d3-sankey

Sankey diagrams visualize the directed flow between nodes in an acyclic network. For example, this diagram shows a possible scenario of UK energy production and consumption in 2050:

Source: Department of Energy & Climate Change, Tom Counsell.

For an interactive editor, see Flow-o-Matic.

Installing

If you use NPM, npm install d3-sankey. Otherwise, download the latest release. You can also load directly from unpkg.com. AMD, CommonJS, and vanilla environments are supported. In vanilla, a d3 global is exported:

<script src="https://unpkg.com/d3-array@1"></script>
<script src="https://unpkg.com/d3-collection@1"></script>
<script src="https://unpkg.com/d3-path@1"></script>
<script src="https://unpkg.com/d3-shape@1"></script>
<script src="https://unpkg.com/d3-sankey@0"></script>
<script>

var sankey = d3.sankey();

</script>

API Reference

# d3.sankey() <>

Constructs a new Sankey generator with the default settings.

# sankey(arguments…) <>

Computes the node and link positions for the given arguments, returning a graph representing the Sankey layout. The returned graph has the following properties:

• graph.nodes - the array of nodes
• graph.links - the array of links

# sankey.update(graph) <>

Recomputes the specified graph’s links’ positions, updating the following properties of each link:

• link.y0 - the link’s vertical starting position (at source node)
• link.y1 - the link’s vertical end position (at target node)

This method is intended to be called after computing the initial Sankey layout, for example when the diagram is repositioned interactively.

# sankey.nodes([nodes]) <>

If nodes is specified, sets the Sankey generator’s nodes accessor to the specified function or array and returns this Sankey generator. If nodes is not specified, returns the current nodes accessor, which defaults to:

function nodes(graph) {
  return graph.nodes;
}

If nodes is specified as a function, the function is invoked when the Sankey layout is generated, being passed any arguments passed to the Sankey generator. This function must return an array of nodes. If nodes is not a function, it must be a constant array of nodes.

Each node must be an object. The following properties are assigned by the Sankey generator:

• node.sourceLinks - the array of outgoing links which have this node as their source
• node.targetLinks - the array of incoming links which have this node as their target
• node.value - the node’s value; this is the sum of link.value for the node’s incoming links, or node.fixedValue if defined
• node.index - the node’s zero-based index within the array of nodes
• node.depth - the node’s zero-based graph depth, derived from the graph topology
• node.height - the node’s zero-based graph height, derived from the graph topology
• node.layer - the node’s zero-based column index, corresponding to its horizontal position
• node.x0 - the node’s minimum horizontal position, derived from node.depth
• node.x1 - the node’s maximum horizontal position (node.x0 + sankey.nodeWidth)
• node.y0 - the node’s minimum vertical position
• node.y1 - the node’s maximum vertical position (node.y1 - node.y0 is proportional to node.value)

See also sankey.links.

# sankey.links([links]) <>

If links is specified, sets the Sankey generator’s links accessor to the specified function or array and returns this Sankey generator. If links is not specified, returns the current links accessor, which defaults to:

function links(graph) {
  return graph.links;
}

If links is specified as a function, the function is invoked when the Sankey layout is generated, being passed any arguments passed to the Sankey generator. This function must return an array of links. If links is not a function, it must be a constant array of links.

Each link must be an object with the following properties:

• link.source - the link’s source node
• link.target - the link’s target node
• link.value - the link’s numeric value

For convenience, a link’s source and target may be initialized using numeric or string identifiers rather than object references; see sankey.nodeId. The following properties are assigned to each link by the Sankey generator:

• link.y0 - the link’s vertical starting position (at source node)
• link.y1 - the link’s vertical end position (at target node)
• link.width - the link’s width (proportional to link.value)
• link.index - the zero-based index of link within the array of links

# sankey.linkSort([sort]) <>

If sort is specified, sets the link sort method and returns this Sankey generator. If sort is not specified, returns the current link sort method, which defaults to undefined, indicating that vertical order of links within each node will be determined automatically by the layout. If sort is null, the order is fixed by the input. Otherwise, the specified sort function determines the order; the function is passed two links, and must return a value less than 0 if the first link should be above the second, and a value greater than 0 if the second link should be above the first, or 0 if the order is not specified.

