alexellis/firecracker-init-lab

firecracker-init-lab

Build a microVM from a container image

Many of the examples you'll find are broken due to changes in Firecracker 1.0 - the official quickstart guide doesn't cover the most interesting thing - working Internet access - or extracting a filesystem from a container. This lab extends the official quickstart so that you can explore what an init process does, and add networking.

Pre-reqs

• A bare-metal Linux host - where can you get bare metal?
• Or a VM that supports nested virtualisation such as on DigitalOcean or GCP.
• Docker installed

Browse:

• Go init process
• Makefile
• boot.sh - commands to start MicroVM
• setup-networking.sh - configure a tap adapter, IP forwarding and IP masquerading
• Dockerfile - for building the root filesystem

Usage

Download and install Firecracker to /usr/local/bin/

Or, alternatively, Arkade can do this for you with:

curl -SLs https://get.arkade.dev | sudo sh
sudo arkade system install firecracker

Edit the IFNAME in setup-networking.sh to match your host's network interface.

Then run the script to create the ftap0 device, and to setup IP masquerading with iptables:

./setup-networking.sh

Download the quickstart Kernel:

make kernel

Check the Kernel is the correct architecture:

file ./vmlinux

If you don't have the file utility, you can add it with sudo apt install -qy file

Make the init process binary, and package it into a container, extract the container into a rootfs image:

make all

In one terminal, start firecracker:

make start

In another, instruct it to boot the rootsfs and Kernel:

make boot

Play around in the first terminal and explore the system:

free -m
cat /proc/cpuinfo
ip addr
ip route

ping -c1 1.1.1.1

echo "nameserver 1.1.1.1" > /etc/resolv.conf
ping -c 4 google.com

apk add --no-cache curl

curl -i https://inlets.dev

Expose a TCP or HTTP service to the Internet

Once you've got something interesting running like a HTTP server, or an SSHD daemon, you can then get ingress from the public Internet using an inlets tunnel. Inlets is a static binary, and there are a couple of simple tutorials you can follow depending on what you want to expose.

• HTTPS tunnel with Let's Encrypt
• TCP tunnel for SSH, reverse proxy etc

Running on a Raspberry Pi

Edit Makefile, and change arch to aarch64

export arch="x86_64"

Snapshot and restore

There is experimental support for snapshot and restore in Firecracker. You will not be able to snapshot on an Intel host and restore on an AMD one, and different generations of CPUs may also be incompatible for snapshot and restore.

You can read more about the current status of snapshot and restore in the Firecracker docs

Run the lab and boot the VM as per the instructions above.

Now, verify the network is up with ping -c 1 172.16.0.2

make pause
make snapshot

Kill the Firecracker process, and then restore the snapshot:

make start

In another terminal, restore the snapshot:

make restore
make resume

Run ./setup-networking.sh again and verify the network is up with ping -c 1 172.16.0.2.
