cisagov/cset

What is CSET?

The Cybersecurity Infrastructure Security Agency (CISA) and the Idaho National Laboratory (INL) develop the Cyber Security Evaluation Tool (CSET®) for asset owners with the primary objective of reducing the risk to the nation’s critical infrastructure. Control systems are defined as electronic devices that control physical processes and as such, are a crucial element in the protection of our nation’s infrastructure.

CSET is a free software tool that guides users through a step-by-step process to collect facility-specific information addressing topics such as hardware, software, administrative policies, and user obligations. It then compares that information to relevant security standards and regulations, assesses overall compliance, and provides appropriate recommendations for improving cybersecurity posture. The tool pulls its recommendations from a collection of the best available cybersecurity standards, guidelines, and practices. Where appropriate, recommendations are linked to a set of actions that can be applied to enhance cybersecurity controls.

CSET provides the following:

• A framework for analyzing cybersecurity vulnerabilities associated with an organization’s overall industrial control system (ICS) and information technology (IT) architecture.

• A consistent and technically sound methodology to identify, analyze, and communicate to security professionals the various vulnerabilities and consequences that may be exploited by cyber means.

• The means for the user to document a process for identifying cybersecurity vulnerabilities.

• Suggested methods to evaluate options for improvement based on existing standards and recommended practices.

View the CSET Overview and CSET Detailed Video to learn more about CSET and how to use the software.

Local installers ("standalone") are available as well as binaries for creating enterprise installations.

How to Install and Run CSET/Enterprise

CSET Enterprise only runs on Windows. The standalone installer and enterprise deployment both require Windows operating systems (Windows 10 or higher for local installations, Windows Server 2016 or higher for enterprise deployments).

For Mac and Linux users, Docker is the recommended approach. See the Running CSET with Docker section below for instructions.

CSET operates on Windows laptops or desktop computers and can also be configured for a client-server architecture.

For more information, see the CSET Installation Options.

System Requirements

Running CSET with Docker

For Mac, Linux, or Windows users who prefer Docker, follow the steps below:

• Clone this repository
• (Recommended) Install Task:
  • Mac: brew install go-task
  • Windows: choco install go-task or winget install Task.Task
  • Linux: sh -c "$(curl --location https://taskfile.dev/install.sh)" -- -d -b /usr/local/bin
• Install Docker Desktop
  • Important: Update the Docker Desktop resource settings and allocate a minimum of 5 GB of memory
• Copy over environment variables from the distribution file:
  • cp .env.example .env
• Run CSET
  • docker compose up -d
• (Optional) Override default host ports by setting environment variables before running compose (or updating .env):
  • WEB_PORT (defaults to 4200 for the Angular UI)
  • WEB_TLS_PORT (defaults to 443 for HTTPS on the UI container)
  • API_PORT (defaults to 5000 for the ASP.NET API)
  • Example: WEB_PORT=4300 API_PORT=5100 docker compose up -d
• Load Database using bak files
  • task load-bak

For an editable development environment with live reload of both the API and Angular UI, you can use the compose.dev.yml file:

docker compose -f compose.dev.yml up or task up:dev

System Requirements for Enterprise Installation

It is recommended that users meet the minimum system hardware and software requirements prior to installing CSET. This includes:

• Pentium dual core 2.2 GHz processor (Intel x86 compatible) • 8 GB free disk space • 4 GB of RAM • Microsoft Windows Server 2016 Edition or higher recommended • Microsoft .NET 10 Runtime • Microsoft ASP.NET Core 7 Runtime • Microsoft SQL Server 2022 or higher recommended • Internet Information Server (IIS) or Kestrel

Other Items of Note: • For all platforms, it is recommended the user upgrade to the latest Windows Service Pack and install critical updates available from the Windows Update web site to ensure the best compatibility and security.

Download

CSET Releases

Questions and Feedback

If you have questions about using CSET, please contact [email protected].

For additional information about CISA, see https://www.cisa.gov/.

To ask questions or request help, propose a feature or module, or report a bug, security vulnerability or unexpected behavior, add a new issue here: https://github.com/cisagov/cset/issues

License

MIT License, Apache License 2.0

Copyright 2018 Battelle Energy Alliance, LLC

See License.txt, and NOTICE.txt

Contact information of authors: [email protected]

Idaho National Laboratory: P.O. Box 1625, MS 3870, Idaho Falls, ID 83415

CISA - NGL Stop 0630 Cybersecurity and Infrastructure Security Agency:

1110 N. Glebe Road Arlington, VA 20598-0630

CISAgov Youtube channel

Includes software licensed under LGPL

LGPL dependencies are required to build CSET. You will be required to acquire them via nuGet in order to build this software. They are not distributed with this source.