# sankey.nodeId([id]) <>

If id is specified, sets the node id accessor to the specified function and returns this Sankey generator. If id is not specified, returns the current node id accessor, which defaults to the numeric node.index:

function id(d) {
  return d.index;
}

The default id accessor allows each link’s source and target to be specified as a zero-based index into the nodes array. For example:

var nodes = [
  {"id": "Alice"},
  {"id": "Bob"},
  {"id": "Carol"}
];

var links = [
  {"source": 0, "target": 1}, // Alice → Bob
  {"source": 1, "target": 2} // Bob → Carol
];

Now consider a different id accessor that returns a string:

function id(d) {
  return d.id;
}

With this accessor, you can use named sources and targets:

var nodes = [
  {"id": "Alice"},
  {"id": "Bob"},
  {"id": "Carol"}
];

var links = [
  {"source": "Alice", "target": "Bob"},
  {"source": "Bob", "target": "Carol"}
];

This is particularly useful when representing graphs in JSON, as JSON does not allow references. See this example.

# sankey.nodeAlign([align]) <>

If align is specified, sets the node alignment method to the specified function and returns this Sankey generator. If align is not specified, returns the current node alignment method, which defaults to d3.sankeyJustify. The specified function is evaluated for each input node in order, being passed the current node and the total depth n of the graph (one plus the maximum node.depth), and must return an integer between 0 and n - 1 that indicates the desired horizontal position of the node in the generated Sankey diagram.

# sankey.nodeSort([sort]) <>

If sort is specified, sets the node sort method and returns this Sankey generator. If sort is not specified, returns the current node sort method, which defaults to undefined, indicating that vertical order of nodes within each column will be determined automatically by the layout. If sort is null, the order is fixed by the input. Otherwise, the specified sort function determines the order; the function is passed two nodes, and must return a value less than 0 if the first node should be above the second, and a value greater than 0 if the second node should be above the first, or 0 if the order is not specified.

# sankey.nodeWidth([width]) <>

If width is specified, sets the node width to the specified number and returns this Sankey generator. If width is not specified, returns the current node width, which defaults to 24.

# sankey.nodePadding([padding]) <>

If padding is specified, sets the vertical separation between nodes at each column to the specified number and returns this Sankey generator. If padding is not specified, returns the current node padding, which defaults to 8.

# sankey.extent([extent]) <>

If extent is specified, sets the extent of the Sankey layout to the specified bounds and returns the layout. The extent bounds are specified as an array [[x0, y0], [x1, y1]], where x0 is the left side of the extent, y0 is the top, x1 is the right and y1 is the bottom. If extent is not specified, returns the current extent which defaults to [[0, 0], [1, 1]].

# sankey.size([size]) <>

An alias for sankey.extent where the minimum x and y of the extent are ⟨0,0⟩. Equivalent to:

sankey.extent([[0, 0], size]);

# sankey.iterations([iterations]) <>

If iterations is specified, sets the number of relaxation iterations when generating the layout and returns this Sankey generator. If iterations is not specified, returns the current number of relaxation iterations, which defaults to 6.

Alignments

See sankey.nodeAlign.

# d3.sankeyLeft(node, n) <>

Returns node.depth.

# d3.sankeyRight(node, n) <>

Returns n - 1 - node.height.

# d3.sankeyCenter(node, n) <>

Like d3.sankeyLeft, except that nodes without any incoming links are moved as right as possible.

# d3.sankeyJustify(node, n) <>

Like d3.sankeyLeft, except that nodes without any outgoing links are moved to the far right.

Links

# d3.sankeyLinkHorizontal() <>

Returns a horizontal link shape suitable for a Sankey diagram. The source accessor is defined as:

function source(d) {
  return [d.source.x1, d.y0];
}

The target accessor is defined as:

function target(d) {
  return [d.target.x0, d.y1];
}

For example, to render the links of a Sankey diagram in SVG, you might say:

svg.append("g")
    .attr("fill", "none")
    .attr("stroke", "#000")
    .attr("stroke-opacity", 0.2)
  .selectAll("path")
  .data(graph.links)
  .join("path")
    .attr("d", d3.sankeyLinkHorizontal())
    .attr("stroke-width", function(d) { return d.width; });
