LeRobot: State-of-the-art AI for real-world robotics

---

🤗 LeRobot aims to provide models, datasets, and tools for real-world robotics in PyTorch. The goal is to lower the barrier to entry to robotics so that everyone can contribute and benefit from sharing datasets and pretrained models.

🤗 LeRobot contains state-of-the-art approaches that have been shown to transfer to the real-world with a focus on imitation learning and reinforcement learning.

🤗 LeRobot already provides a set of pretrained models, datasets with human collected demonstrations, and simulation environments to get started without assembling a robot. In the coming weeks, the plan is to add more and more support for real-world robotics on the most affordable and capable robots out there.

🤗 LeRobot hosts pretrained models and datasets on this Hugging Face community page: huggingface.co/lerobot

Examples of pretrained models on simulation environments

Installation

LeRobot works with Python 3.10+ and PyTorch 2.2+.

Environment Setup

Create a virtual environment with Python 3.10 and activate it, e.g. with miniconda:

conda create -y -n lerobot python=3.10
conda activate lerobot

When using miniconda, install ffmpeg in your environment:

conda install ffmpeg -c conda-forge

NOTE: This usually installs ffmpeg 7.X for your platform compiled with the libsvtav1 encoder. If libsvtav1 is not supported (check supported encoders with ffmpeg -encoders), you can:

• [On any platform] Explicitly install ffmpeg 7.X using:

conda install ffmpeg=7.1.1 -c conda-forge

• [On Linux only] Install ffmpeg build dependencies and compile ffmpeg from source with libsvtav1, and make sure you use the corresponding ffmpeg binary to your install with which ffmpeg.

Install LeRobot 🤗

From Source

First, clone the repository and navigate into the directory:

git clone https://github.com/huggingface/lerobot.git
cd lerobot

Then, install the library in editable mode. This is useful if you plan to contribute to the code.

pip install -e .

NOTE: If you encounter build errors, you may need to install additional dependencies (cmake, build-essential, and ffmpeg libs). On Linux, run: sudo apt-get install cmake build-essential python3-dev pkg-config libavformat-dev libavcodec-dev libavdevice-dev libavutil-dev libswscale-dev libswresample-dev libavfilter-dev. For other systems, see: Compiling PyAV

For simulations, 🤗 LeRobot comes with gymnasium environments that can be installed as extras:

• aloha
• xarm
• pusht

For instance, to install 🤗 LeRobot with aloha and pusht, use:

pip install -e ".[aloha, pusht]"

Installation from PyPI

Core Library: Install the base package with:

pip install lerobot

This installs only the default dependencies.

Extra Features: To install additional functionality, use one of the following:

pip install 'lerobot[all]'          # All available features
pip install 'lerobot[aloha,pusht]'  # Specific features (Aloha & Pusht)
pip install 'lerobot[feetech]'      # Feetech motor support

Replace [...] with your desired features.

Available Tags: For a full list of optional dependencies, see: https://pypi.org/project/lerobot/

Weights & Biases

To use Weights and Biases for experiment tracking, log in with

wandb login

(note: you will also need to enable WandB in the configuration. See below.)

Visualize datasets

Check out example 1 that illustrates how to use our dataset class which automatically downloads data from the Hugging Face hub.

You can also locally visualize episodes from a dataset on the hub by executing our script from the command line:

lerobot-dataset-viz \
    --repo-id lerobot/pusht \
    --episode-index 0

or from a dataset in a local folder with the root option and the --local-files-only (in the following case the dataset will be searched for in ./my_local_data_dir/lerobot/pusht)

lerobot-dataset-viz \
    --repo-id lerobot/pusht \
    --root ./my_local_data_dir \
    --local-files-only 1 \
    --episode-index 0

It will open rerun.io and display the camera streams, robot states and actions, like this:

https://github-production-user-asset-6210df.s3.amazonaws.com/4681518/328035972-fd46b787-b532-47e2-bb6f-fd536a55a7ed.mov?X-Amz-Algorithm=AWS4-HMAC-SHA256&X-Amz-Credential=AKIAVCODYLSA53PQK4ZA%2F20240505%2Fus-east-1%2Fs3%2Faws4_request&X-Amz-Date=20240505T172924Z&X-Amz-Expires=300&X-Amz-Signature=d680b26c532eeaf80740f08af3320d22ad0b8a4e4da1bcc4f33142c15b509eda&X-Amz-SignedHeaders=host&actor_id=24889239&key_id=0&repo_id=748713144

Our script can also visualize datasets stored on a distant server. See lerobot-dataset-viz --help for more instructions.

