AlamofireNetworkActivityIndicator
Controls the visibility of the network activity indicator on iOS using Alamofire.
Features
Requirements
- iOS 10.0+
- Xcode 11+
- Swift 5.1+
Dependencies
Communication
- If you need help, use Stack Overflow. (Tag 'alamofire')
- If you'd like to ask a general question, use Stack Overflow.
- If you found a bug, open an issue.
- If you have a feature request, open an issue.
- If you want to contribute, submit a pull request.
Installation
CocoaPods
CocoaPods is a dependency manager for Cocoa projects. For usage and installation instructions, visit their website. To integrate Alamofire into your Xcode project using CocoaPods, specify it in your Podfile:
pod 'AlamofireNetworkActivityIndicator', '~> 3.1'
Carthage
Carthage is a decentralized dependency manager that builds your dependencies and provides you with binary frameworks. To integrate Alamofire into your Xcode project using Carthage, specify it in your Cartfile:
github "Alamofire/AlamofireNetworkActivityIndicator" ~> 3.1
Swift Package Manager (requires Xcode 11)
- Select File > Swift Packages > Add Package Dependency. Enter
https://github.com/Alamofire/AlamofireNetworkActivityIndicator in the "Choose Package Repository" dialog.
- In the next page, specify the version resolving rule as "Up to Next Major" with "3.1.0" as its earliest version.
- After Xcode checking out the source and resolving the version, you can choose the "AlamofireNetworkActivityIndicator" library and add it to your app target.
Manually
If you prefer not to use either of the aforementioned dependency managers, you can integrate AlamofireNetworkActivityIndicator into your project manually.
Embedded Framework
- Open up Terminal,
cd into your top-level project directory, and run the following command "if" your project is not initialized as a git repository:
$ git init
- Add AlamofireNetworkActivityIndicator as a git submodule by running the following command:
$ git submodule add https://github.com/Alamofire/AlamofireNetworkActivityIndicator.git
-
Open the new AlamofireNetworkActivityIndicator folder, and drag the AlamofireNetworkActivityIndicator.xcodeproj into the Project Navigator of your application's Xcode project.
It should appear nested underneath your application's blue project icon. Whether it is above or below all the other Xcode groups does not matter.
-
Select the AlamofireNetworkActivityIndicator.xcodeproj in the Project Navigator and verify the deployment target matches that of your application target.
-
Next, select your application project in the Project Navigator (blue project icon) to navigate to the target configuration window and select the application target under the "Targets" heading in the sidebar.
-
In the tab bar at the top of that window, open the "General" panel.
-
Click on the + button under the "Embedded Binaries" section.
-
You will see two different AlamofireNetworkActivityIndicator.xcodeproj folders each with two different versions of the AlamofireNetworkActivityIndicator.framework nested inside a Products folder.
It does not matter which Products folder you choose from.
-
Select the AlamofireNetworkActivityIndicator.framework and add it to your project.
-
And that's it!
The AlamofireNetworkActivityIndicator.framework is automagically added as a target dependency, linked framework and embedded framework in a copy files build phase which is all you need to build on the simulator and a device.
Usage
The NetworkActivityIndicatorManager manages the state of the network activity indicator. To begin using it, all that is required is to enable the shared instance in application:didFinishLaunchingWithOptions: in your AppDelegate.
NetworkActivityIndicatorManager.shared.isEnabled = true
By enabling the shared manager for the system, the network activity indicator will show and hide automatically as Alamofire requests start and complete.
Notifications
The NetworkActivityIndicatorManager manages the currently active network request count by observing notifications emitted from Alamofire. By observing the task state changes, the shared manager always knows how many requests are currently active and updates the visibility of the activity indicator accordingly.
It is possible to have the shared manager observe URLSession instances not inside Alamofire. You will need to emit matching notifications from the URLSessionDelegate matching those found in Alamofire.
Delay Timers
In order to make the activity indicator experience for a user as pleasant as possible, there need to be start and stop delays added in to avoid flickering. There are two such delay timers built into the shared manager.
Start Delay
The start delay is a time interval indicating the minimum duration of networking activity that should occur before the activity indicator is displayed. This helps avoid needlessly displaying the indicator for really fast network requests. The default value is 1.0 second. You can easily change the default value if needed.
NetworkActivityIndicatorManager.shared.startDelay = 1.0
Completion Delay
The completion delay is a time interval indicating the duration of time that no networking activity should be observed before dismissing the activity indicator. This allows the activity indicator to be continuously displayed between multiple network requests. Without this delay, the activity indicator tends to flicker. The default value is 0.2 seconds. You can easily change the default value if needed.
NetworkActivityIndicatorManager.shared.completionDelay = 0.2
FAQ
Why is this not in Alamofire?
In order to allow Alamofire to continue to be used in App Extensions, this logic could not be included in the Alamofire framework. In order to submit an App Extension to the App Store, it can only be linked against frameworks that specify they only use App Extension safe APIs. Since we want users to be able to use Alamofire in App Extensions, we MUST set the Require Only App Extension Safe APIs to true. Because of this, we cannot call non-safe App Extension APIs in the Alamofire framework. Controlling the activity indicator on iOS is done through non-safe App Extension APIs. Because of this, a separate library needed to be created.
But what about availability you say? Doesn't help in this case because availability checks still compile all the code. We could not use #if os(iOS) either because you cannot compile out logic specifically for iOS, but not for an iOS App Extension.
Credits
Alamofire is owned and maintained by the Alamofire Software Foundation. You can follow them on Twitter at @AlamofireSF for project updates and releases.
Donations
The ASF is looking to raise money to officially stay registered as a federal non-profit organization.
Registering will allow us members to gain some legal protections and also allow us to put donations to use, tax free.
Donating to the ASF will enable us to:
- Pay our yearly legal fees to keep the non-profit in good status
- Pay for our mail servers to help us stay on top of all questions and security issues
- Potentially fund test servers to make it easier for us to test the edge cases
- Potentially fund developers to work on one of our projects full-time
The community adoption of the ASF libraries has been amazing.
We are greatly humbled by your enthusiasm around the projects, and want to continue to do everything we can to move the needle forward.
With your continued support, the ASF will be able to improve its reach and also provide better legal safety for the core members.
If you use any of our libraries for work, see if your employers would be interested in donating.
Any amount you can donate today to help us reach our goal would be greatly appreciated.
License
AlamofireNetworkActivityIndicator is released under the MIT license. See LICENSE for details.
