman-compose

A Python library is used to communicate with Podman over a socket. Symlink the socket into the project directory:

ln -sf /run/user/$(id -u)/podman/podman.sock podman.sock

If the Podman socket is not running, enable it:

systemctl --user enable --now podman.socket

Create the isolated network for build containers (no access to Redis or other services):

podman network create asu-build

Copy the example configuration and adjust as needed:

cp asu.example.toml asu.toml

Now you can either use the latest ASU containers or build them yourself:

# use existing containers
podman-compose pull

# build containers locally
podman-compose build

Start all services:

podman-compose up -d

This will start the server, a Redis instance and one worker. Once running, the API is available at http://localhost:8000. Modify podman-compose.yml to change the port.

Optional: caching proxy

To cache upstream package downloads between builds, enable the nginx caching proxy:

podman-compose -f podman-compose.yml -f podman-compose.cache.yml up -d

Set cache_url = "http://cache" in asu.toml to route build container package downloads through the cache.

Production

For production it's recommended to use a reverse proxy like nginx or caddy. You can find a Caddy sample configuration in misc/Caddyfile.

If you want your server to remain active after you log out, enable "linger":

loginctl enable-linger

System requirements

• 2 GB RAM (4 GB recommended)
• 2 CPU cores (4 cores recommended)
• 50 GB disk space (200 GB recommended)

Development

After cloning this repository, install uv which manages the Python dependencies.

# Install uv
curl -LsSf https://astral.sh/uv/install.sh | sh

# Install dependencies
uv sync --extra dev

Running Redis

podman run -d --name redis -p 6379:6379 redis:alpine

Running the server

uv run fastapi dev asu/main.py

Running a worker

uv run rq worker

API

The API is documented via OpenAPI and can be viewed interactively on the server:

• https://sysupgrade.openwrt.org/docs/
• https://sysupgrade.openwrt.org/redoc