The LeRobotDataset format

A dataset in LeRobotDataset format is very simple to use. It can be loaded from a repository on the Hugging Face hub or a local folder simply with e.g. dataset = LeRobotDataset("lerobot/aloha_static_coffee") and can be indexed into like any Hugging Face and PyTorch dataset. For instance dataset[0] will retrieve a single temporal frame from the dataset containing observation(s) and an action as PyTorch tensors ready to be fed to a model.

A specificity of LeRobotDataset is that, rather than retrieving a single frame by its index, we can retrieve several frames based on their temporal relationship with the indexed frame, by setting delta_timestamps to a list of relative times with respect to the indexed frame. For example, with delta_timestamps = {"observation.image": [-1, -0.5, -0.2, 0]} one can retrieve, for a given index, 4 frames: 3 "previous" frames 1 second, 0.5 seconds, and 0.2 seconds before the indexed frame, and the indexed frame itself (corresponding to the 0 entry). See example 1_load_lerobot_dataset.py for more details on delta_timestamps.

Under the hood, the LeRobotDataset format makes use of several ways to serialize data which can be useful to understand if you plan to work more closely with this format. We tried to make a flexible yet simple dataset format that would cover most type of features and specificities present in reinforcement learning and robotics, in simulation and in real-world, with a focus on cameras and robot states but easily extended to other types of sensory inputs as long as they can be represented by a tensor.

Here are the important details and internal structure organization of a typical LeRobotDataset instantiated with dataset = LeRobotDataset("lerobot/aloha_static_coffee"). The exact features will change from dataset to dataset but not the main aspects:

dataset attributes:
  ├ hf_dataset: a Hugging Face dataset (backed by Arrow/parquet). Typical features example:
  │  ├ observation.images.cam_high (VideoFrame):
  │  │   VideoFrame = {'path': path to a mp4 video, 'timestamp' (float32): timestamp in the video}
  │  ├ observation.state (list of float32): position of an arm joints (for instance)
  │  ... (more observations)
  │  ├ action (list of float32): goal position of an arm joints (for instance)
  │  ├ episode_index (int64): index of the episode for this sample
  │  ├ frame_index (int64): index of the frame for this sample in the episode ; starts at 0 for each episode
  │  ├ timestamp (float32): timestamp in the episode
  │  ├ next.done (bool): indicates the end of an episode ; True for the last frame in each episode
  │  └ index (int64): general index in the whole dataset
  ├ meta: a LeRobotDatasetMetadata object containing:
  │  ├ info: a dictionary of metadata on the dataset
  │  │  ├ codebase_version (str): this is to keep track of the codebase version the dataset was created with
  │  │  ├ fps (int): frame per second the dataset is recorded/synchronized to
  │  │  ├ features (dict): all features contained in the dataset with their shapes and types
  │  │  ├ total_episodes (int): total number of episodes in the dataset
  │  │  ├ total_frames (int): total number of frames in the dataset
  │  │  ├ robot_type (str): robot type used for recording
  │  │  ├ data_path (str): formattable string for the parquet files
  │  │  └ video_path (str): formattable string for the video files (if using videos)
  │  ├ episodes: a DataFrame containing episode metadata with columns:
  │  │  ├ episode_index (int): index of the episode
  │  │  ├ tasks (list): list of tasks for this episode
  │  │  ├ length (int): number of frames in this episode
  │  │  ├ dataset_from_index (int): start index of this episode in the dataset
  │  │  └ dataset_to_index (int): end index of this episode in the dataset
  │  ├ stats: a dictionary of statistics (max, mean, min, std) for each feature in the dataset, for instance
  │  │  ├ observation.images.front_cam: {'max': tensor with same number of dimensions (e.g. `(c, 1, 1)` for images, `(c,)` for states), etc.}
  │  │  └ ...
  │  └ tasks: a DataFrame containing task information with task names as index and task_index as values
  ├ root (Path): local directory where the dataset is stored
  ├ image_transforms (Callable): optional image transformations to apply to visual modalities
  └ delta_timestamps (dict): optional delta timestamps for temporal queries

A LeRobotDataset is serialised using several widespread file formats for each of its parts, namely:

• hf_dataset stored using Hugging Face datasets library serialization to parquet
• videos are stored in mp4 format to save space
• metadata are stored in plain json/jsonl files

Dataset can be uploaded/downloaded from the HuggingFace hub seamlessly. To work on a local dataset, you can specify its location with the root argument if it's not in the default ~/.cache/huggingface/lerobot location.

Reproduce state-of-the-art (SOTA)

We provide some pretrained policies on our hub page that can achieve state-of-the-art performances. You can reproduce their training by loading the config from their run. Simply running:

lerobot-train --config_path=lerobot/diffusion_pusht

reproduces SOTA results for Diffusion Policy on the PushT task.

Contribute

If you would like to contribute to 🤗 LeRobot, please check out our contribution guide.

Add a pretrained policy

Once you have trained a policy you may upload it to the Hugging Face hub using a hub id that looks like ${hf_user}/${repo_name} (e.g. lerobot/diffusion_pusht).

You first need to find the checkpoint folder located inside your experiment directory (e.g. outputs/train/2024-05-05/20-21-12_aloha_act_default/checkpoints/002500). Within that there is a pretrained_model directory which should contain:

• config.json: A serialized version of the policy configuration (following the policy's dataclass config).
• model.safetensors: A set of torch.nn.Module parameters, saved in Hugging Face Safetensors format.
• train_config.json: A consolidated configuration containing all parameters used for training. The policy configuration should match config.json exactly. This is useful for anyone who wants to evaluate your policy or for reproducibility.

To upload these to the hub, run the following:

huggingface-cli upload ${hf_user}/${repo_name} path/to/pretrained_model

See eval.py for an example of how other people may use your policy.

Acknowledgment

• The LeRobot team 🤗 for building SmolVLA Paper, Blog.
• Thanks to Tony Zhao, Zipeng Fu and colleagues for open sourcing ACT policy, ALOHA environments and datasets. Ours are adapted from ALOHA and Mobile ALOHA.
• Thanks to Cheng Chi, Zhenjia Xu and colleagues for open sourcing Diffusion policy, Pusht environment and datasets, as well as UMI datasets. Ours are adapted from Diffusion Policy and UMI Gripper.
• Thanks to Nicklas Hansen, Yunhai Feng and colleagues for open sourcing TDMPC policy, Simxarm environments and datasets. Ours are adapted from TDMPC and FOWM.
• Thanks to Antonio Loquercio and Ashish Kumar for their early support.
• Thanks to Seungjae (Jay) Lee, Mahi Shafiullah and colleagues for open sourcing VQ-BeT policy and helping us adapt the codebase to our repository. The policy is adapted from VQ-BeT repo.

Citation

If you want, you can cite this work with:

@misc{cadene2024lerobot,
    author = {Cadene, Remi and Alibert, Simon and Soare, Alexander and Gallouedec, Quentin and Zouitine, Adil and Palma, Steven and Kooijmans, Pepijn and Aractingi, Michel and Shukor, Mustafa and Aubakirova, Dana and Russi, Martino and Capuano, Francesco and Pascal, Caroline and Choghari, Jade and Moss, Jess and Wolf, Thomas},
    title = {LeRobot: State-of-the-art Machine Learning for Real-World Robotics in Pytorch},
    howpublished = "\url{https://github.com/huggingface/lerobot}",
    year = {2024}
}
